vtkMultiProcessController Class Reference
#include <vtkMultiProcessController.h>
Detailed Description
Multiprocessing communication superclass.vtkMultiProcessController is used to control multiple processes in a distributed computing environment. It has methods for executing single/multiple method(s) on multiple processors, triggering registered callbacks (Remote Methods) (AddRMI(), TriggerRMI()) and communication. Please note that the communication is done using the communicator which is accessible to the user. Therefore it is possible to get the communicator with GetCommunicator() and use it to send and receive data. This is the encoured communication method. The internal (RMI) communications are done using a second internal communicator (called RMICommunicator).
- Examples:
- vtkMultiProcessController (Examples)
Definition at line 67 of file vtkMultiProcessController.h.
| vtkProcessFunctionType | SingleMethod |
| void * | SingleData |
| vtkProcessFunctionType | MultipleMethod [MAX_PROCESSES] |
| void * | MultipleData [MAX_PROCESSES] |
| vtkCollection * | RMIs |
| int | BreakFlag |
| int | ForceDeepCopy |
| vtkOutputWindow * | OutputWindow |
| vtkCommunicator * | Communicator |
| vtkCommunicator * | RMICommunicator |
| int | Send (const int *data, vtkIdType length, int remoteProcessId, int tag) |
| int | Send (const unsigned long *data, vtkIdType length, int remoteProcessId, int tag) |
| int | Send (const char *data, vtkIdType length, int remoteProcessId, int tag) |
| int | Send (const unsigned char *data, vtkIdType length, int remoteProcessId, int tag) |
| int | Send (const float *data, vtkIdType length, int remoteProcessId, int tag) |
| int | Send (const double *data, vtkIdType length, int remoteProcessId, int tag) |
| int | Send (vtkDataObject *data, int remoteId, int tag) |
| int | Send (vtkDataArray *data, int remoteId, int tag) |
| int | Receive (int *data, vtkIdType length, int remoteProcessId, int tag) |
| int | Receive (unsigned long *data, vtkIdType length, int remoteProcessId, int tag) |
| int | Receive (char *data, vtkIdType length, int remoteProcessId, int tag) |
| int | Receive (unsigned char *data, vtkIdType length, int remoteProcessId, int tag) |
| int | Receive (float *data, vtkIdType length, int remoteProcessId, int tag) |
| int | Receive (double *data, vtkIdType length, int remoteProcessId, int tag) |
| int | Receive (vtkDataObject *data, int remoteId, int tag) |
| int | Receive (vtkDataArray *data, int remoteId, int tag) |
| vtkDataObject * | ReceiveDataObject (int remoteId, int tag) |
| int | Broadcast (int *data, vtkIdType length, int srcProcessId) |
| int | Broadcast (unsigned long *data, vtkIdType length, int srcProcessId) |
| int | Broadcast (unsigned char *data, vtkIdType length, int srcProcessId) |
| int | Broadcast (char *data, vtkIdType length, int srcProcessId) |
| int | Broadcast (float *data, vtkIdType length, int srcProcessId) |
| int | Broadcast (double *data, vtkIdType length, int srcProcessId) |
| int | Broadcast (vtkDataObject *data, int srcProcessId) |
| int | Broadcast (vtkDataArray *data, int srcProcessId) |
| int | Gather (const int *sendBuffer, int *recvBuffer, vtkIdType length, int destProcessId) |
| int | Gather (const unsigned long *sendBuffer, unsigned long *recvBuffer, vtkIdType length, int destProcessId) |
| int | Gather (const unsigned char *sendBuffer, unsigned char *recvBuffer, vtkIdType length, int destProcessId) |
| int | Gather (const char *sendBuffer, char *recvBuffer, vtkIdType length, int destProcessId) |
| int | Gather (const float *sendBuffer, float *recvBuffer, vtkIdType length, int destProcessId) |
| int | Gather (const double *sendBuffer, double *recvBuffer, vtkIdType length, int destProcessId) |
| int | Gather (vtkDataArray *sendBuffer, vtkDataArray *recvBuffer, int destProcessId) |
| int | GatherV (const int *sendBuffer, int *recvBuffer, vtkIdType sendLength, vtkIdType *recvLengths, vtkIdType *offsets, int destProcessId) |
| int | GatherV (const unsigned long *sendBuffer, unsigned long *recvBuffer, vtkIdType sendLength, vtkIdType *recvLengths, vtkIdType *offsets, int destProcessId) |
| int | GatherV (const unsigned char *sendBuffer, unsigned char *recvBuffer, vtkIdType sendLength, vtkIdType *recvLengths, vtkIdType *offsets, int destProcessId) |
| int | GatherV (const char *sendBuffer, char *recvBuffer, vtkIdType sendLength, vtkIdType *recvLengths, vtkIdType *offsets, int destProcessId) |
| int | GatherV (const float *sendBuffer, float *recvBuffer, vtkIdType sendLength, vtkIdType *recvLengths, vtkIdType *offsets, int destProcessId) |
| int | GatherV (const double *sendBuffer, double *recvBuffer, vtkIdType sendLength, vtkIdType *recvLengths, vtkIdType *offsets, int destProcessId) |
| int | Scatter (const int *sendBuffer, int *recvBuffer, vtkIdType length, int srcProcessId) |
| int | Scatter (const unsigned long *sendBuffer, unsigned long *recvBuffer, vtkIdType length, int srcProcessId) |
| int | Scatter (const unsigned char *sendBuffer, unsigned char *recvBuffer, vtkIdType length, int srcProcessId) |
| int | Scatter (const char *sendBuffer, char *recvBuffer, vtkIdType length, int srcProcessId) |
| int | Scatter (const float *sendBuffer, float *recvBuffer, vtkIdType length, int srcProcessId) |
| int | Scatter (const double *sendBuffer, double *recvBuffer, vtkIdType length, int srcProcessId) |
| int | Scatter (vtkDataArray *sendBuffer, vtkDataArray *recvBuffer, int srcProcessId) |
| int | ScatterV (const int *sendBuffer, int *recvBuffer, vtkIdType *sendLengths, vtkIdType *offsets, vtkIdType recvLength, int srcProcessId) |
| int | ScatterV (const unsigned long *sendBuffer, unsigned long *recvBuffer, vtkIdType *sendLengths, vtkIdType *offsets, vtkIdType recvLength, int srcProcessId) |
| int | ScatterV (const unsigned char *sendBuffer, unsigned char *recvBuffer, vtkIdType *sendLengths, vtkIdType *offsets, vtkIdType recvLength, int srcProcessId) |
| int | ScatterV (const char *sendBuffer, char *recvBuffer, vtkIdType *sendLengths, vtkIdType *offsets, vtkIdType recvLength, int srcProcessId) |
| int | ScatterV (const float *sendBuffer, float *recvBuffer, vtkIdType *sendLengths, vtkIdType *offsets, vtkIdType recvLength, int srcProcessId) |
| int | ScatterV (const double *sendBuffer, double *recvBuffer, vtkIdType *sendLengths, vtkIdType *offsets, vtkIdType recvLength, int srcProcessId) |
| int | AllGather (const int *sendBuffer, int *recvBuffer, vtkIdType length) |
| int | AllGather (const unsigned long *sendBuffer, unsigned long *recvBuffer, vtkIdType length) |
| int | AllGather (const unsigned char *sendBuffer, unsigned char *recvBuffer, vtkIdType length) |
| int | AllGather (const char *sendBuffer, char *recvBuffer, vtkIdType length) |
| int | AllGather (const float *sendBuffer, float *recvBuffer, vtkIdType length) |
| int | AllGather (const double *sendBuffer, double *recvBuffer, vtkIdType length) |
| int | AllGather (vtkDataArray *sendBuffer, vtkDataArray *recvBuffer) |
| int | AllGatherV (const int *sendBuffer, int *recvBuffer, vtkIdType sendLength, vtkIdType *recvLengths, vtkIdType *offsets) |
| int | AllGatherV (const unsigned long *sendBuffer, unsigned long *recvBuffer, vtkIdType sendLength, vtkIdType *recvLengths, vtkIdType *offsets) |
