vtkOpenGLRenderer Class Reference
#include <vtkOpenGLRenderer.h>
Detailed Description
OpenGL renderer.vtkOpenGLRenderer is a concrete implementation of the abstract class vtkRenderer. vtkOpenGLRenderer interfaces to the OpenGL graphics library.
Definition at line 29 of file vtkOpenGLRenderer.h.
Public Types | |
| typedef vtkRenderer | Superclass |
Public Member Functions | |
| virtual const char * | GetClassName () |
| virtual int | IsA (const char *type) |
| void | PrintSelf (ostream &os, vtkIndent indent) |
| void | DeviceRender (void) |
| virtual void | DeviceRenderTranslucentPolygonalGeometry () |
| void | ClearLights (void) |
| void | Clear (void) |
| int | UpdateLights (void) |
| int | GetDepthPeelingHigherLayer () |
Static Public Member Functions | |
| static vtkOpenGLRenderer * | New () |
| static int | IsTypeOf (const char *type) |
| static vtkOpenGLRenderer * | SafeDownCast (vtkObject *o) |
Protected Member Functions | |
| vtkOpenGLRenderer () | |
| ~vtkOpenGLRenderer () | |
| void | CheckCompilation (unsigned int fragmentShader) |
| virtual void | DevicePickRender () |
| virtual void | StartPick (unsigned int pickFromSize) |
| virtual void | UpdatePickId () |
| virtual void | DonePick () |
| virtual unsigned int | GetPickedId () |
| virtual unsigned int | GetNumPickedIds () |
| virtual int | GetPickedIds (unsigned int atMost, unsigned int *callerBuffer) |
| virtual double | GetPickedZ () |
| int | RenderPeel (int layer) |
| int | GetUseTextureUniformVariable () |
| int | GetTextureUniformVariable () |
Protected Attributes | |
| int | NumberOfLightsBound |
| class vtkGLPickInfo * | PickInfo |
| double | PickedZ |
| int | DepthPeelingIsSupported |
| int | DepthPeelingIsSupportedChecked |
| vtkOpenGLRendererLayerList * | LayerList |
| unsigned int | OpaqueLayerZ |
| unsigned int | TransparentLayerZ |
| unsigned int | ProgramShader |
| unsigned int | DepthFormat |
| int | DepthPeelingHigherLayer |
| int | ViewportX |
| int | ViewportY |
| int | ViewportWidth |
| int | ViewportHeight |
Friends | |
| class | vtkOpenGLProperty |
| class | vtkOpenGLTexture |
| class | vtkOpenGLImageActor |
Member Typedef Documentation
Constructor & Destructor Documentation
| vtkOpenGLRenderer::vtkOpenGLRenderer | ( | ) | [protected] |
| vtkOpenGLRenderer::~vtkOpenGLRenderer | ( | ) | [protected] |
Member Function Documentation
| static vtkOpenGLRenderer* vtkOpenGLRenderer::New | ( | ) | [static] |
Create a vtkRenderer with a black background, a white ambient light, two-sided lighting turned on, a viewport of (0,0,1,1), and backface culling turned off.
Reimplemented from vtkRenderer.
| virtual const char* vtkOpenGLRenderer::GetClassName | ( | ) | [virtual] |
Reimplemented from vtkRenderer.
| static int vtkOpenGLRenderer::IsTypeOf | ( | const char * | name | ) | [static] |
Return 1 if this class type is the same type of (or a subclass of) the named class. Returns 0 otherwise. This method works in combination with vtkTypeRevisionMacro found in vtkSetGet.h.
Reimplemented from vtkRenderer.
| virtual int vtkOpenGLRenderer::IsA | ( | const char * | name | ) | [virtual] |
Return 1 if this class is the same type of (or a subclass of) the named class. Returns 0 otherwise. This method works in combination with vtkTypeRevisionMacro found in vtkSetGet.h.
Reimplemented from vtkRenderer.
| static vtkOpenGLRenderer* vtkOpenGLRenderer::SafeDownCast | ( | vtkObject * | o | ) | [static] |
Reimplemented from vtkRenderer.
| void vtkOpenGLRenderer::PrintSelf | ( | ostream & | os, | |
| vtkIndent | indent | |||
| ) | [virtual] |
Methods invoked by print to print information about the object including superclasses. Typically not called by the user (use Print() instead) but used in the hierarchical print process to combine the output of several classes.
Reimplemented from vtkRenderer.
| void vtkOpenGLRenderer::DeviceRender | ( | void | ) | [virtual] |
Concrete open gl render method.
Implements vtkRenderer.
| virtual void vtkOpenGLRenderer::DeviceRenderTranslucentPolygonalGeometry | ( | ) | [virtual] |
Render translucent polygonal geometry. Default implementation just call UpdateTranslucentPolygonalGeometry(). Subclasses of vtkRenderer that can deal with depth peeling must override this method.
Reimplemented from vtkRenderer.
| void vtkOpenGLRenderer::ClearLights | ( | void | ) |
Internal method temporarily removes lights before reloading them into graphics pipeline.
| void vtkOpenGLRenderer::Clear | ( | void | ) | [virtual] |
Clear the image to the background color.
Reimplemented from vtkRenderer.
| int vtkOpenGLRenderer::UpdateLights | ( | void | ) | [virtual] |
Ask lights to load themselves into graphics pipeline.
