vtkXMLWriter Class Reference
#include <vtkXMLWriter.h>
Detailed Description
Superclass for VTK's XML file writers.vtkXMLWriter provides methods implementing most of the functionality needed to write VTK XML file formats. Concrete subclasses provide actual writer implementations calling upon this functionality.
Definition at line 50 of file vtkXMLWriter.h.
Member Typedef Documentation
| typedef vtkAlgorithm vtkXMLWriter::Superclass |
Reimplemented from vtkAlgorithm.
Reimplemented in vtkXMLCompositeDataWriter, vtkXMLDataSetWriter, vtkXMLHierarchicalBoxDataWriter, vtkXMLHyperOctreeWriter, vtkXMLImageDataWriter, vtkXMLMultiBlockDataWriter, vtkXMLPDataSetWriter, vtkXMLPDataWriter, vtkXMLPImageDataWriter, vtkXMLPolyDataWriter, vtkXMLPPolyDataWriter, vtkXMLPRectilinearGridWriter, vtkXMLPStructuredDataWriter, vtkXMLPStructuredGridWriter, vtkXMLPUnstructuredDataWriter, vtkXMLPUnstructuredGridWriter, vtkXMLRectilinearGridWriter, vtkXMLStructuredDataWriter, vtkXMLStructuredGridWriter, vtkXMLUnstructuredDataWriter, vtkXMLUnstructuredGridWriter, vtkXMLPHierarchicalBoxDataWriter, and vtkXMLPMultiBlockDataWriter.
Definition at line 53 of file vtkXMLWriter.h.
| typedef vtkIdType vtkXMLWriter::OffsetType |
A type used for data sizes and offsets for stream i/o. Using vtkIdType should satisfy most users. This could be streamoff if it is deemed portable. It could also be split into OffsetType (streamoff) and PositionType (streampos).
Definition at line 69 of file vtkXMLWriter.h.
Member Enumeration Documentation
| anonymous enum |
Enumerate big and little endian byte order settings.
Definition at line 59 of file vtkXMLWriter.h.
| anonymous enum |
Enumerate the supported data modes. Ascii = Inline ascii data. Binary = Inline binary data (base64 encoded, possibly compressed). Appended = Appended binary data (possibly compressed and/or base64).
Definition at line 78 of file vtkXMLWriter.h.
| anonymous enum |
Enumerate the supported vtkIdType bit lengths. Int32 = File stores 32-bit values for vtkIdType. Int64 = File stores 64-bit values for vtkIdType.
Definition at line 87 of file vtkXMLWriter.h.
Constructor & Destructor Documentation
| vtkXMLWriter::vtkXMLWriter | ( | ) | [protected] |
| vtkXMLWriter::~vtkXMLWriter | ( | ) | [protected] |
Member Function Documentation
| virtual const char* vtkXMLWriter::GetClassName | ( | ) | [virtual] |
Reimplemented from vtkAlgorithm.
Reimplemented in vtkXMLCompositeDataWriter, vtkXMLDataSetWriter, vtkXMLHierarchicalBoxDataWriter, vtkXMLHyperOctreeWriter, vtkXMLImageDataWriter, vtkXMLMultiBlockDataWriter, vtkXMLPDataSetWriter, vtkXMLPDataWriter, vtkXMLPImageDataWriter, vtkXMLPolyDataWriter, vtkXMLPPolyDataWriter, vtkXMLPRectilinearGridWriter, vtkXMLPStructuredDataWriter, vtkXMLPStructuredGridWriter, vtkXMLPUnstructuredDataWriter, vtkXMLPUnstructuredGridWriter, vtkXMLRectilinearGridWriter, vtkXMLStructuredDataWriter, vtkXMLStructuredGridWriter, vtkXMLUnstructuredDataWriter, vtkXMLUnstructuredGridWriter, vtkXMLPHierarchicalBoxDataWriter, and vtkXMLPMultiBlockDataWriter.
| static int vtkXMLWriter::IsTypeOf | ( | const char * | name | ) | [static] |
Return 1 if this class type is the same type of (or a subclass of) the named class. Returns 0 otherwise. This method works in combination with vtkTypeMacro found in vtkSetGet.h.
Reimplemented from vtkAlgorithm.
