vtkImageEuclideanToPolar Class Reference
#include <vtkImageEuclideanToPolar.h>
Detailed Description
Converts 2D Euclidean coordinates to polar.For each pixel with vector components x,y, this filter outputs theta in component0, and radius in component1.
Definition at line 31 of file vtkImageEuclideanToPolar.h.
Public Types | |
| typedef vtkThreadedImageAlgorithm | Superclass |
Public Member Functions | |
| virtual const char * | GetClassName () |
| virtual int | IsA (const char *type) |
| void | PrintSelf (ostream &os, vtkIndent indent) |
| virtual void | SetThetaMaximum (double) |
| virtual double | GetThetaMaximum () |
Static Public Member Functions | |
| static vtkImageEuclideanToPolar * | New () |
| static int | IsTypeOf (const char *type) |
| static vtkImageEuclideanToPolar * | SafeDownCast (vtkObject *o) |
Protected Member Functions | |
| vtkImageEuclideanToPolar () | |
| ~vtkImageEuclideanToPolar () | |
| void | ThreadedExecute (vtkImageData *inData, vtkImageData *outData, int ext[6], int id) |
Protected Attributes | |
| double | ThetaMaximum |
Member Typedef Documentation
Reimplemented from vtkThreadedImageAlgorithm.
Definition at line 36 of file vtkImageEuclideanToPolar.h.
Constructor & Destructor Documentation
| vtkImageEuclideanToPolar::vtkImageEuclideanToPolar | ( | ) | [protected] |
| vtkImageEuclideanToPolar::~vtkImageEuclideanToPolar | ( | ) | [inline, protected] |
Definition at line 49 of file vtkImageEuclideanToPolar.h.
Member Function Documentation
| static vtkImageEuclideanToPolar* vtkImageEuclideanToPolar::New | ( | ) | [static] |
Create an object with Debug turned off, modified time initialized to zero, and reference counting on.
Reimplemented from vtkAlgorithm.
| virtual const char* vtkImageEuclideanToPolar::GetClassName | ( | ) | [virtual] |
Reimplemented from vtkThreadedImageAlgorithm.
| static int vtkImageEuclideanToPolar::IsTypeOf | ( | const char * | name | ) | [static] |
Return 1 if this class type is the same type of (or a subclass of) the named class. Returns 0 otherwise. This method works in combination with vtkTypeRevisionMacro found in vtkSetGet.h.
Reimplemented from vtkThreadedImageAlgorithm.
| virtual int vtkImageEuclideanToPolar::IsA | ( | const char * | name | ) | [virtual] |
Return 1 if this class is the same type of (or a subclass of) the named class. Returns 0 otherwise. This method works in combination with vtkTypeRevisionMacro found in vtkSetGet.h.
Reimplemented from vtkThreadedImageAlgorithm.
| static vtkImageEuclideanToPolar* vtkImageEuclideanToPolar::SafeDownCast | ( | vtkObject * | o | ) | [static] |
Reimplemented from vtkThreadedImageAlgorithm.
| void vtkImageEuclideanToPolar::PrintSelf | ( | ostream & | os, | |
| vtkIndent | indent | |||
| ) | [virtual] |
Methods invoked by print to print information about the object including superclasses. Typically not called by the user (use Print() instead) but used in the hierarchical print process to combine the output of several classes.
Reimplemented from vtkThreadedImageAlgorithm.
| virtual void vtkImageEuclideanToPolar::SetThetaMaximum | ( | double | ) | [virtual] |
Theta is an angle. Maximum specifies when it maps back to 0. ThetaMaximum defaults to 255 instead of 2PI, because unsigned char is expected as input. The output type must be the same as input type.
| virtual double vtkImageEuclideanToPolar::GetThetaMaximum | ( | ) | [virtual] |
Theta is an angle. Maximum specifies when it maps back to 0. ThetaMaximum defaults to 255 instead of 2PI, because unsigned char is expected as input. The output type must be the same as input type.
| void vtkImageEuclideanToPolar::ThreadedExecute | ( | vtkImageData * | inData, | |
| vtkImageData * | outData, | |||
| int | ext[6], | |||
| int | id | |||
| ) | [protected, virtual] |
Reimplemented from vtkThreadedImageAlgorithm.
Member Data Documentation
double vtkImageEuclideanToPolar::ThetaMaximum [protected] |
Definition at line 49 of file vtkImageEuclideanToPolar.h.
The documentation for this class was generated from the following file:
- dox/Imaging/vtkImageEuclideanToPolar.h