| int | AllGatherV (const unsigned char *sendBuffer, unsigned char *recvBuffer, vtkIdType sendLength, vtkIdType *recvLengths, vtkIdType *offsets) |
| int | AllGatherV (const char *sendBuffer, char *recvBuffer, vtkIdType sendLength, vtkIdType *recvLengths, vtkIdType *offsets) |
| int | AllGatherV (const float *sendBuffer, float *recvBuffer, vtkIdType sendLength, vtkIdType *recvLengths, vtkIdType *offsets) |
| int | AllGatherV (const double *sendBuffer, double *recvBuffer, vtkIdType sendLength, vtkIdType *recvLengths, vtkIdType *offsets) |
| int | Reduce (const int *sendBuffer, int *recvBuffer, vtkIdType length, int operation, int destProcessId) |
| int | Reduce (const unsigned long *sendBuffer, unsigned long *recvBuffer, vtkIdType length, int operation, int destProcessId) |
| int | Reduce (const unsigned char *sendBuffer, unsigned char *recvBuffer, vtkIdType length, int operation, int destProcessId) |
| int | Reduce (const char *sendBuffer, char *recvBuffer, vtkIdType length, int operation, int destProcessId) |
| int | Reduce (const float *sendBuffer, float *recvBuffer, vtkIdType length, int operation, int destProcessId) |
| int | Reduce (const double *sendBuffer, double *recvBuffer, vtkIdType length, int operation, int destProcessId) |
| int | Reduce (vtkDataArray *sendBuffer, vtkDataArray *recvBuffer, int operation, int destProcessId) |
| int | Reduce (const int *sendBuffer, int *recvBuffer, vtkIdType length, vtkCommunicator::Operation *operation, int destProcessId) |
| int | Reduce (const unsigned long *sendBuffer, unsigned long *recvBuffer, vtkIdType length, vtkCommunicator::Operation *operation, int destProcessId) |
| int | Reduce (const unsigned char *sendBuffer, unsigned char *recvBuffer, vtkIdType length, vtkCommunicator::Operation *operation, int destProcessId) |
| int | Reduce (const char *sendBuffer, char *recvBuffer, vtkIdType length, vtkCommunicator::Operation *operation, int destProcessId) |
| int | Reduce (const float *sendBuffer, float *recvBuffer, vtkIdType length, vtkCommunicator::Operation *operation, int destProcessId) |
| int | Reduce (const double *sendBuffer, double *recvBuffer, vtkIdType length, vtkCommunicator::Operation *operation, int destProcessId) |
| int | Reduce (vtkDataArray *sendBuffer, vtkDataArray *recvBuffer, vtkCommunicator::Operation *operation, int destProcessId) |
| int | AllReduce (const int *sendBuffer, int *recvBuffer, vtkIdType length, int operation) |
| int | AllReduce (const unsigned long *sendBuffer, unsigned long *recvBuffer, vtkIdType length, int operation) |
| int | AllReduce (const unsigned char *sendBuffer, unsigned char *recvBuffer, vtkIdType length, int operation) |
| int | AllReduce (const char *sendBuffer, char *recvBuffer, vtkIdType length, int operation) |
| int | AllReduce (const float *sendBuffer, float *recvBuffer, vtkIdType length, int operation) |
| int | AllReduce (const double *sendBuffer, double *recvBuffer, vtkIdType length, int operation) |
| int | AllReduce (vtkDataArray *sendBuffer, vtkDataArray *recvBuffer, int operation) |
| int | AllReduce (const int *sendBuffer, int *recvBuffer, vtkIdType length, vtkCommunicator::Operation *operation) |
| int | AllReduce (const unsigned long *sendBuffer, unsigned long *recvBuffer, vtkIdType length, vtkCommunicator::Operation *operation) |
| int | AllReduce (const unsigned char *sendBuffer, unsigned char *recvBuffer, vtkIdType length, vtkCommunicator::Operation *operation) |
| int | AllReduce (const char *sendBuffer, char *recvBuffer, vtkIdType length, vtkCommunicator::Operation *operation) |
| int | AllReduce (const float *sendBuffer, float *recvBuffer, vtkIdType length, vtkCommunicator::Operation *operation) |
| int | AllReduce (const double *sendBuffer, double *recvBuffer, vtkIdType length, vtkCommunicator::Operation *operation) |
| int | AllReduce (vtkDataArray *sendBuffer, vtkDataArray *recvBuffer, vtkCommunicator::Operation *operation) |
| vtkMultiProcessController () | |
| ~vtkMultiProcessController () | |
| void | ProcessRMI (int remoteProcessId, void *arg, int argLength, int rmiTag) |
| virtual vtkMultiProcessController * | GetLocalController () |
Public Types | |
| enum | Errors { RMI_NO_ERROR, RMI_TAG_ERROR, RMI_ARG_ERROR } |
| enum | Consts { MAX_PROCESSES = 8192, ANY_SOURCE = -1, INVALID_SOURCE = -2 } |
| enum | Tags { RMI_TAG = 1, RMI_ARG_TAG = 2, BREAK_RMI_TAG = 3, XML_WRITER_DATA_INFO = 4 } |
| typedef vtkObject | Superclass |
Public Member Functions | |
| virtual const char * | GetClassName () |
| virtual int | IsA (const char *type) |
| void | PrintSelf (ostream &os, vtkIndent indent) |
| virtual void | Initialize (int *vtkNotUsed(argc), char ***vtkNotUsed(argv))=0 |
| virtual void | Finalize ()=0 |
| virtual void | Finalize (int finalizedExternally)=0 |
| virtual void | SingleMethodExecute ()=0 |
| virtual void | MultipleMethodExecute ()=0 |
| int | GetLocalProcessId () |
| virtual void | CreateOutputWindow ()=0 |
| unsigned long | AddRMI (vtkRMIFunctionType, void *localArg, int tag) |
| int | RemoveFirstRMI (int tag) |
| int | RemoveRMI (unsigned long id) |
| void | TriggerRMI (int remoteProcessId, void *arg, int argLength, int tag) |
| void | TriggerBreakRMIs () |
| void | Barrier () |
| virtual void | Initialize (int *vtkNotUsed(argc), char ***vtkNotUsed(argv), int initializedExternally)=0 |
| void | SetNumberOfProcesses (int num) |
| int | GetNumberOfProcesses () |
| void | SetSingleMethod (vtkProcessFunctionType, void *data) |
| void | SetMultipleMethod (int index, vtkProcessFunctionType, void *data) |
| virtual vtkMultiProcessController * | CreateSubController (vtkProcessGroup *group) |
| void | RemoveRMI (vtkRMIFunctionType f, void *arg, int tag) |
| void | TriggerRMI (int remoteProcessId, const char *arg, int tag) |
| void | TriggerRMI (int remoteProcessId, int tag) |
| int | ProcessRMIs (int reportErrors, int dont_loop=0) |
| int | ProcessRMIs () |
| virtual void | SetBreakFlag (int) |
| virtual int | GetBreakFlag () |
| virtual vtkCommunicator * | GetCommunicator () |
Static Public Member Functions | |
| static int | IsTypeOf (const char *type) |
| static vtkMultiProcessController * | SafeDownCast (vtkObject *o) |
| static vtkMultiProcessController * | GetGlobalController () |
| static void | SetGlobalController (vtkMultiProcessController *controller) |
| static int | GetBreakRMITag () |
| static int | GetRMITag () |
| static int | GetRMIArgTag () |
Member Typedef Documentation
Reimplemented from vtkObject.
Reimplemented in vtkDummyController, vtkMPIController, and vtkSocketController.
Definition at line 70 of file vtkMultiProcessController.h.
Member Enumeration Documentation
Definition at line 243 of file vtkMultiProcessController.h.
Definition at line 257 of file vtkMultiProcessController.h.
Constructor & Destructor Documentation
| vtkMultiProcessController::vtkMultiProcessController | ( | ) | [protected] |
This method sends data to another process. Tag eliminates ambiguity when multiple sends or receives exist in the same process.
| vtkMultiProcessController::~vtkMultiProcessController | ( | ) | [protected] |
This method sends data to another process. Tag eliminates ambiguity when multiple sends or receives exist in the same process.
Member Function Documentation
| virtual const char* vtkMultiProcessController::GetClassName | ( | ) | [virtual] |
Reimplemented from vtkObject.
