vtkVolumeProperty Class Reference
#include <vtkVolumeProperty.h>
Detailed Description
represents the common properties for rendering a volume.vtkVolumeProperty is used to represent common properties associated with volume rendering. This includes properties for determining the type of interpolation to use when sampling a volume, the color of a volume, the scalar opacity of a volume, the gradient opacity of a volume, and the shading parameters of a volume.
When the scalar opacity or the gradient opacity of a volume is not set, then the function is defined to be a constant value of 1.0. When a scalar and gradient opacity are both set simultaneously, then the opacity is defined to be the product of the scalar opacity and gradient opacity transfer functions.
Most properties can be set per "component" for volume mappers that support multiple independent components. If you are using 2 component data as LV or 4 component data as RGBV (as specified in the mapper) only the first scalar opacity and gradient opacity transfer functions will be used (and all color functions will be ignored). Omitting the index parameter on the Set/Get methods will access index = 0.
- Examples:
- vtkVolumeProperty (Examples)
Definition at line 58 of file vtkVolumeProperty.h.
Member Typedef Documentation
Constructor & Destructor Documentation
| vtkVolumeProperty::vtkVolumeProperty | ( | ) | [protected] |
| vtkVolumeProperty::~vtkVolumeProperty | ( | ) | [protected] |
Member Function Documentation
| static vtkVolumeProperty* vtkVolumeProperty::New | ( | ) | [static] |
Create an object with Debug turned off, modified time initialized to zero, and reference counting on.
Reimplemented from vtkObject.
| virtual const char* vtkVolumeProperty::GetClassName | ( | ) | [virtual] |
Reimplemented from vtkObject.
| static int vtkVolumeProperty::IsTypeOf | ( | const char * | name | ) | [static] |
Return 1 if this class type is the same type of (or a subclass of) the named class. Returns 0 otherwise. This method works in combination with vtkTypeRevisionMacro found in vtkSetGet.h.
Reimplemented from vtkObject.
| virtual int vtkVolumeProperty::IsA | ( | const char * | name | ) | [virtual] |
Return 1 if this class is the same type of (or a subclass of) the named class. Returns 0 otherwise. This method works in combination with vtkTypeRevisionMacro found in vtkSetGet.h.
Reimplemented from vtkObject.
| static vtkVolumeProperty* vtkVolumeProperty::SafeDownCast | ( | vtkObject * | o | ) | [static] |
Reimplemented from vtkObject.
| void vtkVolumeProperty::PrintSelf | ( | ostream & | os, | |
| vtkIndent | indent | |||
| ) | [virtual] |
| void vtkVolumeProperty::DeepCopy | ( | vtkVolumeProperty * | p | ) |
| unsigned long vtkVolumeProperty::GetMTime | ( | ) | [virtual] |
Get the modified time for this object (or the properties registered with this object).
Reimplemented from vtkObject.
| virtual void vtkVolumeProperty::SetIndependentComponents | ( | int | ) | [virtual] |
Does the data have independent components, or do some define color only? If IndependentComponents is On (the default) then each component will be independently passed through a lookup table to determine RGBA, shaded. Some volume Mappers can handle 1 to 4 component unsigned char or unsigned short data (see each mapper header file to determine functionality). If IndependentComponents is Off, then you must have either 2 or 4 component data. For 2 component data, the first is passed through the first color transfer function and the second component is passed through the first opacity transfer function. Normals will be generated off of the second component. For 4 component data, the first three will directly represent RGB (no lookup table). The fourth component will be passed through the first scalar opacity transfer function for opacity. Normals will be generated from the fourth component.
| virtual int vtkVolumeProperty::GetIndependentComponents | ( | ) | [virtual] |
Does the data have independent components, or do some define color only? If IndependentComponents is On (the default) then each component will be independently passed through a lookup table to determine RGBA, shaded. Some volume Mappers can handle 1 to 4 component unsigned char or unsigned short data (see each mapper header file to determine functionality). If IndependentComponents is Off, then you must have either 2 or 4 component data. For 2 component data, the first is passed through the first color transfer function and the second component is passed through the first opacity transfer function. Normals will be generated off of the second component. For 4 component data, the first three will directly represent RGB (no lookup table). The fourth component will be passed through the first scalar opacity transfer function for opacity. Normals will be generated from the fourth component.
