implements IOS specific functions required by vtkRenderWindowInteractor. More...
#include <vtkIOSRenderWindowInteractor.h>
Public Types | |
| typedef vtkRenderWindowInteractor | Superclass |
Public Member Functions | |
| virtual int | IsA (const char *type) |
| vtkIOSRenderWindowInteractor * | NewInstance () const |
| void | PrintSelf (ostream &os, vtkIndent indent) |
| virtual void | Initialize () |
| void | TerminateApp () |
| virtual void | ExitCallback () |
| virtual void | Enable () |
| virtual void | Disable () |
| int | GetContactIndex (void *ptr) |
| void | ClearContactIndex (void *ptr) |
Static Public Member Functions | |
| static vtkIOSRenderWindowInteractor * | New () |
| static int | IsTypeOf (const char *type) |
| static vtkIOSRenderWindowInteractor * | SafeDownCast (vtkObjectBase *o) |
| static void | SetClassExitMethod (void(*f)(void *), void *arg) |
| static void | SetClassExitMethodArgDelete (void(*f)(void *)) |
Protected Member Functions | |
| virtual vtkObjectBase * | NewInstanceInternal () const |
| vtkIOSRenderWindowInteractor () | |
| ~vtkIOSRenderWindowInteractor () | |
| virtual void | StartEventLoop () |
| void | SetTimerDictionary (void *dictionary) |
| void * | GetTimerDictionary () |
| virtual int | InternalCreateTimer (int timerId, int timerType, unsigned long duration) |
| virtual int | InternalDestroyTimer (int platformTimerId) |
| void | SetIOSManager (void *manager) |
| void * | GetIOSManager () |
Protected Attributes | |
| void * | IDLookup [VTKI_MAX_POINTERS] |
Static Protected Attributes | |
| static void(* | ClassExitMethod )(void *) |
| static void(* | ClassExitMethodArgDelete )(void *) |
| static void * | ClassExitMethodArg |
Detailed Description
implements IOS specific functions required by vtkRenderWindowInteractor.
The interactor interfaces with vtkIOSRenderWindow and vtkIOSGLView to trap messages from the IOS window manager and send them to vtk.
IMPORTANT: This header must be in C++ only because it is included by .cxx files. That means no Objective C may be used. That's why some instance variables are void* instead of what they really should be.
Definition at line 34 of file vtkIOSRenderWindowInteractor.h.
Member Typedef Documentation
Reimplemented from vtkRenderWindowInteractor.
Definition at line 40 of file vtkIOSRenderWindowInteractor.h.
Constructor & Destructor Documentation
| vtkIOSRenderWindowInteractor::vtkIOSRenderWindowInteractor | ( | ) | [protected] |
| vtkIOSRenderWindowInteractor::~vtkIOSRenderWindowInteractor | ( | ) | [protected] |
Member Function Documentation
| static vtkIOSRenderWindowInteractor* vtkIOSRenderWindowInteractor::New | ( | ) | [static] |
Construct object so that light follows camera motion.
Reimplemented from vtkRenderWindowInteractor.
| static int vtkIOSRenderWindowInteractor::IsTypeOf | ( | const char * | name | ) | [static] |
Return 1 if this class type is the same type of (or a subclass of) the named class. Returns 0 otherwise. This method works in combination with vtkTypeMacro found in vtkSetGet.h.
Reimplemented from vtkRenderWindowInteractor.
| virtual int vtkIOSRenderWindowInteractor::IsA | ( | const char * | name | ) | [virtual] |
Return 1 if this class is the same type of (or a subclass of) the named class. Returns 0 otherwise. This method works in combination with vtkTypeMacro found in vtkSetGet.h.
Reimplemented from vtkRenderWindowInteractor.
| static vtkIOSRenderWindowInteractor* vtkIOSRenderWindowInteractor::SafeDownCast | ( | vtkObjectBase * | o | ) | [static] |
Reimplemented from vtkRenderWindowInteractor.
| virtual vtkObjectBase* vtkIOSRenderWindowInteractor::NewInstanceInternal | ( | ) | const [protected, virtual] |
Reimplemented from vtkRenderWindowInteractor.
Reimplemented from vtkRenderWindowInteractor.
| void vtkIOSRenderWindowInteractor::PrintSelf | ( | ostream & | os, |
| vtkIndent | indent | ||
| ) | [virtual] |
Methods invoked by print to print information about the object including superclasses. Typically not called by the user (use Print() instead) but used in the hierarchical print process to combine the output of several classes.
Reimplemented from vtkRenderWindowInteractor.
| virtual void vtkIOSRenderWindowInteractor::Initialize | ( | ) | [virtual] |
Initialize the even handler
Reimplemented from vtkRenderWindowInteractor.
| virtual void vtkIOSRenderWindowInteractor::Enable | ( | ) | [virtual] |
Enable/Disable interactions. By default interactors are enabled when initialized. Initialize() must be called prior to enabling/disabling interaction. These methods are used when a window/widget is being shared by multiple renderers and interactors. This allows a "modal" display where one interactor is active when its data is to be displayed and all other interactors associated with the widget are disabled when their data is not displayed.