Reimplemented in vtkDummyController, vtkMPIController, and vtkSocketController.
| static int vtkMultiProcessController::IsTypeOf | ( | const char * | name | ) | [static] |
Return 1 if this class type is the same type of (or a subclass of) the named class. Returns 0 otherwise. This method works in combination with vtkTypeRevisionMacro found in vtkSetGet.h.
Reimplemented from vtkObject.
Reimplemented in vtkDummyController, vtkMPIController, and vtkSocketController.
| virtual int vtkMultiProcessController::IsA | ( | const char * | name | ) | [virtual] |
Return 1 if this class is the same type of (or a subclass of) the named class. Returns 0 otherwise. This method works in combination with vtkTypeRevisionMacro found in vtkSetGet.h.
Reimplemented from vtkObject.
Reimplemented in vtkDummyController, vtkMPIController, and vtkSocketController.
| static vtkMultiProcessController* vtkMultiProcessController::SafeDownCast | ( | vtkObject * | o | ) | [static] |
Reimplemented from vtkObject.
Reimplemented in vtkDummyController, vtkMPIController, and vtkSocketController.
| void vtkMultiProcessController::PrintSelf | ( | ostream & | os, | |
| vtkIndent | indent | |||
| ) | [virtual] |
Methods invoked by print to print information about the object including superclasses. Typically not called by the user (use Print() instead) but used in the hierarchical print process to combine the output of several classes.
Reimplemented from vtkObject.
Reimplemented in vtkDummyController, vtkMPIController, and vtkSocketController.
| virtual void vtkMultiProcessController::Initialize | ( | int * | vtkNotUsedargc, | |
| char *** | vtkNotUsedargv | |||
| ) | [pure virtual] |
This method is for setting up the processes. If a subclass needs to initialize process communication (i.e. MPI) it would over ride this method.
| virtual void vtkMultiProcessController::Initialize | ( | int * | vtkNotUsedargc, | |
| char *** | vtkNotUsedargv, | |||
| int | initializedExternally | |||
| ) | [pure virtual] |
This method is for setting up the processes. If a subclass needs to initialize process communication (i.e. MPI) it would over ride this method. Provided for initialization outside vtk.
Implemented in vtkMPIController.
| virtual void vtkMultiProcessController::Finalize | ( | ) | [pure virtual] |
This method is for cleaning up. If a subclass needs to clean up process communication (i.e. MPI) it would over ride this method.
Implemented in vtkDummyController, vtkMPIController, and vtkSocketController.
| virtual void vtkMultiProcessController::Finalize | ( | int | finalizedExternally | ) | [pure virtual] |
This method is for cleaning up. If a subclass needs to clean up process communication (i.e. MPI) it would over ride this method. Provided for finalization outside vtk.
Implemented in vtkDummyController, vtkMPIController, and vtkSocketController.
| void vtkMultiProcessController::SetNumberOfProcesses | ( | int | num | ) |
Set the number of processes you will be using. This defaults to the maximum number available. If you set this to a value higher than the default, you will get an error.
| int vtkMultiProcessController::GetNumberOfProcesses | ( | ) |
Set the number of processes you will be using. This defaults to the maximum number available. If you set this to a value higher than the default, you will get an error.
| void vtkMultiProcessController::SetSingleMethod | ( | vtkProcessFunctionType | , | |
| void * | data | |||
| ) |
Set the SingleMethod to f() and the UserData of the for the method to be executed by all of the processes when SingleMethodExecute is called. All the processes will start by calling this function.
| virtual void vtkMultiProcessController::SingleMethodExecute | ( | ) | [pure virtual] |
Execute the SingleMethod (as define by SetSingleMethod) using this->NumberOfProcesses processes. This will only return when all the processes finish executing their methods.
Implemented in vtkDummyController, vtkMPIController, and vtkSocketController.
| void vtkMultiProcessController::SetMultipleMethod | ( | int | index, | |
| vtkProcessFunctionType | , | |||
| void * | data | |||
| ) |
Set the MultipleMethod to f() and the UserData of the for the method to be executed by the process index when MultipleMethodExecute is called. This is for having each process start with a different function and data argument.
| virtual void vtkMultiProcessController::MultipleMethodExecute | ( | ) | [pure virtual] |
Execute the MultipleMethods (as define by calling SetMultipleMethod for each of the required this->NumberOfProcesses methods) using this->NumberOfProcesses processes.
Implemented in vtkDummyController, vtkMPIController, and vtkSocketController.
| int vtkMultiProcessController::GetLocalProcessId | ( | ) |
Tells you which process [0, NumProcess) you are in.
Reimplemented in vtkDummyController.
| static vtkMultiProcessController* vtkMultiProcessController::GetGlobalController | ( | ) | [static] |
This convenience method returns the controller associated with the local process. It returns NULL until the processes are spawned. It is better if you hang on to the controller passed as an argument to the SingleMethod or MultipleMethod functions.
| virtual void vtkMultiProcessController::CreateOutputWindow | ( | ) | [pure virtual] |
This method can be used to tell the controller to create a special output window in which all messages are preceded by the process id.
Implemented in vtkDummyController, vtkMPIController, and vtkSocketController.
| virtual vtkMultiProcessController* vtkMultiProcessController::CreateSubController | ( | vtkProcessGroup * | group | ) | [virtual] |
Creates a new controller with the processes specified by the given group. The new controller will already be initialized for you. You are responsible for deleting the controller once you are done. It is invalid to pass this method a group with a different communicator than is used by this controller. This operation is collective accross all processes defined in the group. It is undefined what will happen if the group is not the same on all processes. This method must be called by all processes in the controller regardless of whether they are in the group. NULL is returned on all process not in the group.
Reimplemented in vtkMPIController.
| unsigned long vtkMultiProcessController::AddRMI | ( | vtkRMIFunctionType | , | |
| void * | localArg, | |||
| int | tag | |||
| ) |
Register remote method invocation in the receiving process which makes the call. It must have a unique tag as an RMI id. The vtkRMIFunctionType has several arguments: localArg (same as passed in), remoteArg, remoteArgLength (memory passed by process triggering the RMI), remoteProcessId. Since only one callback can be registered per tag, this method will remove any previously registered callback for the given tag. Returns a unique Id for the RMI registration which can be used to unregister the callback. RemoveRMI() should be preferred over RemoveFirstRMI() since it avoid accidental removal of callbacks.
| int vtkMultiProcessController::RemoveFirstRMI | ( | int | tag | ) |
Remove the first RMI matching the tag.
| int vtkMultiProcessController::RemoveRMI | ( | unsigned long | id | ) |
Remove the RMI matching the id. The id is the same id returned by AddRMI().
| void vtkMultiProcessController::RemoveRMI | ( | vtkRMIFunctionType | f, | |
| void * | arg, | |||
| int | tag | |||
| ) | [inline] |
Take an RMI away.
Definition at line 183 of file vtkMultiProcessController.h.
| void vtkMultiProcessController::TriggerRMI | ( | int | remoteProcessId, | |
| void * | arg, | |||
| int | argLength, | |||
| int | tag | |||
| ) |
A method to trigger a method invocation in another process.
| void vtkMultiProcessController::TriggerBreakRMIs | ( | ) |
A conveniance method. Called on process 0 to break "ProcessRMIs" loop on all other processes.
| void vtkMultiProcessController::TriggerRMI | ( | int | remoteProcessId, | |
| const char * | arg, | |||
| int | tag | |||
| ) | [inline] |
Convenience method when the arg is a string.
Definition at line 197 of file vtkMultiProcessController.h.
| void vtkMultiProcessController::TriggerRMI | ( | int | remoteProcessId, | |
| int | tag | |||
| ) | [inline] |
Convenience method when there is no argument.
