vtkOrientedPolygonalHandleRepresentation3D Class Reference
#include <vtkOrientedPolygonalHandleRepresentation3D.h>
Detailed Description
represent a user defined handle geometry in 3D while maintaining a fixed orientation w.r.t the camera.This class serves as the geometrical representation of a vtkHandleWidget. The handle can be represented by an arbitrary polygonal data (vtkPolyData), set via SetHandle(vtkPolyData *). The actual position of the handle will be initially assumed to be (0,0,0). You can specify an offset from this position if desired. This class differs from vtkPolygonalHandleRepresentation3D in that the handle will always remain front facing, ie it maintains a fixed orientation with respect to the camera. This is done by using vtkFollowers internally to render the actors.
Definition at line 38 of file vtkOrientedPolygonalHandleRepresentation3D.h.
| typedef vtkAbstractPolygonalHandleRepresentation3D | Superclass |
| static int | IsTypeOf (const char *type) |
| static vtkOrientedPolygonalHandleRepresentation3D * | SafeDownCast (vtkObject *o) |
| virtual const char * | GetClassName () |
| virtual int | IsA (const char *type) |
| void | PrintSelf (ostream &os, vtkIndent indent) |
Static Public Member Functions | |
| static vtkOrientedPolygonalHandleRepresentation3D * | New () |
Protected Member Functions | |
| vtkOrientedPolygonalHandleRepresentation3D () | |
| ~vtkOrientedPolygonalHandleRepresentation3D () | |
| virtual void | UpdateHandle () |
Member Typedef Documentation
| typedef vtkAbstractPolygonalHandleRepresentation3D vtkOrientedPolygonalHandleRepresentation3D::Superclass |
Standard methods for instances of this class.
Reimplemented from vtkAbstractPolygonalHandleRepresentation3D.
Definition at line 48 of file vtkOrientedPolygonalHandleRepresentation3D.h.
Constructor & Destructor Documentation
| vtkOrientedPolygonalHandleRepresentation3D::vtkOrientedPolygonalHandleRepresentation3D | ( | ) | [protected] |
| vtkOrientedPolygonalHandleRepresentation3D::~vtkOrientedPolygonalHandleRepresentation3D | ( | ) | [protected] |
Member Function Documentation
| static vtkOrientedPolygonalHandleRepresentation3D* vtkOrientedPolygonalHandleRepresentation3D::New | ( | ) | [static] |
Instantiate this class.
Reimplemented from vtkObject.
| virtual const char* vtkOrientedPolygonalHandleRepresentation3D::GetClassName | ( | ) | [virtual] |
Standard methods for instances of this class.
Reimplemented from vtkAbstractPolygonalHandleRepresentation3D.
| static int vtkOrientedPolygonalHandleRepresentation3D::IsTypeOf | ( | const char * | type | ) | [static] |
Standard methods for instances of this class.
Reimplemented from vtkAbstractPolygonalHandleRepresentation3D.
| virtual int vtkOrientedPolygonalHandleRepresentation3D::IsA | ( | const char * | type | ) | [virtual] |
Standard methods for instances of this class.
Reimplemented from vtkAbstractPolygonalHandleRepresentation3D.
| static vtkOrientedPolygonalHandleRepresentation3D* vtkOrientedPolygonalHandleRepresentation3D::SafeDownCast | ( | vtkObject * | o | ) | [static] |
Standard methods for instances of this class.
Reimplemented from vtkAbstractPolygonalHandleRepresentation3D.
| void vtkOrientedPolygonalHandleRepresentation3D::PrintSelf | ( | ostream & | os, | |
| vtkIndent | indent | |||
| ) | [virtual] |
Standard methods for instances of this class.
Reimplemented from vtkAbstractPolygonalHandleRepresentation3D.
| virtual void vtkOrientedPolygonalHandleRepresentation3D::UpdateHandle | ( | ) | [protected, virtual] |
Override the superclass method.
Reimplemented from vtkAbstractPolygonalHandleRepresentation3D.
The documentation for this class was generated from the following file:
- dox/Widgets/vtkOrientedPolygonalHandleRepresentation3D.h