Reimplemented in vtkXMLCompositeDataWriter, vtkXMLDataSetWriter, vtkXMLHierarchicalBoxDataWriter, vtkXMLHyperOctreeWriter, vtkXMLImageDataWriter, vtkXMLMultiBlockDataWriter, vtkXMLPDataSetWriter, vtkXMLPDataWriter, vtkXMLPImageDataWriter, vtkXMLPolyDataWriter, vtkXMLPPolyDataWriter, vtkXMLPRectilinearGridWriter, vtkXMLPStructuredDataWriter, vtkXMLPStructuredGridWriter, vtkXMLPUnstructuredDataWriter, vtkXMLPUnstructuredGridWriter, vtkXMLRectilinearGridWriter, vtkXMLStructuredDataWriter, vtkXMLStructuredGridWriter, vtkXMLUnstructuredDataWriter, vtkXMLUnstructuredGridWriter, vtkXMLPHierarchicalBoxDataWriter, and vtkXMLPMultiBlockDataWriter.
| virtual int vtkXMLWriter::IsA | ( | const char * | name | ) | [virtual] |
Return 1 if this class is the same type of (or a subclass of) the named class. Returns 0 otherwise. This method works in combination with vtkTypeMacro found in vtkSetGet.h.
Reimplemented from vtkAlgorithm.
Reimplemented in vtkXMLCompositeDataWriter, vtkXMLDataSetWriter, vtkXMLHierarchicalBoxDataWriter, vtkXMLHyperOctreeWriter, vtkXMLImageDataWriter, vtkXMLMultiBlockDataWriter, vtkXMLPDataSetWriter, vtkXMLPDataWriter, vtkXMLPImageDataWriter, vtkXMLPolyDataWriter, vtkXMLPPolyDataWriter, vtkXMLPRectilinearGridWriter, vtkXMLPStructuredDataWriter, vtkXMLPStructuredGridWriter, vtkXMLPUnstructuredDataWriter, vtkXMLPUnstructuredGridWriter, vtkXMLRectilinearGridWriter, vtkXMLStructuredDataWriter, vtkXMLStructuredGridWriter, vtkXMLUnstructuredDataWriter, vtkXMLUnstructuredGridWriter, vtkXMLPHierarchicalBoxDataWriter, and vtkXMLPMultiBlockDataWriter.
| static vtkXMLWriter* vtkXMLWriter::SafeDownCast | ( | vtkObject * | o | ) | [static] |
Reimplemented from vtkAlgorithm.
Reimplemented in vtkXMLCompositeDataWriter, vtkXMLDataSetWriter, vtkXMLHierarchicalBoxDataWriter, vtkXMLHyperOctreeWriter, vtkXMLImageDataWriter, vtkXMLMultiBlockDataWriter, vtkXMLPDataSetWriter, vtkXMLPDataWriter, vtkXMLPImageDataWriter, vtkXMLPolyDataWriter, vtkXMLPPolyDataWriter, vtkXMLPRectilinearGridWriter, vtkXMLPStructuredDataWriter, vtkXMLPStructuredGridWriter, vtkXMLPUnstructuredDataWriter, vtkXMLPUnstructuredGridWriter, vtkXMLRectilinearGridWriter, vtkXMLStructuredDataWriter, vtkXMLStructuredGridWriter, vtkXMLUnstructuredDataWriter, vtkXMLUnstructuredGridWriter, vtkXMLPHierarchicalBoxDataWriter, and vtkXMLPMultiBlockDataWriter.
| void vtkXMLWriter::PrintSelf | ( | ostream & | os, | |
| vtkIndent | indent | |||
| ) | [virtual] |
Methods invoked by print to print information about the object including superclasses. Typically not called by the user (use Print() instead) but used in the hierarchical print process to combine the output of several classes.
Reimplemented from vtkAlgorithm.
Reimplemented in vtkXMLCompositeDataWriter, vtkXMLDataSetWriter, vtkXMLHierarchicalBoxDataWriter, vtkXMLHyperOctreeWriter, vtkXMLImageDataWriter, vtkXMLMultiBlockDataWriter, vtkXMLPDataSetWriter, vtkXMLPDataWriter, vtkXMLPImageDataWriter, vtkXMLPolyDataWriter, vtkXMLPPolyDataWriter, vtkXMLPRectilinearGridWriter, vtkXMLPStructuredDataWriter, vtkXMLPStructuredGridWriter, vtkXMLPUnstructuredDataWriter, vtkXMLPUnstructuredGridWriter, vtkXMLRectilinearGridWriter, vtkXMLStructuredDataWriter, vtkXMLStructuredGridWriter, vtkXMLUnstructuredDataWriter, vtkXMLUnstructuredGridWriter, vtkXMLPHierarchicalBoxDataWriter, and vtkXMLPMultiBlockDataWriter.
| virtual void vtkXMLWriter::SetByteOrder | ( | int | ) | [virtual] |
Get/Set the byte order of data written to the file. The default is the machine's hardware byte order.
| virtual int vtkXMLWriter::GetByteOrder | ( | ) | [virtual] |
Get/Set the byte order of data written to the file. The default is the machine's hardware byte order.
