#include <vtkDenseArray.h>
vtkDenseArray is a concrete vtkArray implementation that stores values using a contiguous block of memory. Values are stored with fortran ordering, meaning that if you iterated over the memory block, the left-most coordinates would vary the fastest.
In addition to the retrieval and update methods provided by vtkTypedArray, vtkDenseArray provides methods to:
Fill the entire array with a specific value.
Retrieve a pointer to the storage memory block.
Definition at line 57 of file vtkDenseArray.h.
Public Member Functions | |
void | PrintSelf (ostream &os, vtkIndent indent) |
vtkArrayExtents | GetExtents () |
vtkIdType | GetNonNullSize () |
void | GetCoordinatesN (const vtkIdType n, vtkArrayCoordinates &coordinates) |
vtkArray * | DeepCopy () |
const T & | GetValue (const vtkArrayCoordinates &coordinates) |
const T & | GetValueN (const vtkIdType n) |
void | SetValue (const vtkArrayCoordinates &coordinates, const T &value) |
void | SetValueN (const vtkIdType n, const T &value) |
void | Fill (const T &value) |
T & | operator[] (const vtkArrayCoordinates &coordinates) |
const T * | GetStorage () const |
T * | GetStorage () |
Static Public Member Functions | |
static vtkDenseArray< T > * | New () |
Protected Member Functions | |
vtkDenseArray () | |
~vtkDenseArray () |
vtkDenseArray< T >::vtkDenseArray | ( | ) | [protected] |
vtkDenseArray< T >::~vtkDenseArray | ( | ) | [protected] |
static vtkDenseArray<T>* vtkDenseArray< T >::New | ( | ) | [static] |
Create an object with Debug turned off, modified time initialized to zero, and reference counting on.
Reimplemented from vtkObject.
void vtkDenseArray< T >::PrintSelf | ( | ostream & | os, | |
vtkIndent | indent | |||
) | [virtual] |
Methods invoked by print to print information about the object including superclasses. Typically not called by the user (use Print() instead) but used in the hierarchical print process to combine the output of several classes.
Reimplemented from vtkTypedArray< T >.
vtkArrayExtents vtkDenseArray< T >::GetExtents | ( | ) | [virtual] |
Returns the extents (the number of dimensions and size along each dimension) of the array.
Implements vtkArray.
vtkIdType vtkDenseArray< T >::GetNonNullSize | ( | ) | [virtual] |
void vtkDenseArray< T >::GetCoordinatesN | ( | const vtkIdType | n, | |
vtkArrayCoordinates & | coordinates | |||
) | [virtual] |
Returns the coordinates of the n-th value in the array, where n is in the range [0, GetNonNullSize()). Note that the order in which coordinates are visited is undefined, but is guaranteed to match the order in which values are visited using vtkTypedArray::GetValueN() and vtkTypedArray::SetValueN().
Implements vtkArray.
vtkArray* vtkDenseArray< T >::DeepCopy | ( | ) | [virtual] |
Returns a new array that is a deep copy of this array.
Implements vtkArray.
const T& vtkDenseArray< T >::GetValue | ( | const vtkArrayCoordinates & | coordinates | ) | [virtual] |
Returns the value stored in the array at the given coordinates. Note that the number of dimensions in the supplied coordinates must match the number of dimensions in the array.
Implements vtkTypedArray< T >.
const T& vtkDenseArray< T >::GetValueN | ( | const vtkIdType | n | ) | [virtual] |
Returns the n-th value stored in the array, where n is in the range [0, GetNonNullSize()). This is useful for efficiently visiting every value in the array. Note that the order in which values are visited is undefined, but is guaranteed to match the order used by vtkArray::GetCoordinatesN().
Implements vtkTypedArray< T >.
void vtkDenseArray< T >::SetValue | ( | const vtkArrayCoordinates & | coordinates, | |
const T & | value | |||
) | [virtual] |
Overwrites the value stored in the array at the given coordinates. Note that the number of dimensions in the supplied coordinates must match the number of dimensions in the array.
Implements vtkTypedArray< T >.
void vtkDenseArray< T >::SetValueN | ( | const vtkIdType | n, | |
const T & | value | |||
) | [virtual] |
Overwrites the n-th value stored in the array, where n is in the range [0, GetNonNullSize()). This is useful for efficiently visiting every value in the array. Note that the order in which values are visited is undefined, but is guaranteed to match the order used by vtkArray::GetCoordinatesN().
Implements vtkTypedArray< T >.
void vtkDenseArray< T >::Fill | ( | const T & | value | ) |
Fills every element in the array with the given value.
T& vtkDenseArray< T >::operator[] | ( | const vtkArrayCoordinates & | coordinates | ) |
Returns a value by-reference, which is useful for performance and code-clarity.
const T* vtkDenseArray< T >::GetStorage | ( | ) | const |
Returns a read-only reference to the underlying storage. Values are stored contiguously with fortran ordering.
T* vtkDenseArray< T >::GetStorage | ( | ) |
Returns a mutable reference to the underlying storage. Values are stored contiguously with fortran ordering. Use at your own risk!
