represent the position of a point in 3D space More...
#include <vtkPointHandleRepresentation3D.h>
Detailed Description
represent the position of a point in 3D space
This class is used to represent a vtkHandleWidget. It represents a position in 3D world coordinates using a x-y-z cursor. The cursor can be configured to show a bounding box and/or shadows.
Definition at line 41 of file vtkPointHandleRepresentation3D.h.
Member Typedef Documentation
Standard methods for instances of this class.
Reimplemented from vtkHandleRepresentation.
Definition at line 49 of file vtkPointHandleRepresentation3D.h.
Constructor & Destructor Documentation
| vtkPointHandleRepresentation3D::vtkPointHandleRepresentation3D | ( | ) | [protected] |
| vtkPointHandleRepresentation3D::~vtkPointHandleRepresentation3D | ( | ) | [protected] |
Member Function Documentation
| static vtkPointHandleRepresentation3D* vtkPointHandleRepresentation3D::New | ( | ) | [static] |
Instantiate this class.
Reimplemented from vtkObject.
| virtual const char* vtkPointHandleRepresentation3D::GetClassName | ( | ) | [virtual] |
Standard methods for instances of this class.
Reimplemented from vtkHandleRepresentation.
| static int vtkPointHandleRepresentation3D::IsTypeOf | ( | const char * | type | ) | [static] |
Standard methods for instances of this class.
Reimplemented from vtkHandleRepresentation.
| virtual int vtkPointHandleRepresentation3D::IsA | ( | const char * | type | ) | [virtual] |
Standard methods for instances of this class.
Reimplemented from vtkHandleRepresentation.
| static vtkPointHandleRepresentation3D* vtkPointHandleRepresentation3D::SafeDownCast | ( | vtkObject * | o | ) | [static] |
Standard methods for instances of this class.
Reimplemented from vtkHandleRepresentation.
| void vtkPointHandleRepresentation3D::PrintSelf | ( | ostream & | os, |
| vtkIndent | indent | ||
| ) | [virtual] |
Standard methods for instances of this class.
Reimplemented from vtkHandleRepresentation.
| virtual void vtkPointHandleRepresentation3D::SetWorldPosition | ( | double | p[3] | ) | [virtual] |
Set the position of the point in world and display coordinates. Note that if the position is set outside of the bounding box, it will be clamped to the boundary of the bounding box. This method overloads the superclasses' SetWorldPosition() and SetDisplayPosition() in order to set the focal point of the cursor properly.
Reimplemented from vtkHandleRepresentation.
| virtual void vtkPointHandleRepresentation3D::SetDisplayPosition | ( | double | p[3] | ) | [virtual] |
Set the position of the point in world and display coordinates. Note that if the position is set outside of the bounding box, it will be clamped to the boundary of the bounding box. This method overloads the superclasses' SetWorldPosition() and SetDisplayPosition() in order to set the focal point of the cursor properly.
Reimplemented from vtkHandleRepresentation.
| void vtkPointHandleRepresentation3D::SetOutline | ( | int | o | ) | [inline] |
Turn on/off the wireframe bounding box.
Definition at line 65 of file vtkPointHandleRepresentation3D.h.
| int vtkPointHandleRepresentation3D::GetOutline | ( | ) | [inline] |
Turn on/off the wireframe bounding box.
Definition at line 67 of file vtkPointHandleRepresentation3D.h.
| void vtkPointHandleRepresentation3D::OutlineOn | ( | ) | [inline] |
Turn on/off the wireframe bounding box.
Definition at line 69 of file vtkPointHandleRepresentation3D.h.
| void vtkPointHandleRepresentation3D::OutlineOff | ( | ) | [inline] |
Turn on/off the wireframe bounding box.
Definition at line 71 of file vtkPointHandleRepresentation3D.h.
| void vtkPointHandleRepresentation3D::SetXShadows | ( | int | o | ) | [inline] |
Turn on/off the wireframe x-shadows.
Definition at line 77 of file vtkPointHandleRepresentation3D.h.
| int vtkPointHandleRepresentation3D::GetXShadows | ( | ) | [inline] |
Turn on/off the wireframe x-shadows.
Definition at line 79 of file vtkPointHandleRepresentation3D.h.
| void vtkPointHandleRepresentation3D::XShadowsOn | ( | ) | [inline] |
Turn on/off the wireframe x-shadows.
Definition at line 81 of file vtkPointHandleRepresentation3D.h.
| void vtkPointHandleRepresentation3D::XShadowsOff | ( | ) | [inline] |
Turn on/off the wireframe x-shadows.
Definition at line 83 of file vtkPointHandleRepresentation3D.h.
| void vtkPointHandleRepresentation3D::SetYShadows | ( | int | o | ) | [inline] |
Turn on/off the wireframe y-shadows.
Definition at line 89 of file vtkPointHandleRepresentation3D.h.
| int vtkPointHandleRepresentation3D::GetYShadows | ( | ) | [inline] |
Turn on/off the wireframe y-shadows.
Definition at line 91 of file vtkPointHandleRepresentation3D.h.
| void vtkPointHandleRepresentation3D::YShadowsOn | ( | ) | [inline] |
Turn on/off the wireframe y-shadows.
Definition at line 93 of file vtkPointHandleRepresentation3D.h.
| void vtkPointHandleRepresentation3D::YShadowsOff | ( | ) | [inline] |
Turn on/off the wireframe y-shadows.
Definition at line 95 of file vtkPointHandleRepresentation3D.h.
| void vtkPointHandleRepresentation3D::SetZShadows | ( | int | o | ) | [inline] |
Turn on/off the wireframe z-shadows.
Definition at line 101 of file vtkPointHandleRepresentation3D.h.
| int vtkPointHandleRepresentation3D::GetZShadows | ( | ) | [inline] |
Turn on/off the wireframe z-shadows.
Definition at line 103 of file vtkPointHandleRepresentation3D.h.
| void vtkPointHandleRepresentation3D::ZShadowsOn | ( | ) | [inline] |
Turn on/off the wireframe z-shadows.
Definition at line 105 of file vtkPointHandleRepresentation3D.h.
| void vtkPointHandleRepresentation3D::ZShadowsOff | ( | ) | [inline] |
Turn on/off the wireframe z-shadows.
Definition at line 107 of file vtkPointHandleRepresentation3D.h.
| void vtkPointHandleRepresentation3D::SetTranslationMode | ( | int | mode | ) |
If translation mode is on, as the widget is moved the bounding box, shadows, and cursor are all translated and sized simultaneously as the point moves (i.e., the left and middle mouse buttons act the same). If translation mode is off, the cursor does not scale itself (based on the specified handle size), and the bounding box and shadows do not move or size themselves as the cursor focal point moves, which is constrained by the bounds of the point representation. (Note that the bounds can be scaled up using the right mouse button, and the bounds can be manually set with the SetBounds() method.)
| virtual int vtkPointHandleRepresentation3D::GetTranslationMode | ( | ) | [virtual] |
If translation mode is on, as the widget is moved the bounding box, shadows, and cursor are all translated and sized simultaneously as the point moves (i.e., the left and middle mouse buttons act the same). If translation mode is off, the cursor does not scale itself (based on the specified handle size), and the bounding box and shadows do not move or size themselves as the cursor focal point moves, which is constrained by the bounds of the point representation. (Note that the bounds can be scaled up using the right mouse button, and the bounds can be manually set with the SetBounds() method.)
| virtual void vtkPointHandleRepresentation3D::TranslationModeOn | ( | ) | [virtual] |
If translation mode is on, as the widget is moved the bounding box, shadows, and cursor are all translated and sized simultaneously as the point moves (i.e., the left and middle mouse buttons act the same). If translation mode is off, the cursor does not scale itself (based on the specified handle size), and the bounding box and shadows do not move or size themselves as the cursor focal point moves, which is constrained by the bounds of the point representation. (Note that the bounds can be scaled up using the right mouse button, and the bounds can be manually set with the SetBounds() method.)
| virtual void vtkPointHandleRepresentation3D::TranslationModeOff | ( | ) | [virtual] |
If translation mode is on, as the widget is moved the bounding box, shadows, and cursor are all translated and sized simultaneously as the point moves (i.e., the left and middle mouse buttons act the same). If translation mode is off, the cursor does not scale itself (based on the specified handle size), and the bounding box and shadows do not move or size themselves as the cursor focal point moves, which is constrained by the bounds of the point representation. (Note that the bounds can be scaled up using the right mouse button, and the bounds can be manually set with the SetBounds() method.)
| void vtkPointHandleRepresentation3D::AllOn | ( | ) | [inline] |
Convenience methods to turn outline and shadows on and off.
Definition at line 129 of file vtkPointHandleRepresentation3D.h.
| void vtkPointHandleRepresentation3D::AllOff | ( | ) | [inline] |
Convenience methods to turn outline and shadows on and off.