| void vtkXMLWriter::SetByteOrderToBigEndian | ( | ) |
Get/Set the byte order of data written to the file. The default is the machine's hardware byte order.
| void vtkXMLWriter::SetByteOrderToLittleEndian | ( | ) |
Get/Set the byte order of data written to the file. The default is the machine's hardware byte order.
| virtual void vtkXMLWriter::SetIdType | ( | int | ) | [virtual] |
Get/Set the size of the vtkIdType values stored in the file. The default is the real size of vtkIdType.
| virtual int vtkXMLWriter::GetIdType | ( | ) | [virtual] |
Get/Set the size of the vtkIdType values stored in the file. The default is the real size of vtkIdType.
| void vtkXMLWriter::SetIdTypeToInt32 | ( | ) |
Get/Set the size of the vtkIdType values stored in the file. The default is the real size of vtkIdType.
| void vtkXMLWriter::SetIdTypeToInt64 | ( | ) |
Get/Set the size of the vtkIdType values stored in the file. The default is the real size of vtkIdType.
| virtual void vtkXMLWriter::SetFileName | ( | const char * | ) | [virtual] |
Get/Set the name of the output file.
| virtual char* vtkXMLWriter::GetFileName | ( | ) | [virtual] |
Get/Set the name of the output file.
| virtual void vtkXMLWriter::SetCompressor | ( | vtkDataCompressor * | ) | [virtual] |
Get/Set the compressor used to compress binary and appended data before writing to the file. Default is a vtkZLibDataCompressor.
| virtual vtkDataCompressor* vtkXMLWriter::GetCompressor | ( | ) | [virtual] |
Get/Set the compressor used to compress binary and appended data before writing to the file. Default is a vtkZLibDataCompressor.
| void vtkXMLWriter::SetCompressorType | ( | int | compressorType | ) |
Convenience functions to set the compressor to certain known types.
| void vtkXMLWriter::SetCompressorTypeToNone | ( | ) | [inline] |
Convenience functions to set the compressor to certain known types.
Definition at line 133 of file vtkXMLWriter.h.
| void vtkXMLWriter::SetCompressorTypeToZLib | ( | ) | [inline] |
Convenience functions to set the compressor to certain known types.
Definition at line 137 of file vtkXMLWriter.h.
| virtual void vtkXMLWriter::SetBlockSize | ( | unsigned int | blockSize | ) | [virtual] |
Get/Set the block size used in compression. When reading, this controls the granularity of how much extra information must be read when only part of the data are requested. The value should be a multiple of the largest scalar data type.
| virtual unsigned int vtkXMLWriter::GetBlockSize | ( | ) | [virtual] |
Get/Set the block size used in compression. When reading, this controls the granularity of how much extra information must be read when only part of the data are requested. The value should be a multiple of the largest scalar data type.
| virtual void vtkXMLWriter::SetDataMode | ( | int | ) | [virtual] |
Get/Set the data mode used for the file's data. The options are vtkXMLWriter::Ascii, vtkXMLWriter::Binary, and vtkXMLWriter::Appended.
| virtual int vtkXMLWriter::GetDataMode | ( | ) | [virtual] |
Get/Set the data mode used for the file's data. The options are vtkXMLWriter::Ascii, vtkXMLWriter::Binary, and vtkXMLWriter::Appended.
| void vtkXMLWriter::SetDataModeToAscii | ( | ) |
Get/Set the data mode used for the file's data. The options are vtkXMLWriter::Ascii, vtkXMLWriter::Binary, and vtkXMLWriter::Appended.
| void vtkXMLWriter::SetDataModeToBinary | ( | ) |
Get/Set the data mode used for the file's data. The options are vtkXMLWriter::Ascii, vtkXMLWriter::Binary, and vtkXMLWriter::Appended.
| void vtkXMLWriter::SetDataModeToAppended | ( | ) |
Get/Set the data mode used for the file's data. The options are vtkXMLWriter::Ascii, vtkXMLWriter::Binary, and vtkXMLWriter::Appended.
| virtual void vtkXMLWriter::SetEncodeAppendedData | ( | int | ) | [virtual] |
Get/Set whether the appended data section is base64 encoded. If encoded, reading and writing will be slower, but the file will be fully valid XML and text-only. If not encoded, the XML specification will be violated, but reading and writing will be fast. The default is to do the encoding.
| virtual int vtkXMLWriter::GetEncodeAppendedData | ( | ) | [virtual] |
Get/Set whether the appended data section is base64 encoded. If encoded, reading and writing will be slower, but the file will be fully valid XML and text-only. If not encoded, the XML specification will be violated, but reading and writing will be fast. The default is to do the encoding.
