Extract a sub grid (VOI) from the structured rectilinear dataset. More...
#include <vtkExtractRectilinearGrid.h>
Detailed Description
Extract a sub grid (VOI) from the structured rectilinear dataset.
vtkExtractRectilinearGrid rounds out the set of filters that extract a subgrid out of a larger structured data set. RIght now, this filter only supports extracting a VOI. In the future, it might support strides like the vtkExtract grid filter.
- See also:
- vtkExtractGrid vtkImageClip vtkGeometryFilter vtkExtractGeometry vtkExtractVOI vtkStructuredGridGeometryFilter
Definition at line 40 of file vtkExtractRectilinearGrid.h.
Member Typedef Documentation
Reimplemented from vtkRectilinearGridAlgorithm.
Reimplemented in vtkPExtractRectilinearGrid.
Definition at line 44 of file vtkExtractRectilinearGrid.h.
Constructor & Destructor Documentation
| vtkExtractRectilinearGrid::vtkExtractRectilinearGrid | ( | ) | [protected] |
| vtkExtractRectilinearGrid::~vtkExtractRectilinearGrid | ( | ) | [protected] |
Member Function Documentation
| static vtkExtractRectilinearGrid* vtkExtractRectilinearGrid::New | ( | ) | [static] |
Create an object with Debug turned off, modified time initialized to zero, and reference counting on.
Reimplemented from vtkRectilinearGridAlgorithm.
Reimplemented in vtkPExtractRectilinearGrid.
| static int vtkExtractRectilinearGrid::IsTypeOf | ( | const char * | name | ) | [static] |
Return 1 if this class type is the same type of (or a subclass of) the named class. Returns 0 otherwise. This method works in combination with vtkTypeMacro found in vtkSetGet.h.
Reimplemented from vtkRectilinearGridAlgorithm.
Reimplemented in vtkPExtractRectilinearGrid.
| virtual int vtkExtractRectilinearGrid::IsA | ( | const char * | name | ) | [virtual] |
Return 1 if this class is the same type of (or a subclass of) the named class. Returns 0 otherwise. This method works in combination with vtkTypeMacro found in vtkSetGet.h.
Reimplemented from vtkRectilinearGridAlgorithm.
Reimplemented in vtkPExtractRectilinearGrid.
| static vtkExtractRectilinearGrid* vtkExtractRectilinearGrid::SafeDownCast | ( | vtkObjectBase * | o | ) | [static] |
Reimplemented from vtkRectilinearGridAlgorithm.
Reimplemented in vtkPExtractRectilinearGrid.
| virtual vtkObjectBase* vtkExtractRectilinearGrid::NewInstanceInternal | ( | ) | const [protected, virtual] |
Reimplemented from vtkRectilinearGridAlgorithm.
Reimplemented in vtkPExtractRectilinearGrid.
Reimplemented from vtkRectilinearGridAlgorithm.
Reimplemented in vtkPExtractRectilinearGrid.
| void vtkExtractRectilinearGrid::PrintSelf | ( | ostream & | os, |
| vtkIndent | indent | ||
| ) | [virtual] |
Methods invoked by print to print information about the object including superclasses. Typically not called by the user (use Print() instead) but used in the hierarchical print process to combine the output of several classes.
Reimplemented from vtkRectilinearGridAlgorithm.
Reimplemented in vtkPExtractRectilinearGrid.
Specify i-j-k (min,max) pairs to extract. The resulting structured grid dataset can be of any topological dimension (i.e., point, line, plane, or 3D grid).
| virtual void vtkExtractRectilinearGrid::SetVOI | ( | int | [6] | ) | [virtual] |
Specify i-j-k (min,max) pairs to extract. The resulting structured grid dataset can be of any topological dimension (i.e., point, line, plane, or 3D grid).
| virtual int* vtkExtractRectilinearGrid::GetVOI | ( | ) | [virtual] |
Specify i-j-k (min,max) pairs to extract. The resulting structured grid dataset can be of any topological dimension (i.e., point, line, plane, or 3D grid).
| virtual void vtkExtractRectilinearGrid::GetVOI | ( | int | data[6] | ) | [virtual] |
Specify i-j-k (min,max) pairs to extract. The resulting structured grid dataset can be of any topological dimension (i.e., point, line, plane, or 3D grid).
| virtual void vtkExtractRectilinearGrid::SetSampleRate | ( | int | , |
| int | , | ||
| int | |||
| ) | [virtual] |
Set the sampling rate in the i, j, and k directions. If the rate is > 1, then the resulting VOI will be subsampled representation of the input. For example, if the SampleRate=(2,2,2), every other point will be selected, resulting in a volume 1/8th the original size. Initial value is (1,1,1).
| virtual void vtkExtractRectilinearGrid::SetSampleRate | ( | int | [3] | ) | [virtual] |
Set the sampling rate in the i, j, and k directions. If the rate is > 1, then the resulting VOI will be subsampled representation of the input. For example, if the SampleRate=(2,2,2), every other point will be selected, resulting in a volume 1/8th the original size. Initial value is (1,1,1).
