vtkTreeRingToPolyData Class Reference
#include <vtkTreeRingToPolyData.h>
Detailed Description
converts a tree to a polygonal data representing radial space filling tree.This algorithm requires that the vtkTreeRingLayout filter has already been applied to the data in order to create the quadruple array (start angle, end angle, inner radius, outer radius) of bounds for each vertex of the tree.
Definition at line 36 of file vtkTreeRingToPolyData.h.
Public Types | |
| typedef vtkPolyDataAlgorithm | Superclass |
Public Member Functions | |
| virtual const char * | GetClassName () |
| virtual int | IsA (const char *type) |
| void | PrintSelf (ostream &os, vtkIndent indent) |
| int | FillInputPortInformation (int port, vtkInformation *info) |
| virtual void | SetSectorsArrayName (const char *name) |
| virtual void | SetShrinkPercentage (double) |
| virtual double | GetShrinkPercentage () |
Static Public Member Functions | |
| static vtkTreeRingToPolyData * | New () |
| static int | IsTypeOf (const char *type) |
| static vtkTreeRingToPolyData * | SafeDownCast (vtkObject *o) |
Protected Member Functions | |
| vtkTreeRingToPolyData () | |
| ~vtkTreeRingToPolyData () | |
| int | RequestData (vtkInformation *, vtkInformationVector **, vtkInformationVector *) |
Protected Attributes | |
| double | ShrinkPercentage |
Member Typedef Documentation
Constructor & Destructor Documentation
| vtkTreeRingToPolyData::vtkTreeRingToPolyData | ( | ) | [protected] |
| vtkTreeRingToPolyData::~vtkTreeRingToPolyData | ( | ) | [protected] |
Member Function Documentation
| static vtkTreeRingToPolyData* vtkTreeRingToPolyData::New | ( | ) | [static] |
Create an object with Debug turned off, modified time initialized to zero, and reference counting on.
Reimplemented from vtkPolyDataAlgorithm.
| virtual const char* vtkTreeRingToPolyData::GetClassName | ( | ) | [virtual] |
Reimplemented from vtkPolyDataAlgorithm.
| static int vtkTreeRingToPolyData::IsTypeOf | ( | const char * | name | ) | [static] |
Return 1 if this class type is the same type of (or a subclass of) the named class. Returns 0 otherwise. This method works in combination with vtkTypeRevisionMacro found in vtkSetGet.h.
Reimplemented from vtkPolyDataAlgorithm.
| virtual int vtkTreeRingToPolyData::IsA | ( | const char * | name | ) | [virtual] |
Return 1 if this class is the same type of (or a subclass of) the named class. Returns 0 otherwise. This method works in combination with vtkTypeRevisionMacro found in vtkSetGet.h.
Reimplemented from vtkPolyDataAlgorithm.
| static vtkTreeRingToPolyData* vtkTreeRingToPolyData::SafeDownCast | ( | vtkObject * | o | ) | [static] |
Reimplemented from vtkPolyDataAlgorithm.
| void vtkTreeRingToPolyData::PrintSelf | ( | ostream & | os, | |
| vtkIndent | indent | |||
| ) | [virtual] |
Methods invoked by print to print information about the object including superclasses. Typically not called by the user (use Print() instead) but used in the hierarchical print process to combine the output of several classes.
Reimplemented from vtkPolyDataAlgorithm.
| virtual void vtkTreeRingToPolyData::SetSectorsArrayName | ( | const char * | name | ) | [inline, virtual] |
The field containing quadruples of the form (start angle, end angle, inner radius, outer radius) representing the bounds of the rectangles for each vertex. This field may be added to the tree using vtkTreeRingLayout. This array must be set.
Definition at line 49 of file vtkTreeRingToPolyData.h.
| virtual void vtkTreeRingToPolyData::SetShrinkPercentage | ( | double | ) | [virtual] |
Define a shrink percentage for each of the sectors.
| virtual double vtkTreeRingToPolyData::GetShrinkPercentage | ( | ) | [virtual] |
Define a shrink percentage for each of the sectors.
| int vtkTreeRingToPolyData::FillInputPortInformation | ( | int | port, | |
| vtkInformation * | info | |||
| ) | [virtual] |
Fill the input port information objects for this algorithm. This is invoked by the first call to GetInputPortInformation for each port so subclasses can specify what they can handle.
Reimplemented from vtkPolyDataAlgorithm.
| int vtkTreeRingToPolyData::RequestData | ( | vtkInformation * | request, | |
| vtkInformationVector ** | inputVector, | |||
| vtkInformationVector * | outputVector | |||
| ) | [protected, virtual] |
This is called by the superclass. This is the method you should override.
Reimplemented from vtkPolyDataAlgorithm.
Member Data Documentation
double vtkTreeRingToPolyData::ShrinkPercentage [protected] |
Definition at line 65 of file vtkTreeRingToPolyData.h.
The documentation for this class was generated from the following file:
- dox/Infovis/vtkTreeRingToPolyData.h
