vtkBridgeCellIteratorOnCellList Class Reference
#include <vtkBridgeCellIteratorOnCellList.h>
Detailed Description
Iterate over a list of cells defined on a dataset. See InitWithCells().
Definition at line 35 of file vtkBridgeCellIteratorOnCellList.h.
Public Types | |
| typedef vtkBridgeCellIteratorStrategy | Superclass |
Public Member Functions | |
| virtual const char * | GetClassName () |
| virtual int | IsA (const char *type) |
| void | PrintSelf (ostream &os, vtkIndent indent) |
| void | Begin () |
| int | IsAtEnd () |
| void | GetCell (vtkGenericAdaptorCell *c) |
| vtkGenericAdaptorCell * | GetCell () |
| void | Next () |
| void | InitWithCells (vtkIdList *cells, vtkBridgeDataSet *ds) |
Static Public Member Functions | |
| static vtkBridgeCellIteratorOnCellList * | New () |
| static int | IsTypeOf (const char *type) |
| static vtkBridgeCellIteratorOnCellList * | SafeDownCast (vtkObject *o) |
Protected Member Functions | |
| vtkBridgeCellIteratorOnCellList () | |
| virtual | ~vtkBridgeCellIteratorOnCellList () |
Protected Attributes | |
| vtkIdList * | Cells |
| vtkBridgeDataSet * | DataSet |
| vtkIdType | Id |
| vtkBridgeCell * | Cell |
Member Typedef Documentation
Standard VTK construction and type macros.
Reimplemented from vtkBridgeCellIteratorStrategy.
Definition at line 40 of file vtkBridgeCellIteratorOnCellList.h.
Constructor & Destructor Documentation
| vtkBridgeCellIteratorOnCellList::vtkBridgeCellIteratorOnCellList | ( | ) | [protected] |
| virtual vtkBridgeCellIteratorOnCellList::~vtkBridgeCellIteratorOnCellList | ( | ) | [protected, virtual] |
Member Function Documentation
| static vtkBridgeCellIteratorOnCellList* vtkBridgeCellIteratorOnCellList::New | ( | ) | [static] |
Create an object with Debug turned off, modified time initialized to zero, and reference counting on.
Reimplemented from vtkObject.
| virtual const char* vtkBridgeCellIteratorOnCellList::GetClassName | ( | ) | [virtual] |
Standard VTK construction and type macros.
Reimplemented from vtkBridgeCellIteratorStrategy.
| static int vtkBridgeCellIteratorOnCellList::IsTypeOf | ( | const char * | type | ) | [static] |
Standard VTK construction and type macros.
Reimplemented from vtkBridgeCellIteratorStrategy.
| virtual int vtkBridgeCellIteratorOnCellList::IsA | ( | const char * | type | ) | [virtual] |
Standard VTK construction and type macros.
Reimplemented from vtkBridgeCellIteratorStrategy.
| static vtkBridgeCellIteratorOnCellList* vtkBridgeCellIteratorOnCellList::SafeDownCast | ( | vtkObject * | o | ) | [static] |
Standard VTK construction and type macros.
Reimplemented from vtkBridgeCellIteratorStrategy.
| void vtkBridgeCellIteratorOnCellList::PrintSelf | ( | ostream & | os, | |
| vtkIndent | indent | |||
| ) | [virtual] |
Standard VTK construction and type macros.
Reimplemented from vtkBridgeCellIteratorStrategy.
| void vtkBridgeCellIteratorOnCellList::Begin | ( | ) | [virtual] |
Move iterator to first position if any (loop initialization).
Implements vtkGenericCellIterator.
| int vtkBridgeCellIteratorOnCellList::IsAtEnd | ( | ) | [virtual] |
Is there no cell at iterator position? (exit condition).
Implements vtkGenericCellIterator.
| void vtkBridgeCellIteratorOnCellList::GetCell | ( | vtkGenericAdaptorCell * | c | ) | [virtual] |
Cell at current position
- Precondition:
- not_at_end: !IsAtEnd()
c_exists: c!=0 THREAD SAFE
Implements vtkGenericCellIterator.
| vtkGenericAdaptorCell* vtkBridgeCellIteratorOnCellList::GetCell | ( | ) | [virtual] |
Cell at current position. NOT THREAD SAFE
- Precondition:
- not_at_end: !IsAtEnd()
- Postcondition:
- result_exits: result!=0
Implements vtkGenericCellIterator.
| void vtkBridgeCellIteratorOnCellList::Next | ( | ) | [virtual] |
Move iterator to next position. (loop progression).
- Precondition:
- not_at_end: !IsAtEnd()
Implements vtkGenericCellIterator.
| void vtkBridgeCellIteratorOnCellList::InitWithCells | ( | vtkIdList * | cells, | |
| vtkBridgeDataSet * | ds | |||
| ) |
Used internally by vtkBridgeCell. Iterate on neighbors defined by `cells' over the dataset `ds'.
- Precondition:
- cells_exist: cells!=0
ds_exists: ds!=0
Member Data Documentation
vtkIdList* vtkBridgeCellIteratorOnCellList::Cells [protected] |
Definition at line 73 of file vtkBridgeCellIteratorOnCellList.h.
vtkBridgeDataSet* vtkBridgeCellIteratorOnCellList::DataSet [protected] |
Definition at line 74 of file vtkBridgeCellIteratorOnCellList.h.
vtkIdType vtkBridgeCellIteratorOnCellList::Id [protected] |
Definition at line 75 of file vtkBridgeCellIteratorOnCellList.h.
vtkBridgeCell* vtkBridgeCellIteratorOnCellList::Cell [protected] |
Definition at line 76 of file vtkBridgeCellIteratorOnCellList.h.
The documentation for this class was generated from the following file:
- dox/GenericFiltering/Testing/Cxx/vtkBridgeCellIteratorOnCellList.h