Definition at line 204 of file vtkMultiProcessController.h.
| int vtkMultiProcessController::ProcessRMIs | ( | int | reportErrors, | |
| int | dont_loop = 0 | |||
| ) |
Calling this method gives control to the controller to start processing RMIs. Possible return values are: RMI_NO_ERROR, RMI_TAG_ERROR : rmi tag could not be received, RMI_ARG_ERROR : rmi arg could not be received. If reportErrors is false, no vtkErrorMacro is called. ProcessRMIs() calls ProcessRMIs(int) with reportErrors = 0. If dont_loop is 1, this call just process one RMI message and exits.
| int vtkMultiProcessController::ProcessRMIs | ( | ) |
Calling this method gives control to the controller to start processing RMIs. Possible return values are: RMI_NO_ERROR, RMI_TAG_ERROR : rmi tag could not be received, RMI_ARG_ERROR : rmi arg could not be received. If reportErrors is false, no vtkErrorMacro is called. ProcessRMIs() calls ProcessRMIs(int) with reportErrors = 0. If dont_loop is 1, this call just process one RMI message and exits.
| virtual void vtkMultiProcessController::SetBreakFlag | ( | int | ) | [virtual] |
Setting this flag to 1 will cause the ProcessRMIs loop to return. This also causes vtkUpStreamPorts to return from their WaitForUpdate loops.
| virtual int vtkMultiProcessController::GetBreakFlag | ( | ) | [virtual] |
Setting this flag to 1 will cause the ProcessRMIs loop to return. This also causes vtkUpStreamPorts to return from their WaitForUpdate loops.
| virtual vtkCommunicator* vtkMultiProcessController::GetCommunicator | ( | ) | [virtual] |
Returns the communicator associated with this controller. A default communicator is created in constructor.
Reimplemented in vtkDummyController.
| static int vtkMultiProcessController::GetBreakRMITag | ( | ) | [inline, static] |
Accessor to some default tags.
Definition at line 236 of file vtkMultiProcessController.h.
| static int vtkMultiProcessController::GetRMITag | ( | ) | [inline, static] |
Accessor to some default tags.
Definition at line 237 of file vtkMultiProcessController.h.
| static int vtkMultiProcessController::GetRMIArgTag | ( | ) | [inline, static] |
Accessor to some default tags.
Definition at line 238 of file vtkMultiProcessController.h.
| void vtkMultiProcessController::Barrier | ( | ) | [inline] |
This method can be used to synchronize processes.
Definition at line 1166 of file vtkMultiProcessController.h.
| static void vtkMultiProcessController::SetGlobalController | ( | vtkMultiProcessController * | controller | ) | [static] |
| int vtkMultiProcessController::Send | ( | const int * | data, | |
| vtkIdType | length, | |||
| int | remoteProcessId, | |||
| int | tag | |||
| ) | [inline] |
This method sends data to another process. Tag eliminates ambiguity when multiple sends or receives exist in the same process.
Definition at line 933 of file vtkMultiProcessController.h.
| int vtkMultiProcessController::Send | ( | const unsigned long * | data, | |
| vtkIdType | length, | |||
| int | remoteProcessId, | |||
| int | tag | |||
| ) | [inline] |
This method sends data to another process. Tag eliminates ambiguity when multiple sends or receives exist in the same process.
Definition at line 946 of file vtkMultiProcessController.h.
| int vtkMultiProcessController::Send | ( | const char * | data, | |
| vtkIdType | length, | |||
| int | remoteProcessId, | |||
| int | tag | |||
| ) | [inline] |
This method sends data to another process. Tag eliminates ambiguity when multiple sends or receives exist in the same process.
Definition at line 961 of file vtkMultiProcessController.h.
| int vtkMultiProcessController::Send | ( | const unsigned char * | data, | |
| vtkIdType | length, | |||
| int | remoteProcessId, | |||
| int | tag | |||
| ) | [inline] |
This method sends data to another process. Tag eliminates ambiguity when multiple sends or receives exist in the same process.
Definition at line 974 of file vtkMultiProcessController.h.
| int vtkMultiProcessController::Send | ( | const float * | data, | |
| vtkIdType | length, | |||
| int | remoteProcessId, | |||
| int | tag | |||
| ) | [inline] |
This method sends data to another process. Tag eliminates ambiguity when multiple sends or receives exist in the same process.
Definition at line 988 of file vtkMultiProcessController.h.
| int vtkMultiProcessController::Send | ( | const double * | data, | |
| vtkIdType | length, | |||
| int | remoteProcessId, | |||
| int | tag | |||
| ) | [inline] |
This method sends data to another process. Tag eliminates ambiguity when multiple sends or receives exist in the same process.
Definition at line 1001 of file vtkMultiProcessController.h.
| int vtkMultiProcessController::Send | ( | vtkDataObject * | data, | |
| int | remoteId, | |||
| int | tag | |||
| ) | [inline] |
This method sends data to another process. Tag eliminates ambiguity when multiple sends or receives exist in the same process.
Definition at line 907 of file vtkMultiProcessController.h.
| int vtkMultiProcessController::Send | ( | vtkDataArray * | data, | |
| int | remoteId, | |||
| int | tag | |||
| ) | [inline] |
This method sends data to another process. Tag eliminates ambiguity when multiple sends or receives exist in the same process.
Definition at line 920 of file vtkMultiProcessController.h.
| int vtkMultiProcessController::Receive | ( | int * | data, | |
| vtkIdType | length, | |||
| int | remoteProcessId, | |||
| int | tag | |||
| ) | [inline] |
This method receives data from a corresponding send. It blocks until the receive is finished. It calls methods in "data" to communicate the sending data.
Definition at line 1069 of file vtkMultiProcessController.h.
| int vtkMultiProcessController::Receive | ( | unsigned long * | data, | |
| vtkIdType | length, | |||
| int | remoteProcessId, | |||
| int | tag | |||
| ) | [inline] |
This method sends data to another process. Tag eliminates ambiguity when multiple sends or receives exist in the same process.
Definition at line 1082 of file vtkMultiProcessController.h.
| int vtkMultiProcessController::Receive | ( | char * | data, | |
| vtkIdType | length, | |||
| int | remoteProcessId, | |||
| int | tag | |||
| ) | [inline] |
This method sends data to another process. Tag eliminates ambiguity when multiple sends or receives exist in the same process.
Definition at line 1097 of file vtkMultiProcessController.h.
| int vtkMultiProcessController::Receive | ( | unsigned char * | data, | |
| vtkIdType | length, | |||
| int | remoteProcessId, | |||
| int | tag | |||
| ) | [inline] |
This method sends data to another process. Tag eliminates ambiguity when multiple sends or receives exist in the same process.
Definition at line 1110 of file vtkMultiProcessController.h.
| int vtkMultiProcessController::Receive | ( | float * | data, | |
| vtkIdType | length, | |||
| int | remoteProcessId, | |||
| int | tag | |||
| ) | [inline] |
This method sends data to another process. Tag eliminates ambiguity when multiple sends or receives exist in the same process.
Definition at line 1124 of file vtkMultiProcessController.h.
| int vtkMultiProcessController::Receive | ( | double * | data, | |
| vtkIdType | length, | |||
| int | remoteProcessId, | |||
| int | tag | |||
| ) | [inline] |
This method sends data to another process. Tag eliminates ambiguity when multiple sends or receives exist in the same process.
Definition at line 1137 of file vtkMultiProcessController.h.
| int vtkMultiProcessController::Receive | ( | vtkDataObject * | data, | |
| int | remoteId, | |||
| int | tag | |||
| ) | [inline] |
This method sends data to another process. Tag eliminates ambiguity when multiple sends or receives exist in the same process.
Definition at line 1030 of file vtkMultiProcessController.h.
| int vtkMultiProcessController::Receive | ( | vtkDataArray * | data, | |
| int | remoteId, | |||
| int | tag | |||
| ) | [inline] |
This method sends data to another process. Tag eliminates ambiguity when multiple sends or receives exist in the same process.
Definition at line 1056 of file vtkMultiProcessController.h.
| vtkDataObject * vtkMultiProcessController::ReceiveDataObject | ( | int | remoteId, | |
| int | tag | |||
| ) | [inline] |
This method sends data to another process. Tag eliminates ambiguity when multiple sends or receives exist in the same process.
Definition at line 1043 of file vtkMultiProcessController.h.
| int vtkMultiProcessController::Broadcast | ( | int * | data, | |
| vtkIdType | length, | |||
| int | srcProcessId | |||
| ) | [inline] |
Broadcast sends the array in the process with id srcProcessId to all of the other processes. All processes must call these method with the same arguments in order for it to complete.
