vtkImageReader2Factory Class Reference
#include <vtkImageReader2Factory.h>
Detailed Description
Superclass of binary file readers.vtkImageReader2Factory: This class is used to create a vtkImageReader2 object given a path name to a file. It calls CanReadFile on all availiable readers until one of them returns ture. The availiable reader list comes from three places. In the InitializeReaders function of this class, built-in VTK classes are added to the list, users can call RegisterReader, or users can create a vtkObjectFactory that has CreateObject method that returns a new vtkImageReader2 sub class when given the string "vtkImageReaderObject". This way applications can be extened with new readers via a plugin dll or by calling RegisterReader. Of course all of the readers that are part of the vtk release are made automatically availiable.
- See also:
- vtkImageReader2
- Examples:
- vtkImageReader2Factory (Examples)
Definition at line 50 of file vtkImageReader2Factory.h.
Public Types | |
| typedef vtkObject | Superclass |
Public Member Functions | |
| virtual const char * | GetClassName () |
| virtual int | IsA (const char *type) |
| void | PrintSelf (ostream &os, vtkIndent indent) |
Static Public Member Functions | |
| static vtkImageReader2Factory * | New () |
| static int | IsTypeOf (const char *type) |
| static vtkImageReader2Factory * | SafeDownCast (vtkObject *o) |
| static void | RegisterReader (vtkImageReader2 *r) |
| static vtkImageReader2 * | CreateImageReader2 (const char *path) |
| static void | GetRegisteredReaders (vtkImageReader2Collection *) |
Protected Member Functions | |
| vtkImageReader2Factory () | |
| ~vtkImageReader2Factory () | |
Static Protected Member Functions | |
| static void | InitializeReaders () |
Friends | |
| class | vtkImageReader2FactoryCleanup |
Member Typedef Documentation
Constructor & Destructor Documentation
| vtkImageReader2Factory::vtkImageReader2Factory | ( | ) | [protected] |
| vtkImageReader2Factory::~vtkImageReader2Factory | ( | ) | [protected] |
Member Function Documentation
| static vtkImageReader2Factory* vtkImageReader2Factory::New | ( | ) | [static] |
Create an object with Debug turned off, modified time initialized to zero, and reference counting on.
Reimplemented from vtkObject.
| virtual const char* vtkImageReader2Factory::GetClassName | ( | ) | [virtual] |
Reimplemented from vtkObject.
| static int vtkImageReader2Factory::IsTypeOf | ( | const char * | name | ) | [static] |
Return 1 if this class type is the same type of (or a subclass of) the named class. Returns 0 otherwise. This method works in combination with vtkTypeRevisionMacro found in vtkSetGet.h.
Reimplemented from vtkObject.
| virtual int vtkImageReader2Factory::IsA | ( | const char * | name | ) | [virtual] |
Return 1 if this class is the same type of (or a subclass of) the named class. Returns 0 otherwise. This method works in combination with vtkTypeRevisionMacro found in vtkSetGet.h.
Reimplemented from vtkObject.
| static vtkImageReader2Factory* vtkImageReader2Factory::SafeDownCast | ( | vtkObject * | o | ) | [static] |
Reimplemented from vtkObject.
| void vtkImageReader2Factory::PrintSelf | ( | ostream & | os, | |
| vtkIndent | indent | |||
| ) | [virtual] |
| static void vtkImageReader2Factory::RegisterReader | ( | vtkImageReader2 * | r | ) | [static] |
registered readers will be queried in CreateImageReader2 to see if they can load a given file.
| static vtkImageReader2* vtkImageReader2Factory::CreateImageReader2 | ( | const char * | path | ) | [static] |
open the image file, it is the callers responsibility to call Delete on the returned object. If no reader is found, null is returned.
| static void vtkImageReader2Factory::GetRegisteredReaders | ( | vtkImageReader2Collection * | ) | [static] |
The caller must allocate the vtkImageReader2Collection and pass in the pointer to this method.
| static void vtkImageReader2Factory::InitializeReaders | ( | ) | [static, protected] |
Friends And Related Function Documentation
friend class vtkImageReader2FactoryCleanup [friend] |
Definition at line 79 of file vtkImageReader2Factory.h.
The documentation for this class was generated from the following file:
- dox/IO/vtkImageReader2Factory.h
