vtkVertexGlyphFilter Class Reference
#include <vtkVertexGlyphFilter.h>
Detailed Description
Make a vtkPolyData with a vertex on each point.This filter throws away all of the cells in the input and replaces them with a vertex on each point. The intended use of this filter is roughly equivalent to the vtkGlyph3D filter, except this filter is specifically for data that has many vertices, making the rendered result faster and less cluttered than the glyph filter.
Definition at line 37 of file vtkVertexGlyphFilter.h.
Public Types | |
| typedef vtkPolyDataAlgorithm | Superclass |
Public Member Functions | |
| virtual const char * | GetClassName () |
| virtual int | IsA (const char *type) |
| virtual void | PrintSelf (ostream &os, vtkIndent indent) |
Static Public Member Functions | |
| static int | IsTypeOf (const char *type) |
| static vtkVertexGlyphFilter * | SafeDownCast (vtkObject *o) |
| static vtkVertexGlyphFilter * | New () |
Protected Member Functions | |
| vtkVertexGlyphFilter () | |
| ~vtkVertexGlyphFilter () | |
| int | RequestData (vtkInformation *, vtkInformationVector **, vtkInformationVector *) |
| int | FillInputPortInformation (int, vtkInformation *) |
Member Typedef Documentation
Constructor & Destructor Documentation
| vtkVertexGlyphFilter::vtkVertexGlyphFilter | ( | ) | [protected] |
| vtkVertexGlyphFilter::~vtkVertexGlyphFilter | ( | ) | [protected] |
Member Function Documentation
| virtual const char* vtkVertexGlyphFilter::GetClassName | ( | ) | [virtual] |
Reimplemented from vtkPolyDataAlgorithm.
| static int vtkVertexGlyphFilter::IsTypeOf | ( | const char * | name | ) | [static] |
Return 1 if this class type is the same type of (or a subclass of) the named class. Returns 0 otherwise. This method works in combination with vtkTypeRevisionMacro found in vtkSetGet.h.
Reimplemented from vtkPolyDataAlgorithm.
| virtual int vtkVertexGlyphFilter::IsA | ( | const char * | name | ) | [virtual] |
Return 1 if this class is the same type of (or a subclass of) the named class. Returns 0 otherwise. This method works in combination with vtkTypeRevisionMacro found in vtkSetGet.h.
Reimplemented from vtkPolyDataAlgorithm.
| static vtkVertexGlyphFilter* vtkVertexGlyphFilter::SafeDownCast | ( | vtkObject * | o | ) | [static] |
Reimplemented from vtkPolyDataAlgorithm.
| virtual void vtkVertexGlyphFilter::PrintSelf | ( | ostream & | os, | |
| vtkIndent | indent | |||
| ) | [virtual] |
Methods invoked by print to print information about the object including superclasses. Typically not called by the user (use Print() instead) but used in the hierarchical print process to combine the output of several classes.
Reimplemented from vtkPolyDataAlgorithm.
| static vtkVertexGlyphFilter* vtkVertexGlyphFilter::New | ( | ) | [static] |
Create an object with Debug turned off, modified time initialized to zero, and reference counting on.
Reimplemented from vtkPolyDataAlgorithm.
| int vtkVertexGlyphFilter::RequestData | ( | vtkInformation * | request, | |
| vtkInformationVector ** | inputVector, | |||
| vtkInformationVector * | outputVector | |||
| ) | [protected, virtual] |
This is called by the superclass. This is the method you should override.
Reimplemented from vtkPolyDataAlgorithm.
| int vtkVertexGlyphFilter::FillInputPortInformation | ( | int | port, | |
| vtkInformation * | info | |||
| ) | [protected, virtual] |
Fill the input port information objects for this algorithm. This is invoked by the first call to GetInputPortInformation for each port so subclasses can specify what they can handle.
Reimplemented from vtkPolyDataAlgorithm.
The documentation for this class was generated from the following file:
- dox/Graphics/vtkVertexGlyphFilter.h
