vtkOpenGLRepresentationPainter Class Reference
#include <vtkOpenGLRepresentationPainter.h>
Detailed Description
painter handling representation using OpenGL.This is OpenGL implementation of a painter handling representation i.e. Points, Wireframe, Surface.
Definition at line 29 of file vtkOpenGLRepresentationPainter.h.
Public Types | |
| typedef vtkRepresentationPainter | Superclass |
Public Member Functions | |
| virtual const char * | GetClassName () |
| virtual int | IsA (const char *type) |
| void | PrintSelf (ostream &os, vtkIndent indent) |
| virtual double | GetTimeToDraw () |
Static Public Member Functions | |
| static vtkOpenGLRepresentationPainter * | New () |
| static int | IsTypeOf (const char *type) |
| static vtkOpenGLRepresentationPainter * | SafeDownCast (vtkObject *o) |
Protected Member Functions | |
| vtkOpenGLRepresentationPainter () | |
| ~vtkOpenGLRepresentationPainter () | |
| void | RenderInternal (vtkRenderer *renderer, vtkActor *actor, unsigned long typeflags, bool forceCompileOnly) |
Member Typedef Documentation
Reimplemented from vtkRepresentationPainter.
Definition at line 34 of file vtkOpenGLRepresentationPainter.h.
Constructor & Destructor Documentation
| vtkOpenGLRepresentationPainter::vtkOpenGLRepresentationPainter | ( | ) | [protected] |
| vtkOpenGLRepresentationPainter::~vtkOpenGLRepresentationPainter | ( | ) | [protected] |
Member Function Documentation
| static vtkOpenGLRepresentationPainter* vtkOpenGLRepresentationPainter::New | ( | ) | [static] |
Create an object with Debug turned off, modified time initialized to zero, and reference counting on.
Reimplemented from vtkRepresentationPainter.
| virtual const char* vtkOpenGLRepresentationPainter::GetClassName | ( | ) | [virtual] |
Reimplemented from vtkRepresentationPainter.
| static int vtkOpenGLRepresentationPainter::IsTypeOf | ( | const char * | name | ) | [static] |
Return 1 if this class type is the same type of (or a subclass of) the named class. Returns 0 otherwise. This method works in combination with vtkTypeRevisionMacro found in vtkSetGet.h.
Reimplemented from vtkRepresentationPainter.
| virtual int vtkOpenGLRepresentationPainter::IsA | ( | const char * | name | ) | [virtual] |
Return 1 if this class is the same type of (or a subclass of) the named class. Returns 0 otherwise. This method works in combination with vtkTypeRevisionMacro found in vtkSetGet.h.
Reimplemented from vtkRepresentationPainter.
| static vtkOpenGLRepresentationPainter* vtkOpenGLRepresentationPainter::SafeDownCast | ( | vtkObject * | o | ) | [static] |
Reimplemented from vtkRepresentationPainter.
| void vtkOpenGLRepresentationPainter::PrintSelf | ( | ostream & | os, | |
| vtkIndent | indent | |||
| ) | [virtual] |
Methods invoked by print to print information about the object including superclasses. Typically not called by the user (use Print() instead) but used in the hierarchical print process to combine the output of several classes.
Reimplemented from vtkRepresentationPainter.
| virtual double vtkOpenGLRepresentationPainter::GetTimeToDraw | ( | ) | [inline, virtual] |
This painter overrides GetTimeToDraw() to never pass the request to the delegate. This is done since this class may propagate a single render request multiple times to the delegate. In that case the time accumulation responsibility is borne by the painter causing the multiple rendering requests i.e. this painter itself.
Reimplemented from vtkPainter.
Definition at line 43 of file vtkOpenGLRepresentationPainter.h.
| void vtkOpenGLRepresentationPainter::RenderInternal | ( | vtkRenderer * | renderer, | |
| vtkActor * | actor, | |||
| unsigned long | typeflags, | |||
| bool | forceCompileOnly | |||
| ) | [protected, virtual] |
Changes the polygon mode according to the representation.
Reimplemented from vtkPainter.
The documentation for this class was generated from the following file:
- dox/Rendering/vtkOpenGLRepresentationPainter.h
