vtkCornerAnnotation Class Reference
#include <vtkCornerAnnotation.h>
Detailed Description
text annotation in four cornersThis is an annotation object that manages four text actors / mappers to provide annotation in the four corners of a viewport
- See also:
- vtkActor2D vtkTextMapper
Definition at line 35 of file vtkCornerAnnotation.h.
Member Typedef Documentation
Constructor & Destructor Documentation
| vtkCornerAnnotation::vtkCornerAnnotation | ( | ) | [protected] |
| vtkCornerAnnotation::~vtkCornerAnnotation | ( | ) | [protected] |
Member Function Documentation
| virtual const char* vtkCornerAnnotation::GetClassName | ( | ) | [virtual] |
Reimplemented from vtkActor2D.
| static int vtkCornerAnnotation::IsTypeOf | ( | const char * | name | ) | [static] |
Return 1 if this class type is the same type of (or a subclass of) the named class. Returns 0 otherwise. This method works in combination with vtkTypeRevisionMacro found in vtkSetGet.h.
Reimplemented from vtkActor2D.
| virtual int vtkCornerAnnotation::IsA | ( | const char * | name | ) | [virtual] |
Return 1 if this class is the same type of (or a subclass of) the named class. Returns 0 otherwise. This method works in combination with vtkTypeRevisionMacro found in vtkSetGet.h.
Reimplemented from vtkActor2D.
| static vtkCornerAnnotation* vtkCornerAnnotation::SafeDownCast | ( | vtkObject * | o | ) | [static] |
Reimplemented from vtkActor2D.
| void vtkCornerAnnotation::PrintSelf | ( | ostream & | os, | |
| vtkIndent | indent | |||
| ) | [virtual] |
Methods invoked by print to print information about the object including superclasses. Typically not called by the user (use Print() instead) but used in the hierarchical print process to combine the output of several classes.
Reimplemented from vtkActor2D.
| static vtkCornerAnnotation* vtkCornerAnnotation::New | ( | ) | [static] |
Instantiate object with a rectangle in normaled view coordinates of (0.2,0.85, 0.8, 0.95).
Reimplemented from vtkActor2D.
| int vtkCornerAnnotation::RenderOpaqueGeometry | ( | vtkViewport * | viewport | ) | [virtual] |
Draw the scalar bar and annotation text to the screen.
Reimplemented from vtkActor2D.
| virtual int vtkCornerAnnotation::RenderTranslucentPolygonalGeometry | ( | vtkViewport * | ) | [inline, virtual] |
Draw the scalar bar and annotation text to the screen.
Reimplemented from vtkActor2D.
Definition at line 48 of file vtkCornerAnnotation.h.
| int vtkCornerAnnotation::RenderOverlay | ( | vtkViewport * | viewport | ) | [virtual] |
Draw the scalar bar and annotation text to the screen.
Reimplemented from vtkActor2D.
| virtual int vtkCornerAnnotation::HasTranslucentPolygonalGeometry | ( | ) | [virtual] |
Does this prop have some translucent polygonal geometry?
Reimplemented from vtkActor2D.
| virtual void vtkCornerAnnotation::SetMaximumLineHeight | ( | double | ) | [virtual] |
Set/Get the maximum height of a line of text as a percentage of the vertical area allocated to this scaled text actor. Defaults to 1.0
| virtual double vtkCornerAnnotation::GetMaximumLineHeight | ( | ) | [virtual] |
Set/Get the maximum height of a line of text as a percentage of the vertical area allocated to this scaled text actor. Defaults to 1.0
| virtual void vtkCornerAnnotation::SetMinimumFontSize | ( | int | ) | [virtual] |
Set/Get the minimum/maximum size font that will be shown. If the font drops below the minimum size it will not be rendered.
| virtual int vtkCornerAnnotation::GetMinimumFontSize | ( | ) | [virtual] |
Set/Get the minimum/maximum size font that will be shown. If the font drops below the minimum size it will not be rendered.
