vtkCompositeDataSetAlgorithm Class Reference
#include <vtkCompositeDataSetAlgorithm.h>
Detailed Description
Superclass for algorithms that produce only vtkCompositeDataSet as output.Algorithms that take any type of data object (including composite dataset) and produce a vtkCompositeDataSet in the output can subclass from this class.
Definition at line 30 of file vtkCompositeDataSetAlgorithm.h.
Member Typedef Documentation
Reimplemented from vtkAlgorithm.
Reimplemented in vtkAppendCompositeDataLeaves, and vtkExtractPiece.
Definition at line 34 of file vtkCompositeDataSetAlgorithm.h.
Constructor & Destructor Documentation
| vtkCompositeDataSetAlgorithm::vtkCompositeDataSetAlgorithm | ( | ) | [protected] |
| vtkCompositeDataSetAlgorithm::~vtkCompositeDataSetAlgorithm | ( | ) | [inline, protected] |
Definition at line 64 of file vtkCompositeDataSetAlgorithm.h.
Member Function Documentation
| static vtkCompositeDataSetAlgorithm* vtkCompositeDataSetAlgorithm::New | ( | ) | [static] |
Create an object with Debug turned off, modified time initialized to zero, and reference counting on.
Reimplemented from vtkAlgorithm.
Reimplemented in vtkAppendCompositeDataLeaves, and vtkExtractPiece.
| virtual const char* vtkCompositeDataSetAlgorithm::GetClassName | ( | ) | [virtual] |
Reimplemented from vtkAlgorithm.
Reimplemented in vtkAppendCompositeDataLeaves, and vtkExtractPiece.
| static int vtkCompositeDataSetAlgorithm::IsTypeOf | ( | const char * | name | ) | [static] |
Return 1 if this class type is the same type of (or a subclass of) the named class. Returns 0 otherwise. This method works in combination with vtkTypeRevisionMacro found in vtkSetGet.h.
Reimplemented from vtkAlgorithm.
Reimplemented in vtkAppendCompositeDataLeaves, and vtkExtractPiece.
| virtual int vtkCompositeDataSetAlgorithm::IsA | ( | const char * | name | ) | [virtual] |
Return 1 if this class is the same type of (or a subclass of) the named class. Returns 0 otherwise. This method works in combination with vtkTypeRevisionMacro found in vtkSetGet.h.
Reimplemented from vtkAlgorithm.
Reimplemented in vtkAppendCompositeDataLeaves, and vtkExtractPiece.
| static vtkCompositeDataSetAlgorithm* vtkCompositeDataSetAlgorithm::SafeDownCast | ( | vtkObject * | o | ) | [static] |
Reimplemented from vtkAlgorithm.
Reimplemented in vtkAppendCompositeDataLeaves, and vtkExtractPiece.
| void vtkCompositeDataSetAlgorithm::PrintSelf | ( | ostream & | os, | |
| vtkIndent | indent | |||
| ) | [virtual] |
Methods invoked by print to print information about the object including superclasses. Typically not called by the user (use Print() instead) but used in the hierarchical print process to combine the output of several classes.
Reimplemented from vtkAlgorithm.
Reimplemented in vtkAppendCompositeDataLeaves, and vtkExtractPiece.
| vtkCompositeDataSet* vtkCompositeDataSetAlgorithm::GetOutput | ( | ) |
Get the output data object for a port on this algorithm.
| vtkCompositeDataSet* vtkCompositeDataSetAlgorithm::GetOutput | ( | int | ) |
Get the output data object for a port on this algorithm.
| void vtkCompositeDataSetAlgorithm::SetInput | ( | vtkDataObject * | ) |
Set an input of this algorithm. You should not override these methods because they are not the only way to connect a pipeline. Note that these methods support old-style pipeline connections. When writing new code you should use the more general vtkAlgorithm::SetInputConnection(). These methods transform the input index to the input port index, not an index of a connection within a single port.
