vtkQtTableRepresentation Class Reference
#include <vtkQtTableRepresentation.h>
Detailed Description
set up a vtkTable in a Qt modelThis class is a wrapper around vtkQtTableModelAdapter. It performs the following functions:
- Keep track of the key column, first data column, and last data column. Populate the appropriate ivars on the Qt adapter.
- Assign colors to each of the data series using a vtkLookupTable. A default lookup table is provided or the user can supply one using SetColorTable().
The user must supply the following items:
- the name of the column that contains the series names,
- the names of the first and last data columns (this range should not contain the key column), and
- (optionally) a vtkLookupTable to use when assigning colors.
Note that this is an abstract class. You really want to use vtkQtTableDataRepresentation or vtkQtTableMetadataRepresentation instead.
Definition at line 62 of file vtkQtTableRepresentation.h.
Public Types | |
| typedef vtkDataRepresentation | Superclass |
Public Member Functions | |
| virtual const char * | GetClassName () |
| virtual int | IsA (const char *type) |
| void | PrintSelf (ostream &os, vtkIndent indent) |
| virtual void | SetInputConnection (vtkAlgorithmOutput *conn) |
| virtual void | Update () |
| void | SetColorTable (vtkLookupTable *t) |
| virtual vtkLookupTable * | GetColorTable () |
| void | SetKeyColumn (const char *col) |
| virtual void | SetFirstDataColumn (const char *) |
| virtual char * | GetFirstDataColumn () |
| virtual void | SetLastDataColumn (const char *) |
| virtual char * | GetLastDataColumn () |
Static Public Member Functions | |
| static int | IsTypeOf (const char *type) |
| static vtkQtTableRepresentation * | SafeDownCast (vtkObject *o) |
Protected Member Functions | |
| vtkQtTableRepresentation () | |
| ~vtkQtTableRepresentation () | |
| virtual void | SetKeyColumnInternal (const char *) |
| virtual char * | GetKeyColumnInternal () |
| virtual void | ResetModel () |
| virtual void | CreateSeriesColors () |
| virtual void | SetModelType () |
Protected Attributes | |
| vtkQtTableModelAdapter * | ModelAdapter |
| vtkLookupTable * | ColorTable |
| vtkDoubleArray * | SeriesColors |
| char * | KeyColumnInternal |
| char * | FirstDataColumn |
| char * | LastDataColumn |
Member Typedef Documentation
Reimplemented from vtkDataRepresentation.
Reimplemented in vtkQtChartRepresentation, vtkQtChartTableRepresentation, vtkQtTableDataRepresentation, and vtkQtTableMetadataRepresentation.
Definition at line 65 of file vtkQtTableRepresentation.h.
Constructor & Destructor Documentation
| vtkQtTableRepresentation::vtkQtTableRepresentation | ( | ) | [protected] |
| vtkQtTableRepresentation::~vtkQtTableRepresentation | ( | ) | [protected] |
Member Function Documentation
| virtual const char* vtkQtTableRepresentation::GetClassName | ( | ) | [virtual] |
Reimplemented from vtkDataRepresentation.
Reimplemented in vtkQtChartRepresentation, vtkQtChartTableRepresentation, vtkQtTableDataRepresentation, and vtkQtTableMetadataRepresentation.
| static int vtkQtTableRepresentation::IsTypeOf | ( | const char * | name | ) | [static] |
Return 1 if this class type is the same type of (or a subclass of) the named class. Returns 0 otherwise. This method works in combination with vtkTypeRevisionMacro found in vtkSetGet.h.
Reimplemented from vtkDataRepresentation.
Reimplemented in vtkQtChartRepresentation, vtkQtChartTableRepresentation, vtkQtTableDataRepresentation, and vtkQtTableMetadataRepresentation.
| virtual int vtkQtTableRepresentation::IsA | ( | const char * | name | ) | [virtual] |
Return 1 if this class is the same type of (or a subclass of) the named class. Returns 0 otherwise. This method works in combination with vtkTypeRevisionMacro found in vtkSetGet.h.
Reimplemented from vtkDataRepresentation.
Reimplemented in vtkQtChartRepresentation, vtkQtChartTableRepresentation, vtkQtTableDataRepresentation, and vtkQtTableMetadataRepresentation.
| static vtkQtTableRepresentation* vtkQtTableRepresentation::SafeDownCast | ( | vtkObject * | o | ) | [static] |
Reimplemented from vtkDataRepresentation.
Reimplemented in vtkQtChartRepresentation, vtkQtChartTableRepresentation, vtkQtTableDataRepresentation, and vtkQtTableMetadataRepresentation.
| void vtkQtTableRepresentation::PrintSelf | ( | ostream & | os, | |
| vtkIndent | indent | |||
| ) | [virtual] |
Methods invoked by print to print information about the object including superclasses. Typically not called by the user (use Print() instead) but used in the hierarchical print process to combine the output of several classes.
Reimplemented from vtkDataRepresentation.
Reimplemented in vtkQtChartRepresentation, vtkQtChartTableRepresentation, vtkQtTableDataRepresentation, and vtkQtTableMetadataRepresentation.
| virtual void vtkQtTableRepresentation::SetInputConnection | ( | vtkAlgorithmOutput * | conn | ) | [virtual] |
Hand in a connection to a vtkTable. NOTE: This must be called BEFORE the representation is added to a view or strange things may happen, including segfaults.
Reimplemented from vtkDataRepresentation.
Reimplemented in vtkQtChartRepresentation, and vtkQtTableMetadataRepresentation.
| void vtkQtTableRepresentation::SetColorTable | ( | vtkLookupTable * | t | ) |
Set/get the lookup table that will be used to determine colors for each series. The table's range should be [0, 1).
| virtual vtkLookupTable* vtkQtTableRepresentation::GetColorTable | ( | ) | [virtual] |
Set/get the lookup table that will be used to determine colors for each series. The table's range should be [0, 1).
| void vtkQtTableRepresentation::SetKeyColumn | ( | const char * | col | ) |
Set/get the name of the column that contains series names. This must be called BEFORE the representation is added to a view. vtkSetStringMacro(KeyColumn);
| virtual void vtkQtTableRepresentation::SetFirstDataColumn | ( | const char * | ) | [virtual] |
Set/get the name of the first data column. This must be called BEFORE the representation is added to a view.
| virtual char* vtkQtTableRepresentation::GetFirstDataColumn | ( | ) | [virtual] |
Set/get the name of the first data column. This must be called BEFORE the representation is added to a view.
| virtual void vtkQtTableRepresentation::SetLastDataColumn | ( | const char * | ) | [virtual] |
Set/get the name of the last data column. This must be called BEFORE the representation is added to a view.
| virtual char* vtkQtTableRepresentation::GetLastDataColumn | ( | ) | [virtual] |
Set/get the name of the last data column. This must be called BEFORE the representation is added to a view.
| virtual void vtkQtTableRepresentation::Update | ( | ) | [virtual] |
Update the table representation
Reimplemented in vtkQtChartRepresentation.
| virtual void vtkQtTableRepresentation::SetKeyColumnInternal | ( | const char * | ) | [protected, virtual] |
| virtual char* vtkQtTableRepresentation::GetKeyColumnInternal | ( | ) | [protected, virtual] |
| virtual void vtkQtTableRepresentation::ResetModel | ( | ) | [protected, virtual] |
| virtual void vtkQtTableRepresentation::CreateSeriesColors | ( | ) | [protected, virtual] |
Reimplemented in vtkQtChartRepresentation.
| virtual void vtkQtTableRepresentation::SetModelType | ( | ) | [inline, protected, virtual] |
This should set the model type to DATA, METADATA or FULL depending on what you want.
Reimplemented in vtkQtTableDataRepresentation, and vtkQtTableMetadataRepresentation.
Definition at line 127 of file vtkQtTableRepresentation.h.
Member Data Documentation
Definition at line 112 of file vtkQtTableRepresentation.h.
vtkLookupTable* vtkQtTableRepresentation::ColorTable [protected] |
Definition at line 116 of file vtkQtTableRepresentation.h.
vtkDoubleArray* vtkQtTableRepresentation::SeriesColors [protected] |
Definition at line 117 of file vtkQtTableRepresentation.h.
char* vtkQtTableRepresentation::KeyColumnInternal [protected] |
Definition at line 118 of file vtkQtTableRepresentation.h.
char* vtkQtTableRepresentation::FirstDataColumn [protected] |
Definition at line 119 of file vtkQtTableRepresentation.h.
char* vtkQtTableRepresentation::LastDataColumn [protected] |
Definition at line 120 of file vtkQtTableRepresentation.h.
The documentation for this class was generated from the following file:
- dox/GUISupport/Qt/vtkQtTableRepresentation.h