| virtual void vtkXMLWriter::EncodeAppendedDataOn | ( | ) | [virtual] |
Get/Set whether the appended data section is base64 encoded. If encoded, reading and writing will be slower, but the file will be fully valid XML and text-only. If not encoded, the XML specification will be violated, but reading and writing will be fast. The default is to do the encoding.
| virtual void vtkXMLWriter::EncodeAppendedDataOff | ( | ) | [virtual] |
Get/Set whether the appended data section is base64 encoded. If encoded, reading and writing will be slower, but the file will be fully valid XML and text-only. If not encoded, the XML specification will be violated, but reading and writing will be fast. The default is to do the encoding.
| void vtkXMLWriter::SetInput | ( | vtkDataObject * | ) |
Set/Get an input of this algorithm. You should not override these methods because they are not the only way to connect a pipeline
| void vtkXMLWriter::SetInput | ( | int | , | |
| vtkDataObject * | ||||
| ) |
Set/Get an input of this algorithm. You should not override these methods because they are not the only way to connect a pipeline
| vtkDataObject* vtkXMLWriter::GetInput | ( | int | port | ) |
Set/Get an input of this algorithm. You should not override these methods because they are not the only way to connect a pipeline
| vtkDataObject* vtkXMLWriter::GetInput | ( | ) | [inline] |
Set/Get an input of this algorithm. You should not override these methods because they are not the only way to connect a pipeline
Reimplemented in vtkXMLDataSetWriter, vtkXMLHyperOctreeWriter, vtkXMLImageDataWriter, vtkXMLPDataSetWriter, vtkXMLPImageDataWriter, vtkXMLPolyDataWriter, vtkXMLPPolyDataWriter, vtkXMLPRectilinearGridWriter, vtkXMLPStructuredGridWriter, vtkXMLPUnstructuredGridWriter, vtkXMLRectilinearGridWriter, vtkXMLStructuredGridWriter, and vtkXMLUnstructuredGridWriter.
Definition at line 180 of file vtkXMLWriter.h.
| virtual const char* vtkXMLWriter::GetDefaultFileExtension | ( | ) | [pure virtual] |
Get the default file extension for files written by this writer.
Implemented in vtkXMLCompositeDataWriter, vtkXMLDataSetWriter, vtkXMLHierarchicalBoxDataWriter, vtkXMLHyperOctreeWriter, vtkXMLImageDataWriter, vtkXMLMultiBlockDataWriter, vtkXMLPDataSetWriter, vtkXMLPImageDataWriter, vtkXMLPolyDataWriter, vtkXMLPPolyDataWriter, vtkXMLPRectilinearGridWriter, vtkXMLPStructuredGridWriter, vtkXMLPUnstructuredGridWriter, vtkXMLRectilinearGridWriter, vtkXMLStructuredGridWriter, and vtkXMLUnstructuredGridWriter.
| int vtkXMLWriter::Write | ( | ) |
Invoke the writer. Returns 1 for success, 0 for failure.
| virtual int vtkXMLWriter::ProcessRequest | ( | vtkInformation * | request, | |
| vtkInformationVector ** | inInfo, | |||
| vtkInformationVector * | outInfo | |||
| ) | [virtual] |
Upstream/Downstream requests form the generalized interface through which executives invoke a algorithm's functionality. Upstream requests correspond to information flow from the algorithm's outputs to its inputs. Downstream requests correspond to information flow from the algorithm's inputs to its outputs. A downstream request is defined by the contents of the request information object. The input to the request is stored in the input information vector passed to ProcessRequest. The results of an downstream request are stored in the output information vector passed to ProcessRequest. An upstream request is defined by the contents of the request information object. The input to the request is stored in the output information vector passed to ProcessRequest. The results of an upstream request are stored in the input information vector passed to ProcessRequest. It returns the boolean status of the pipeline (false means failure).
Reimplemented from vtkAlgorithm.
Reimplemented in vtkXMLCompositeDataWriter, vtkXMLPUnstructuredDataWriter, vtkXMLStructuredDataWriter, and vtkXMLUnstructuredDataWriter.
| virtual void vtkXMLWriter::SetTimeStep | ( | int | ) | [virtual] |
Which TimeStep to write.
| virtual int vtkXMLWriter::GetTimeStep | ( | ) | [virtual] |
Which TimeStep to write.
| virtual int* vtkXMLWriter::GetTimeStepRange | ( | ) | [virtual] |
Which TimeStepRange to write.
| virtual void vtkXMLWriter::GetTimeStepRange | ( | int & | , | |
| int & | ||||
| ) | [virtual] |
Which TimeStepRange to write.
| virtual void vtkXMLWriter::GetTimeStepRange | ( | int | [2] | ) | [virtual] |
Which TimeStepRange to write.
