Superclass for algorithms that produce only vtkUnstructureGridBase subclasses as output. More...
#include <vtkUnstructuredGridBaseAlgorithm.h>
Detailed Description
Superclass for algorithms that produce only vtkUnstructureGridBase subclasses as output.
vtkUnstructuredGridBaseAlgorithm is a convenience class to make writing algorithms easier. There are some assumptions and defaults made by this class you should be aware of. This class defaults such that your filter will have one input port and one output port. If that is not the case simply change it with SetNumberOfInputPorts etc. See this classes constructor for the default. This class also provides a FillInputPortInfo method that by default says that all inputs will be UnstructuredGridBase. If that isn't the case then please override this method in your subclass.
Definition at line 38 of file vtkUnstructuredGridBaseAlgorithm.h.
Member Typedef Documentation
Reimplemented from vtkAlgorithm.
Reimplemented in vtkUnstructuredGridGeometryFilter.
Definition at line 43 of file vtkUnstructuredGridBaseAlgorithm.h.
Constructor & Destructor Documentation
Member Function Documentation
| static vtkUnstructuredGridBaseAlgorithm* vtkUnstructuredGridBaseAlgorithm::New | ( | ) | [static] |
Create an object with Debug turned off, modified time initialized to zero, and reference counting on.
Reimplemented from vtkAlgorithm.
Reimplemented in vtkUnstructuredGridGeometryFilter.
| static int vtkUnstructuredGridBaseAlgorithm::IsTypeOf | ( | const char * | name | ) | [static] |
Return 1 if this class type is the same type of (or a subclass of) the named class. Returns 0 otherwise. This method works in combination with vtkTypeMacro found in vtkSetGet.h.
Reimplemented from vtkAlgorithm.
Reimplemented in vtkUnstructuredGridGeometryFilter.
| virtual int vtkUnstructuredGridBaseAlgorithm::IsA | ( | const char * | name | ) | [virtual] |
Return 1 if this class is the same type of (or a subclass of) the named class. Returns 0 otherwise. This method works in combination with vtkTypeMacro found in vtkSetGet.h.
Reimplemented from vtkAlgorithm.
Reimplemented in vtkUnstructuredGridGeometryFilter.
| static vtkUnstructuredGridBaseAlgorithm* vtkUnstructuredGridBaseAlgorithm::SafeDownCast | ( | vtkObjectBase * | o | ) | [static] |
Reimplemented from vtkAlgorithm.
Reimplemented in vtkUnstructuredGridGeometryFilter.
| virtual vtkObjectBase* vtkUnstructuredGridBaseAlgorithm::NewInstanceInternal | ( | ) | const [protected, virtual] |
Reimplemented from vtkAlgorithm.
Reimplemented in vtkUnstructuredGridGeometryFilter.
Reimplemented from vtkAlgorithm.
Reimplemented in vtkUnstructuredGridGeometryFilter.
| void vtkUnstructuredGridBaseAlgorithm::PrintSelf | ( | ostream & | os, |
| vtkIndent | indent | ||
| ) | [virtual] |
Methods invoked by print to print information about the object including superclasses. Typically not called by the user (use Print() instead) but used in the hierarchical print process to combine the output of several classes.
Reimplemented from vtkAlgorithm.
Reimplemented in vtkUnstructuredGridGeometryFilter.
Get the output data object for a port on this algorithm.
Get the output data object for a port on this algorithm.
| virtual void vtkUnstructuredGridBaseAlgorithm::SetOutput | ( | vtkDataObject * | d | ) | [virtual] |
Get the output data object for a port on this algorithm.
| virtual int vtkUnstructuredGridBaseAlgorithm::ProcessRequest | ( | vtkInformation * | , |
| vtkInformationVector ** | , | ||
| vtkInformationVector * | |||
| ) | [virtual] |
see vtkAlgorithm for details
Reimplemented from vtkAlgorithm.
Assign a data object as input. Note that this method does not establish a pipeline connection. Use SetInputConnection() to setup a pipeline connection.
Assign a data object as input. Note that this method does not establish a pipeline connection. Use SetInputConnection() to setup a pipeline connection.
Assign a data object as input. Note that this method does not establish a pipeline connection. Use SetInputConnection() to setup a pipeline connection.
Assign a data object as input. Note that this method does not establish a pipeline connection. Use SetInputConnection() to setup a pipeline connection.
| virtual int vtkUnstructuredGridBaseAlgorithm::RequestInformation | ( | vtkInformation * | request, |
| vtkInformationVector ** | inputVector, | ||
| vtkInformationVector * | outputVector | ||
| ) | [protected, virtual] |
| virtual int vtkUnstructuredGridBaseAlgorithm::RequestData | ( | vtkInformation * | request, |
| vtkInformationVector ** | inputVector, | ||
| vtkInformationVector * | outputVector | ||
| ) | [protected, virtual] |
This is called by the superclass. This is the method you should override.
Reimplemented in vtkUnstructuredGridGeometryFilter.
| virtual int vtkUnstructuredGridBaseAlgorithm::RequestDataObject | ( | vtkInformation * | request, |
| vtkInformationVector ** | inputVector, | ||
| vtkInformationVector * | outputVector | ||
| ) | [protected, virtual] |
This is called by the superclass. This is the method you should override.
| virtual int vtkUnstructuredGridBaseAlgorithm::RequestUpdateExtent | ( | vtkInformation * | , |
| vtkInformationVector ** | , | ||
| vtkInformationVector * | |||
| ) | [protected, virtual] |
This is called by the superclass. This is the method you should override.
Reimplemented in vtkUnstructuredGridGeometryFilter.
| virtual int vtkUnstructuredGridBaseAlgorithm::FillOutputPortInformation | ( | int | port, |
| vtkInformation * | info | ||
| ) | [protected, virtual] |
Fill the output port information objects for this algorithm. This is invoked by the first call to GetOutputPortInformation for each port so subclasses can specify what they can handle.
Reimplemented from vtkAlgorithm.
| virtual int vtkUnstructuredGridBaseAlgorithm::FillInputPortInformation | ( | int | port, |
| vtkInformation * | info | ||
| ) | [protected, virtual] |
Fill the input port information objects for this algorithm. This is invoked by the first call to GetInputPortInformation for each port so subclasses can specify what they can handle.
Reimplemented from vtkAlgorithm.
Reimplemented in vtkUnstructuredGridGeometryFilter.
The documentation for this class was generated from the following file:
- /Users/kitware/Dashboards/MyTests/VTK_BLD_Release_docs/Utilities/Doxygen/dox/Common/ExecutionModel/vtkUnstructuredGridBaseAlgorithm.h
