vtkImplicitWindowFunction Class Reference
#include <vtkImplicitWindowFunction.h>
Detailed Description
implicit function maps another implicit function to lie within a specified rangevtkImplicitWindowFunction is used to modify the output of another implicit function to lie within a specified "window", or function range. This can be used to add "thickness" to cutting or clipping functions.
This class works as follows. First, it evaluates the function value of the user-specified implicit function. Then, based on the window range specified, it maps the function value into the window values specified.
- See also:
- vtkImplicitFunction
Definition at line 40 of file vtkImplicitWindowFunction.h.
Public Types | |
| typedef vtkImplicitFunction | Superclass |
Public Member Functions | |
| virtual const char * | GetClassName () |
| virtual int | IsA (const char *type) |
| void | PrintSelf (ostream &os, vtkIndent indent) |
| void | EvaluateGradient (double x[3], double n[3]) |
| unsigned long | GetMTime () |
| double | EvaluateFunction (double x[3]) |
| double | EvaluateFunction (double x, double y, double z) |
| virtual void | SetImplicitFunction (vtkImplicitFunction *) |
| virtual vtkImplicitFunction * | GetImplicitFunction () |
| virtual void | SetWindowRange (double, double) |
| void | SetWindowRange (double[2]) |
| virtual double * | GetWindowRange () |
| virtual void | GetWindowRange (double data[2]) |
| virtual void | SetWindowValues (double, double) |
| void | SetWindowValues (double[2]) |
| virtual double * | GetWindowValues () |
| virtual void | GetWindowValues (double data[2]) |
| virtual void | Register (vtkObjectBase *o) |
| virtual void | UnRegister (vtkObjectBase *o) |
Static Public Member Functions | |
| static int | IsTypeOf (const char *type) |
| static vtkImplicitWindowFunction * | SafeDownCast (vtkObject *o) |
| static vtkImplicitWindowFunction * | New () |
Protected Member Functions | |
| vtkImplicitWindowFunction () | |
| ~vtkImplicitWindowFunction () | |
| virtual void | ReportReferences (vtkGarbageCollector *) |
Protected Attributes | |
| vtkImplicitFunction * | ImplicitFunction |
| double | WindowRange [2] |
| double | WindowValues [2] |
Member Typedef Documentation
Constructor & Destructor Documentation
| vtkImplicitWindowFunction::vtkImplicitWindowFunction | ( | ) | [protected] |
| vtkImplicitWindowFunction::~vtkImplicitWindowFunction | ( | ) | [protected] |
Member Function Documentation
| virtual const char* vtkImplicitWindowFunction::GetClassName | ( | ) | [virtual] |
Reimplemented from vtkImplicitFunction.
| static int vtkImplicitWindowFunction::IsTypeOf | ( | const char * | name | ) | [static] |
Return 1 if this class type is the same type of (or a subclass of) the named class. Returns 0 otherwise. This method works in combination with vtkTypeRevisionMacro found in vtkSetGet.h.
Reimplemented from vtkImplicitFunction.
| virtual int vtkImplicitWindowFunction::IsA | ( | const char * | name | ) | [virtual] |
Return 1 if this class is the same type of (or a subclass of) the named class. Returns 0 otherwise. This method works in combination with vtkTypeRevisionMacro found in vtkSetGet.h.
Reimplemented from vtkImplicitFunction.
| static vtkImplicitWindowFunction* vtkImplicitWindowFunction::SafeDownCast | ( | vtkObject * | o | ) | [static] |
Reimplemented from vtkImplicitFunction.
| void vtkImplicitWindowFunction::PrintSelf | ( | ostream & | os, | |
| vtkIndent | indent | |||
| ) | [virtual] |
Methods invoked by print to print information about the object including superclasses. Typically not called by the user (use Print() instead) but used in the hierarchical print process to combine the output of several classes.
Reimplemented from vtkImplicitFunction.
| static vtkImplicitWindowFunction* vtkImplicitWindowFunction::New | ( | ) | [static] |
Construct object with window range (0,1) and window values (0,1).
