vtkImageToStructuredPoints Class Reference
#include <vtkImageToStructuredPoints.h>
Detailed Description
Attaches image pipeline to VTK.vtkImageToStructuredPoints changes an image cache format to a structured points dataset. It takes an Input plus an optional VectorInput. The VectorInput converts the RGB scalar components of the VectorInput to vector pointdata attributes. This filter will try to reference count the data but in some cases it must make a copy.
Definition at line 37 of file vtkImageToStructuredPoints.h.
Public Types | |
| typedef vtkImageAlgorithm | Superclass |
Public Member Functions | |
| virtual const char * | GetClassName () |
| virtual int | IsA (const char *type) |
| void | PrintSelf (ostream &os, vtkIndent indent) |
| void | SetVectorInput (vtkImageData *input) |
| vtkImageData * | GetVectorInput () |
Static Public Member Functions | |
| static vtkImageToStructuredPoints * | New () |
| static int | IsTypeOf (const char *type) |
| static vtkImageToStructuredPoints * | SafeDownCast (vtkObject *o) |
Protected Member Functions | |
| vtkImageToStructuredPoints () | |
| ~vtkImageToStructuredPoints () | |
| virtual int | RequestData (vtkInformation *, vtkInformationVector **, vtkInformationVector *) |
| virtual int | RequestInformation (vtkInformation *, vtkInformationVector **, vtkInformationVector *) |
| virtual int | RequestUpdateExtent (vtkInformation *, vtkInformationVector **, vtkInformationVector *) |
| virtual int | FillOutputPortInformation (int, vtkInformation *) |
| virtual int | FillInputPortInformation (int, vtkInformation *) |
Protected Attributes | |
| int | Translate [3] |
Member Typedef Documentation
Constructor & Destructor Documentation
| vtkImageToStructuredPoints::vtkImageToStructuredPoints | ( | ) | [protected] |
| vtkImageToStructuredPoints::~vtkImageToStructuredPoints | ( | ) | [protected] |
Member Function Documentation
| static vtkImageToStructuredPoints* vtkImageToStructuredPoints::New | ( | ) | [static] |
Create an object with Debug turned off, modified time initialized to zero, and reference counting on.
Reimplemented from vtkAlgorithm.
| virtual const char* vtkImageToStructuredPoints::GetClassName | ( | ) | [virtual] |
Reimplemented from vtkImageAlgorithm.
| static int vtkImageToStructuredPoints::IsTypeOf | ( | const char * | name | ) | [static] |
Return 1 if this class type is the same type of (or a subclass of) the named class. Returns 0 otherwise. This method works in combination with vtkTypeRevisionMacro found in vtkSetGet.h.
Reimplemented from vtkImageAlgorithm.
| virtual int vtkImageToStructuredPoints::IsA | ( | const char * | name | ) | [virtual] |
Return 1 if this class is the same type of (or a subclass of) the named class. Returns 0 otherwise. This method works in combination with vtkTypeRevisionMacro found in vtkSetGet.h.
Reimplemented from vtkImageAlgorithm.
| static vtkImageToStructuredPoints* vtkImageToStructuredPoints::SafeDownCast | ( | vtkObject * | o | ) | [static] |
Reimplemented from vtkImageAlgorithm.
| void vtkImageToStructuredPoints::PrintSelf | ( | ostream & | os, | |
| vtkIndent | indent | |||
| ) | [virtual] |
Methods invoked by print to print information about the object including superclasses. Typically not called by the user (use Print() instead) but used in the hierarchical print process to combine the output of several classes.
Reimplemented from vtkImageAlgorithm.
| void vtkImageToStructuredPoints::SetVectorInput | ( | vtkImageData * | input | ) |
Set/Get the input object from the image pipeline.
| vtkImageData* vtkImageToStructuredPoints::GetVectorInput | ( | ) |
Set/Get the input object from the image pipeline.
| virtual int vtkImageToStructuredPoints::RequestData | ( | vtkInformation * | request, | |
| vtkInformationVector ** | inputVector, | |||
| vtkInformationVector * | outputVector | |||
| ) | [protected, virtual] |
This is called by the superclass. This is the method you should override.
Reimplemented from vtkImageAlgorithm.
| virtual int vtkImageToStructuredPoints::RequestInformation | ( | vtkInformation * | , | |
| vtkInformationVector ** | , | |||
| vtkInformationVector * | ||||
| ) | [protected, virtual] |
Reimplemented from vtkImageAlgorithm.
| virtual int vtkImageToStructuredPoints::RequestUpdateExtent | ( | vtkInformation * | , | |
| vtkInformationVector ** | , | |||
| vtkInformationVector * | ||||
| ) | [protected, virtual] |
Reimplemented from vtkImageAlgorithm.
| virtual int vtkImageToStructuredPoints::FillOutputPortInformation | ( | int | port, | |
| vtkInformation * | info | |||
| ) | [protected, virtual] |
Fill the output port information objects for this algorithm. This is invoked by the first call to GetOutputPortInformation for each port so subclasses can specify what they can handle.
Reimplemented from vtkImageAlgorithm.
| virtual int vtkImageToStructuredPoints::FillInputPortInformation | ( | int | port, | |
| vtkInformation * | info | |||
| ) | [protected, virtual] |
Fill the input port information objects for this algorithm. This is invoked by the first call to GetInputPortInformation for each port so subclasses can specify what they can handle.
Reimplemented from vtkImageAlgorithm.
Member Data Documentation
int vtkImageToStructuredPoints::Translate[3] [protected] |
Definition at line 55 of file vtkImageToStructuredPoints.h.
The documentation for this class was generated from the following file:
- dox/Filtering/vtkImageToStructuredPoints.h