| virtual void vtkXMLWriter::SetTimeStepRange | ( | int | , | |
| int | ||||
| ) | [virtual] |
Which TimeStepRange to write.
| void vtkXMLWriter::SetTimeStepRange | ( | int | [2] | ) |
Which TimeStepRange to write.
| virtual int vtkXMLWriter::GetNumberOfTimeSteps | ( | ) | [virtual] |
Set the number of time steps
| virtual void vtkXMLWriter::SetNumberOfTimeSteps | ( | int | ) | [virtual] |
Set the number of time steps
| void vtkXMLWriter::Start | ( | ) |
API to interface an outside the VTK pipeline control
| void vtkXMLWriter::Stop | ( | ) |
API to interface an outside the VTK pipeline control
| void vtkXMLWriter::WriteNextTime | ( | double | time | ) |
API to interface an outside the VTK pipeline control
| virtual int vtkXMLWriter::RequestInformation | ( | vtkInformation * | request, | |
| vtkInformationVector ** | inputVector, | |||
| vtkInformationVector * | outputVector | |||
| ) | [protected, virtual] |
| virtual int vtkXMLWriter::RequestData | ( | vtkInformation * | request, | |
| vtkInformationVector ** | inputVector, | |||
| vtkInformationVector * | outputVector | |||
| ) | [protected, virtual] |
Reimplemented in vtkXMLCompositeDataWriter.
| virtual void vtkXMLWriter::SetDataStream | ( | vtkOutputStream * | ) | [protected, virtual] |
| virtual vtkOutputStream* vtkXMLWriter::GetDataStream | ( | ) | [protected, virtual] |
| virtual int vtkXMLWriter::WriteInternal | ( | ) | [protected, virtual] |
Reimplemented in vtkXMLDataSetWriter, vtkXMLPDataSetWriter, and vtkXMLPDataWriter.
| virtual int vtkXMLWriter::WriteData | ( | ) | [inline, protected, virtual] |
Reimplemented in vtkXMLCompositeDataWriter, vtkXMLHyperOctreeWriter, and vtkXMLPDataWriter.
Definition at line 313 of file vtkXMLWriter.h.
| virtual const char* vtkXMLWriter::GetDataSetName | ( | ) | [protected, pure virtual] |
Implemented in vtkXMLCompositeDataWriter, vtkXMLDataSetWriter, vtkXMLHyperOctreeWriter, vtkXMLImageDataWriter, vtkXMLPDataSetWriter, vtkXMLPImageDataWriter, vtkXMLPolyDataWriter, vtkXMLPPolyDataWriter, vtkXMLPRectilinearGridWriter, vtkXMLPStructuredGridWriter, vtkXMLPUnstructuredGridWriter, vtkXMLRectilinearGridWriter, vtkXMLStructuredGridWriter, vtkXMLUnstructuredDataWriter, and vtkXMLUnstructuredGridWriter.
| virtual int vtkXMLWriter::GetDataSetMajorVersion | ( | ) | [protected, virtual] |
Reimplemented in vtkXMLCompositeDataWriter.
| virtual int vtkXMLWriter::GetDataSetMinorVersion | ( | ) | [protected, virtual] |
Reimplemented in vtkXMLCompositeDataWriter.
| vtkDataSet* vtkXMLWriter::GetInputAsDataSet | ( | ) | [protected] |
| int vtkXMLWriter::StartFile | ( | ) | [protected] |
| virtual void vtkXMLWriter::WriteFileAttributes | ( | ) | [protected, virtual] |
| int vtkXMLWriter::EndFile | ( | ) | [protected] |
| void vtkXMLWriter::DeleteAFile | ( | ) | [protected] |
| void vtkXMLWriter::DeleteAFile | ( | const char * | name | ) | [protected] |
| virtual int vtkXMLWriter::WritePrimaryElement | ( | ostream & | os, | |
| vtkIndent | indent | |||
| ) | [protected, virtual] |
| virtual void vtkXMLWriter::WritePrimaryElementAttributes | ( | ostream & | os, | |
| vtkIndent | indent | |||
| ) | [protected, virtual] |
| void vtkXMLWriter::StartAppendedData | ( | ) | [protected] |
| void vtkXMLWriter::EndAppendedData | ( | ) | [protected] |
| OffsetType vtkXMLWriter::ReserveAttributeSpace | ( | const char * | attr, | |
| int | length = 20 | |||
| ) | [protected] |
| OffsetType vtkXMLWriter::GetAppendedDataOffset | ( | ) | [protected] |
| OffsetType vtkXMLWriter::WriteAppendedDataOffset | ( | OffsetType | streamPos, | |
| OffsetType & | lastoffset, | |||
| const char * | attr = 0 | |||
| ) | [protected] |
