vtkQtBarChartView Class Reference
#include <vtkQtBarChartView.h>
Detailed Description
Wraps a vtkQtChartArea into a VTK view.vtkQtBarChartView is a type vtkQtChartView designed for line charts.
- See also:
- vtkQtChartView
Definition at line 40 of file vtkQtBarChartView.h.
Public Types | |
| typedef vtkQtChartViewBase | Superclass |
Public Member Functions | |
| virtual const char * | GetClassName () |
| virtual int | IsA (const char *type) |
| void | PrintSelf (ostream &os, vtkIndent indent) |
| virtual void | Update () |
| void | SetHelpFormat (const char *format) |
| void | SetOutlineStyle (int outline) |
| void | SetBarGroupFraction (float fraction) |
| void | SetBarWidthFraction (float fraction) |
| virtual void | AddChartSelectionHandlers (vtkQtChartMouseSelection *selector) |
| virtual vtkQtChartSeriesModelCollection * | GetChartSeriesModel () |
Static Public Member Functions | |
| static vtkQtBarChartView * | New () |
| static int | IsTypeOf (const char *type) |
| static vtkQtBarChartView * | SafeDownCast (vtkObject *o) |
Protected Member Functions | |
| vtkQtBarChartView () | |
| ~vtkQtBarChartView () | |
Protected Attributes | |
| vtkQtBarChart * | BarChart |
| vtkQtChartSeriesModelCollection * | BarModel |
Member Typedef Documentation
Constructor & Destructor Documentation
| vtkQtBarChartView::vtkQtBarChartView | ( | ) | [protected] |
| vtkQtBarChartView::~vtkQtBarChartView | ( | ) | [protected] |
Member Function Documentation
| static vtkQtBarChartView* vtkQtBarChartView::New | ( | ) | [static] |
Create an object with Debug turned off, modified time initialized to zero, and reference counting on.
Reimplemented from vtkQtChartViewBase.
| virtual const char* vtkQtBarChartView::GetClassName | ( | ) | [virtual] |
Reimplemented from vtkQtChartViewBase.
| static int vtkQtBarChartView::IsTypeOf | ( | const char * | name | ) | [static] |
Return 1 if this class type is the same type of (or a subclass of) the named class. Returns 0 otherwise. This method works in combination with vtkTypeRevisionMacro found in vtkSetGet.h.
Reimplemented from vtkQtChartViewBase.
| virtual int vtkQtBarChartView::IsA | ( | const char * | name | ) | [virtual] |
Return 1 if this class is the same type of (or a subclass of) the named class. Returns 0 otherwise. This method works in combination with vtkTypeRevisionMacro found in vtkSetGet.h.
Reimplemented from vtkQtChartViewBase.
| static vtkQtBarChartView* vtkQtBarChartView::SafeDownCast | ( | vtkObject * | o | ) | [static] |
Reimplemented from vtkQtChartViewBase.
| void vtkQtBarChartView::PrintSelf | ( | ostream & | os, | |
| vtkIndent | indent | |||
| ) | [virtual] |
Methods invoked by print to print information about the object including superclasses. Typically not called by the user (use Print() instead) but used in the hierarchical print process to combine the output of several classes.
Reimplemented from vtkQtChartViewBase.
| virtual void vtkQtBarChartView::Update | ( | ) | [virtual] |
Updates the view.
Reimplemented from vtkQtChartViewBase.
| void vtkQtBarChartView::SetHelpFormat | ( | const char * | format | ) |
Sets the bar chart help format.
| void vtkQtBarChartView::SetOutlineStyle | ( | int | outline | ) |
Sets the bar outline style.
| void vtkQtBarChartView::SetBarGroupFraction | ( | float | fraction | ) |
Sets the bar group width fraction.
| void vtkQtBarChartView::SetBarWidthFraction | ( | float | fraction | ) |
Sets the bar width fraction.
| virtual void vtkQtBarChartView::AddChartSelectionHandlers | ( | vtkQtChartMouseSelection * | selector | ) | [virtual] |
Adds bar chart selection handlers to the mouse selection.
Reimplemented from vtkQtChartViewBase.
| virtual vtkQtChartSeriesModelCollection* vtkQtBarChartView::GetChartSeriesModel | ( | ) | [virtual] |
Gets the bar chart series model.
Reimplemented from vtkQtChartViewBase.
Member Data Documentation
vtkQtBarChart* vtkQtBarChartView::BarChart [protected] |
Definition at line 77 of file vtkQtBarChartView.h.
Definition at line 78 of file vtkQtBarChartView.h.
The documentation for this class was generated from the following file:
- dox/GUISupport/Qt/vtkQtBarChartView.h