| virtual void vtkCornerAnnotation::SetMaximumFontSize | ( | int | ) | [virtual] |
Set/Get the minimum/maximum size font that will be shown. If the font drops below the minimum size it will not be rendered.
| virtual int vtkCornerAnnotation::GetMaximumFontSize | ( | ) | [virtual] |
Set/Get the minimum/maximum size font that will be shown. If the font drops below the minimum size it will not be rendered.
| virtual void vtkCornerAnnotation::SetLinearFontScaleFactor | ( | double | ) | [virtual] |
Set/Get font scaling factors The font size, f, is calculated as the largest possible value such that the annotations for the given viewport do not overlap. This font size is scaled non-linearly with the viewport size, to maintain an acceptable readable size at larger viewport sizes, without being too big. f' = linearScale * pow(f,nonlinearScale)
| virtual double vtkCornerAnnotation::GetLinearFontScaleFactor | ( | ) | [virtual] |
Set/Get font scaling factors The font size, f, is calculated as the largest possible value such that the annotations for the given viewport do not overlap. This font size is scaled non-linearly with the viewport size, to maintain an acceptable readable size at larger viewport sizes, without being too big. f' = linearScale * pow(f,nonlinearScale)
| virtual void vtkCornerAnnotation::SetNonlinearFontScaleFactor | ( | double | ) | [virtual] |
Set/Get font scaling factors The font size, f, is calculated as the largest possible value such that the annotations for the given viewport do not overlap. This font size is scaled non-linearly with the viewport size, to maintain an acceptable readable size at larger viewport sizes, without being too big. f' = linearScale * pow(f,nonlinearScale)
| virtual double vtkCornerAnnotation::GetNonlinearFontScaleFactor | ( | ) | [virtual] |
Set/Get font scaling factors The font size, f, is calculated as the largest possible value such that the annotations for the given viewport do not overlap. This font size is scaled non-linearly with the viewport size, to maintain an acceptable readable size at larger viewport sizes, without being too big. f' = linearScale * pow(f,nonlinearScale)
| virtual void vtkCornerAnnotation::ReleaseGraphicsResources | ( | vtkWindow * | ) | [virtual] |
Release any graphics resources that are being consumed by this actor. The parameter window could be used to determine which graphic resources to release.
Reimplemented from vtkActor2D.
| void vtkCornerAnnotation::SetText | ( | int | i, | |
| const char * | text | |||
| ) |
Set/Get the text to be displayed for each corner
| const char* vtkCornerAnnotation::GetText | ( | int | i | ) |
Set/Get the text to be displayed for each corner
| void vtkCornerAnnotation::ClearAllTexts | ( | ) |
Set/Get the text to be displayed for each corner
| void vtkCornerAnnotation::CopyAllTextsFrom | ( | vtkCornerAnnotation * | ca | ) |
Set/Get the text to be displayed for each corner
| void vtkCornerAnnotation::SetImageActor | ( | vtkImageActor * | ) |
Set an image actor to look at for slice information
| virtual vtkImageActor* vtkCornerAnnotation::GetImageActor | ( | ) | [virtual] |
Set an image actor to look at for slice information
| void vtkCornerAnnotation::SetWindowLevel | ( | vtkImageMapToWindowLevelColors * | ) |
Set an instance of vtkImageMapToWindowLevelColors to use for looking at window level changes
| virtual vtkImageMapToWindowLevelColors* vtkCornerAnnotation::GetWindowLevel | ( | ) | [virtual] |
Set an instance of vtkImageMapToWindowLevelColors to use for looking at window level changes
| virtual void vtkCornerAnnotation::SetLevelShift | ( | double | ) | [virtual] |
Set the value to shift the level by.
| virtual double vtkCornerAnnotation::GetLevelShift | ( | ) | [virtual] |
Set the value to shift the level by.
| virtual void vtkCornerAnnotation::SetLevelScale | ( | double | ) | [virtual] |
Set the value to scale the level by.
| virtual double vtkCornerAnnotation::GetLevelScale | ( | ) | [virtual] |
Set the value to scale the level by.
