vtkOpenGLLightingPainter Class Reference

#include <vtkOpenGLLightingPainter.h>

Inheritance diagram for vtkOpenGLLightingPainter:

Inheritance graph
[legend]
Collaboration diagram for vtkOpenGLLightingPainter:

Collaboration graph
[legend]

List of all members.


Detailed Description

painter that manages lighting.

This painter manages lighting. Ligting is disabled when rendering points/lines and no normals are present or rendering Polygons/TStrips and representation is points and no normals are present.

Definition at line 31 of file vtkOpenGLLightingPainter.h.


Public Types

typedef vtkLightingPainter Superclass

Public Member Functions

virtual const char * GetClassName ()
virtual int IsA (const char *type)
void PrintSelf (ostream &os, vtkIndent indent)
virtual double GetTimeToDraw ()

Static Public Member Functions

static vtkOpenGLLightingPainterNew ()
static int IsTypeOf (const char *type)
static vtkOpenGLLightingPainterSafeDownCast (vtkObject *o)

Protected Member Functions

 vtkOpenGLLightingPainter ()
 ~vtkOpenGLLightingPainter ()
virtual void RenderInternal (vtkRenderer *renderer, vtkActor *actor, unsigned long typeflags, bool forceCompileOnly)

Member Typedef Documentation

Reimplemented from vtkLightingPainter.

Definition at line 35 of file vtkOpenGLLightingPainter.h.


Constructor & Destructor Documentation

vtkOpenGLLightingPainter::vtkOpenGLLightingPainter (  )  [protected]

vtkOpenGLLightingPainter::~vtkOpenGLLightingPainter (  )  [protected]


Member Function Documentation

static vtkOpenGLLightingPainter* vtkOpenGLLightingPainter::New (  )  [static]

Create an object with Debug turned off, modified time initialized to zero, and reference counting on.

Reimplemented from vtkLightingPainter.

virtual const char* vtkOpenGLLightingPainter::GetClassName (  )  [virtual]

Reimplemented from vtkLightingPainter.

static int vtkOpenGLLightingPainter::IsTypeOf ( const char *  name  )  [static]

Return 1 if this class type is the same type of (or a subclass of) the named class. Returns 0 otherwise. This method works in combination with vtkTypeRevisionMacro found in vtkSetGet.h.

Reimplemented from vtkLightingPainter.

virtual int vtkOpenGLLightingPainter::IsA ( const char *  name  )  [virtual]

Return 1 if this class is the same type of (or a subclass of) the named class. Returns 0 otherwise. This method works in combination with vtkTypeRevisionMacro found in vtkSetGet.h.

Reimplemented from vtkLightingPainter.

static vtkOpenGLLightingPainter* vtkOpenGLLightingPainter::SafeDownCast ( vtkObject o  )  [static]

Reimplemented from vtkLightingPainter.

void vtkOpenGLLightingPainter::PrintSelf ( ostream &  os,
vtkIndent  indent
) [virtual]

Methods invoked by print to print information about the object including superclasses. Typically not called by the user (use Print() instead) but used in the hierarchical print process to combine the output of several classes.

Reimplemented from vtkLightingPainter.

virtual double vtkOpenGLLightingPainter::GetTimeToDraw (  )  [inline, virtual]

This painter overrides GetTimeToDraw() to never pass the request to the delegate. This is done since this class may propagate a single render request multiple times to the delegate. In that case the time accumulation responsibility is borne by the painter causing the multiple rendering requests i.e. this painter itself.

Reimplemented from vtkPainter.

Definition at line 44 of file vtkOpenGLLightingPainter.h.

virtual void vtkOpenGLLightingPainter::RenderInternal ( vtkRenderer renderer,
vtkActor actor,
unsigned long  typeflags,
bool  forceCompileOnly
) [protected, virtual]

Setups lighting state before calling render on delegate painter.

Reimplemented from vtkPainter.


The documentation for this class was generated from the following file:
