vtkExtractPolyDataPiece Class Reference

Return specified piece, including specified. More...

#include <vtkExtractPolyDataPiece.h>

Inheritance diagram for vtkExtractPolyDataPiece:

Inheritance graph
[legend]
Collaboration diagram for vtkExtractPolyDataPiece:

Collaboration graph
[legend]
List of all members.

Public Methods

virtual const char * GetClassName ()
virtual int IsA (const char *type)
void PrintSelf (ostream &os, vtkIndent indent)
virtual void SetCreateGhostCells (int)
virtual int GetCreateGhostCells ()
virtual void CreateGhostCellsOn ()
virtual void CreateGhostCellsOff ()

Static Public Methods

vtkExtractPolyDataPiece * New ()
int IsTypeOf (const char *type)
vtkExtractPolyDataPiece * SafeDownCast (vtkObject *o)

Protected Methods

 vtkExtractPolyDataPiece ()
 ~vtkExtractPolyDataPiece ()
void Execute ()
void ExecuteInformation ()
void ComputeInputUpdateExtents (vtkDataObject *out)
void ComputeCellTags (vtkIntArray *cellTags, vtkIdList *pointOwnership, int piece, int numPieces)
void AddGhostLevel (vtkPolyData *input, vtkIntArray *cellTags, int ghostLevel)

Protected Attributes

int CreateGhostCells

Detailed Description

Return specified piece, including specified.

Date:
2001/11/13 14:25:56
Revision:
1.5
number of ghost levels.
Tests:
vtkExtractPolyDataPiece (Tests)

Definition at line 56 of file vtkExtractPolyDataPiece.h.


Constructor & Destructor Documentation

vtkExtractPolyDataPiece::vtkExtractPolyDataPiece   [protected]


vtkExtractPolyDataPiece::~vtkExtractPolyDataPiece   [inline, protected]


Definition at line 72 of file vtkExtractPolyDataPiece.h.


Member Function Documentation

vtkExtractPolyDataPiece* vtkExtractPolyDataPiece::New   [static]


Instantiate object with no start, end, or progress methods.

Reimplemented from vtkPolyDataSource.

virtual const char* vtkExtractPolyDataPiece::GetClassName   [virtual]


Return the class name as a string. This method is defined in all subclasses of vtkObject with the vtkTypeMacro found in vtkSetGet.h.

Reimplemented from vtkPolyDataToPolyDataFilter.

int vtkExtractPolyDataPiece::IsTypeOf const char *    type [static]


Return 1 if this class type is the same type of (or a subclass of) the named class. Returns 0 otherwise. This method works in combination with vtkTypeMacro found in vtkSetGet.h.

Reimplemented from vtkPolyDataToPolyDataFilter.

virtual int vtkExtractPolyDataPiece::IsA const char *    type [virtual]


Return 1 if this class is the same type of (or a subclass of) the named class. Returns 0 otherwise. This method works in combination with vtkTypeMacro found in vtkSetGet.h.

Reimplemented from vtkPolyDataToPolyDataFilter.

vtkExtractPolyDataPiece* vtkExtractPolyDataPiece::SafeDownCast vtkObject   o [static]


Will cast the supplied object to vtkObject* is this is a safe operation (i.e., a safe downcast); otherwise NULL is returned. This method is defined in all subclasses of vtkObject with the vtkTypeMacro found in vtkSetGet.h.

Reimplemented from vtkPolyDataToPolyDataFilter.

void vtkExtractPolyDataPiece::PrintSelf ostream &    os,
vtkIndent    indent
[virtual]


Methods invoked by print to print information about the object including superclasses. Typically not called by the user (use Print() instead) but used in the hierarchical print process to combine the output of several classes.

Reimplemented from vtkSource.

virtual void vtkExtractPolyDataPiece::SetCreateGhostCells int    [virtual]


Turn on/off creating ghost cells (on by default).

virtual int vtkExtractPolyDataPiece::GetCreateGhostCells   [virtual]


Turn on/off creating ghost cells (on by default).

virtual void vtkExtractPolyDataPiece::CreateGhostCellsOn   [virtual]


Turn on/off creating ghost cells (on by default).

virtual void vtkExtractPolyDataPiece::CreateGhostCellsOff   [virtual]


Turn on/off creating ghost cells (on by default).

void vtkExtractPolyDataPiece::Execute   [protected, virtual]


This method is the old style execute method

Reimplemented from vtkSource.

void vtkExtractPolyDataPiece::ExecuteInformation   [protected, virtual]


Reimplemented from vtkSource.

void vtkExtractPolyDataPiece::ComputeInputUpdateExtents vtkDataObject   out [protected, virtual]


What is the input update extent that is required to produce the desired output? By default, the whole input is always required but this is overridden in many subclasses.

Reimplemented from vtkPolyDataSource.

void vtkExtractPolyDataPiece::ComputeCellTags vtkIntArray   cellTags,
vtkIdList   pointOwnership,
int    piece,
int    numPieces
[protected]


void vtkExtractPolyDataPiece::AddGhostLevel vtkPolyData   input,
vtkIntArray   cellTags,
int    ghostLevel
[protected]



Member Data Documentation

int vtkExtractPolyDataPiece::CreateGhostCells [protected]


Definition at line 85 of file vtkExtractPolyDataPiece.h.


The documentation for this class was generated from the following file:
