uses Qt to render the supplied text to an image. More...
#include <vtkStringToImage.h>
Public Types | |
| typedef vtkObject | Superclass |
Public Member Functions | |
| virtual const char * | GetClassName () |
| virtual int | IsA (const char *type) |
| virtual void | PrintSelf (ostream &os, vtkIndent indent) |
| virtual vtkVector2i | GetBounds (vtkTextProperty *property, const vtkUnicodeString &string)=0 |
| virtual vtkVector2i | GetBounds (vtkTextProperty *property, const vtkStdString &string)=0 |
| virtual int | RenderString (vtkTextProperty *property, const vtkUnicodeString &string, vtkImageData *data)=0 |
| virtual int | RenderString (vtkTextProperty *property, const vtkStdString &string, vtkImageData *data)=0 |
| virtual void | SetScaleToPowerOfTwo (bool scale) |
| virtual bool | GetScaleToPowerOfTwo () |
Static Public Member Functions | |
| static int | IsTypeOf (const char *type) |
| static vtkStringToImage * | SafeDownCast (vtkObject *o) |
Protected Member Functions | |
| vtkStringToImage () | |
| ~vtkStringToImage () | |
Protected Attributes | |
| bool | Antialias |
| bool | ScaleToPowerOfTwo |
Detailed Description
uses Qt to render the supplied text to an image.
Definition at line 34 of file vtkStringToImage.h.
Member Typedef Documentation
Reimplemented from vtkObject.
Reimplemented in vtkQtStringToImage, and vtkFreeTypeStringToImage.
Definition at line 37 of file vtkStringToImage.h.
Constructor & Destructor Documentation
| vtkStringToImage::vtkStringToImage | ( | ) | [protected] |
| vtkStringToImage::~vtkStringToImage | ( | ) | [protected] |
Member Function Documentation
| virtual const char* vtkStringToImage::GetClassName | ( | ) | [virtual] |
Reimplemented from vtkObject.
Reimplemented in vtkQtStringToImage, and vtkFreeTypeStringToImage.
| static int vtkStringToImage::IsTypeOf | ( | const char * | name | ) | [static] |
Return 1 if this class type is the same type of (or a subclass of) the named class. Returns 0 otherwise. This method works in combination with vtkTypeMacro found in vtkSetGet.h.
Reimplemented from vtkObject.
Reimplemented in vtkQtStringToImage, and vtkFreeTypeStringToImage.
| virtual int vtkStringToImage::IsA | ( | const char * | name | ) | [virtual] |
Return 1 if this class is the same type of (or a subclass of) the named class. Returns 0 otherwise. This method works in combination with vtkTypeMacro found in vtkSetGet.h.
Reimplemented from vtkObject.
Reimplemented in vtkQtStringToImage, and vtkFreeTypeStringToImage.
| static vtkStringToImage* vtkStringToImage::SafeDownCast | ( | vtkObject * | o | ) | [static] |
Reimplemented from vtkObject.
Reimplemented in vtkQtStringToImage, and vtkFreeTypeStringToImage.
| virtual void vtkStringToImage::PrintSelf | ( | ostream & | os, |
| vtkIndent | indent | ||
| ) | [virtual] |
Methods invoked by print to print information about the object including superclasses. Typically not called by the user (use Print() instead) but used in the hierarchical print process to combine the output of several classes.
Reimplemented from vtkObject.
Reimplemented in vtkQtStringToImage, and vtkFreeTypeStringToImage.
| virtual vtkVector2i vtkStringToImage::GetBounds | ( | vtkTextProperty * | property, |
| const vtkUnicodeString & | string | ||
| ) | [pure virtual] |
Given a text property and a string, get the bounding box [xmin, xmax] x [ymin, ymax]. Note that this is the bounding box of the area where actual pixels will be written, given a text/pen/baseline location of (0,0). For example, if the string starts with a 'space', or depending on the orientation, you can end up with a [-20, -10] x [5, 10] bbox (the math to get the real bbox is straightforward). Return 1 on success, 0 otherwise. You can use IsBoundingBoxValid() to test if the computed bbox is valid (it may not if GetBoundingBox() failed or if the string was empty).
Implemented in vtkQtStringToImage, and vtkFreeTypeStringToImage.
| virtual vtkVector2i vtkStringToImage::GetBounds | ( | vtkTextProperty * | property, |
| const vtkStdString & | string | ||
| ) | [pure virtual] |
Given a text property and a string, get the bounding box [xmin, xmax] x [ymin, ymax]. Note that this is the bounding box of the area where actual pixels will be written, given a text/pen/baseline location of (0,0). For example, if the string starts with a 'space', or depending on the orientation, you can end up with a [-20, -10] x [5, 10] bbox (the math to get the real bbox is straightforward). Return 1 on success, 0 otherwise. You can use IsBoundingBoxValid() to test if the computed bbox is valid (it may not if GetBoundingBox() failed or if the string was empty).
Implemented in vtkQtStringToImage, and vtkFreeTypeStringToImage.
| virtual int vtkStringToImage::RenderString | ( | vtkTextProperty * | property, |
| const vtkUnicodeString & | string, | ||
| vtkImageData * | data | ||
| ) | [pure virtual] |
Given a text property and a string, this function initializes the vtkImageData *data and renders it in a vtkImageData.
Implemented in vtkQtStringToImage, and vtkFreeTypeStringToImage.
| virtual int vtkStringToImage::RenderString | ( | vtkTextProperty * | property, |
| const vtkStdString & | string, | ||
| vtkImageData * | data | ||
| ) | [pure virtual] |
Given a text property and a string, this function initializes the vtkImageData *data and renders it in a vtkImageData.
Implemented in vtkQtStringToImage, and vtkFreeTypeStringToImage.
| virtual void vtkStringToImage::SetScaleToPowerOfTwo | ( | bool | scale | ) | [virtual] |
Should we produce images at powers of 2, makes rendering on old OpenGL hardware easier. Default is false.
Reimplemented in vtkFreeTypeStringToImage.
| virtual bool vtkStringToImage::GetScaleToPowerOfTwo | ( | ) | [virtual] |
Should we produce images at powers of 2, makes rendering on old OpenGL hardware easier. Default is false.
Member Data Documentation
bool vtkStringToImage::Antialias [protected] |
Definition at line 78 of file vtkStringToImage.h.
bool vtkStringToImage::ScaleToPowerOfTwo [protected] |
Definition at line 79 of file vtkStringToImage.h.
The documentation for this class was generated from the following file:
- dox/Rendering/vtkStringToImage.h
