vtkImageConnector Class Reference

#include <vtkImageConnector.h>

Inheritance diagram for vtkImageConnector:

Inheritance graph
[legend]
Collaboration diagram for vtkImageConnector:

Collaboration graph
[legend]

List of all members.


Detailed Description

Create a binary image of a sphere.

vtkImageConnector is a helper class for connectivity filters. It is not meant to be used directly. It implements a stack and breadth first search necessary for some connectivity filters. Filtered axes sets the dimensionality of the neighbor comparison, and cannot be more than three dimensions. As implemented, only voxels which share faces are considered neighbors.

Definition at line 52 of file vtkImageConnector.h.


Public Types

typedef vtkObject Superclass

Public Member Functions

virtual const char * GetClassName ()
virtual int IsA (const char *type)
void PrintSelf (ostream &os, vtkIndent indent)
vtkImageConnectorSeedNewSeed (int index[3], void *ptr)
void AddSeed (vtkImageConnectorSeed *seed)
void AddSeedToEnd (vtkImageConnectorSeed *seed)
void RemoveAllSeeds ()
void MarkData (vtkImageData *data, int dimensionality, int ext[6])
virtual void SetConnectedValue (unsigned char)
virtual unsigned char GetConnectedValue ()
virtual void SetUnconnectedValue (unsigned char)
virtual unsigned char GetUnconnectedValue ()

Static Public Member Functions

static vtkImageConnectorNew ()
static int IsTypeOf (const char *type)
static vtkImageConnectorSafeDownCast (vtkObject *o)

Protected Member Functions

 vtkImageConnector ()
 ~vtkImageConnector ()
vtkImageConnectorSeedPopSeed ()

Protected Attributes

unsigned char ConnectedValue
unsigned char UnconnectedValue
vtkImageConnectorSeedSeeds
vtkImageConnectorSeedLastSeed

Member Typedef Documentation

Reimplemented from vtkObject.

Definition at line 57 of file vtkImageConnector.h.


Constructor & Destructor Documentation

vtkImageConnector::vtkImageConnector (  )  [protected]

vtkImageConnector::~vtkImageConnector (  )  [protected]


Member Function Documentation

static vtkImageConnector* vtkImageConnector::New (  )  [static]

Create an object with Debug turned off, modified time initialized to zero, and reference counting on.

Reimplemented from vtkObject.

virtual const char* vtkImageConnector::GetClassName (  )  [virtual]

Reimplemented from vtkObject.

static int vtkImageConnector::IsTypeOf ( const char *  name  )  [static]

Return 1 if this class type is the same type of (or a subclass of) the named class. Returns 0 otherwise. This method works in combination with vtkTypeRevisionMacro found in vtkSetGet.h.

Reimplemented from vtkObject.

virtual int vtkImageConnector::IsA ( const char *  name  )  [virtual]

Return 1 if this class is the same type of (or a subclass of) the named class. Returns 0 otherwise. This method works in combination with vtkTypeRevisionMacro found in vtkSetGet.h.

Reimplemented from vtkObject.

static vtkImageConnector* vtkImageConnector::SafeDownCast ( vtkObject o  )  [static]

Reimplemented from vtkObject.

void vtkImageConnector::PrintSelf ( ostream &  os,
vtkIndent  indent
) [virtual]

Methods invoked by print to print information about the object including superclasses. Typically not called by the user (use Print() instead) but used in the hierarchical print process to combine the output of several classes.

Reimplemented from vtkObject.

vtkImageConnectorSeed* vtkImageConnector::NewSeed ( int  index[3],
void *  ptr
)

void vtkImageConnector::AddSeed ( vtkImageConnectorSeed seed  )

void vtkImageConnector::AddSeedToEnd ( vtkImageConnectorSeed seed  )

void vtkImageConnector::RemoveAllSeeds (  )

virtual void vtkImageConnector::SetConnectedValue ( unsigned  char  )  [virtual]

Values used by the MarkRegion method

virtual unsigned char vtkImageConnector::GetConnectedValue (  )  [virtual]

Values used by the MarkRegion method

virtual void vtkImageConnector::SetUnconnectedValue ( unsigned  char  )  [virtual]

Values used by the MarkRegion method

virtual unsigned char vtkImageConnector::GetUnconnectedValue (  )  [virtual]

Values used by the MarkRegion method

void vtkImageConnector::MarkData ( vtkImageData data,
int  dimensionality,
int  ext[6]
)

Input a data of 0's and "UnconnectedValue"s. Seeds of this object are used to find connected pixels. All pixels connected to seeds are set to ConnectedValue. The data has to be unsigned char.

vtkImageConnectorSeed* vtkImageConnector::PopSeed (  )  [protected]


Member Data Documentation

unsigned char vtkImageConnector::ConnectedValue [protected]

Definition at line 86 of file vtkImageConnector.h.

unsigned char vtkImageConnector::UnconnectedValue [protected]

Definition at line 87 of file vtkImageConnector.h.

Definition at line 91 of file vtkImageConnector.h.

Definition at line 92 of file vtkImageConnector.h.


The documentation for this class was generated from the following file:
