vtkCompositeDataProbeFilter Class Reference
#include <vtkCompositeDataProbeFilter.h>
Detailed Description
subclass of vtkProbeFilter which supports composite datasets in the input.vtkCompositeDataProbeFilter supports probing into multi-group datasets. It sequentially probes through each concrete dataset within the composite probing at only those locations at which there were no hits when probing earlier datasets. For Hierarchical datasets, this traversal through leaf datasets is done in reverse order of levels i.e. highest level first.
Definition at line 31 of file vtkCompositeDataProbeFilter.h.
Public Types | |
| typedef vtkProbeFilter | Superclass |
Public Member Functions | |
| virtual const char * | GetClassName () |
| virtual int | IsA (const char *type) |
| void | PrintSelf (ostream &os, vtkIndent indent) |
Static Public Member Functions | |
| static vtkCompositeDataProbeFilter * | New () |
| static int | IsTypeOf (const char *type) |
| static vtkCompositeDataProbeFilter * | SafeDownCast (vtkObject *o) |
Protected Member Functions | |
| vtkCompositeDataProbeFilter () | |
| ~vtkCompositeDataProbeFilter () | |
| virtual int | FillInputPortInformation (int port, vtkInformation *info) |
| virtual vtkExecutive * | CreateDefaultExecutive () |
| virtual int | RequestData (vtkInformation *, vtkInformationVector **, vtkInformationVector *) |
Member Typedef Documentation
Reimplemented from vtkProbeFilter.
Reimplemented in vtkPProbeFilter.
Definition at line 35 of file vtkCompositeDataProbeFilter.h.
Constructor & Destructor Documentation
| vtkCompositeDataProbeFilter::vtkCompositeDataProbeFilter | ( | ) | [protected] |
| vtkCompositeDataProbeFilter::~vtkCompositeDataProbeFilter | ( | ) | [protected] |
Member Function Documentation
| static vtkCompositeDataProbeFilter* vtkCompositeDataProbeFilter::New | ( | ) | [static] |
Create an object with Debug turned off, modified time initialized to zero, and reference counting on.
Reimplemented from vtkProbeFilter.
Reimplemented in vtkPProbeFilter.
| virtual const char* vtkCompositeDataProbeFilter::GetClassName | ( | ) | [virtual] |
| static int vtkCompositeDataProbeFilter::IsTypeOf | ( | const char * | name | ) | [static] |
Return 1 if this class type is the same type of (or a subclass of) the named class. Returns 0 otherwise. This method works in combination with vtkTypeRevisionMacro found in vtkSetGet.h.
Reimplemented from vtkProbeFilter.
Reimplemented in vtkPProbeFilter.
| virtual int vtkCompositeDataProbeFilter::IsA | ( | const char * | name | ) | [virtual] |
Return 1 if this class is the same type of (or a subclass of) the named class. Returns 0 otherwise. This method works in combination with vtkTypeRevisionMacro found in vtkSetGet.h.
Reimplemented from vtkProbeFilter.
Reimplemented in vtkPProbeFilter.
| static vtkCompositeDataProbeFilter* vtkCompositeDataProbeFilter::SafeDownCast | ( | vtkObject * | o | ) | [static] |
| void vtkCompositeDataProbeFilter::PrintSelf | ( | ostream & | os, | |
| vtkIndent | indent | |||
| ) | [virtual] |
Methods invoked by print to print information about the object including superclasses. Typically not called by the user (use Print() instead) but used in the hierarchical print process to combine the output of several classes.
Reimplemented from vtkProbeFilter.
Reimplemented in vtkPProbeFilter.
| virtual int vtkCompositeDataProbeFilter::FillInputPortInformation | ( | int | port, | |
| vtkInformation * | info | |||
| ) | [protected, virtual] |
Change input information to accept composite datasets as the input which is probed into.
Reimplemented from vtkDataSetAlgorithm.
Reimplemented in vtkPProbeFilter.
| virtual int vtkCompositeDataProbeFilter::RequestData | ( | vtkInformation * | , | |
| vtkInformationVector ** | , | |||
| vtkInformationVector * | ||||
| ) | [protected, virtual] |
| virtual vtkExecutive* vtkCompositeDataProbeFilter::CreateDefaultExecutive | ( | ) | [protected, virtual] |
Create a default executive.
Reimplemented from vtkAlgorithm.
The documentation for this class was generated from the following file:
- dox/Graphics/vtkCompositeDataProbeFilter.h