| virtual void vtkCornerAnnotation::SetTextProperty | ( | vtkTextProperty * | p | ) | [virtual] |
Set/Get the text property of all corners.
| virtual vtkTextProperty* vtkCornerAnnotation::GetTextProperty | ( | ) | [virtual] |
Set/Get the text property of all corners.
| virtual void vtkCornerAnnotation::ShowSliceAndImageOn | ( | ) | [virtual] |
Even if there is an image actor, should <slice> and <image> be displayed?
| virtual void vtkCornerAnnotation::ShowSliceAndImageOff | ( | ) | [virtual] |
Even if there is an image actor, should <slice> and <image> be displayed?
| virtual void vtkCornerAnnotation::SetShowSliceAndImage | ( | int | ) | [virtual] |
Even if there is an image actor, should <slice> and <image> be displayed?
| virtual int vtkCornerAnnotation::GetShowSliceAndImage | ( | ) | [virtual] |
Even if there is an image actor, should <slice> and <image> be displayed?
| virtual void vtkCornerAnnotation::TextReplace | ( | vtkImageActor * | ia, | |
| vtkImageMapToWindowLevelColors * | wl | |||
| ) | [protected, virtual] |
Search for replacable tokens and replace
| virtual void vtkCornerAnnotation::SetTextActorsPosition | ( | int | vsize[2] | ) | [protected, virtual] |
Set text actor positions given a viewport size and justification
| virtual void vtkCornerAnnotation::SetTextActorsJustification | ( | ) | [protected, virtual] |
Set text actor positions given a viewport size and justification
Member Data Documentation
double vtkCornerAnnotation::MaximumLineHeight [protected] |
Definition at line 140 of file vtkCornerAnnotation.h.
vtkTextProperty* vtkCornerAnnotation::TextProperty [protected] |
Definition at line 142 of file vtkCornerAnnotation.h.
Definition at line 144 of file vtkCornerAnnotation.h.
double vtkCornerAnnotation::LevelShift [protected] |
Definition at line 145 of file vtkCornerAnnotation.h.
double vtkCornerAnnotation::LevelScale [protected] |
Definition at line 146 of file vtkCornerAnnotation.h.
vtkImageActor* vtkCornerAnnotation::ImageActor [protected] |
Definition at line 147 of file vtkCornerAnnotation.h.
vtkImageActor* vtkCornerAnnotation::LastImageActor [protected] |
Definition at line 148 of file vtkCornerAnnotation.h.
char* vtkCornerAnnotation::CornerText[4] [protected] |
Definition at line 150 of file vtkCornerAnnotation.h.
int vtkCornerAnnotation::FontSize [protected] |
Definition at line 152 of file vtkCornerAnnotation.h.
vtkActor2D* vtkCornerAnnotation::TextActor[4] [protected] |
Definition at line 153 of file vtkCornerAnnotation.h.
vtkTimeStamp vtkCornerAnnotation::BuildTime [protected] |
Definition at line 154 of file vtkCornerAnnotation.h.
int vtkCornerAnnotation::LastSize[2] [protected] |
Definition at line 155 of file vtkCornerAnnotation.h.
vtkTextMapper* vtkCornerAnnotation::TextMapper[4] [protected] |
Definition at line 156 of file vtkCornerAnnotation.h.
int vtkCornerAnnotation::MinimumFontSize [protected] |
Definition at line 158 of file vtkCornerAnnotation.h.
int vtkCornerAnnotation::MaximumFontSize [protected] |
Definition at line 159 of file vtkCornerAnnotation.h.
double vtkCornerAnnotation::LinearFontScaleFactor [protected] |
Definition at line 161 of file vtkCornerAnnotation.h.
double vtkCornerAnnotation::NonlinearFontScaleFactor [protected] |
Definition at line 162 of file vtkCornerAnnotation.h.
int vtkCornerAnnotation::ShowSliceAndImage [protected] |
Definition at line 164 of file vtkCornerAnnotation.h.
The documentation for this class was generated from the following file:
- dox/Hybrid/vtkCornerAnnotation.h