Definition at line 136 of file vtkPointHandleRepresentation3D.h.
| void vtkPointHandleRepresentation3D::SetProperty | ( | vtkProperty * | ) |
Set/Get the handle properties when unselected and selected.
| void vtkPointHandleRepresentation3D::SetSelectedProperty | ( | vtkProperty * | ) |
Set/Get the handle properties when unselected and selected.
| virtual vtkProperty* vtkPointHandleRepresentation3D::GetProperty | ( | ) | [virtual] |
Set/Get the handle properties when unselected and selected.
| virtual vtkProperty* vtkPointHandleRepresentation3D::GetSelectedProperty | ( | ) | [virtual] |
Set/Get the handle properties when unselected and selected.
| virtual void vtkPointHandleRepresentation3D::SetHotSpotSize | ( | double | ) | [virtual] |
Set the "hot spot" size; i.e., the region around the focus, in which the motion vector is used to control the constrained sliding action. Note the size is specified as a fraction of the length of the diagonal of the point widget's bounding box.
| virtual double vtkPointHandleRepresentation3D::GetHotSpotSize | ( | ) | [virtual] |
Set the "hot spot" size; i.e., the region around the focus, in which the motion vector is used to control the constrained sliding action. Note the size is specified as a fraction of the length of the diagonal of the point widget's bounding box.
| virtual void vtkPointHandleRepresentation3D::SetHandleSize | ( | double | size | ) | [virtual] |
Overload the superclasses SetHandleSize() method to update internal variables.
Reimplemented from vtkWidgetRepresentation.
| virtual double* vtkPointHandleRepresentation3D::GetBounds | ( | ) | [virtual] |
Methods to make this class properly act like a vtkWidgetRepresentation.
Reimplemented from vtkWidgetRepresentation.
| virtual void vtkPointHandleRepresentation3D::BuildRepresentation | ( | ) | [virtual] |
Methods to make this class properly act like a vtkWidgetRepresentation.
Implements vtkWidgetRepresentation.
| virtual void vtkPointHandleRepresentation3D::StartWidgetInteraction | ( | double | eventPos[2] | ) | [virtual] |
Methods to make this class properly act like a vtkWidgetRepresentation.
Reimplemented from vtkWidgetRepresentation.
| virtual void vtkPointHandleRepresentation3D::WidgetInteraction | ( | double | eventPos[2] | ) | [virtual] |
Methods to make this class properly act like a vtkWidgetRepresentation.
Reimplemented from vtkWidgetRepresentation.
| virtual int vtkPointHandleRepresentation3D::ComputeInteractionState | ( | int | X, |
| int | Y, | ||
| int | modify = 0 |
||
| ) | [virtual] |
Methods to make this class properly act like a vtkWidgetRepresentation.
Reimplemented from vtkWidgetRepresentation.
| virtual void vtkPointHandleRepresentation3D::PlaceWidget | ( | double | bounds[6] | ) | [virtual] |
Methods to make this class properly act like a vtkWidgetRepresentation.
| virtual void vtkPointHandleRepresentation3D::ShallowCopy | ( | vtkProp * | prop | ) | [virtual] |
Methods to make this class behave as a vtkProp.
Reimplemented from vtkHandleRepresentation.
| virtual void vtkPointHandleRepresentation3D::DeepCopy | ( | vtkProp * | prop | ) | [virtual] |
Methods to make this class behave as a vtkProp.
Reimplemented from vtkHandleRepresentation.
| virtual void vtkPointHandleRepresentation3D::GetActors | ( | vtkPropCollection * | ) | [virtual] |
Methods to make this class behave as a vtkProp.
Reimplemented from vtkWidgetRepresentation.
| virtual void vtkPointHandleRepresentation3D::ReleaseGraphicsResources | ( | vtkWindow * | ) | [virtual] |
Methods to make this class behave as a vtkProp.
Reimplemented from vtkWidgetRepresentation.
| virtual int vtkPointHandleRepresentation3D::RenderOpaqueGeometry | ( | vtkViewport * | viewport | ) | [virtual] |
| virtual int vtkPointHandleRepresentation3D::RenderTranslucentPolygonalGeometry | ( | vtkViewport * | viewport | ) | [virtual] |
| virtual int vtkPointHandleRepresentation3D::HasTranslucentPolygonalGeometry | ( | ) | [virtual] |
Methods to make this class behave as a vtkProp.
Reimplemented from vtkWidgetRepresentation.
| void vtkPointHandleRepresentation3D::Highlight | ( | int | highlight | ) |
| virtual void vtkPointHandleRepresentation3D::SetSmoothMotion | ( | int | ) | [virtual] |
Turn on/off smooth motion of the handle. See the documentation of MoveFocusRequest for details. By default, SmoothMotion is ON. However, in certain applications the user may want to turn it off. For instance when using certain specific PointPlacer's with the representation such as the vtkCellCentersPointPlacer, which causes the representation to snap to the center of cells, or using a vtkPolygonalSurfacePointPlacer which constrains the widget to the surface of a mesh. In such cases, inherent restrictions on handle placement might conflict with a request for smooth motion of the handles.
