vtkInteractorStyleImage Class Reference

#include <vtkInteractorStyleImage.h>

Inheritance diagram for vtkInteractorStyleImage:

[legend]

Collaboration diagram for vtkInteractorStyleImage:

[legend]

List of all members.

Detailed Description

interactive manipulation of the camera specialized for images

vtkInteractorStyleImage allows the user to interactively manipulate (rotate, pan, zoomm etc.) the camera. vtkInteractorStyleImage is specially designed to work with images that are being rendered with vtkImageActor. Several events are overloaded from its superclass vtkInteractorStyle, hence the mouse bindings are different. (The bindings keep the camera's view plane normal perpendicular to the x-y plane.) In summary the mouse events are as follows: + Left Mouse button triggers window level events + CTRL Left Mouse spins the camera around its view plane normal + SHIFT Left Mouse pans the camera + CTRL SHIFT Left Mouse dollys (a positional zoom) the camera + Middle mouse button pans the camera + Right mouse button dollys the camera. + SHIFT Right Mouse triggers pick events

Note that the renderer's actors are not moved; instead the camera is moved.

See also:: vtkInteractorStyle vtkInteractorStyleTrackballActor vtkInteractorStyleJoystickCamera vtkInteractorStyleJoystickActor

Events:: vtkCommand::PickEvent vtkCommand::InteractionEvent vtkCommand::EndPickEvent vtkCommand::StartPickEvent vtkCommand::StartWindowLevelEvent vtkCommand::WindowLevelEvent vtkCommand::EndWindowLevelEvent vtkCommand::ResetWindowLevelEvent

Tests:: vtkInteractorStyleImage (Tests)

Definition at line 56 of file vtkInteractorStyleImage.h.


Public Types
typedef vtkInteractorStyleTrackballCamera	Superclass
Public Member Functions
virtual const char *	GetClassName ()
virtual int	IsA (const char *type)
void	PrintSelf (ostream &os, vtkIndent indent)
virtual void	OnChar ()
virtual void	WindowLevel ()
virtual void	Pick ()
virtual void	StartWindowLevel ()
virtual void	EndWindowLevel ()
virtual void	StartPick ()
virtual void	EndPick ()

virtual int *	GetWindowLevelStartPosition ()
virtual void	GetWindowLevelStartPosition (int &, int &)
virtual void	GetWindowLevelStartPosition (int[2])
virtual int *	GetWindowLevelCurrentPosition ()
virtual void	GetWindowLevelCurrentPosition (int &, int &)
virtual void	GetWindowLevelCurrentPosition (int[2])

virtual void	OnMouseMove ()
virtual void	OnLeftButtonDown ()
virtual void	OnLeftButtonUp ()
virtual void	OnRightButtonDown ()
virtual void	OnRightButtonUp ()
Static Public Member Functions
static vtkInteractorStyleImage *	New ()
static int	IsTypeOf (const char *type)
static vtkInteractorStyleImage *	SafeDownCast (vtkObject *o)
Protected Member Functions
	vtkInteractorStyleImage ()
	~vtkInteractorStyleImage ()
Protected Attributes
int	WindowLevelStartPosition [2]
int	WindowLevelCurrentPosition [2]

Member Typedef Documentation

typedef vtkInteractorStyleTrackballCamera vtkInteractorStyleImage::Superclass

Reimplemented from vtkInteractorStyleTrackballCamera.

Reimplemented in vtkInteractorStyleTreeMapHover.

Definition at line 60 of file vtkInteractorStyleImage.h.

Constructor & Destructor Documentation

vtkInteractorStyleImage::vtkInteractorStyleImage ( ) [protected]

vtkInteractorStyleImage::~vtkInteractorStyleImage ( ) [protected]

Member Function Documentation

static vtkInteractorStyleImage* vtkInteractorStyleImage::New ( ) [static]

This class must be supplied with a vtkRenderWindowInteractor wrapper or parent. This class should not normally be instantiated by application programmers.

Reimplemented from vtkInteractorStyleTrackballCamera.

Reimplemented in vtkInteractorStyleTreeMapHover.

virtual const char* vtkInteractorStyleImage::GetClassName ( ) [virtual]

Reimplemented from vtkInteractorStyleTrackballCamera.

Reimplemented in vtkInteractorStyleTreeMapHover.

static int vtkInteractorStyleImage::IsTypeOf ( const char * name ) [static]

Return 1 if this class type is the same type of (or a subclass of) the named class. Returns 0 otherwise. This method works in combination with vtkTypeRevisionMacro found in vtkSetGet.h.

Reimplemented from vtkInteractorStyleTrackballCamera.

Reimplemented in vtkInteractorStyleTreeMapHover.

virtual int vtkInteractorStyleImage::IsA ( const char * name ) [virtual]

Return 1 if this class is the same type of (or a subclass of) the named class. Returns 0 otherwise. This method works in combination with vtkTypeRevisionMacro found in vtkSetGet.h.

Reimplemented from vtkInteractorStyleTrackballCamera.

Reimplemented in vtkInteractorStyleTreeMapHover.

static vtkInteractorStyleImage* vtkInteractorStyleImage::SafeDownCast ( vtkObject * o ) [static]

Reimplemented from vtkInteractorStyleTrackballCamera.

Reimplemented in vtkInteractorStyleTreeMapHover.

void vtkInteractorStyleImage::PrintSelf	(	ostream &	os,
		vtkIndent	indent
	)			`[virtual]`

Methods invoked by print to print information about the object including superclasses. Typically not called by the user (use Print() instead) but used in the hierarchical print process to combine the output of several classes.

Reimplemented from vtkInteractorStyleTrackballCamera.

Reimplemented in vtkInteractorStyleTreeMapHover.

virtual int* vtkInteractorStyleImage::GetWindowLevelStartPosition ( ) [virtual]