| virtual void vtkVolumeProperty::IndependentComponentsOn | ( | ) | [virtual] |
Does the data have independent components, or do some define color only? If IndependentComponents is On (the default) then each component will be independently passed through a lookup table to determine RGBA, shaded. Some volume Mappers can handle 1 to 4 component unsigned char or unsigned short data (see each mapper header file to determine functionality). If IndependentComponents is Off, then you must have either 2 or 4 component data. For 2 component data, the first is passed through the first color transfer function and the second component is passed through the first opacity transfer function. Normals will be generated off of the second component. For 4 component data, the first three will directly represent RGB (no lookup table). The fourth component will be passed through the first scalar opacity transfer function for opacity. Normals will be generated from the fourth component.
| virtual void vtkVolumeProperty::IndependentComponentsOff | ( | ) | [virtual] |
Does the data have independent components, or do some define color only? If IndependentComponents is On (the default) then each component will be independently passed through a lookup table to determine RGBA, shaded. Some volume Mappers can handle 1 to 4 component unsigned char or unsigned short data (see each mapper header file to determine functionality). If IndependentComponents is Off, then you must have either 2 or 4 component data. For 2 component data, the first is passed through the first color transfer function and the second component is passed through the first opacity transfer function. Normals will be generated off of the second component. For 4 component data, the first three will directly represent RGB (no lookup table). The fourth component will be passed through the first scalar opacity transfer function for opacity. Normals will be generated from the fourth component.
| virtual void vtkVolumeProperty::SetInterpolationType | ( | int | ) | [virtual] |
Set the interpolation type for sampling a volume.
| virtual int vtkVolumeProperty::GetInterpolationType | ( | ) | [virtual] |
Set the interpolation type for sampling a volume.
| void vtkVolumeProperty::SetInterpolationTypeToNearest | ( | ) | [inline] |
Set the interpolation type for sampling a volume.
Definition at line 95 of file vtkVolumeProperty.h.
| void vtkVolumeProperty::SetInterpolationTypeToLinear | ( | ) | [inline] |
Set the interpolation type for sampling a volume.
Definition at line 97 of file vtkVolumeProperty.h.
| const char * vtkVolumeProperty::GetInterpolationTypeAsString | ( | void | ) | [inline] |
Return the interpolation type as a descriptive character string.
Definition at line 354 of file vtkVolumeProperty.h.
| virtual void vtkVolumeProperty::SetComponentWeight | ( | int | index, | |
| double | value | |||
| ) | [virtual] |
Set/Get the scalar component weights
| virtual double vtkVolumeProperty::GetComponentWeight | ( | int | index | ) | [virtual] |
Set/Get the scalar component weights
| void vtkVolumeProperty::SetColor | ( | int | index, | |
| vtkPiecewiseFunction * | function | |||
| ) |
Set the color of a volume to a gray level transfer function for the component indicated by index. This will set the color channels for this component to 1.
| void vtkVolumeProperty::SetColor | ( | vtkPiecewiseFunction * | f | ) | [inline] |
Set the color of a volume to a gray level transfer function for the component indicated by index. This will set the color channels for this component to 1.
Definition at line 113 of file vtkVolumeProperty.h.
| void vtkVolumeProperty::SetColor | ( | int | index, | |
| vtkColorTransferFunction * | function | |||
| ) |
Set the color of a volume to an RGB transfer function for the component indicated by index. This will set the color channels for this component to 3. This will also recompute the color channels
| void vtkVolumeProperty::SetColor | ( | vtkColorTransferFunction * | f | ) | [inline] |
Set the color of a volume to an RGB transfer function for the component indicated by index. This will set the color channels for this component to 3. This will also recompute the color channels
Definition at line 121 of file vtkVolumeProperty.h.
| int vtkVolumeProperty::GetColorChannels | ( | int | index | ) |
Get the number of color channels in the transfer function for the given component.
| int vtkVolumeProperty::GetColorChannels | ( | ) | [inline] |
Get the number of color channels in the transfer function for the given component.
Definition at line 128 of file vtkVolumeProperty.h.
| vtkPiecewiseFunction* vtkVolumeProperty::GetGrayTransferFunction | ( | int | index | ) |
Get the gray transfer function. If no transfer function has been set for this component, a default one is created and returned.
| vtkPiecewiseFunction* vtkVolumeProperty::GetGrayTransferFunction | ( | ) | [inline] |
Get the gray transfer function. If no transfer function has been set for this component, a default one is created and returned.