| virtual int vtkPointHandleRepresentation3D::GetSmoothMotion | ( | ) | [virtual] |
Turn on/off smooth motion of the handle. See the documentation of MoveFocusRequest for details. By default, SmoothMotion is ON. However, in certain applications the user may want to turn it off. For instance when using certain specific PointPlacer's with the representation such as the vtkCellCentersPointPlacer, which causes the representation to snap to the center of cells, or using a vtkPolygonalSurfacePointPlacer which constrains the widget to the surface of a mesh. In such cases, inherent restrictions on handle placement might conflict with a request for smooth motion of the handles.
| virtual void vtkPointHandleRepresentation3D::SmoothMotionOn | ( | ) | [virtual] |
Turn on/off smooth motion of the handle. See the documentation of MoveFocusRequest for details. By default, SmoothMotion is ON. However, in certain applications the user may want to turn it off. For instance when using certain specific PointPlacer's with the representation such as the vtkCellCentersPointPlacer, which causes the representation to snap to the center of cells, or using a vtkPolygonalSurfacePointPlacer which constrains the widget to the surface of a mesh. In such cases, inherent restrictions on handle placement might conflict with a request for smooth motion of the handles.
| virtual void vtkPointHandleRepresentation3D::SmoothMotionOff | ( | ) | [virtual] |
Turn on/off smooth motion of the handle. See the documentation of MoveFocusRequest for details. By default, SmoothMotion is ON. However, in certain applications the user may want to turn it off. For instance when using certain specific PointPlacer's with the representation such as the vtkCellCentersPointPlacer, which causes the representation to snap to the center of cells, or using a vtkPolygonalSurfacePointPlacer which constrains the widget to the surface of a mesh. In such cases, inherent restrictions on handle placement might conflict with a request for smooth motion of the handles.
| void vtkPointHandleRepresentation3D::Scale | ( | double * | p1, |
| double * | p2, | ||
| double | eventPos[2] | ||
| ) | [protected] |
| void vtkPointHandleRepresentation3D::SizeBounds | ( | ) | [protected] |
| void vtkPointHandleRepresentation3D::MoveFocusRequest | ( | double * | p1, |
| double * | p2, | ||
| double | eventPos[2], | ||
| double | requestedDisplayPos[3] | ||
| ) | [protected] |
| void vtkPointHandleRepresentation3D::CreateDefaultProperties | ( | ) | [protected] |
| int vtkPointHandleRepresentation3D::DetermineConstraintAxis | ( | int | constraint, |
| double * | x, | ||
| double * | startPoint | ||
| ) | [protected] |
Member Data Documentation
vtkActor* vtkPointHandleRepresentation3D::Actor [protected] |
Definition at line 211 of file vtkPointHandleRepresentation3D.h.
vtkPolyDataMapper* vtkPointHandleRepresentation3D::Mapper [protected] |
Definition at line 212 of file vtkPointHandleRepresentation3D.h.
vtkCursor3D* vtkPointHandleRepresentation3D::Cursor3D [protected] |
Definition at line 213 of file vtkPointHandleRepresentation3D.h.
Definition at line 217 of file vtkPointHandleRepresentation3D.h.
double vtkPointHandleRepresentation3D::LastPickPosition[3] [protected] |
Definition at line 218 of file vtkPointHandleRepresentation3D.h.
double vtkPointHandleRepresentation3D::LastEventPosition[2] [protected] |
Definition at line 219 of file vtkPointHandleRepresentation3D.h.
int vtkPointHandleRepresentation3D::ConstraintAxis [protected] |
Definition at line 222 of file vtkPointHandleRepresentation3D.h.
vtkProperty* vtkPointHandleRepresentation3D::Property [protected] |
Definition at line 242 of file vtkPointHandleRepresentation3D.h.
Definition at line 243 of file vtkPointHandleRepresentation3D.h.
double vtkPointHandleRepresentation3D::HotSpotSize [protected] |
Definition at line 247 of file vtkPointHandleRepresentation3D.h.
int vtkPointHandleRepresentation3D::WaitingForMotion [protected] |
Definition at line 249 of file vtkPointHandleRepresentation3D.h.
int vtkPointHandleRepresentation3D::WaitCount [protected] |
Definition at line 250 of file vtkPointHandleRepresentation3D.h.
Definition at line 253 of file vtkPointHandleRepresentation3D.h.
int vtkPointHandleRepresentation3D::TranslationMode [protected] |
Definition at line 256 of file vtkPointHandleRepresentation3D.h.
int vtkPointHandleRepresentation3D::SmoothMotion [protected] |
Definition at line 258 of file vtkPointHandleRepresentation3D.h.
The documentation for this class was generated from the following file:
- dox/Widgets/vtkPointHandleRepresentation3D.h