Definition at line 317 of file vtkMultiProcessController.h.
| int vtkMultiProcessController::Broadcast | ( | unsigned long * | data, | |
| vtkIdType | length, | |||
| int | srcProcessId | |||
| ) | [inline] |
This method sends data to another process. Tag eliminates ambiguity when multiple sends or receives exist in the same process.
Definition at line 320 of file vtkMultiProcessController.h.
| int vtkMultiProcessController::Broadcast | ( | unsigned char * | data, | |
| vtkIdType | length, | |||
| int | srcProcessId | |||
| ) | [inline] |
This method sends data to another process. Tag eliminates ambiguity when multiple sends or receives exist in the same process.
Definition at line 323 of file vtkMultiProcessController.h.
| int vtkMultiProcessController::Broadcast | ( | char * | data, | |
| vtkIdType | length, | |||
| int | srcProcessId | |||
| ) | [inline] |
This method sends data to another process. Tag eliminates ambiguity when multiple sends or receives exist in the same process.
Definition at line 326 of file vtkMultiProcessController.h.
| int vtkMultiProcessController::Broadcast | ( | float * | data, | |
| vtkIdType | length, | |||
| int | srcProcessId | |||
| ) | [inline] |
This method sends data to another process. Tag eliminates ambiguity when multiple sends or receives exist in the same process.
Definition at line 329 of file vtkMultiProcessController.h.
| int vtkMultiProcessController::Broadcast | ( | double * | data, | |
| vtkIdType | length, | |||
| int | srcProcessId | |||
| ) | [inline] |
This method sends data to another process. Tag eliminates ambiguity when multiple sends or receives exist in the same process.
Definition at line 332 of file vtkMultiProcessController.h.
| int vtkMultiProcessController::Broadcast | ( | vtkDataObject * | data, | |
| int | srcProcessId | |||
| ) | [inline] |
This method sends data to another process. Tag eliminates ambiguity when multiple sends or receives exist in the same process.
Definition at line 341 of file vtkMultiProcessController.h.
| int vtkMultiProcessController::Broadcast | ( | vtkDataArray * | data, | |
| int | srcProcessId | |||
| ) | [inline] |
This method sends data to another process. Tag eliminates ambiguity when multiple sends or receives exist in the same process.
Definition at line 344 of file vtkMultiProcessController.h.
| int vtkMultiProcessController::Gather | ( | const int * | sendBuffer, | |
| int * | recvBuffer, | |||
| vtkIdType | length, | |||
| int | destProcessId | |||
| ) | [inline] |
Gather collects arrays in the process with id destProcessId. Each process (including the destination) sends the contents of its send buffer to the destination process. The destination process receives the messages and stores them in rank order. The length argument (which must be the same on all processes) is the length of the sendBuffers. The recvBuffer (on te destination process) must be of length length*numProcesses. Gather is the inverse operation of Scatter.
Definition at line 357 of file vtkMultiProcessController.h.
| int vtkMultiProcessController::Gather | ( | const unsigned long * | sendBuffer, | |
| unsigned long * | recvBuffer, | |||
| vtkIdType | length, | |||
| int | destProcessId | |||
| ) | [inline] |
This method sends data to another process. Tag eliminates ambiguity when multiple sends or receives exist in the same process.
Definition at line 362 of file vtkMultiProcessController.h.
| int vtkMultiProcessController::Gather | ( | const unsigned char * | sendBuffer, | |
| unsigned char * | recvBuffer, | |||
| vtkIdType | length, | |||
| int | destProcessId | |||
| ) | [inline] |
This method sends data to another process. Tag eliminates ambiguity when multiple sends or receives exist in the same process.
Definition at line 367 of file vtkMultiProcessController.h.
| int vtkMultiProcessController::Gather | ( | const char * | sendBuffer, | |
| char * | recvBuffer, | |||
| vtkIdType | length, | |||
| int | destProcessId | |||
| ) | [inline] |
This method sends data to another process. Tag eliminates ambiguity when multiple sends or receives exist in the same process.
Definition at line 372 of file vtkMultiProcessController.h.
| int vtkMultiProcessController::Gather | ( | const float * | sendBuffer, | |
| float * | recvBuffer, | |||
| vtkIdType | length, | |||
| int | destProcessId | |||
| ) | [inline] |
This method sends data to another process. Tag eliminates ambiguity when multiple sends or receives exist in the same process.
Definition at line 377 of file vtkMultiProcessController.h.
| int vtkMultiProcessController::Gather | ( | const double * | sendBuffer, | |
| double * | recvBuffer, | |||
| vtkIdType | length, | |||
| int | destProcessId | |||
| ) | [inline] |
This method sends data to another process. Tag eliminates ambiguity when multiple sends or receives exist in the same process.
Definition at line 382 of file vtkMultiProcessController.h.
| int vtkMultiProcessController::Gather | ( | vtkDataArray * | sendBuffer, | |
| vtkDataArray * | recvBuffer, | |||
| int | destProcessId | |||
| ) | [inline] |
This method sends data to another process. Tag eliminates ambiguity when multiple sends or receives exist in the same process.
Definition at line 395 of file vtkMultiProcessController.h.
| int vtkMultiProcessController::GatherV | ( | const int * | sendBuffer, | |
| int * | recvBuffer, | |||
| vtkIdType | sendLength, | |||
| vtkIdType * | recvLengths, | |||
| vtkIdType * | offsets, | |||
| int | destProcessId | |||
| ) | [inline] |
GatherV is the vector variant of Gather. It extends the functionality of Gather by allowing a varying count of data from each process. GatherV collects arrays in the process with id destProcessId. Each process (including the destination) sends the contents of its send buffer to the destination process. The destination process receives the messages and stores them in rank order. The sendLength argument defines how much the local process sends to destProcessId and recvLengths is an array containing the amount destProcessId receives from each process, in rank order.
Definition at line 411 of file vtkMultiProcessController.h.
| int vtkMultiProcessController::GatherV | ( | const unsigned long * | sendBuffer, | |
| unsigned long * | recvBuffer, | |||
| vtkIdType | sendLength, | |||
| vtkIdType * | recvLengths, | |||
| vtkIdType * | offsets, | |||
| int | destProcessId | |||
| ) | [inline] |
This method sends data to another process. Tag eliminates ambiguity when multiple sends or receives exist in the same process.
Definition at line 418 of file vtkMultiProcessController.h.
| int vtkMultiProcessController::GatherV | ( | const unsigned char * | sendBuffer, | |
| unsigned char * | recvBuffer, | |||
| vtkIdType | sendLength, | |||
| vtkIdType * | recvLengths, | |||
| vtkIdType * | offsets, | |||
| int | destProcessId | |||
| ) | [inline] |
This method sends data to another process. Tag eliminates ambiguity when multiple sends or receives exist in the same process.
Definition at line 425 of file vtkMultiProcessController.h.
| int vtkMultiProcessController::GatherV | ( | const char * | sendBuffer, | |
| char * | recvBuffer, | |||
| vtkIdType | sendLength, | |||
| vtkIdType * | recvLengths, | |||
| vtkIdType * | offsets, | |||
| int | destProcessId | |||
| ) | [inline] |
This method sends data to another process. Tag eliminates ambiguity when multiple sends or receives exist in the same process.
Definition at line 432 of file vtkMultiProcessController.h.
| int vtkMultiProcessController::GatherV | ( | const float * | sendBuffer, | |
| float * | recvBuffer, | |||
| vtkIdType | sendLength, | |||
| vtkIdType * | recvLengths, | |||
| vtkIdType * | offsets, | |||
| int | destProcessId | |||
| ) | [inline] |
This method sends data to another process. Tag eliminates ambiguity when multiple sends or receives exist in the same process.
Definition at line 439 of file vtkMultiProcessController.h.
| int vtkMultiProcessController::GatherV | ( | const double * | sendBuffer, | |
| double * | recvBuffer, | |||
| vtkIdType | sendLength, | |||
| vtkIdType * | recvLengths, | |||
| vtkIdType * | offsets, | |||
| int | destProcessId | |||
| ) | [inline] |
This method sends data to another process. Tag eliminates ambiguity when multiple sends or receives exist in the same process.