Definition at line 135 of file vtkVolumeProperty.h.
| vtkColorTransferFunction* vtkVolumeProperty::GetRGBTransferFunction | ( | int | index | ) |
Get the RGB transfer function for the given component. If no transfer function has been set for this component, a default one is created and returned.
| vtkColorTransferFunction* vtkVolumeProperty::GetRGBTransferFunction | ( | ) | [inline] |
Get the RGB transfer function for the given component. If no transfer function has been set for this component, a default one is created and returned.
Definition at line 144 of file vtkVolumeProperty.h.
| void vtkVolumeProperty::SetScalarOpacity | ( | int | index, | |
| vtkPiecewiseFunction * | function | |||
| ) |
Set the opacity of a volume to an opacity transfer function based on scalar value for the component indicated by index.
| void vtkVolumeProperty::SetScalarOpacity | ( | vtkPiecewiseFunction * | f | ) | [inline] |
Set the opacity of a volume to an opacity transfer function based on scalar value for the component indicated by index.
Definition at line 152 of file vtkVolumeProperty.h.
| vtkPiecewiseFunction* vtkVolumeProperty::GetScalarOpacity | ( | int | index | ) |
Get the scalar opacity transfer function for the given component. If no transfer function has been set for this component, a default one is created and returned.
| vtkPiecewiseFunction* vtkVolumeProperty::GetScalarOpacity | ( | ) | [inline] |
Get the scalar opacity transfer function for the given component. If no transfer function has been set for this component, a default one is created and returned.
Definition at line 161 of file vtkVolumeProperty.h.
| void vtkVolumeProperty::SetScalarOpacityUnitDistance | ( | int | index, | |
| double | distance | |||
| ) |
Set/Get the unit distance on which the scalar opacity transfer function is defined. By default this is 1.0, meaning that over a distance of 1.0 units, a given opacity (from the transfer function) is accumulated. This is adjusted for the actual sampling distance during rendering.
| void vtkVolumeProperty::SetScalarOpacityUnitDistance | ( | double | distance | ) | [inline] |
Set/Get the unit distance on which the scalar opacity transfer function is defined. By default this is 1.0, meaning that over a distance of 1.0 units, a given opacity (from the transfer function) is accumulated. This is adjusted for the actual sampling distance during rendering.
Definition at line 172 of file vtkVolumeProperty.h.
| double vtkVolumeProperty::GetScalarOpacityUnitDistance | ( | int | index | ) |
Set/Get the unit distance on which the scalar opacity transfer function is defined. By default this is 1.0, meaning that over a distance of 1.0 units, a given opacity (from the transfer function) is accumulated. This is adjusted for the actual sampling distance during rendering.
| double vtkVolumeProperty::GetScalarOpacityUnitDistance | ( | ) | [inline] |
Set/Get the unit distance on which the scalar opacity transfer function is defined. By default this is 1.0, meaning that over a distance of 1.0 units, a given opacity (from the transfer function) is accumulated. This is adjusted for the actual sampling distance during rendering.
Definition at line 175 of file vtkVolumeProperty.h.
| void vtkVolumeProperty::SetGradientOpacity | ( | int | index, | |
| vtkPiecewiseFunction * | function | |||
| ) |
Set the opacity of a volume to an opacity transfer function based on gradient magnitude for the given component.
| void vtkVolumeProperty::SetGradientOpacity | ( | vtkPiecewiseFunction * | function | ) | [inline] |
Set the opacity of a volume to an opacity transfer function based on gradient magnitude for the given component.
Definition at line 184 of file vtkVolumeProperty.h.
| vtkPiecewiseFunction* vtkVolumeProperty::GetGradientOpacity | ( | int | index | ) |
Get the gradient magnitude opacity transfer function for the given component. If no transfer function has been set for this component, a default one is created and returned. This default function is always returned if DisableGradientOpacity is On for that component.
| vtkPiecewiseFunction* vtkVolumeProperty::GetGradientOpacity | ( | ) | [inline] |
Get the gradient magnitude opacity transfer function for the given component. If no transfer function has been set for this component, a default one is created and returned. This default function is always returned if DisableGradientOpacity is On for that component.