| virtual int* vtkExtractRectilinearGrid::GetSampleRate | ( | ) | [virtual] |
Set the sampling rate in the i, j, and k directions. If the rate is > 1, then the resulting VOI will be subsampled representation of the input. For example, if the SampleRate=(2,2,2), every other point will be selected, resulting in a volume 1/8th the original size. Initial value is (1,1,1).
| virtual void vtkExtractRectilinearGrid::GetSampleRate | ( | int | data[3] | ) | [virtual] |
Set the sampling rate in the i, j, and k directions. If the rate is > 1, then the resulting VOI will be subsampled representation of the input. For example, if the SampleRate=(2,2,2), every other point will be selected, resulting in a volume 1/8th the original size. Initial value is (1,1,1).
| virtual void vtkExtractRectilinearGrid::SetIncludeBoundary | ( | int | ) | [virtual] |
Control whether to enforce that the "boundary" of the grid is output in the subsampling process. (This ivar only has effect when the SampleRate in any direction is not equal to 1.) When this ivar IncludeBoundary is on, the subsampling will always include the boundary of the grid even though the sample rate is not an even multiple of the grid dimensions. (By default IncludeBoundary is off.)
| virtual int vtkExtractRectilinearGrid::GetIncludeBoundary | ( | ) | [virtual] |
Control whether to enforce that the "boundary" of the grid is output in the subsampling process. (This ivar only has effect when the SampleRate in any direction is not equal to 1.) When this ivar IncludeBoundary is on, the subsampling will always include the boundary of the grid even though the sample rate is not an even multiple of the grid dimensions. (By default IncludeBoundary is off.)
| virtual void vtkExtractRectilinearGrid::IncludeBoundaryOn | ( | ) | [virtual] |
Control whether to enforce that the "boundary" of the grid is output in the subsampling process. (This ivar only has effect when the SampleRate in any direction is not equal to 1.) When this ivar IncludeBoundary is on, the subsampling will always include the boundary of the grid even though the sample rate is not an even multiple of the grid dimensions. (By default IncludeBoundary is off.)
| virtual void vtkExtractRectilinearGrid::IncludeBoundaryOff | ( | ) | [virtual] |
Control whether to enforce that the "boundary" of the grid is output in the subsampling process. (This ivar only has effect when the SampleRate in any direction is not equal to 1.) When this ivar IncludeBoundary is on, the subsampling will always include the boundary of the grid even though the sample rate is not an even multiple of the grid dimensions. (By default IncludeBoundary is off.)
| virtual int vtkExtractRectilinearGrid::RequestData | ( | vtkInformation * | request, |
| vtkInformationVector ** | inputVector, | ||
| vtkInformationVector * | outputVector | ||
| ) | [protected, virtual] |
This is called by the superclass. This is the method you should override.
Reimplemented from vtkRectilinearGridAlgorithm.
Reimplemented in vtkPExtractRectilinearGrid.
| virtual int vtkExtractRectilinearGrid::RequestInformation | ( | vtkInformation * | , |
| vtkInformationVector ** | , | ||
| vtkInformationVector * | |||
| ) | [protected, virtual] |
Reimplemented from vtkRectilinearGridAlgorithm.
Reimplemented in vtkPExtractRectilinearGrid.
| virtual int vtkExtractRectilinearGrid::RequestUpdateExtent | ( | vtkInformation * | , |
| vtkInformationVector ** | , | ||
| vtkInformationVector * | |||
| ) | [protected, virtual] |
This is called by the superclass. This is the method you should override.
Reimplemented from vtkRectilinearGridAlgorithm.
Reimplemented in vtkPExtractRectilinearGrid.
| bool vtkExtractRectilinearGrid::RequestDataImpl | ( | int | voi[6], |
| vtkInformationVector ** | inputVector, | ||
| vtkInformationVector * | outputVector | ||
| ) | [protected] |
Implementation for RequestData using a specified VOI. This is because the parallel filter needs to muck around with the VOI to get spacing and partitioning to play nice.
Member Data Documentation
int vtkExtractRectilinearGrid::VOI[6] [protected] |
Definition at line 94 of file vtkExtractRectilinearGrid.h.
int vtkExtractRectilinearGrid::SampleRate[3] [protected] |
Definition at line 95 of file vtkExtractRectilinearGrid.h.
int vtkExtractRectilinearGrid::IncludeBoundary [protected] |
Definition at line 96 of file vtkExtractRectilinearGrid.h.
Definition at line 98 of file vtkExtractRectilinearGrid.h.
The documentation for this class was generated from the following file:
- /Users/kitware/Dashboards/MyTests/VTK_BLD_Release_docs/Utilities/Doxygen/dox/Filters/Extraction/vtkExtractRectilinearGrid.h