Reimplemented from vtkObject.
| double vtkImplicitWindowFunction::EvaluateFunction | ( | double | x[3] | ) | [virtual] |
Evaluate window function.
Implements vtkImplicitFunction.
| double vtkImplicitWindowFunction::EvaluateFunction | ( | double | x, | |
| double | y, | |||
| double | z | |||
| ) | [inline] |
Evaluate window function.
Reimplemented from vtkImplicitFunction.
Definition at line 52 of file vtkImplicitWindowFunction.h.
| void vtkImplicitWindowFunction::EvaluateGradient | ( | double | x[3], | |
| double | n[3] | |||
| ) | [virtual] |
Evaluate window function gradient. Just return implicit function gradient.
Implements vtkImplicitFunction.
| virtual void vtkImplicitWindowFunction::SetImplicitFunction | ( | vtkImplicitFunction * | ) | [virtual] |
Specify an implicit function to operate on.
| virtual vtkImplicitFunction* vtkImplicitWindowFunction::GetImplicitFunction | ( | ) | [virtual] |
Specify an implicit function to operate on.
| virtual void vtkImplicitWindowFunction::SetWindowRange | ( | double | , | |
| double | ||||
| ) | [virtual] |
Specify the range of function values which are considered to lie within the window. WindowRange[0] is assumed to be less than WindowRange[1].
| void vtkImplicitWindowFunction::SetWindowRange | ( | double | [2] | ) |
Specify the range of function values which are considered to lie within the window. WindowRange[0] is assumed to be less than WindowRange[1].
| virtual double* vtkImplicitWindowFunction::GetWindowRange | ( | ) | [virtual] |
Specify the range of function values which are considered to lie within the window. WindowRange[0] is assumed to be less than WindowRange[1].
| virtual void vtkImplicitWindowFunction::GetWindowRange | ( | double | data[2] | ) | [virtual] |
Specify the range of function values which are considered to lie within the window. WindowRange[0] is assumed to be less than WindowRange[1].
| virtual void vtkImplicitWindowFunction::SetWindowValues | ( | double | , | |
| double | ||||
| ) | [virtual] |
Specify the range of output values that the window range is mapped into. This is effectively a scaling and shifting of the original function values.
| void vtkImplicitWindowFunction::SetWindowValues | ( | double | [2] | ) |
Specify the range of output values that the window range is mapped into. This is effectively a scaling and shifting of the original function values.
| virtual double* vtkImplicitWindowFunction::GetWindowValues | ( | ) | [virtual] |
Specify the range of output values that the window range is mapped into. This is effectively a scaling and shifting of the original function values.
| virtual void vtkImplicitWindowFunction::GetWindowValues | ( | double | data[2] | ) | [virtual] |
Specify the range of output values that the window range is mapped into. This is effectively a scaling and shifting of the original function values.
| unsigned long vtkImplicitWindowFunction::GetMTime | ( | ) | [virtual] |
Override modified time retrieval because of object dependencies.
Reimplemented from vtkImplicitFunction.
| virtual void vtkImplicitWindowFunction::Register | ( | vtkObjectBase * | o | ) | [virtual] |
Participate in garbage collection.
Reimplemented from vtkObjectBase.
| virtual void vtkImplicitWindowFunction::UnRegister | ( | vtkObjectBase * | o | ) | [virtual] |
Participate in garbage collection.
Reimplemented from vtkObjectBase.
| virtual void vtkImplicitWindowFunction::ReportReferences | ( | vtkGarbageCollector * | ) | [protected, virtual] |
Reimplemented from vtkObjectBase.
Member Data Documentation
Definition at line 97 of file vtkImplicitWindowFunction.h.
double vtkImplicitWindowFunction::WindowRange[2] [protected] |
Definition at line 98 of file vtkImplicitWindowFunction.h.
double vtkImplicitWindowFunction::WindowValues[2] [protected] |
Definition at line 99 of file vtkImplicitWindowFunction.h.
The documentation for this class was generated from the following file:
- dox/Filtering/vtkImplicitWindowFunction.h