| OffsetType vtkXMLWriter::ForwardAppendedDataOffset | ( | OffsetType | streamPos, | |
| OffsetType | offset, | |||
| const char * | attr = 0 | |||
| ) | [protected] |
| OffsetType vtkXMLWriter::ForwardAppendedDataDouble | ( | OffsetType | streamPos, | |
| double | value, | |||
| const char * | attr | |||
| ) | [protected] |
| int vtkXMLWriter::WriteScalarAttribute | ( | const char * | name, | |
| int | data | |||
| ) | [protected] |
| int vtkXMLWriter::WriteScalarAttribute | ( | const char * | name, | |
| float | data | |||
| ) | [protected] |
| int vtkXMLWriter::WriteScalarAttribute | ( | const char * | name, | |
| double | data | |||
| ) | [protected] |
| int vtkXMLWriter::WriteVectorAttribute | ( | const char * | name, | |
| int | length, | |||
| int * | data | |||
| ) | [protected] |
| int vtkXMLWriter::WriteVectorAttribute | ( | const char * | name, | |
| int | length, | |||
| float * | data | |||
| ) | [protected] |
| int vtkXMLWriter::WriteVectorAttribute | ( | const char * | name, | |
| int | length, | |||
| double * | data | |||
| ) | [protected] |
| int vtkXMLWriter::WriteDataModeAttribute | ( | const char * | name | ) | [protected] |
| int vtkXMLWriter::WriteWordTypeAttribute | ( | const char * | name, | |
| int | dataType | |||
| ) | [protected] |
| int vtkXMLWriter::WriteStringAttribute | ( | const char * | name, | |
| const char * | value | |||
| ) | [protected] |
| void vtkXMLWriter::WriteArrayHeader | ( | vtkAbstractArray * | a, | |
| vtkIndent | indent, | |||
| const char * | alternateName, | |||
| int | writeNumTuples, | |||
| int | timestep | |||
| ) | [protected] |
| void vtkXMLWriter::WriteArrayFooter | ( | ostream & | os, | |
| vtkIndent | indent, | |||
| vtkAbstractArray * | a, | |||
| int | shortFormat | |||
| ) | [protected] |
| void vtkXMLWriter::WriteArrayInline | ( | vtkAbstractArray * | a, | |
| vtkIndent | indent, | |||
| const char * | alternateName = 0, |
|||
| int | writeNumTuples = 0 | |||
| ) | [protected] |
| void vtkXMLWriter::WriteInlineData | ( | vtkAbstractArray * | a, | |
| vtkIndent | indent | |||
| ) | [protected] |
| void vtkXMLWriter::WriteArrayAppended | ( | vtkAbstractArray * | a, | |
| vtkIndent | indent, | |||
| OffsetsManager & | offs, | |||
| const char * | alternateName = 0, |
|||
| int | writeNumTuples = 0, |
|||
| int | timestep = 0 | |||
| ) | [protected] |
| int vtkXMLWriter::WriteAsciiData | ( | vtkAbstractArray * | a, | |
| vtkIndent | indent | |||
| ) | [protected] |
| int vtkXMLWriter::WriteBinaryData | ( | vtkAbstractArray * | a | ) | [protected] |
| int vtkXMLWriter::WriteBinaryDataInternal | ( | vtkAbstractArray * | a, | |
| OffsetType | data_size | |||
| ) | [protected] |
| void vtkXMLWriter::WriteArrayAppendedData | ( | vtkAbstractArray * | a, | |
| OffsetType | pos, | |||
| OffsetType & | lastoffset | |||
| ) | [protected] |
| void vtkXMLWriter::WriteFieldData | ( | vtkIndent | indent | ) | [protected] |
| void vtkXMLWriter::WriteFieldDataInline | ( | vtkFieldData * | fd, | |
| vtkIndent | indent | |||
| ) | [protected] |
| void vtkXMLWriter::WritePointDataInline | ( | vtkPointData * | pd, | |
| vtkIndent | indent | |||
| ) | [protected] |
| void vtkXMLWriter::WriteCellDataInline | ( | vtkCellData * | cd, | |
| vtkIndent | indent | |||
| ) | [protected] |
| void vtkXMLWriter::WriteFieldDataAppended | ( | vtkFieldData * | fd, | |
| vtkIndent | indent, | |||
| OffsetsManagerGroup * | fdManager | |||
| ) | [protected] |
| void vtkXMLWriter::WriteFieldDataAppendedData | ( | vtkFieldData * | fd, | |
| int | timestep, | |||
| OffsetsManagerGroup * | fdManager | |||
| ) | [protected] |
| void vtkXMLWriter::WritePointDataAppended | ( | vtkPointData * | pd, | |
| vtkIndent | indent, | |||