Reimplemented from vtkRenderWindowInteractor.
| virtual void vtkIOSRenderWindowInteractor::Disable | ( | ) | [virtual] |
Enable/Disable interactions. By default interactors are enabled when initialized. Initialize() must be called prior to enabling/disabling interaction. These methods are used when a window/widget is being shared by multiple renderers and interactors. This allows a "modal" display where one interactor is active when its data is to be displayed and all other interactors associated with the widget are disabled when their data is not displayed.
Reimplemented from vtkRenderWindowInteractor.
| void vtkIOSRenderWindowInteractor::TerminateApp | ( | ) | [virtual] |
IOS specific application terminate, calls ClassExitMethod then calls PostQuitMessage(0) to terminate app. An application can Specify ExitMethod for alternative behaviour (i.e. suppresion of keyboard exit)
Reimplemented from vtkRenderWindowInteractor.
| static void vtkIOSRenderWindowInteractor::SetClassExitMethod | ( | void(*)(void *) | f, |
| void * | arg | ||
| ) | [static] |
Methods to set the default exit method for the class. This method is only used if no instance level ExitMethod has been defined. It is provided as a means to control how an interactor is exited given the various language bindings (tcl, IOS, etc.).
| static void vtkIOSRenderWindowInteractor::SetClassExitMethodArgDelete | ( | void(*)(void *) | f | ) | [static] |
Methods to set the default exit method for the class. This method is only used if no instance level ExitMethod has been defined. It is provided as a means to control how an interactor is exited given the various language bindings (tcl, IOS, etc.).
| virtual void vtkIOSRenderWindowInteractor::ExitCallback | ( | ) | [virtual] |
These methods correspond to the the Exit, User and Pick callbacks. They allow for the Style to invoke them.
Reimplemented from vtkRenderWindowInteractor.
| int vtkIOSRenderWindowInteractor::GetContactIndex | ( | void * | ptr | ) |
For multitouch events translate a UITouch ref into a constant index for tracking across multiple calls
| void vtkIOSRenderWindowInteractor::ClearContactIndex | ( | void * | ptr | ) |
For multitouch events translate a UITouch ref into a constant index for tracking across multiple calls
| void vtkIOSRenderWindowInteractor::SetTimerDictionary | ( | void * | dictionary | ) | [protected] |
Accessors for the IOS member variables. These should be used at all time, even by this class.
| void* vtkIOSRenderWindowInteractor::GetTimerDictionary | ( | ) | [protected] |
Accessors for the IOS member variables. These should be used at all time, even by this class.
| virtual int vtkIOSRenderWindowInteractor::InternalCreateTimer | ( | int | timerId, |
| int | timerType, | ||
| unsigned long | duration | ||
| ) | [protected, virtual] |
IOS-specific internal timer methods. See the superclass for detailed documentation.
Reimplemented from vtkRenderWindowInteractor.
| virtual int vtkIOSRenderWindowInteractor::InternalDestroyTimer | ( | int | platformTimerId | ) | [protected, virtual] |
IOS-specific internal timer methods. See the superclass for detailed documentation.
Reimplemented from vtkRenderWindowInteractor.
| virtual void vtkIOSRenderWindowInteractor::StartEventLoop | ( | ) | [protected, virtual] |
This will start up the event loop and never return. If you call this method it will loop processing events until the application is exited.
Reimplemented from vtkRenderWindowInteractor.
| void vtkIOSRenderWindowInteractor::SetIOSManager | ( | void * | manager | ) | [protected] |
Accessors for the IOS manager (Really an NSMutableDictionary*). It manages all IOS objects in this C++ class.
| void* vtkIOSRenderWindowInteractor::GetIOSManager | ( | ) | [protected] |
Accessors for the IOS manager (Really an NSMutableDictionary*). It manages all IOS objects in this C++ class.
Member Data Documentation
void(* vtkIOSRenderWindowInteractor::ClassExitMethod)(void *) [static, protected] |
Class variables so an exit method can be defined for this class (used to set different exit methods for various language bindings, i.e. tcl, java, IOS)
Definition at line 102 of file vtkIOSRenderWindowInteractor.h.
void(* vtkIOSRenderWindowInteractor::ClassExitMethodArgDelete)(void *) [static, protected] |
Class variables so an exit method can be defined for this class (used to set different exit methods for various language bindings, i.e. tcl, java, IOS)
Definition at line 103 of file vtkIOSRenderWindowInteractor.h.
void* vtkIOSRenderWindowInteractor::ClassExitMethodArg [static, protected] |
Class variables so an exit method can be defined for this class (used to set different exit methods for various language bindings, i.e. tcl, java, IOS)
Definition at line 104 of file vtkIOSRenderWindowInteractor.h.
void* vtkIOSRenderWindowInteractor::IDLookup[VTKI_MAX_POINTERS] [protected] |
Definition at line 107 of file vtkIOSRenderWindowInteractor.h.
The documentation for this class was generated from the following file:
- /Users/kitware/Dashboards/MyTests/VTK_BLD_Release_docs/Utilities/Doxygen/dox/Rendering/OpenGL2/vtkIOSRenderWindowInteractor.h