Definition at line 194 of file vtkVolumeProperty.h.
| virtual void vtkVolumeProperty::SetDisableGradientOpacity | ( | int | index, | |
| int | value | |||
| ) | [virtual] |
Enable/Disable the gradient opacity function for the given component. If set to true, any call to GetGradientOpacity() will return a default function for this component. Note that the gradient opacity function is still stored, it is not set or reset and can be retrieved using GetStoredGradientOpacity().
| virtual void vtkVolumeProperty::SetDisableGradientOpacity | ( | int | value | ) | [inline, virtual] |
Enable/Disable the gradient opacity function for the given component. If set to true, any call to GetGradientOpacity() will return a default function for this component. Note that the gradient opacity function is still stored, it is not set or reset and can be retrieved using GetStoredGradientOpacity().
Definition at line 205 of file vtkVolumeProperty.h.
| virtual void vtkVolumeProperty::DisableGradientOpacityOn | ( | int | index | ) | [inline, virtual] |
Enable/Disable the gradient opacity function for the given component. If set to true, any call to GetGradientOpacity() will return a default function for this component. Note that the gradient opacity function is still stored, it is not set or reset and can be retrieved using GetStoredGradientOpacity().
Definition at line 207 of file vtkVolumeProperty.h.
| virtual void vtkVolumeProperty::DisableGradientOpacityOn | ( | ) | [inline, virtual] |
Enable/Disable the gradient opacity function for the given component. If set to true, any call to GetGradientOpacity() will return a default function for this component. Note that the gradient opacity function is still stored, it is not set or reset and can be retrieved using GetStoredGradientOpacity().
Definition at line 209 of file vtkVolumeProperty.h.
| virtual void vtkVolumeProperty::DisableGradientOpacityOff | ( | int | index | ) | [inline, virtual] |
Enable/Disable the gradient opacity function for the given component. If set to true, any call to GetGradientOpacity() will return a default function for this component. Note that the gradient opacity function is still stored, it is not set or reset and can be retrieved using GetStoredGradientOpacity().
Definition at line 211 of file vtkVolumeProperty.h.
| virtual void vtkVolumeProperty::DisableGradientOpacityOff | ( | ) | [inline, virtual] |
Enable/Disable the gradient opacity function for the given component. If set to true, any call to GetGradientOpacity() will return a default function for this component. Note that the gradient opacity function is still stored, it is not set or reset and can be retrieved using GetStoredGradientOpacity().
Definition at line 213 of file vtkVolumeProperty.h.
| virtual int vtkVolumeProperty::GetDisableGradientOpacity | ( | int | index | ) | [virtual] |
Enable/Disable the gradient opacity function for the given component. If set to true, any call to GetGradientOpacity() will return a default function for this component. Note that the gradient opacity function is still stored, it is not set or reset and can be retrieved using GetStoredGradientOpacity().
| virtual int vtkVolumeProperty::GetDisableGradientOpacity | ( | ) | [inline, virtual] |
Enable/Disable the gradient opacity function for the given component. If set to true, any call to GetGradientOpacity() will return a default function for this component. Note that the gradient opacity function is still stored, it is not set or reset and can be retrieved using GetStoredGradientOpacity().
Definition at line 216 of file vtkVolumeProperty.h.
| vtkPiecewiseFunction* vtkVolumeProperty::GetStoredGradientOpacity | ( | int | index | ) |
Enable/Disable the gradient opacity function for the given component. If set to true, any call to GetGradientOpacity() will return a default function for this component. Note that the gradient opacity function is still stored, it is not set or reset and can be retrieved using GetStoredGradientOpacity().
| vtkPiecewiseFunction* vtkVolumeProperty::GetStoredGradientOpacity | ( | ) | [inline] |
Enable/Disable the gradient opacity function for the given component. If set to true, any call to GetGradientOpacity() will return a default function for this component. Note that the gradient opacity function is still stored, it is not set or reset and can be retrieved using GetStoredGradientOpacity().