| OffsetsManagerGroup * | pdManager | |||
| ) | [protected] |
| void vtkXMLWriter::WritePointDataAppendedData | ( | vtkPointData * | pd, | |
| int | timestep, | |||
| OffsetsManagerGroup * | pdManager | |||
| ) | [protected] |
| void vtkXMLWriter::WriteCellDataAppended | ( | vtkCellData * | cd, | |
| vtkIndent | indent, | |||
| OffsetsManagerGroup * | cdManager | |||
| ) | [protected] |
| void vtkXMLWriter::WriteCellDataAppendedData | ( | vtkCellData * | cd, | |
| int | timestep, | |||
| OffsetsManagerGroup * | cdManager | |||
| ) | [protected] |
| void vtkXMLWriter::WriteAttributeIndices | ( | vtkDataSetAttributes * | dsa, | |
| char ** | names | |||
| ) | [protected] |
| void vtkXMLWriter::WritePointsAppended | ( | vtkPoints * | points, | |
| vtkIndent | indent, | |||
| OffsetsManager * | manager | |||
| ) | [protected] |
| void vtkXMLWriter::WritePointsAppendedData | ( | vtkPoints * | points, | |
| int | timestep, | |||
| OffsetsManager * | pdManager | |||
| ) | [protected] |
| void vtkXMLWriter::WriteCoordinatesInline | ( | vtkDataArray * | xc, | |
| vtkDataArray * | yc, | |||
| vtkDataArray * | zc, | |||
| vtkIndent | indent | |||
| ) | [protected] |
| void vtkXMLWriter::WriteCoordinatesAppended | ( | vtkDataArray * | xc, | |
| vtkDataArray * | yc, | |||
| vtkDataArray * | zc, | |||
| vtkIndent | indent, | |||
| OffsetsManagerGroup * | coordManager | |||
| ) | [protected] |
| void vtkXMLWriter::WriteCoordinatesAppendedData | ( | vtkDataArray * | xc, | |
| vtkDataArray * | yc, | |||
| vtkDataArray * | zc, | |||
| int | timestep, | |||
| OffsetsManagerGroup * | coordManager | |||
| ) | [protected] |
| virtual vtkAbstractArray* vtkXMLWriter::CreateArrayForPoints | ( | vtkAbstractArray * | inArray | ) | [protected, virtual] |
Reimplemented in vtkXMLStructuredDataWriter.
| virtual vtkAbstractArray* vtkXMLWriter::CreateArrayForCells | ( | vtkAbstractArray * | inArray | ) | [protected, virtual] |
Reimplemented in vtkXMLStructuredDataWriter.
| virtual vtkDataArray* vtkXMLWriter::CreateExactCoordinates | ( | vtkDataArray * | inArray, | |
| int | xyz | |||
| ) | [protected, virtual] |
Reimplemented in vtkXMLRectilinearGridWriter.
| void vtkXMLWriter::WritePPointData | ( | vtkPointData * | pd, | |
| vtkIndent | indent | |||
| ) | [protected] |
| void vtkXMLWriter::WritePCellData | ( | vtkCellData * | cd, | |
| vtkIndent | indent | |||
| ) | [protected] |
| void vtkXMLWriter::WritePArray | ( | vtkAbstractArray * | a, | |
| vtkIndent | indent, | |||
| const char * | alternateName = 0 | |||
| ) | [protected] |
| void vtkXMLWriter::WritePCoordinates | ( | vtkDataArray * | xc, | |
| vtkDataArray * | yc, | |||
| vtkDataArray * | zc, | |||
| vtkIndent | indent | |||
| ) | [protected] |
| int vtkXMLWriter::WriteBinaryDataInternal | ( | void * | data, | |
| OffsetType | numWords, | |||
| int | wordType | |||
| ) | [protected] |
| int vtkXMLWriter::WriteBinaryDataBlock | ( | unsigned char * | in_data, | |
| OffsetType | numWords, | |||
| int | wordType | |||
| ) | [protected] |
| void vtkXMLWriter::PerformByteSwap | ( | void * | data, | |
| OffsetType | numWords, | |||
| int | wordSize | |||
| ) | [protected] |
| int vtkXMLWriter::CreateCompressionHeader | ( | OffsetType | size | ) | [protected] |
| int vtkXMLWriter::WriteCompressionBlock | ( | unsigned char * | data, | |
| OffsetType | size | |||
| ) | [protected] |
| int vtkXMLWriter::WriteCompressionHeader | ( | ) | [protected] |
| OffsetType vtkXMLWriter::GetWordTypeSize | ( | int | dataType | ) | [protected] |
| const char* vtkXMLWriter::GetWordTypeName | ( | int | dataType | ) | [protected] |
| OffsetType vtkXMLWriter::GetOutputWordTypeSize | ( | int | dataType | ) | [protected] |
