vtkQtListView Class Reference
#include <vtkQtListView.h>
Detailed Description
A VTK view based on a Qt List view.vtkQtListView is a VTK view using an underlying QListView.
- Thanks:
- Thanks to Brian Wylie from Sandia National Laboratories for implementing this class
Definition at line 48 of file vtkQtListView.h.
Public Types | |
| enum | { FIELD_DATA = 0, POINT_DATA = 1, CELL_DATA = 2, VERTEX_DATA = 3, EDGE_DATA = 4, ROW_DATA = 5 } |
| typedef vtkQtView | Superclass |
Public Member Functions | |
| virtual const char * | GetClassName () |
| virtual int | IsA (const char *type) |
| void | PrintSelf (ostream &os, vtkIndent indent) |
| virtual QWidget * | GetWidget () |
| void | SetEnableDragDrop (bool) |
| void | SetAlternatingRowColors (bool) |
| void | SetDecorationStrategy (int) |
| void | SetVisibleColumn (int col) |
| void | SetFilterRegExp (const QRegExp &pattern) |
| virtual void | ApplyViewTheme (vtkViewTheme *theme) |
| virtual void | Update () |
| virtual int | GetFieldType () |
| void | SetFieldType (int) |
| void | SetColorArrayName (const char *name) |
| const char * | GetColorArrayName () |
| void | SetColorByArray (bool vis) |
| bool | GetColorByArray () |
| virtual void | ColorByArrayOn () |
| virtual void | ColorByArrayOff () |
| void | SetIconSheet (QImage sheet) |
| void | SetIconSize (int w, int h) |
| void | SetIconSheetSize (int w, int h) |
| void | SetIconArrayName (const char *name) |
Static Public Member Functions | |
| static vtkQtListView * | New () |
| static int | IsTypeOf (const char *type) |
| static vtkQtListView * | SafeDownCast (vtkObject *o) |
Protected Member Functions | |
| vtkQtListView () | |
| ~vtkQtListView () | |
| virtual void | AddRepresentationInternal (vtkDataRepresentation *rep) |
| virtual void | RemoveRepresentationInternal (vtkDataRepresentation *rep) |
Member Typedef Documentation
| typedef vtkQtView vtkQtListView::Superclass |
Member Enumeration Documentation
| anonymous enum |
Definition at line 63 of file vtkQtListView.h.
Constructor & Destructor Documentation
| vtkQtListView::vtkQtListView | ( | ) | [protected] |
| vtkQtListView::~vtkQtListView | ( | ) | [protected] |
Member Function Documentation
| static vtkQtListView* vtkQtListView::New | ( | ) | [static] |
Create an object with Debug turned off, modified time initialized to zero, and reference counting on.
Reimplemented from vtkView.
| virtual const char* vtkQtListView::GetClassName | ( | ) | [virtual] |
Reimplemented from vtkQtView.
| static int vtkQtListView::IsTypeOf | ( | const char * | name | ) | [static] |
Return 1 if this class type is the same type of (or a subclass of) the named class. Returns 0 otherwise. This method works in combination with vtkTypeMacro found in vtkSetGet.h.
Reimplemented from vtkQtView.
| virtual int vtkQtListView::IsA | ( | const char * | name | ) | [virtual] |
Return 1 if this class is the same type of (or a subclass of) the named class. Returns 0 otherwise. This method works in combination with vtkTypeMacro found in vtkSetGet.h.
Reimplemented from vtkQtView.
| static vtkQtListView* vtkQtListView::SafeDownCast | ( | vtkObject * | o | ) | [static] |
Reimplemented from vtkQtView.
| void vtkQtListView::PrintSelf | ( | ostream & | os, | |
| vtkIndent | indent | |||
| ) | [virtual] |
| virtual QWidget* vtkQtListView::GetWidget | ( | ) | [virtual] |
Get the main container of this view (a QWidget). The application typically places the view with a call to GetWidget(): something like this this->ui->box->layout()->addWidget(this->View->GetWidget());
Implements vtkQtView.
| virtual int vtkQtListView::GetFieldType | ( | ) | [virtual] |
The field type to copy into the output table. Should be one of FIELD_DATA, POINT_DATA, CELL_DATA, VERTEX_DATA, EDGE_DATA.
| void vtkQtListView::SetFieldType | ( | int | ) |
The field type to copy into the output table. Should be one of FIELD_DATA, POINT_DATA, CELL_DATA, VERTEX_DATA, EDGE_DATA.
| void vtkQtListView::SetEnableDragDrop | ( | bool | ) |
Enable drag and drop on this widget
| void vtkQtListView::SetAlternatingRowColors | ( | bool | ) |
Have the view alternate its row colors
| void vtkQtListView::SetDecorationStrategy | ( | int | ) |
The strategy for how to decorate rows. Should be one of vtkQtTableModelAdapter::COLORS, vtkQtTableModelAdapter::ICONS, or vtkQtTableModelAdapter::NONE. Default is NONE.
| void vtkQtListView::SetColorArrayName | ( | const char * | name | ) |
The array to use for coloring items in view. Default is "color".
| const char* vtkQtListView::GetColorArrayName | ( | ) |
The array to use for coloring items in view. Default is "color".
| void vtkQtListView::SetColorByArray | ( | bool | vis | ) |
Whether to color vertices. Default is off.
| bool vtkQtListView::GetColorByArray | ( | ) |
Whether to color vertices. Default is off.
| virtual void vtkQtListView::ColorByArrayOn | ( | ) | [virtual] |
Whether to color vertices. Default is off.
| virtual void vtkQtListView::ColorByArrayOff | ( | ) | [virtual] |
Whether to color vertices. Default is off.
| void vtkQtListView::SetVisibleColumn | ( | int | col | ) |
The column to display
| void vtkQtListView::SetFilterRegExp | ( | const QRegExp & | pattern | ) |
The column used to filter on
| void vtkQtListView::SetIconSheet | ( | QImage | sheet | ) |
Set the icon ivars. Only used if the decoration strategy is set to ICONS.
| void vtkQtListView::SetIconSize | ( | int | w, | |
| int | h | |||
| ) |
Set the icon ivars. Only used if the decoration strategy is set to ICONS.
| void vtkQtListView::SetIconSheetSize | ( | int | w, | |
| int | h | |||
| ) |
Set the icon ivars. Only used if the decoration strategy is set to ICONS.
| void vtkQtListView::SetIconArrayName | ( | const char * | name | ) |
Set the icon ivars. Only used if the decoration strategy is set to ICONS.
| virtual void vtkQtListView::ApplyViewTheme | ( | vtkViewTheme * | theme | ) | [virtual] |
| virtual void vtkQtListView::Update | ( | ) | [virtual] |
Updates the view.
Reimplemented from vtkView.
| virtual void vtkQtListView::AddRepresentationInternal | ( | vtkDataRepresentation * | rep | ) | [protected, virtual] |
| virtual void vtkQtListView::RemoveRepresentationInternal | ( | vtkDataRepresentation * | rep | ) | [protected, virtual] |
The documentation for this class was generated from the following file:
- dox/GUISupport/Qt/vtkQtListView.h