Definition at line 446 of file vtkMultiProcessController.h.
| int vtkMultiProcessController::Scatter | ( | const int * | sendBuffer, | |
| int * | recvBuffer, | |||
| vtkIdType | length, | |||
| int | srcProcessId | |||
| ) | [inline] |
Scatter takes an array in the process with id srcProcessId and distributes it. Each process (including the source) receives a portion of the send buffer. Process 0 receives the first length values, process 1 receives the second length values, and so on. Scatter is the inverse operation of Gather.
Definition at line 470 of file vtkMultiProcessController.h.
| int vtkMultiProcessController::Scatter | ( | const unsigned long * | sendBuffer, | |
| unsigned long * | recvBuffer, | |||
| vtkIdType | length, | |||
| int | srcProcessId | |||
| ) | [inline] |
This method sends data to another process. Tag eliminates ambiguity when multiple sends or receives exist in the same process.
Definition at line 475 of file vtkMultiProcessController.h.
| int vtkMultiProcessController::Scatter | ( | const unsigned char * | sendBuffer, | |
| unsigned char * | recvBuffer, | |||
| vtkIdType | length, | |||
| int | srcProcessId | |||
| ) | [inline] |
This method sends data to another process. Tag eliminates ambiguity when multiple sends or receives exist in the same process.
Definition at line 480 of file vtkMultiProcessController.h.
| int vtkMultiProcessController::Scatter | ( | const char * | sendBuffer, | |
| char * | recvBuffer, | |||
| vtkIdType | length, | |||
| int | srcProcessId | |||
| ) | [inline] |
This method sends data to another process. Tag eliminates ambiguity when multiple sends or receives exist in the same process.
Definition at line 485 of file vtkMultiProcessController.h.
| int vtkMultiProcessController::Scatter | ( | const float * | sendBuffer, | |
| float * | recvBuffer, | |||
| vtkIdType | length, | |||
| int | srcProcessId | |||
| ) | [inline] |
This method sends data to another process. Tag eliminates ambiguity when multiple sends or receives exist in the same process.
Definition at line 490 of file vtkMultiProcessController.h.
| int vtkMultiProcessController::Scatter | ( | const double * | sendBuffer, | |
| double * | recvBuffer, | |||
| vtkIdType | length, | |||
| int | srcProcessId | |||
| ) | [inline] |
This method sends data to another process. Tag eliminates ambiguity when multiple sends or receives exist in the same process.
Definition at line 495 of file vtkMultiProcessController.h.
| int vtkMultiProcessController::Scatter | ( | vtkDataArray * | sendBuffer, | |
| vtkDataArray * | recvBuffer, | |||
| int | srcProcessId | |||
| ) | [inline] |
This method sends data to another process. Tag eliminates ambiguity when multiple sends or receives exist in the same process.
Definition at line 508 of file vtkMultiProcessController.h.
| int vtkMultiProcessController::ScatterV | ( | const int * | sendBuffer, | |
| int * | recvBuffer, | |||
| vtkIdType * | sendLengths, | |||
| vtkIdType * | offsets, | |||
| vtkIdType | recvLength, | |||
| int | srcProcessId | |||
| ) | [inline] |
ScatterV is the vector variant of Scatter. It extends the functionality of Scatter by allowing a varying count of data to each process. ScatterV takes an array in the process with id srcProcessId and distributes it. Each process (including the source) receives a portion of the send buffer defined by the sendLengths and offsets arrays.
Definition at line 520 of file vtkMultiProcessController.h.
| int vtkMultiProcessController::ScatterV | ( | const unsigned long * | sendBuffer, | |
| unsigned long * | recvBuffer, | |||
| vtkIdType * | sendLengths, | |||
| vtkIdType * | offsets, | |||
| vtkIdType | recvLength, | |||
| int | srcProcessId | |||
| ) | [inline] |
This method sends data to another process. Tag eliminates ambiguity when multiple sends or receives exist in the same process.
Definition at line 527 of file vtkMultiProcessController.h.
| int vtkMultiProcessController::ScatterV | ( | const unsigned char * | sendBuffer, | |
| unsigned char * | recvBuffer, | |||
| vtkIdType * | sendLengths, | |||
| vtkIdType * | offsets, | |||
| vtkIdType | recvLength, | |||
| int | srcProcessId | |||
| ) | [inline] |
This method sends data to another process. Tag eliminates ambiguity when multiple sends or receives exist in the same process.
Definition at line 534 of file vtkMultiProcessController.h.
| int vtkMultiProcessController::ScatterV | ( | const char * | sendBuffer, | |
| char * | recvBuffer, | |||
| vtkIdType * | sendLengths, | |||
| vtkIdType * | offsets, | |||
| vtkIdType | recvLength, | |||
| int | srcProcessId | |||
| ) | [inline] |
This method sends data to another process. Tag eliminates ambiguity when multiple sends or receives exist in the same process.
Definition at line 541 of file vtkMultiProcessController.h.
| int vtkMultiProcessController::ScatterV | ( | const float * | sendBuffer, | |
| float * | recvBuffer, | |||
| vtkIdType * | sendLengths, | |||
| vtkIdType * | offsets, | |||
| vtkIdType | recvLength, | |||
| int | srcProcessId | |||
| ) | [inline] |
This method sends data to another process. Tag eliminates ambiguity when multiple sends or receives exist in the same process.
Definition at line 548 of file vtkMultiProcessController.h.
| int vtkMultiProcessController::ScatterV | ( | const double * | sendBuffer, | |
| double * | recvBuffer, | |||
| vtkIdType * | sendLengths, | |||
| vtkIdType * | offsets, | |||
| vtkIdType | recvLength, | |||
| int | srcProcessId | |||
| ) | [inline] |
This method sends data to another process. Tag eliminates ambiguity when multiple sends or receives exist in the same process.
Definition at line 555 of file vtkMultiProcessController.h.
| int vtkMultiProcessController::AllGather | ( | const int * | sendBuffer, | |
| int * | recvBuffer, | |||
| vtkIdType | length | |||
| ) | [inline] |
Same as gather except that the result ends up on all processes.
Definition at line 575 of file vtkMultiProcessController.h.
| int vtkMultiProcessController::AllGather | ( | const unsigned long * | sendBuffer, | |
| unsigned long * | recvBuffer, | |||
| vtkIdType | length | |||
| ) | [inline] |
This method sends data to another process. Tag eliminates ambiguity when multiple sends or receives exist in the same process.
Definition at line 578 of file vtkMultiProcessController.h.
| int vtkMultiProcessController::AllGather | ( | const unsigned char * | sendBuffer, | |
| unsigned char * | recvBuffer, | |||
| vtkIdType | length | |||
| ) | [inline] |
This method sends data to another process. Tag eliminates ambiguity when multiple sends or receives exist in the same process.
Definition at line 582 of file vtkMultiProcessController.h.
| int vtkMultiProcessController::AllGather | ( | const char * | sendBuffer, | |
| char * | recvBuffer, | |||
| vtkIdType | length | |||
| ) | [inline] |
This method sends data to another process. Tag eliminates ambiguity when multiple sends or receives exist in the same process.
Definition at line 586 of file vtkMultiProcessController.h.
| int vtkMultiProcessController::AllGather | ( | const float * | sendBuffer, | |
| float * | recvBuffer, | |||
| vtkIdType | length | |||
| ) | [inline] |
This method sends data to another process. Tag eliminates ambiguity when multiple sends or receives exist in the same process.
Definition at line 589 of file vtkMultiProcessController.h.
| int vtkMultiProcessController::AllGather | ( | const double * | sendBuffer, | |
| double * | recvBuffer, | |||
| vtkIdType | length | |||
| ) | [inline] |
This method sends data to another process. Tag eliminates ambiguity when multiple sends or receives exist in the same process.
Definition at line 592 of file vtkMultiProcessController.h.
| int vtkMultiProcessController::AllGather | ( | vtkDataArray * | sendBuffer, | |
| vtkDataArray * | recvBuffer | |||
| ) | [inline] |
This method sends data to another process. Tag eliminates ambiguity when multiple sends or receives exist in the same process.
