vtkGlyph3DMapper Class Reference
#include <vtkGlyph3DMapper.h>
Detailed Description
vtkGlyph3D on the GPU.Do the same job than vtkGlyph3D but on the GPU. For this reason, it is a mapper not a vtkPolyDataAlgorithm. Also, some methods of vtkGlyph3D don't make sense in vtkGlyph3DMapper: GeneratePointIds, old-style SetSource, PointIdsName, IsPointVisible.
- See also:
- vtkGlyph3D
- Tests:
- vtkGlyph3DMapper (Tests)
Definition at line 37 of file vtkGlyph3DMapper.h.
| enum | OrientationModes { DIRECTION = 0, ROTATION = 1 } |
| virtual void | SetOrientationMode (int) |
| virtual int | GetOrientationMode () |
| void | SetOrientationModeToDirection () |
| void | SetOrientationModeToRotation () |
| const char * | GetOrientationModeAsString () |
| virtual bool | GetSupportsSelection () |
| vtkGlyph3DMapper () | |
| ~vtkGlyph3DMapper () | |
Public Types | |
| enum | ArrayIndexes { SCALE = 0, SOURCE_INDEX = 1, MASK = 2, ORIENTATION = 3 } |
| enum | ScaleModes { NO_DATA_SCALING = 0, SCALE_BY_MAGNITUDE = 1, SCALE_BY_COMPONENTS = 2 } |
| typedef vtkMapper | Superclass |
Public Member Functions | |
| virtual const char * | GetClassName () |
| virtual int | IsA (const char *type) |
| void | PrintSelf (ostream &os, vtkIndent indent) |
| void | SetSource (int idx, vtkPolyData *pd) |
| void | SetSource (vtkPolyData *pd) |
| vtkPolyData * | GetSource (int idx=0) |
| void | SetScaleModeToScaleByMagnitude () |
| void | SetScaleModeToScaleByVectorComponents () |
| void | SetScaleModeToNoDataScaling () |
| const char * | GetScaleModeAsString () |
| virtual double * | GetBounds () |
| virtual void | GetBounds (double bounds[6]) |
| virtual void | Render (vtkRenderer *ren, vtkActor *act) |
| void | SetMaskArray (const char *maskarrayname) |
| void | SetMaskArray (int fieldAttributeType) |
| void | SetOrientationArray (const char *orientationarrayname) |
| void | SetOrientationArray (int fieldAttributeType) |
| void | SetScaleArray (const char *scalarsarrayname) |
| void | SetScaleArray (int fieldAttributeType) |
| void | SetSourceIndexArray (const char *arrayname) |
| void | SetSourceIndexArray (int fieldAttributeType) |
| void | SetSourceConnection (int idx, vtkAlgorithmOutput *algOutput) |
| void | SetSourceConnection (vtkAlgorithmOutput *algOutput) |
| virtual void | SetScaling (bool) |
| virtual void | ScalingOn () |
| virtual void | ScalingOff () |
| virtual bool | GetScaling () |
| virtual void | SetScaleMode (int) |
| virtual int | GetScaleMode () |
| virtual void | SetScaleFactor (double) |
| virtual double | GetScaleFactor () |
| virtual void | SetRange (double, double) |
| void | SetRange (double[2]) |
| virtual double * | GetRange () |
| virtual void | GetRange (double data[2]) |
| virtual void | SetOrient (bool) |
| virtual bool | GetOrient () |
| virtual void | OrientOn () |
| virtual void | OrientOff () |
| virtual void | SetClamping (bool) |
| virtual bool | GetClamping () |
| virtual void | ClampingOn () |
| virtual void | ClampingOff () |
| virtual void | SetSourceIndexing (bool) |
| virtual bool | GetSourceIndexing () |
| virtual void | SourceIndexingOn () |
| virtual void | SourceIndexingOff () |
| virtual void | SetNestedDisplayLists (bool) |
| virtual bool | GetNestedDisplayLists () |
| virtual void | NestedDisplayListsOn () |
| virtual void | NestedDisplayListsOff () |
| virtual void | SetMasking (bool) |
| virtual bool | GetMasking () |
| virtual void | MaskingOn () |
| virtual void | MaskingOff () |
| virtual void | SetSelectionColorId (unsigned int) |
| virtual unsigned int | GetSelectionColorId () |
| virtual void | SetSelectMode (int) |
Static Public Member Functions | |
| static vtkGlyph3DMapper * | New () |
| static int | IsTypeOf (const char *type) |
| static vtkGlyph3DMapper * | SafeDownCast (vtkObject *o) |
Protected Member Functions | |
| virtual int | RequestUpdateExtent (vtkInformation *request, vtkInformationVector **inInfo, vtkInformationVector *outInfo) |
| virtual int | FillInputPortInformation (int port, vtkInformation *info) |
| vtkPolyData * | GetSource (int idx, vtkInformationVector *sourceInfo) |
| vtkDataArray * | GetMaskArray (vtkDataSet *input) |
| vtkDataArray * | GetSourceIndexArray (vtkDataSet *input) |
| vtkDataArray * | GetOrientationArray (vtkDataSet *input) |
| vtkDataArray * | GetScaleArray (vtkDataSet *input) |
| vtkUnsignedCharArray * | GetColors (vtkDataSet *input) |
Protected Attributes | |
| bool | Scaling |
| double | ScaleFactor |
| int | ScaleMode |
| double | Range [2] |
| bool | Orient |
| bool | Clamping |
| bool | SourceIndexing |
| bool | Masking |
| int | OrientationMode |
| bool | NestedDisplayLists |
| unsigned int | SelectionColorId |
| int | SelectMode |
Member Typedef Documentation
Reimplemented from vtkMapper.