| void vtkCompositeDataSetAlgorithm::SetInput | ( | int | , | |
| vtkDataObject * | ||||
| ) |
Set an input of this algorithm. You should not override these methods because they are not the only way to connect a pipeline. Note that these methods support old-style pipeline connections. When writing new code you should use the more general vtkAlgorithm::SetInputConnection(). These methods transform the input index to the input port index, not an index of a connection within a single port.
| virtual int vtkCompositeDataSetAlgorithm::ProcessRequest | ( | vtkInformation * | request, | |
| vtkInformationVector ** | inputVector, | |||
| vtkInformationVector * | outputVector | |||
| ) | [virtual] |
see vtkAlgorithm for details
Reimplemented from vtkAlgorithm.
| virtual int vtkCompositeDataSetAlgorithm::RequestDataObject | ( | vtkInformation * | , | |
| vtkInformationVector ** | , | |||
| vtkInformationVector * | ||||
| ) | [inline, protected, virtual] |
This is called by the superclass. This is the method you should override.
Reimplemented in vtkAppendCompositeDataLeaves, and vtkExtractPiece.
Definition at line 69 of file vtkCompositeDataSetAlgorithm.h.
| virtual int vtkCompositeDataSetAlgorithm::RequestInformation | ( | vtkInformation * | , | |
| vtkInformationVector ** | , | |||
| vtkInformationVector * | ||||
| ) | [inline, protected, virtual] |
This is called by the superclass. This is the method you should override.
Definition at line 77 of file vtkCompositeDataSetAlgorithm.h.
| virtual int vtkCompositeDataSetAlgorithm::RequestData | ( | vtkInformation * | , | |
| vtkInformationVector ** | , | |||
| vtkInformationVector * | ||||
| ) | [inline, protected, virtual] |
This is called by the superclass. This is the method you should override.
Reimplemented in vtkAppendCompositeDataLeaves, and vtkExtractPiece.
Definition at line 85 of file vtkCompositeDataSetAlgorithm.h.
| virtual int vtkCompositeDataSetAlgorithm::RequestUpdateExtent | ( | vtkInformation * | , | |
| vtkInformationVector ** | , | |||
| vtkInformationVector * | ||||
| ) | [inline, protected, virtual] |
This is called by the superclass. This is the method you should override.
Reimplemented in vtkExtractPiece.
Definition at line 93 of file vtkCompositeDataSetAlgorithm.h.
| virtual vtkExecutive* vtkCompositeDataSetAlgorithm::CreateDefaultExecutive | ( | ) | [protected, virtual] |
Create a default executive. If the DefaultExecutivePrototype is set, a copy of it is created in CreateDefaultExecutive() using NewInstance(). Otherwise, vtkStreamingDemandDrivenPipeline is created.
Reimplemented from vtkAlgorithm.
| virtual int vtkCompositeDataSetAlgorithm::FillOutputPortInformation | ( | int | port, | |
| vtkInformation * | info | |||
| ) | [protected, virtual] |
Fill the output port information objects for this algorithm. This is invoked by the first call to GetOutputPortInformation for each port so subclasses can specify what they can handle.
Reimplemented from vtkAlgorithm.
| virtual int vtkCompositeDataSetAlgorithm::FillInputPortInformation | ( | int | port, | |
| vtkInformation * | info | |||
| ) | [protected, virtual] |
Fill the input port information objects for this algorithm. This is invoked by the first call to GetInputPortInformation for each port so subclasses can specify what they can handle.
Reimplemented from vtkAlgorithm.
Reimplemented in vtkAppendCompositeDataLeaves.
| vtkDataObject* vtkCompositeDataSetAlgorithm::GetInput | ( | int | port | ) | [protected] |
Reimplemented in vtkAppendCompositeDataLeaves.
The documentation for this class was generated from the following file:
- dox/Filtering/vtkCompositeDataSetAlgorithm.h