Definition at line 603 of file vtkMultiProcessController.h.
| int vtkMultiProcessController::AllGatherV | ( | const int * | sendBuffer, | |
| int * | recvBuffer, | |||
| vtkIdType | sendLength, | |||
| vtkIdType * | recvLengths, | |||
| vtkIdType * | offsets | |||
| ) | [inline] |
Same as GatherV except that the result is placed in all processes.
Definition at line 609 of file vtkMultiProcessController.h.
| int vtkMultiProcessController::AllGatherV | ( | const unsigned long * | sendBuffer, | |
| unsigned long * | recvBuffer, | |||
| vtkIdType | sendLength, | |||
| vtkIdType * | recvLengths, | |||
| vtkIdType * | offsets | |||
| ) | [inline] |
This method sends data to another process. Tag eliminates ambiguity when multiple sends or receives exist in the same process.
Definition at line 616 of file vtkMultiProcessController.h.
| int vtkMultiProcessController::AllGatherV | ( | const unsigned char * | sendBuffer, | |
| unsigned char * | recvBuffer, | |||
| vtkIdType | sendLength, | |||
| vtkIdType * | recvLengths, | |||
| vtkIdType * | offsets | |||
| ) | [inline] |
This method sends data to another process. Tag eliminates ambiguity when multiple sends or receives exist in the same process.
Definition at line 623 of file vtkMultiProcessController.h.
| int vtkMultiProcessController::AllGatherV | ( | const char * | sendBuffer, | |
| char * | recvBuffer, | |||
| vtkIdType | sendLength, | |||
| vtkIdType * | recvLengths, | |||
| vtkIdType * | offsets | |||
| ) | [inline] |
This method sends data to another process. Tag eliminates ambiguity when multiple sends or receives exist in the same process.
Definition at line 630 of file vtkMultiProcessController.h.
| int vtkMultiProcessController::AllGatherV | ( | const float * | sendBuffer, | |
| float * | recvBuffer, | |||
| vtkIdType | sendLength, | |||
| vtkIdType * | recvLengths, | |||
| vtkIdType * | offsets | |||
| ) | [inline] |
This method sends data to another process. Tag eliminates ambiguity when multiple sends or receives exist in the same process.
Definition at line 637 of file vtkMultiProcessController.h.
| int vtkMultiProcessController::AllGatherV | ( | const double * | sendBuffer, | |
| double * | recvBuffer, | |||
| vtkIdType | sendLength, | |||
| vtkIdType * | recvLengths, | |||
| vtkIdType * | offsets | |||
| ) | [inline] |
This method sends data to another process. Tag eliminates ambiguity when multiple sends or receives exist in the same process.
Definition at line 644 of file vtkMultiProcessController.h.
| int vtkMultiProcessController::Reduce | ( | const int * | sendBuffer, | |
| int * | recvBuffer, | |||
| vtkIdType | length, | |||
| int | operation, | |||
| int | destProcessId | |||
| ) | [inline] |
Reduce an array to the given destination process. This version of Reduce takes an identifier defined in the vtkCommunicator::StandardOperations enum to define the operation.
Definition at line 666 of file vtkMultiProcessController.h.
| int vtkMultiProcessController::Reduce | ( | const unsigned long * | sendBuffer, | |
| unsigned long * | recvBuffer, | |||
| vtkIdType | length, | |||
| int | operation, | |||
| int | destProcessId | |||
| ) | [inline] |
This method sends data to another process. Tag eliminates ambiguity when multiple sends or receives exist in the same process.
Definition at line 671 of file vtkMultiProcessController.h.
| int vtkMultiProcessController::Reduce | ( | const unsigned char * | sendBuffer, | |
| unsigned char * | recvBuffer, | |||
| vtkIdType | length, | |||
| int | operation, | |||
| int | destProcessId | |||
| ) | [inline] |
This method sends data to another process. Tag eliminates ambiguity when multiple sends or receives exist in the same process.
Definition at line 676 of file vtkMultiProcessController.h.
| int vtkMultiProcessController::Reduce | ( | const char * | sendBuffer, | |
| char * | recvBuffer, | |||
| vtkIdType | length, | |||
| int | operation, | |||
| int | destProcessId | |||
| ) | [inline] |
This method sends data to another process. Tag eliminates ambiguity when multiple sends or receives exist in the same process.
Definition at line 681 of file vtkMultiProcessController.h.
| int vtkMultiProcessController::Reduce | ( | const float * | sendBuffer, | |
| float * | recvBuffer, | |||
| vtkIdType | length, | |||
| int | operation, | |||
| int | destProcessId | |||
| ) | [inline] |
This method sends data to another process. Tag eliminates ambiguity when multiple sends or receives exist in the same process.
Definition at line 686 of file vtkMultiProcessController.h.
| int vtkMultiProcessController::Reduce | ( | const double * | sendBuffer, | |
| double * | recvBuffer, | |||
| vtkIdType | length, | |||
| int | operation, | |||
| int | destProcessId | |||
| ) | [inline] |
This method sends data to another process. Tag eliminates ambiguity when multiple sends or receives exist in the same process.
Definition at line 691 of file vtkMultiProcessController.h.
| int vtkMultiProcessController::Reduce | ( | vtkDataArray * | sendBuffer, | |
| vtkDataArray * | recvBuffer, | |||
| int | operation, | |||
| int | destProcessId | |||
| ) | [inline] |
This method sends data to another process. Tag eliminates ambiguity when multiple sends or receives exist in the same process.
Definition at line 704 of file vtkMultiProcessController.h.
| int vtkMultiProcessController::Reduce | ( | const int * | sendBuffer, | |
| int * | recvBuffer, | |||
| vtkIdType | length, | |||
| vtkCommunicator::Operation * | operation, | |||
| int | destProcessId | |||
| ) | [inline] |
Reduce an array to the given destination process. This version of Reduce takes a custom operation as a subclass of vtkCommunicator::Operation.
Definition at line 715 of file vtkMultiProcessController.h.
| int vtkMultiProcessController::Reduce | ( | const unsigned long * | sendBuffer, | |
| unsigned long * | recvBuffer, | |||
| vtkIdType | length, | |||
| vtkCommunicator::Operation * | operation, | |||
| int | destProcessId | |||
| ) | [inline] |
This method sends data to another process. Tag eliminates ambiguity when multiple sends or receives exist in the same process.
Definition at line 721 of file vtkMultiProcessController.h.
| int vtkMultiProcessController::Reduce | ( | const unsigned char * | sendBuffer, | |
| unsigned char * | recvBuffer, | |||
| vtkIdType | length, | |||
| vtkCommunicator::Operation * | operation, | |||
| int | destProcessId | |||
| ) | [inline] |
This method sends data to another process. Tag eliminates ambiguity when multiple sends or receives exist in the same process.
Definition at line 727 of file vtkMultiProcessController.h.
| int vtkMultiProcessController::Reduce | ( | const char * | sendBuffer, | |
| char * | recvBuffer, | |||
| vtkIdType | length, | |||
| vtkCommunicator::Operation * | operation, | |||
| int | destProcessId | |||
| ) | [inline] |
This method sends data to another process. Tag eliminates ambiguity when multiple sends or receives exist in the same process.
Definition at line 733 of file vtkMultiProcessController.h.
| int vtkMultiProcessController::Reduce | ( | const float * | sendBuffer, | |
| float * | recvBuffer, | |||
| vtkIdType | length, | |||
| vtkCommunicator::Operation * | operation, | |||
| int | destProcessId | |||
| ) | [inline] |
This method sends data to another process. Tag eliminates ambiguity when multiple sends or receives exist in the same process.
Definition at line 739 of file vtkMultiProcessController.h.
| int vtkMultiProcessController::Reduce | ( | const double * | sendBuffer, | |
| double * | recvBuffer, | |||
| vtkIdType | length, | |||
| vtkCommunicator::Operation * | operation, | |||
| int | destProcessId | |||
| ) | [inline] |
This method sends data to another process. Tag eliminates ambiguity when multiple sends or receives exist in the same process.
Definition at line 745 of file vtkMultiProcessController.h.
| int vtkMultiProcessController::Reduce | ( | vtkDataArray * | sendBuffer, | |
| vtkDataArray * | recvBuffer, | |||
| vtkCommunicator::Operation * | operation, | |||
| int | destProcessId | |||
| ) | [inline] |
This method sends data to another process. Tag eliminates ambiguity when multiple sends or receives exist in the same process.
