vtkCylinder Class Reference
#include <vtkCylinder.h>
Detailed Description
implicit function for a cylindervtkCylinder computes the implicit function and function gradient for a cylinder. vtkCylinder is a concrete implementation of vtkImplicitFunction. Cylinder is centered at Center and axes of rotation is along the y-axis. (Use the superclass' vtkImplicitFunction transformation matrix if necessary to reposition.)
- Warning:
- The cylinder is infinite in extent. To truncate the cylinder use the vtkImplicitBoolean in combination with clipping planes.
- Tests:
- vtkCylinder (Tests)
Definition at line 37 of file vtkCylinder.h.
Public Types | |
| typedef vtkImplicitFunction | Superclass |
Public Member Functions | |
| virtual const char * | GetClassName () |
| virtual int | IsA (const char *type) |
| void | PrintSelf (ostream &os, vtkIndent indent) |
| void | EvaluateGradient (double x[3], double g[3]) |
| double | EvaluateFunction (double x[3]) |
| double | EvaluateFunction (double x, double y, double z) |
| virtual void | SetRadius (double) |
| virtual double | GetRadius () |
| virtual void | SetCenter (double, double, double) |
| virtual void | SetCenter (double[3]) |
| virtual double * | GetCenter () |
| virtual void | GetCenter (double data[3]) |
Static Public Member Functions | |
| static int | IsTypeOf (const char *type) |
| static vtkCylinder * | SafeDownCast (vtkObject *o) |
| static vtkCylinder * | New () |
Protected Member Functions | |
| vtkCylinder () | |
| ~vtkCylinder () | |
Protected Attributes | |
| double | Radius |
| double | Center [3] |
Member Typedef Documentation
Constructor & Destructor Documentation
| vtkCylinder::vtkCylinder | ( | ) | [protected] |
| vtkCylinder::~vtkCylinder | ( | ) | [inline, protected] |
Definition at line 69 of file vtkCylinder.h.
Member Function Documentation
| virtual const char* vtkCylinder::GetClassName | ( | ) | [virtual] |
Reimplemented from vtkImplicitFunction.
| static int vtkCylinder::IsTypeOf | ( | const char * | name | ) | [static] |
Return 1 if this class type is the same type of (or a subclass of) the named class. Returns 0 otherwise. This method works in combination with vtkTypeRevisionMacro found in vtkSetGet.h.
Reimplemented from vtkImplicitFunction.
| virtual int vtkCylinder::IsA | ( | const char * | name | ) | [virtual] |
Return 1 if this class is the same type of (or a subclass of) the named class. Returns 0 otherwise. This method works in combination with vtkTypeRevisionMacro found in vtkSetGet.h.
Reimplemented from vtkImplicitFunction.
| static vtkCylinder* vtkCylinder::SafeDownCast | ( | vtkObject * | o | ) | [static] |
Reimplemented from vtkImplicitFunction.
| void vtkCylinder::PrintSelf | ( | ostream & | os, | |
| vtkIndent | indent | |||
| ) | [virtual] |
Methods invoked by print to print information about the object including superclasses. Typically not called by the user (use Print() instead) but used in the hierarchical print process to combine the output of several classes.
Reimplemented from vtkImplicitFunction.
| static vtkCylinder* vtkCylinder::New | ( | ) | [static] |
Construct cylinder radius of 0.5.
Reimplemented from vtkObject.
| double vtkCylinder::EvaluateFunction | ( | double | x[3] | ) | [virtual] |
Evaluate cylinder equation F(x,y,z) = (x-x0)^2 + (z-z0)^2 - R^2.
Implements vtkImplicitFunction.
| double vtkCylinder::EvaluateFunction | ( | double | x, | |
| double | y, | |||
| double | z | |||
| ) | [inline] |
Evaluate cylinder equation F(x,y,z) = (x-x0)^2 + (z-z0)^2 - R^2.
Reimplemented from vtkImplicitFunction.
Definition at line 49 of file vtkCylinder.h.
| void vtkCylinder::EvaluateGradient | ( | double | x[3], | |
| double | g[3] | |||
| ) | [virtual] |
Evaluate cylinder function gradient.
Implements vtkImplicitFunction.
| virtual void vtkCylinder::SetRadius | ( | double | ) | [virtual] |
Set/Get cylinder radius.
| virtual double vtkCylinder::GetRadius | ( | ) | [virtual] |
Set/Get cylinder radius.
| virtual void vtkCylinder::SetCenter | ( | double | , | |
| double | , | |||
| double | ||||
| ) | [virtual] |
Set/Get cylinder center
| virtual void vtkCylinder::SetCenter | ( | double | [3] | ) | [virtual] |
Set/Get cylinder center
| virtual double* vtkCylinder::GetCenter | ( | ) | [virtual] |
Set/Get cylinder center
| virtual void vtkCylinder::GetCenter | ( | double | data[3] | ) | [virtual] |
Set/Get cylinder center
Member Data Documentation
double vtkCylinder::Radius [protected] |
Definition at line 69 of file vtkCylinder.h.
double vtkCylinder::Center[3] [protected] |
Definition at line 72 of file vtkCylinder.h.
The documentation for this class was generated from the following file:
- dox/Filtering/vtkCylinder.h
