vtkChartParallelCoordinates Class Reference
#include <vtkChartParallelCoordinates.h>
Detailed Description
Factory class for drawing 2D charts.This defines the interface for a parallel coordinates chart.
Definition at line 36 of file vtkChartParallelCoordinates.h.
Member Typedef Documentation
Constructor & Destructor Documentation
| vtkChartParallelCoordinates::vtkChartParallelCoordinates | ( | ) | [protected] |
| vtkChartParallelCoordinates::~vtkChartParallelCoordinates | ( | ) | [protected] |
Member Function Documentation
| virtual const char* vtkChartParallelCoordinates::GetClassName | ( | ) | [virtual] |
Reimplemented from vtkChart.
| static int vtkChartParallelCoordinates::IsTypeOf | ( | const char * | name | ) | [static] |
Return 1 if this class type is the same type of (or a subclass of) the named class. Returns 0 otherwise. This method works in combination with vtkTypeMacro found in vtkSetGet.h.
Reimplemented from vtkChart.
| virtual int vtkChartParallelCoordinates::IsA | ( | const char * | name | ) | [virtual] |
Return 1 if this class is the same type of (or a subclass of) the named class. Returns 0 otherwise. This method works in combination with vtkTypeMacro found in vtkSetGet.h.
Reimplemented from vtkChart.
| static vtkChartParallelCoordinates* vtkChartParallelCoordinates::SafeDownCast | ( | vtkObject * | o | ) | [static] |
Reimplemented from vtkChart.
| virtual void vtkChartParallelCoordinates::PrintSelf | ( | ostream & | os, | |
| vtkIndent | indent | |||
| ) | [virtual] |
| static vtkChartParallelCoordinates* vtkChartParallelCoordinates::New | ( | ) | [static] |
Creates a parallel coordinates chart
Reimplemented from vtkObject.
| virtual void vtkChartParallelCoordinates::Update | ( | ) | [virtual] |
Perform any updates to the item that may be necessary before rendering. The scene should take care of calling this on all items before their Paint function is invoked.
Reimplemented from vtkAbstractContextItem.
| virtual bool vtkChartParallelCoordinates::Paint | ( | vtkContext2D * | painter | ) | [virtual] |
Paint event for the chart, called whenever the chart needs to be drawn
Implements vtkChart.
| void vtkChartParallelCoordinates::SetColumnVisibility | ( | const vtkStdString & | name, | |
| bool | visible | |||
| ) |
Set the visibility of the specified column.
| void vtkChartParallelCoordinates::SetColumnVisibilityAll | ( | bool | visible | ) |
Set the visibility of all columns (true will make them all visible, false will remove all visible columns).
| bool vtkChartParallelCoordinates::GetColumnVisibility | ( | const vtkStdString & | name | ) |
Get the visibility of the specified column.
| virtual vtkStringArray* vtkChartParallelCoordinates::GetVisibleColumns | ( | ) | [virtual] |
Get a list of the columns, and the order in which they are displayed.
Get the plot at the specified index, returns null if the index is invalid.
Reimplemented from vtkChart.
| virtual vtkIdType vtkChartParallelCoordinates::GetNumberOfPlots | ( | ) | [virtual] |
Get the number of plots the chart contains.
Reimplemented from vtkChart.
| virtual vtkAxis* vtkChartParallelCoordinates::GetAxis | ( | int | axisIndex | ) | [virtual] |
Get the axis specified by axisIndex.
Reimplemented from vtkChart.
| virtual vtkIdType vtkChartParallelCoordinates::GetNumberOfAxes | ( | ) | [virtual] |
Get the number of axes in the current chart.
Reimplemented from vtkChart.
| virtual void vtkChartParallelCoordinates::RecalculateBounds | ( | ) | [virtual] |
Request that the chart recalculates the range of its axes. Especially useful in applications after the parameters of plots have been modified.
Reimplemented from vtkChart.
| virtual void vtkChartParallelCoordinates::SetPlot | ( | vtkPlotParallelCoordinates * | plot | ) | [virtual] |
Set plot to use for the chart. Since this type of chart can only contain one plot, this will replace the previous plot.
| virtual bool vtkChartParallelCoordinates::Hit | ( | const vtkContextMouseEvent & | mouse | ) | [virtual] |
Return true if the supplied x, y coordinate is inside the item.
Reimplemented from vtkAbstractContextItem.
| virtual bool vtkChartParallelCoordinates::MouseEnterEvent | ( | const vtkContextMouseEvent & | mouse | ) | [virtual] |
Mouse enter event.
Reimplemented from vtkAbstractContextItem.
| virtual bool vtkChartParallelCoordinates::MouseMoveEvent | ( | const vtkContextMouseEvent & | mouse | ) | [virtual] |
Mouse move event.
Reimplemented from vtkAbstractContextItem.
| virtual bool vtkChartParallelCoordinates::MouseLeaveEvent | ( | const vtkContextMouseEvent & | mouse | ) | [virtual] |
Mouse leave event.
Reimplemented from vtkAbstractContextItem.
| virtual bool vtkChartParallelCoordinates::MouseButtonPressEvent | ( | const vtkContextMouseEvent & | mouse | ) | [virtual] |
Mouse button down event
Reimplemented from vtkAbstractContextItem.
| virtual bool vtkChartParallelCoordinates::MouseButtonReleaseEvent | ( | const vtkContextMouseEvent & | mouse | ) | [virtual] |
Mouse button release event.
Reimplemented from vtkAbstractContextItem.
| virtual bool vtkChartParallelCoordinates::MouseWheelEvent | ( | const vtkContextMouseEvent & | mouse, | |
| int | delta | |||
| ) | [virtual] |
Mouse wheel event, positive delta indicates forward movement of the wheel.
Reimplemented from vtkAbstractContextItem.
| void vtkChartParallelCoordinates::ResetSelection | ( | ) | [protected] |
| void vtkChartParallelCoordinates::UpdateGeometry | ( | ) | [protected] |
| void vtkChartParallelCoordinates::CalculatePlotTransform | ( | ) | [protected] |
| void vtkChartParallelCoordinates::SwapAxes | ( | int | a1, | |
| int | a2 | |||
| ) | [protected] |
Member Data Documentation
Private* vtkChartParallelCoordinates::Storage [protected] |
Definition at line 124 of file vtkChartParallelCoordinates.h.
bool vtkChartParallelCoordinates::GeometryValid [protected] |
Definition at line 128 of file vtkChartParallelCoordinates.h.
vtkIdTypeArray* vtkChartParallelCoordinates::Selection [protected] |
Selected indices for the table the plot is rendering
Definition at line 131 of file vtkChartParallelCoordinates.h.
A list of the visible columns in the chart.
Definition at line 134 of file vtkChartParallelCoordinates.h.
vtkTimeStamp vtkChartParallelCoordinates::BuildTime [protected] |
The point cache is marked dirty until it has been initialized.
Definition at line 137 of file vtkChartParallelCoordinates.h.
The documentation for this class was generated from the following file:
- dox/Charts/vtkChartParallelCoordinates.h