Definition at line 760 of file vtkMultiProcessController.h.
| int vtkMultiProcessController::AllReduce | ( | const int * | sendBuffer, | |
| int * | recvBuffer, | |||
| vtkIdType | length, | |||
| int | operation | |||
| ) | [inline] |
Same as Reduce except that the result is placed in all of the processes.
Definition at line 770 of file vtkMultiProcessController.h.
| int vtkMultiProcessController::AllReduce | ( | const unsigned long * | sendBuffer, | |
| unsigned long * | recvBuffer, | |||
| vtkIdType | length, | |||
| int | operation | |||
| ) | [inline] |
This method sends data to another process. Tag eliminates ambiguity when multiple sends or receives exist in the same process.
Definition at line 775 of file vtkMultiProcessController.h.
| int vtkMultiProcessController::AllReduce | ( | const unsigned char * | sendBuffer, | |
| unsigned char * | recvBuffer, | |||
| vtkIdType | length, | |||
| int | operation | |||
| ) | [inline] |
This method sends data to another process. Tag eliminates ambiguity when multiple sends or receives exist in the same process.
Definition at line 780 of file vtkMultiProcessController.h.
| int vtkMultiProcessController::AllReduce | ( | const char * | sendBuffer, | |
| char * | recvBuffer, | |||
| vtkIdType | length, | |||
| int | operation | |||
| ) | [inline] |
This method sends data to another process. Tag eliminates ambiguity when multiple sends or receives exist in the same process.
Definition at line 785 of file vtkMultiProcessController.h.
| int vtkMultiProcessController::AllReduce | ( | const float * | sendBuffer, | |
| float * | recvBuffer, | |||
| vtkIdType | length, | |||
| int | operation | |||
| ) | [inline] |
This method sends data to another process. Tag eliminates ambiguity when multiple sends or receives exist in the same process.
Definition at line 790 of file vtkMultiProcessController.h.
| int vtkMultiProcessController::AllReduce | ( | const double * | sendBuffer, | |
| double * | recvBuffer, | |||
| vtkIdType | length, | |||
| int | operation | |||
| ) | [inline] |
This method sends data to another process. Tag eliminates ambiguity when multiple sends or receives exist in the same process.
Definition at line 795 of file vtkMultiProcessController.h.
| int vtkMultiProcessController::AllReduce | ( | vtkDataArray * | sendBuffer, | |
| vtkDataArray * | recvBuffer, | |||
| int | operation | |||
| ) | [inline] |
This method sends data to another process. Tag eliminates ambiguity when multiple sends or receives exist in the same process.
Definition at line 808 of file vtkMultiProcessController.h.
| int vtkMultiProcessController::AllReduce | ( | const int * | sendBuffer, | |
| int * | recvBuffer, | |||
| vtkIdType | length, | |||
| vtkCommunicator::Operation * | operation | |||
| ) | [inline] |
This method sends data to another process. Tag eliminates ambiguity when multiple sends or receives exist in the same process.
Definition at line 813 of file vtkMultiProcessController.h.
| int vtkMultiProcessController::AllReduce | ( | const unsigned long * | sendBuffer, | |
| unsigned long * | recvBuffer, | |||
| vtkIdType | length, | |||
| vtkCommunicator::Operation * | operation | |||
| ) | [inline] |
This method sends data to another process. Tag eliminates ambiguity when multiple sends or receives exist in the same process.
Definition at line 818 of file vtkMultiProcessController.h.
| int vtkMultiProcessController::AllReduce | ( | const unsigned char * | sendBuffer, | |
| unsigned char * | recvBuffer, | |||
| vtkIdType | length, | |||
| vtkCommunicator::Operation * | operation | |||
| ) | [inline] |
This method sends data to another process. Tag eliminates ambiguity when multiple sends or receives exist in the same process.
Definition at line 823 of file vtkMultiProcessController.h.
| int vtkMultiProcessController::AllReduce | ( | const char * | sendBuffer, | |
| char * | recvBuffer, | |||
| vtkIdType | length, | |||
| vtkCommunicator::Operation * | operation | |||
| ) | [inline] |
This method sends data to another process. Tag eliminates ambiguity when multiple sends or receives exist in the same process.
Definition at line 828 of file vtkMultiProcessController.h.
| int vtkMultiProcessController::AllReduce | ( | const float * | sendBuffer, | |
| float * | recvBuffer, | |||
| vtkIdType | length, | |||
| vtkCommunicator::Operation * | operation | |||
| ) | [inline] |
This method sends data to another process. Tag eliminates ambiguity when multiple sends or receives exist in the same process.
Definition at line 833 of file vtkMultiProcessController.h.
| int vtkMultiProcessController::AllReduce | ( | const double * | sendBuffer, | |
| double * | recvBuffer, | |||
| vtkIdType | length, | |||
| vtkCommunicator::Operation * | operation | |||
| ) | [inline] |
This method sends data to another process. Tag eliminates ambiguity when multiple sends or receives exist in the same process.
Definition at line 838 of file vtkMultiProcessController.h.
| int vtkMultiProcessController::AllReduce | ( | vtkDataArray * | sendBuffer, | |
| vtkDataArray * | recvBuffer, | |||
| vtkCommunicator::Operation * | operation | |||
| ) | [inline] |
This method sends data to another process. Tag eliminates ambiguity when multiple sends or receives exist in the same process.
Definition at line 850 of file vtkMultiProcessController.h.
| void vtkMultiProcessController::ProcessRMI | ( | int | remoteProcessId, | |
| void * | arg, | |||
| int | argLength, | |||
| int | rmiTag | |||
| ) | [protected] |
This method sends data to another process. Tag eliminates ambiguity when multiple sends or receives exist in the same process.
| virtual vtkMultiProcessController* vtkMultiProcessController::GetLocalController | ( | ) | [protected, virtual] |
This method sends data to another process. Tag eliminates ambiguity when multiple sends or receives exist in the same process.
Member Data Documentation
This method sends data to another process. Tag eliminates ambiguity when multiple sends or receives exist in the same process.
Definition at line 862 of file vtkMultiProcessController.h.
void* vtkMultiProcessController::SingleData [protected] |
This method sends data to another process. Tag eliminates ambiguity when multiple sends or receives exist in the same process.
Definition at line 863 of file vtkMultiProcessController.h.
vtkProcessFunctionType vtkMultiProcessController::MultipleMethod[MAX_PROCESSES] [protected] |
This method sends data to another process. Tag eliminates ambiguity when multiple sends or receives exist in the same process.
Definition at line 864 of file vtkMultiProcessController.h.
void* vtkMultiProcessController::MultipleData[MAX_PROCESSES] [protected] |
This method sends data to another process. Tag eliminates ambiguity when multiple sends or receives exist in the same process.
Definition at line 865 of file vtkMultiProcessController.h.
vtkCollection* vtkMultiProcessController::RMIs [protected] |
This method sends data to another process. Tag eliminates ambiguity when multiple sends or receives exist in the same process.
Definition at line 867 of file vtkMultiProcessController.h.
int vtkMultiProcessController::BreakFlag [protected] |
This method sends data to another process. Tag eliminates ambiguity when multiple sends or receives exist in the same process.
Definition at line 871 of file vtkMultiProcessController.h.
int vtkMultiProcessController::ForceDeepCopy [protected] |
This method sends data to another process. Tag eliminates ambiguity when multiple sends or receives exist in the same process.
Definition at line 881 of file vtkMultiProcessController.h.
vtkOutputWindow* vtkMultiProcessController::OutputWindow [protected] |
This method sends data to another process. Tag eliminates ambiguity when multiple sends or receives exist in the same process.
Definition at line 883 of file vtkMultiProcessController.h.
vtkCommunicator* vtkMultiProcessController::Communicator [protected] |
This method sends data to another process. Tag eliminates ambiguity when multiple sends or receives exist in the same process.
Definition at line 888 of file vtkMultiProcessController.h.
This method sends data to another process. Tag eliminates ambiguity when multiple sends or receives exist in the same process.
Definition at line 897 of file vtkMultiProcessController.h.
The documentation for this class was generated from the following file:
- dox/Parallel/vtkMultiProcessController.h