| char** vtkXMLWriter::CreateStringArray | ( | int | numStrings | ) | [protected] |
| void vtkXMLWriter::DestroyStringArray | ( | int | numStrings, | |
| char ** | strings | |||
| ) | [protected] |
| virtual void vtkXMLWriter::GetProgressRange | ( | float * | range | ) | [protected, virtual] |
| virtual void vtkXMLWriter::SetProgressRange | ( | float * | range, | |
| int | curStep, | |||
| int | numSteps | |||
| ) | [protected, virtual] |
| virtual void vtkXMLWriter::SetProgressRange | ( | float * | range, | |
| int | curStep, | |||
| float * | fractions | |||
| ) | [protected, virtual] |
| virtual void vtkXMLWriter::SetProgressPartial | ( | float | fraction | ) | [protected, virtual] |
| virtual void vtkXMLWriter::UpdateProgressDiscrete | ( | float | progress | ) | [protected, virtual] |
| int vtkXMLWriter::OpenFile | ( | ) | [protected] |
| void vtkXMLWriter::CloseFile | ( | ) | [protected] |
Friends And Related Function Documentation
friend class vtkXMLWriterHelper [friend] |
Definition at line 470 of file vtkXMLWriter.h.
Member Data Documentation
char* vtkXMLWriter::FileName [protected] |
Definition at line 232 of file vtkXMLWriter.h.
ostream* vtkXMLWriter::Stream [protected] |
Definition at line 235 of file vtkXMLWriter.h.
int vtkXMLWriter::ByteOrder [protected] |
Definition at line 238 of file vtkXMLWriter.h.
int vtkXMLWriter::IdType [protected] |
Definition at line 241 of file vtkXMLWriter.h.
int vtkXMLWriter::DataMode [protected] |
Definition at line 245 of file vtkXMLWriter.h.
int vtkXMLWriter::EncodeAppendedData [protected] |
Definition at line 248 of file vtkXMLWriter.h.
OffsetType vtkXMLWriter::AppendedDataPosition [protected] |
Definition at line 251 of file vtkXMLWriter.h.
OffsetsManagerGroup* vtkXMLWriter::FieldDataOM [protected] |
Definition at line 254 of file vtkXMLWriter.h.
Int32IdType* vtkXMLWriter::Int32IdTypeBuffer [protected] |
Definition at line 287 of file vtkXMLWriter.h.
unsigned char* vtkXMLWriter::ByteSwapBuffer [protected] |
Definition at line 290 of file vtkXMLWriter.h.
vtkDataCompressor* vtkXMLWriter::Compressor [protected] |
Definition at line 293 of file vtkXMLWriter.h.
unsigned int vtkXMLWriter::BlockSize [protected] |
Definition at line 294 of file vtkXMLWriter.h.
OffsetType vtkXMLWriter::CompressionBlockNumber [protected] |
Definition at line 295 of file vtkXMLWriter.h.
HeaderType* vtkXMLWriter::CompressionHeader [protected] |
Definition at line 296 of file vtkXMLWriter.h.
unsigned int vtkXMLWriter::CompressionHeaderLength [protected] |
Definition at line 297 of file vtkXMLWriter.h.
OffsetType vtkXMLWriter::CompressionHeaderPosition [protected] |
Definition at line 298 of file vtkXMLWriter.h.
vtkOutputStream* vtkXMLWriter::DataStream [protected] |
Definition at line 302 of file vtkXMLWriter.h.
float vtkXMLWriter::ProgressRange[2] [protected] |
Definition at line 450 of file vtkXMLWriter.h.
ofstream* vtkXMLWriter::OutFile [protected] |
Definition at line 452 of file vtkXMLWriter.h.
int vtkXMLWriter::TimeStep [protected] |
Definition at line 458 of file vtkXMLWriter.h.
int vtkXMLWriter::CurrentTimeIndex [protected] |
Definition at line 459 of file vtkXMLWriter.h.
int vtkXMLWriter::NumberOfTimeSteps [protected] |
Definition at line 460 of file vtkXMLWriter.h.
int vtkXMLWriter::TimeStepRange[2] [protected] |
Definition at line 462 of file vtkXMLWriter.h.
int vtkXMLWriter::UserContinueExecuting [protected] |
Definition at line 466 of file vtkXMLWriter.h.
unsigned long* vtkXMLWriter::NumberOfTimeValues [protected] |
Definition at line 468 of file vtkXMLWriter.h.
The documentation for this class was generated from the following file:
- dox/IO/vtkXMLWriter.h
