vtkTreeMapView Class Reference
#include <vtkTreeMapView.h>
Detailed Description
Displays a tree as a tree map.vtkTreeMapView shows a vtkTree in a tree map, where each vertex in the tree is represented by a box. Child boxes are contained within the parent box, and may be colored and sized by various parameters.
- Examples:
- vtkTreeMapView (Examples)
- Tests:
- vtkTreeMapView (Tests)
Definition at line 55 of file vtkTreeMapView.h.
Member Typedef Documentation
Constructor & Destructor Documentation
| vtkTreeMapView::vtkTreeMapView | ( | ) | [protected] |
| vtkTreeMapView::~vtkTreeMapView | ( | ) | [protected] |
Member Function Documentation
| static vtkTreeMapView* vtkTreeMapView::New | ( | ) | [static] |
Create an object with Debug turned off, modified time initialized to zero, and reference counting on.
Reimplemented from vtkRenderView.
| virtual const char* vtkTreeMapView::GetClassName | ( | ) | [virtual] |
Reimplemented from vtkRenderView.
| static int vtkTreeMapView::IsTypeOf | ( | const char * | name | ) | [static] |
Return 1 if this class type is the same type of (or a subclass of) the named class. Returns 0 otherwise. This method works in combination with vtkTypeRevisionMacro found in vtkSetGet.h.
Reimplemented from vtkRenderView.
| virtual int vtkTreeMapView::IsA | ( | const char * | name | ) | [virtual] |
Return 1 if this class is the same type of (or a subclass of) the named class. Returns 0 otherwise. This method works in combination with vtkTypeRevisionMacro found in vtkSetGet.h.
Reimplemented from vtkRenderView.
| static vtkTreeMapView* vtkTreeMapView::SafeDownCast | ( | vtkObject * | o | ) | [static] |
Reimplemented from vtkRenderView.
| void vtkTreeMapView::PrintSelf | ( | ostream & | os, | |
| vtkIndent | indent | |||
| ) | [virtual] |
Methods invoked by print to print information about the object including superclasses. Typically not called by the user (use Print() instead) but used in the hierarchical print process to combine the output of several classes.
Reimplemented from vtkRenderView.
| void vtkTreeMapView::SetColorArrayName | ( | const char * | name | ) |
The name of the array used to color the treemap.
| const char* vtkTreeMapView::GetColorArrayName | ( | ) |
The name of the array used to color the treemap.
| void vtkTreeMapView::SetSizeArrayName | ( | const char * | name | ) |
The name of the array used to size the treemap rectangles.
| const char* vtkTreeMapView::GetSizeArrayName | ( | ) |
The name of the array used to size the treemap rectangles.
| void vtkTreeMapView::SetLabelArrayName | ( | const char * | name | ) |
The name of the array used to label the treemap. This must be a string array.
| const char* vtkTreeMapView::GetLabelArrayName | ( | ) |
The name of the array used to label the treemap. This must be a string array.
| void vtkTreeMapView::SetHoverArrayName | ( | const char * | name | ) |
The name of the array whose value appears when the mouse hovers over a rectangle in the treemap. This must be a string array.
| const char* vtkTreeMapView::GetHoverArrayName | ( | ) |
The name of the array whose value appears when the mouse hovers over a rectangle in the treemap. This must be a string array.
| void vtkTreeMapView::SetLayoutStrategy | ( | const char * | name | ) |
Sets the treemap layout strategy
| void vtkTreeMapView::SetLayoutStrategyToBox | ( | ) |
Sets the treemap layout strategy
| void vtkTreeMapView::SetLayoutStrategyToSliceAndDice | ( | ) |
Sets the treemap layout strategy
| void vtkTreeMapView::SetLayoutStrategyToSquarify | ( | ) |
Sets the treemap layout strategy
| void vtkTreeMapView::SetBorderPercentage | ( | double | pcent | ) |
Sets the amount of border around child rectangles. The percentage should be between 0 and 1.