Definition at line 219 of file vtkVolumeProperty.h.
| void vtkVolumeProperty::SetShade | ( | int | index, | |
| int | value | |||
| ) |
Set/Get the shading of a volume. If shading is turned off, then the mapper for the volume will not perform shading calculations. If shading is turned on, the mapper may perform shading calculations - in some cases shading does not apply (for example, in a maximum intensity projection) and therefore shading will not be performed even if this flag is on. For a compositing type of mapper, turning shading off is generally the same as setting ambient=1, diffuse=0, specular=0. Shading can be independently turned on/off per component.
| void vtkVolumeProperty::SetShade | ( | int | value | ) | [inline] |
Set/Get the shading of a volume. If shading is turned off, then the mapper for the volume will not perform shading calculations. If shading is turned on, the mapper may perform shading calculations - in some cases shading does not apply (for example, in a maximum intensity projection) and therefore shading will not be performed even if this flag is on. For a compositing type of mapper, turning shading off is generally the same as setting ambient=1, diffuse=0, specular=0. Shading can be independently turned on/off per component.
Definition at line 233 of file vtkVolumeProperty.h.
| int vtkVolumeProperty::GetShade | ( | int | index | ) |
Set/Get the shading of a volume. If shading is turned off, then the mapper for the volume will not perform shading calculations. If shading is turned on, the mapper may perform shading calculations - in some cases shading does not apply (for example, in a maximum intensity projection) and therefore shading will not be performed even if this flag is on. For a compositing type of mapper, turning shading off is generally the same as setting ambient=1, diffuse=0, specular=0. Shading can be independently turned on/off per component.
| int vtkVolumeProperty::GetShade | ( | ) | [inline] |
Set/Get the shading of a volume. If shading is turned off, then the mapper for the volume will not perform shading calculations. If shading is turned on, the mapper may perform shading calculations - in some cases shading does not apply (for example, in a maximum intensity projection) and therefore shading will not be performed even if this flag is on. For a compositing type of mapper, turning shading off is generally the same as setting ambient=1, diffuse=0, specular=0. Shading can be independently turned on/off per component.
Definition at line 235 of file vtkVolumeProperty.h.
| void vtkVolumeProperty::ShadeOn | ( | int | index | ) |
Set/Get the shading of a volume. If shading is turned off, then the mapper for the volume will not perform shading calculations. If shading is turned on, the mapper may perform shading calculations - in some cases shading does not apply (for example, in a maximum intensity projection) and therefore shading will not be performed even if this flag is on. For a compositing type of mapper, turning shading off is generally the same as setting ambient=1, diffuse=0, specular=0. Shading can be independently turned on/off per component.
| void vtkVolumeProperty::ShadeOn | ( | ) | [inline] |
Set/Get the shading of a volume. If shading is turned off, then the mapper for the volume will not perform shading calculations. If shading is turned on, the mapper may perform shading calculations - in some cases shading does not apply (for example, in a maximum intensity projection) and therefore shading will not be performed even if this flag is on. For a compositing type of mapper, turning shading off is generally the same as setting ambient=1, diffuse=0, specular=0. Shading can be independently turned on/off per component.
Definition at line 237 of file vtkVolumeProperty.h.
| void vtkVolumeProperty::ShadeOff | ( | int | index | ) |
Set/Get the shading of a volume. If shading is turned off, then the mapper for the volume will not perform shading calculations. If shading is turned on, the mapper may perform shading calculations - in some cases shading does not apply (for example, in a maximum intensity projection) and therefore shading will not be performed even if this flag is on. For a compositing type of mapper, turning shading off is generally the same as setting ambient=1, diffuse=0, specular=0. Shading can be independently turned on/off per component.
| void vtkVolumeProperty::ShadeOff | ( | ) | [inline] |
Set/Get the shading of a volume. If shading is turned off, then the mapper for the volume will not perform shading calculations. If shading is turned on, the mapper may perform shading calculations - in some cases shading does not apply (for example, in a maximum intensity projection) and therefore shading will not be performed even if this flag is on. For a compositing type of mapper, turning shading off is generally the same as setting ambient=1, diffuse=0, specular=0. Shading can be independently turned on/off per component.
Definition at line 239 of file vtkVolumeProperty.h.
| void vtkVolumeProperty::SetAmbient | ( | int | index, | |
| double | value | |||
| ) |
Set/Get the ambient lighting coefficient.
| void vtkVolumeProperty::SetAmbient | ( | double | value | ) | [inline] |
Set/Get the ambient lighting coefficient.
