vtkFocalPlaneContourRepresentation Class Reference
#include <vtkFocalPlaneContourRepresentation.h>
Detailed Description
represent a contour drawn on the focal plane.The contour will stay on the focal plane irrespective of camera position/orientation changes. The class was written in order to be able to draw contours on a volume widget and have the contours overlayed on the focal plane in order to do contour segmentation. The superclass, vtkContourRepresentation handles contours that are drawn in actual world position co-ordinates, so they would rotate with the camera position/ orientation changes
Definition at line 39 of file vtkFocalPlaneContourRepresentation.h.
| typedef vtkContourRepresentation | Superclass |
| virtual const char * | GetClassName () |
| virtual int | IsA (const char *type) |
| void | PrintSelf (ostream &os, vtkIndent indent) |
| static int | IsTypeOf (const char *type) |
| static vtkFocalPlaneContourRepresentation * | SafeDownCast (vtkObject *o) |
Public Member Functions | |
| virtual int | GetNthNodeDisplayPosition (int n, double pos[2]) |
| virtual int | GetNthNodeWorldPosition (int n, double pos[3]) |
| virtual void | UpdateContourWorldPositionsBasedOnDisplayPositions () |
| virtual int | UpdateContour () |
| virtual void | UpdateLines (int index) |
| virtual int | GetIntermediatePointWorldPosition (int n, int idx, double point[3]) |
| virtual int | GetIntermediatePointDisplayPosition (int n, int idx, double point[3]) |
Protected Member Functions | |
| vtkFocalPlaneContourRepresentation () | |
| ~vtkFocalPlaneContourRepresentation () | |
Member Typedef Documentation
Standard VTK methods.
Reimplemented from vtkContourRepresentation.
Reimplemented in vtkOrientedGlyphFocalPlaneContourRepresentation.
Definition at line 44 of file vtkFocalPlaneContourRepresentation.h.
Constructor & Destructor Documentation
| vtkFocalPlaneContourRepresentation::vtkFocalPlaneContourRepresentation | ( | ) | [protected] |
| vtkFocalPlaneContourRepresentation::~vtkFocalPlaneContourRepresentation | ( | ) | [protected] |
Member Function Documentation
| virtual const char* vtkFocalPlaneContourRepresentation::GetClassName | ( | ) | [virtual] |
Standard VTK methods.
Reimplemented from vtkContourRepresentation.
Reimplemented in vtkOrientedGlyphFocalPlaneContourRepresentation.
| static int vtkFocalPlaneContourRepresentation::IsTypeOf | ( | const char * | type | ) | [static] |
Standard VTK methods.
Reimplemented from vtkContourRepresentation.
Reimplemented in vtkOrientedGlyphFocalPlaneContourRepresentation.
| virtual int vtkFocalPlaneContourRepresentation::IsA | ( | const char * | type | ) | [virtual] |
Standard VTK methods.
Reimplemented from vtkContourRepresentation.
Reimplemented in vtkOrientedGlyphFocalPlaneContourRepresentation.
| static vtkFocalPlaneContourRepresentation* vtkFocalPlaneContourRepresentation::SafeDownCast | ( | vtkObject * | o | ) | [static] |
Standard VTK methods.
Reimplemented from vtkContourRepresentation.
Reimplemented in vtkOrientedGlyphFocalPlaneContourRepresentation.
| void vtkFocalPlaneContourRepresentation::PrintSelf | ( | ostream & | os, | |
| vtkIndent | indent | |||
| ) | [virtual] |
Standard VTK methods.
Reimplemented from vtkContourRepresentation.
Reimplemented in vtkOrientedGlyphFocalPlaneContourRepresentation.
| virtual int vtkFocalPlaneContourRepresentation::GetIntermediatePointWorldPosition | ( | int | n, | |
| int | idx, | |||
| double | point[3] | |||
| ) | [virtual] |
Get the world position of the intermediate point at index idx between nodes n and (n+1) (or n and 0 if n is the last node and the loop is closed). Returns 1 on success or 0 if n or idx are out of range.
Reimplemented from vtkContourRepresentation.
| virtual int vtkFocalPlaneContourRepresentation::GetIntermediatePointDisplayPosition | ( | int | n, | |
| int | idx, | |||
| double | point[3] | |||
| ) | [virtual] |
Get the world position of the intermediate point at index idx between nodes n and (n+1) (or n and 0 if n is the last node and the loop is closed). Returns 1 on success or 0 if n or idx are out of range.
| virtual int vtkFocalPlaneContourRepresentation::GetNthNodeDisplayPosition | ( | int | n, | |
| double | pos[2] | |||
| ) | [virtual] |
Get the nth node's display position. Will return 1 on success, or 0 if there are not at least (n+1) nodes (0 based counting).
Reimplemented from vtkContourRepresentation.
| virtual int vtkFocalPlaneContourRepresentation::GetNthNodeWorldPosition | ( | int | n, | |
| double | pos[3] | |||
| ) | [virtual] |
Get the nth node's world position. Will return 1 on success, or 0 if there are not at least (n+1) nodes (0 based counting).
Reimplemented from vtkContourRepresentation.
| virtual void vtkFocalPlaneContourRepresentation::UpdateContourWorldPositionsBasedOnDisplayPositions | ( | ) | [virtual] |
The class maintains its true contour locations based on display co-ords This method syncs the world co-ords data structure with the display co-ords.
| virtual int vtkFocalPlaneContourRepresentation::UpdateContour | ( | ) | [virtual] |
The method must be called whenever the contour needs to be updated, usually from RenderOpaqueGeometry()
Reimplemented from vtkContourRepresentation.
| virtual void vtkFocalPlaneContourRepresentation::UpdateLines | ( | int | index | ) | [virtual] |
Reimplemented from vtkContourRepresentation.
The documentation for this class was generated from the following file:
- dox/Widgets/vtkFocalPlaneContourRepresentation.h