| double vtkTreeMapView::GetBorderPercentage | ( | ) |
Sets the amount of border around child rectangles. The percentage should be between 0 and 1.
| void vtkTreeMapView::SetFontSizeRange | ( | const int | maxSize, | |
| const int | minSize, | |||
| const int | delta = 4 | |||
| ) |
The sizes of the fonts used for labeling.
| void vtkTreeMapView::GetFontSizeRange | ( | int | range[3] | ) |
The sizes of the fonts used for labeling.
| virtual void vtkTreeMapView::SetupRenderWindow | ( | vtkRenderWindow * | win | ) | [virtual] |
Sets up interactor style.
Reimplemented from vtkRenderView.
| virtual void vtkTreeMapView::ApplyViewTheme | ( | vtkViewTheme * | theme | ) | [virtual] |
Apply the theme to this view.
Reimplemented from vtkRenderView.
| virtual void vtkTreeMapView::AddInputConnection | ( | vtkAlgorithmOutput * | conn | ) | [protected, virtual] |
Connects the algorithm output to the internal pipeline.
| virtual void vtkTreeMapView::RemoveInputConnection | ( | vtkAlgorithmOutput * | conn | ) | [protected, virtual] |
Disconnects the algorithm output from the internal pipeline.
| virtual void vtkTreeMapView::ProcessEvents | ( | vtkObject * | caller, | |
| unsigned long | eventId, | |||
| void * | callData | |||
| ) | [protected, virtual] |
Called to process the user event from the interactor style.
Reimplemented from vtkRenderView.
| virtual void vtkTreeMapView::PrepareForRendering | ( | ) | [protected, virtual] |
Prepares the view for rendering.
Reimplemented from vtkRenderView.
| virtual void vtkTreeMapView::SetColorArrayNameInternal | ( | const char * | ) | [protected, virtual] |
Gets the internal color array name.
| virtual char* vtkTreeMapView::GetColorArrayNameInternal | ( | ) | [protected, virtual] |
Gets the internal color array name.
Member Data Documentation
char* vtkTreeMapView::ColorArrayNameInternal [protected] |
Definition at line 137 of file vtkTreeMapView.h.
vtkTreeLevelsFilter* vtkTreeMapView::TreeLevelsFilter [protected] |
Definition at line 142 of file vtkTreeMapView.h.
Definition at line 143 of file vtkTreeMapView.h.
vtkTreeMapLayout* vtkTreeMapView::TreeMapLayout [protected] |
Definition at line 144 of file vtkTreeMapView.h.
vtkBoxLayoutStrategy* vtkTreeMapView::BoxLayout [protected] |
Definition at line 145 of file vtkTreeMapView.h.
Definition at line 146 of file vtkTreeMapView.h.
vtkSquarifyLayoutStrategy* vtkTreeMapView::SquarifyLayout [protected] |
Definition at line 147 of file vtkTreeMapView.h.
vtkTreeMapToPolyData* vtkTreeMapView::TreeMapToPolyData [protected] |
Definition at line 148 of file vtkTreeMapView.h.
vtkPolyDataMapper* vtkTreeMapView::TreeMapMapper [protected] |
Definition at line 149 of file vtkTreeMapView.h.
vtkActor* vtkTreeMapView::TreeMapActor [protected] |
Definition at line 150 of file vtkTreeMapView.h.
vtkLabeledTreeMapDataMapper* vtkTreeMapView::LabelMapper [protected] |
Definition at line 151 of file vtkTreeMapView.h.
vtkActor2D* vtkTreeMapView::LabelActor [protected] |
Definition at line 152 of file vtkTreeMapView.h.
vtkLookupTable* vtkTreeMapView::ColorLUT [protected] |
Definition at line 153 of file vtkTreeMapView.h.
The documentation for this class was generated from the following file:
- dox/Views/vtkTreeMapView.h