Definition at line 245 of file vtkVolumeProperty.h.
| double vtkVolumeProperty::GetAmbient | ( | int | index | ) |
Set/Get the ambient lighting coefficient.
| double vtkVolumeProperty::GetAmbient | ( | ) | [inline] |
Set/Get the ambient lighting coefficient.
Definition at line 247 of file vtkVolumeProperty.h.
| void vtkVolumeProperty::SetDiffuse | ( | int | index, | |
| double | value | |||
| ) |
Set/Get the diffuse lighting coefficient.
| void vtkVolumeProperty::SetDiffuse | ( | double | value | ) | [inline] |
Set/Get the diffuse lighting coefficient.
Definition at line 253 of file vtkVolumeProperty.h.
| double vtkVolumeProperty::GetDiffuse | ( | int | index | ) |
Set/Get the diffuse lighting coefficient.
| double vtkVolumeProperty::GetDiffuse | ( | ) | [inline] |
Set/Get the diffuse lighting coefficient.
Definition at line 255 of file vtkVolumeProperty.h.
| void vtkVolumeProperty::SetSpecular | ( | int | index, | |
| double | value | |||
| ) |
Set/Get the specular lighting coefficient.
| void vtkVolumeProperty::SetSpecular | ( | double | value | ) | [inline] |
Set/Get the specular lighting coefficient.
Definition at line 261 of file vtkVolumeProperty.h.
| double vtkVolumeProperty::GetSpecular | ( | int | index | ) |
Set/Get the specular lighting coefficient.
| double vtkVolumeProperty::GetSpecular | ( | ) | [inline] |
Set/Get the specular lighting coefficient.
Definition at line 263 of file vtkVolumeProperty.h.
| void vtkVolumeProperty::SetSpecularPower | ( | int | index, | |
| double | value | |||
| ) |
Set/Get the specular power.
| void vtkVolumeProperty::SetSpecularPower | ( | double | value | ) | [inline] |
Set/Get the specular power.
Definition at line 269 of file vtkVolumeProperty.h.
| double vtkVolumeProperty::GetSpecularPower | ( | int | index | ) |
Set/Get the specular power.
| double vtkVolumeProperty::GetSpecularPower | ( | ) | [inline] |
Set/Get the specular power.
Definition at line 271 of file vtkVolumeProperty.h.
| void vtkVolumeProperty::UpdateMTimes | ( | ) |
WARNING: INTERNAL METHOD - NOT INTENDED FOR GENERAL USE UpdateMTimes performs a Modified() on all TimeStamps. This is used by vtkVolume when the property is set, so that any other object that might have been caching information for the property will rebuild.
| vtkTimeStamp vtkVolumeProperty::GetGradientOpacityMTime | ( | int | index | ) |
WARNING: INTERNAL METHOD - NOT INTENDED FOR GENERAL USE Get the time that the gradient opacity transfer function was set
| vtkTimeStamp vtkVolumeProperty::GetGradientOpacityMTime | ( | ) | [inline] |
WARNING: INTERNAL METHOD - NOT INTENDED FOR GENERAL USE Get the time that the gradient opacity transfer function was set
Definition at line 285 of file vtkVolumeProperty.h.
| vtkTimeStamp vtkVolumeProperty::GetScalarOpacityMTime | ( | int | index | ) |
WARNING: INTERNAL METHOD - NOT INTENDED FOR GENERAL USE Get the time that the scalar opacity transfer function was set.
| vtkTimeStamp vtkVolumeProperty::GetScalarOpacityMTime | ( | ) | [inline] |
WARNING: INTERNAL METHOD - NOT INTENDED FOR GENERAL USE Get the time that the scalar opacity transfer function was set.