Reimplemented from vtkRenderer.
| int vtkOpenGLRenderer::GetDepthPeelingHigherLayer | ( | ) |
Is rendering at translucent geometry stage using depth peeling and rendering a layer other than the first one? (Boolean value) If so, the uniform variables UseTexture and Texture can be set. (Used by vtkOpenGLProperty or vtkOpenGLTexture)
| void vtkOpenGLRenderer::CheckCompilation | ( | unsigned int | fragmentShader | ) | [protected] |
Check the compilation status of some fragment shader source.
| virtual void vtkOpenGLRenderer::DevicePickRender | ( | ) | [protected, virtual] |
Implements vtkViewport.
| virtual void vtkOpenGLRenderer::StartPick | ( | unsigned int | pickFromSize | ) | [protected, virtual] |
Implements vtkViewport.
| virtual void vtkOpenGLRenderer::UpdatePickId | ( | ) | [protected, virtual] |
Implements vtkViewport.
| virtual void vtkOpenGLRenderer::DonePick | ( | ) | [protected, virtual] |
Implements vtkViewport.
| virtual unsigned int vtkOpenGLRenderer::GetPickedId | ( | ) | [protected, virtual] |
Implements vtkViewport.
| virtual unsigned int vtkOpenGLRenderer::GetNumPickedIds | ( | ) | [protected, virtual] |
Implements vtkViewport.
| virtual int vtkOpenGLRenderer::GetPickedIds | ( | unsigned int | atMost, | |
| unsigned int * | callerBuffer | |||
| ) | [protected, virtual] |
Implements vtkViewport.
| virtual double vtkOpenGLRenderer::GetPickedZ | ( | ) | [protected, virtual] |
Return the Z value for the last picked Prop.
Implements vtkViewport.
| int vtkOpenGLRenderer::RenderPeel | ( | int | layer | ) | [protected] |
Render a peel layer. If there is no more GPU RAM to save the texture, return false otherwise returns true. Also if layer==0 and no prop have been rendered (there is no translucent geometry), it returns false.
- Precondition:
- positive_layer: layer>=0
| int vtkOpenGLRenderer::GetUseTextureUniformVariable | ( | ) | [protected] |
Access to the OpenGL program shader uniform variable "useTexture" from the vtkOpenGLProperty or vtkOpenGLTexture.
| int vtkOpenGLRenderer::GetTextureUniformVariable | ( | ) | [protected] |
Access to the OpenGL program shader uniform variable "texture" from the vtkOpenGLProperty or vtkOpenGLTexture.
Friends And Related Function Documentation
friend class vtkOpenGLProperty [friend] |
Definition at line 91 of file vtkOpenGLRenderer.h.
friend class vtkOpenGLTexture [friend] |
Definition at line 92 of file vtkOpenGLRenderer.h.
friend class vtkOpenGLImageActor [friend] |
Definition at line 93 of file vtkOpenGLRenderer.h.
Member Data Documentation
int vtkOpenGLRenderer::NumberOfLightsBound [protected] |
Definition at line 32 of file vtkOpenGLRenderer.h.
class vtkGLPickInfo* vtkOpenGLRenderer::PickInfo [protected] |
Definition at line 80 of file vtkOpenGLRenderer.h.
double vtkOpenGLRenderer::PickedZ [protected] |
Definition at line 82 of file vtkOpenGLRenderer.h.
int vtkOpenGLRenderer::DepthPeelingIsSupported [protected] |
This flag is on if the current OpenGL context supports extensions required by the depth peeling technique.
Definition at line 106 of file vtkOpenGLRenderer.h.
int vtkOpenGLRenderer::DepthPeelingIsSupportedChecked [protected] |
This flag is on once the OpenGL extensions required by the depth peeling technique have been checked.
Definition at line 110 of file vtkOpenGLRenderer.h.
vtkOpenGLRendererLayerList* vtkOpenGLRenderer::LayerList [protected] |
Used by the depth peeling technique to store the transparency layers.
Definition at line 113 of file vtkOpenGLRenderer.h.
unsigned int vtkOpenGLRenderer::OpaqueLayerZ [protected] |
Definition at line 115 of file vtkOpenGLRenderer.h.
unsigned int vtkOpenGLRenderer::TransparentLayerZ [protected] |
Definition at line 116 of file vtkOpenGLRenderer.h.
unsigned int vtkOpenGLRenderer::ProgramShader [protected] |
Definition at line 117 of file vtkOpenGLRenderer.h.
int vtkOpenGLRenderer::ViewportX [protected] |
Cache viewport values for depth peeling.
Definition at line 121 of file vtkOpenGLRenderer.h.
int vtkOpenGLRenderer::ViewportY [protected] |
Cache viewport values for depth peeling.
Definition at line 122 of file vtkOpenGLRenderer.h.
int vtkOpenGLRenderer::ViewportWidth [protected] |
Cache viewport values for depth peeling.
Definition at line 123 of file vtkOpenGLRenderer.h.
int vtkOpenGLRenderer::ViewportHeight [protected] |
Cache viewport values for depth peeling.
Definition at line 124 of file vtkOpenGLRenderer.h.
unsigned int vtkOpenGLRenderer::DepthFormat [protected] |
Actual depth format: vtkgl::DEPTH_COMPONENT16_ARB or vtkgl::DEPTH_COMPONENT24_ARB
Definition at line 129 of file vtkOpenGLRenderer.h.
int vtkOpenGLRenderer::DepthPeelingHigherLayer [protected] |
Definition at line 135 of file vtkOpenGLRenderer.h.
The documentation for this class was generated from the following file:
- dox/Rendering/vtkOpenGLRenderer.h
