Return specified piece, including specified number of ghost levels. More...
#include <vtkTransmitPolyDataPiece.h>
Detailed Description
Return specified piece, including specified number of ghost levels.
This filter updates the appropriate piece by requesting the piece from process 0. Process 0 always updates all of the data. It is important that Execute get called on all processes, otherwise the filter will deadlock.
Definition at line 32 of file vtkTransmitPolyDataPiece.h.
Member Typedef Documentation
Reimplemented from vtkPolyDataAlgorithm.
Definition at line 36 of file vtkTransmitPolyDataPiece.h.
Constructor & Destructor Documentation
| vtkTransmitPolyDataPiece::vtkTransmitPolyDataPiece | ( | ) | [protected] |
| vtkTransmitPolyDataPiece::~vtkTransmitPolyDataPiece | ( | ) | [protected] |
Member Function Documentation
| static vtkTransmitPolyDataPiece* vtkTransmitPolyDataPiece::New | ( | ) | [static] |
Create an object with Debug turned off, modified time initialized to zero, and reference counting on.
Reimplemented from vtkPolyDataAlgorithm.
| static int vtkTransmitPolyDataPiece::IsTypeOf | ( | const char * | name | ) | [static] |
Return 1 if this class type is the same type of (or a subclass of) the named class. Returns 0 otherwise. This method works in combination with vtkTypeMacro found in vtkSetGet.h.
Reimplemented from vtkPolyDataAlgorithm.
| virtual int vtkTransmitPolyDataPiece::IsA | ( | const char * | name | ) | [virtual] |
Return 1 if this class is the same type of (or a subclass of) the named class. Returns 0 otherwise. This method works in combination with vtkTypeMacro found in vtkSetGet.h.
Reimplemented from vtkPolyDataAlgorithm.
| static vtkTransmitPolyDataPiece* vtkTransmitPolyDataPiece::SafeDownCast | ( | vtkObjectBase * | o | ) | [static] |
Reimplemented from vtkPolyDataAlgorithm.
| virtual vtkObjectBase* vtkTransmitPolyDataPiece::NewInstanceInternal | ( | ) | const [protected, virtual] |
Reimplemented from vtkPolyDataAlgorithm.
Reimplemented from vtkPolyDataAlgorithm.
| void vtkTransmitPolyDataPiece::PrintSelf | ( | ostream & | os, |
| vtkIndent | indent | ||
| ) | [virtual] |
Methods invoked by print to print information about the object including superclasses. Typically not called by the user (use Print() instead) but used in the hierarchical print process to combine the output of several classes.
Reimplemented from vtkPolyDataAlgorithm.
| virtual void vtkTransmitPolyDataPiece::SetController | ( | vtkMultiProcessController * | ) | [virtual] |
By defualt this filter uses the global controller, but this method can be used to set another instead.
| virtual vtkMultiProcessController* vtkTransmitPolyDataPiece::GetController | ( | ) | [virtual] |
By defualt this filter uses the global controller, but this method can be used to set another instead.
| virtual void vtkTransmitPolyDataPiece::SetCreateGhostCells | ( | int | ) | [virtual] |
Turn on/off creating ghost cells (on by default).
| virtual int vtkTransmitPolyDataPiece::GetCreateGhostCells | ( | ) | [virtual] |
Turn on/off creating ghost cells (on by default).
| virtual void vtkTransmitPolyDataPiece::CreateGhostCellsOn | ( | ) | [virtual] |
Turn on/off creating ghost cells (on by default).
| virtual void vtkTransmitPolyDataPiece::CreateGhostCellsOff | ( | ) | [virtual] |
Turn on/off creating ghost cells (on by default).
| int vtkTransmitPolyDataPiece::RequestData | ( | vtkInformation * | request, |
| vtkInformationVector ** | inputVector, | ||
| vtkInformationVector * | outputVector | ||
| ) | [protected, virtual] |
This is called by the superclass. This is the method you should override.
Reimplemented from vtkPolyDataAlgorithm.
| void vtkTransmitPolyDataPiece::RootExecute | ( | vtkPolyData * | input, |
| vtkPolyData * | output, | ||
| vtkInformation * | outInfo | ||
| ) | [protected] |
| void vtkTransmitPolyDataPiece::SatelliteExecute | ( | int | procId, |
| vtkPolyData * | output, | ||
| vtkInformation * | outInfo | ||
| ) | [protected] |
| int vtkTransmitPolyDataPiece::RequestInformation | ( | vtkInformation * | , |
| vtkInformationVector ** | , | ||
| vtkInformationVector * | |||
| ) | [protected, virtual] |
Reimplemented from vtkPolyDataAlgorithm.
| int vtkTransmitPolyDataPiece::RequestUpdateExtent | ( | vtkInformation * | , |
| vtkInformationVector ** | , | ||
| vtkInformationVector * | |||
| ) | [protected, virtual] |
This is called by the superclass. This is the method you should override.
Reimplemented from vtkPolyDataAlgorithm.
Member Data Documentation
int vtkTransmitPolyDataPiece::CreateGhostCells [protected] |
Definition at line 64 of file vtkTransmitPolyDataPiece.h.
Definition at line 65 of file vtkTransmitPolyDataPiece.h.
The documentation for this class was generated from the following file:
- dox/Filters/Parallel/vtkTransmitPolyDataPiece.h