Definition at line 293 of file vtkVolumeProperty.h.
| vtkTimeStamp vtkVolumeProperty::GetRGBTransferFunctionMTime | ( | int | index | ) |
WARNING: INTERNAL METHOD - NOT INTENDED FOR GENERAL USE Get the time that the RGBTransferFunction was set
| vtkTimeStamp vtkVolumeProperty::GetRGBTransferFunctionMTime | ( | ) | [inline] |
WARNING: INTERNAL METHOD - NOT INTENDED FOR GENERAL USE Get the time that the RGBTransferFunction was set
Definition at line 301 of file vtkVolumeProperty.h.
| vtkTimeStamp vtkVolumeProperty::GetGrayTransferFunctionMTime | ( | int | index | ) |
WARNING: INTERNAL METHOD - NOT INTENDED FOR GENERAL USE Get the time that the GrayTransferFunction was set
| vtkTimeStamp vtkVolumeProperty::GetGrayTransferFunctionMTime | ( | ) | [inline] |
WARNING: INTERNAL METHOD - NOT INTENDED FOR GENERAL USE Get the time that the GrayTransferFunction was set
Definition at line 309 of file vtkVolumeProperty.h.
| virtual void vtkVolumeProperty::CreateDefaultGradientOpacity | ( | int | index | ) | [protected, virtual] |
Member Data Documentation
int vtkVolumeProperty::IndependentComponents [protected] |
Definition at line 318 of file vtkVolumeProperty.h.
double vtkVolumeProperty::ComponentWeight[VTK_MAX_VRCOMP] [protected] |
Definition at line 319 of file vtkVolumeProperty.h.
int vtkVolumeProperty::InterpolationType [protected] |
Definition at line 321 of file vtkVolumeProperty.h.
int vtkVolumeProperty::ColorChannels[VTK_MAX_VRCOMP] [protected] |
Definition at line 323 of file vtkVolumeProperty.h.
vtkPiecewiseFunction* vtkVolumeProperty::GrayTransferFunction[VTK_MAX_VRCOMP] [protected] |
Definition at line 325 of file vtkVolumeProperty.h.
vtkTimeStamp vtkVolumeProperty::GrayTransferFunctionMTime[VTK_MAX_VRCOMP] [protected] |
Definition at line 326 of file vtkVolumeProperty.h.
vtkColorTransferFunction* vtkVolumeProperty::RGBTransferFunction[VTK_MAX_VRCOMP] [protected] |
Definition at line 328 of file vtkVolumeProperty.h.
vtkTimeStamp vtkVolumeProperty::RGBTransferFunctionMTime[VTK_MAX_VRCOMP] [protected] |
Definition at line 329 of file vtkVolumeProperty.h.
vtkPiecewiseFunction* vtkVolumeProperty::ScalarOpacity[VTK_MAX_VRCOMP] [protected] |
Definition at line 331 of file vtkVolumeProperty.h.
vtkTimeStamp vtkVolumeProperty::ScalarOpacityMTime[VTK_MAX_VRCOMP] [protected] |
Definition at line 332 of file vtkVolumeProperty.h.
double vtkVolumeProperty::ScalarOpacityUnitDistance[VTK_MAX_VRCOMP] [protected] |
Definition at line 333 of file vtkVolumeProperty.h.
vtkPiecewiseFunction* vtkVolumeProperty::GradientOpacity[VTK_MAX_VRCOMP] [protected] |
Definition at line 335 of file vtkVolumeProperty.h.
vtkTimeStamp vtkVolumeProperty::GradientOpacityMTime[VTK_MAX_VRCOMP] [protected] |
Definition at line 336 of file vtkVolumeProperty.h.
vtkPiecewiseFunction* vtkVolumeProperty::DefaultGradientOpacity[VTK_MAX_VRCOMP] [protected] |
Definition at line 337 of file vtkVolumeProperty.h.
int vtkVolumeProperty::DisableGradientOpacity[VTK_MAX_VRCOMP] [protected] |
Definition at line 338 of file vtkVolumeProperty.h.
int vtkVolumeProperty::Shade[VTK_MAX_VRCOMP] [protected] |
Definition at line 340 of file vtkVolumeProperty.h.
double vtkVolumeProperty::Ambient[VTK_MAX_VRCOMP] [protected] |
Definition at line 341 of file vtkVolumeProperty.h.
double vtkVolumeProperty::Diffuse[VTK_MAX_VRCOMP] [protected] |
Definition at line 342 of file vtkVolumeProperty.h.
double vtkVolumeProperty::Specular[VTK_MAX_VRCOMP] [protected] |
Definition at line 343 of file vtkVolumeProperty.h.
double vtkVolumeProperty::SpecularPower[VTK_MAX_VRCOMP] [protected] |
Definition at line 344 of file vtkVolumeProperty.h.
The documentation for this class was generated from the following file:
- dox/Rendering/vtkVolumeProperty.h