Reimplemented in vtkOpenGLGlyph3DMapper.
Definition at line 41 of file vtkGlyph3DMapper.h.
Member Enumeration Documentation
Definition at line 100 of file vtkGlyph3DMapper.h.
Orientation mode indicates if the OrientationArray provides the direction vector for the orientation or the rotations around each axes. Default is DIRECTION
Definition at line 141 of file vtkGlyph3DMapper.h.
Constructor & Destructor Documentation
| vtkGlyph3DMapper::vtkGlyph3DMapper | ( | ) | [protected] |
WARNING: INTERNAL METHOD - NOT INTENDED FOR GENERAL USE DO NOT USE THIS METHOD OUTSIDE OF THE RENDERING PROCESS Used by vtkHardwareSelector to determine if the prop supports hardware selection.
| vtkGlyph3DMapper::~vtkGlyph3DMapper | ( | ) | [protected] |
WARNING: INTERNAL METHOD - NOT INTENDED FOR GENERAL USE DO NOT USE THIS METHOD OUTSIDE OF THE RENDERING PROCESS Used by vtkHardwareSelector to determine if the prop supports hardware selection.
Member Function Documentation
| static vtkGlyph3DMapper* vtkGlyph3DMapper::New | ( | ) | [static] |
Create an object with Debug turned off, modified time initialized to zero, and reference counting on.
Reimplemented from vtkAlgorithm.
Reimplemented in vtkOpenGLGlyph3DMapper.
| virtual const char* vtkGlyph3DMapper::GetClassName | ( | ) | [virtual] |
| static int vtkGlyph3DMapper::IsTypeOf | ( | const char * | name | ) | [static] |
Return 1 if this class type is the same type of (or a subclass of) the named class. Returns 0 otherwise. This method works in combination with vtkTypeMacro found in vtkSetGet.h.
Reimplemented from vtkMapper.
Reimplemented in vtkOpenGLGlyph3DMapper.
| virtual int vtkGlyph3DMapper::IsA | ( | const char * | name | ) | [virtual] |
Return 1 if this class is the same type of (or a subclass of) the named class. Returns 0 otherwise. This method works in combination with vtkTypeMacro found in vtkSetGet.h.
Reimplemented from vtkMapper.
Reimplemented in vtkOpenGLGlyph3DMapper.
| static vtkGlyph3DMapper* vtkGlyph3DMapper::SafeDownCast | ( | vtkObject * | o | ) | [static] |
| void vtkGlyph3DMapper::PrintSelf | ( | ostream & | os, | |
| vtkIndent | indent | |||
| ) | [virtual] |
Methods invoked by print to print information about the object including superclasses. Typically not called by the user (use Print() instead) but used in the hierarchical print process to combine the output of several classes.
Reimplemented from vtkMapper.
Reimplemented in vtkOpenGLGlyph3DMapper.
| void vtkGlyph3DMapper::SetSourceConnection | ( | int | idx, | |
| vtkAlgorithmOutput * | algOutput | |||
| ) |
Specify a source object at a specified table location. New style. Source connection is stored in port 1. This method is equivalent to SetInputConnection(1, id, outputPort).
| void vtkGlyph3DMapper::SetSourceConnection | ( | vtkAlgorithmOutput * | algOutput | ) | [inline] |
Specify a source object at a specified table location. New style. Source connection is stored in port 1. This method is equivalent to SetInputConnection(1, id, outputPort).
Definition at line 58 of file vtkGlyph3DMapper.h.
| void vtkGlyph3DMapper::SetSource | ( | int | idx, | |
| vtkPolyData * | pd | |||
| ) |
Specify a source object at a specified table location.
| void vtkGlyph3DMapper::SetSource | ( | vtkPolyData * | pd | ) |
Set the source to use for he glyph. Old style. See SetSourceConnection.
| vtkPolyData* vtkGlyph3DMapper::GetSource | ( | int | idx = 0 |
) |
Get a pointer to a source object at a specified table location.
| virtual void vtkGlyph3DMapper::SetScaling | ( | bool | ) | [virtual] |
Turn on/off scaling of source geometry. When turned on, ScaleFactor controls the scale applied. To scale with some data array, ScaleMode should be set accordingly.
| virtual void vtkGlyph3DMapper::ScalingOn | ( | ) | [virtual] |
Turn on/off scaling of source geometry. When turned on, ScaleFactor controls the scale applied. To scale with some data array, ScaleMode should be set accordingly.
| virtual void vtkGlyph3DMapper::ScalingOff | ( | ) | [virtual] |
Turn on/off scaling of source geometry. When turned on, ScaleFactor controls the scale applied. To scale with some data array, ScaleMode should be set accordingly.
| virtual bool vtkGlyph3DMapper::GetScaling | ( | ) | [virtual] |
Turn on/off scaling of source geometry. When turned on, ScaleFactor controls the scale applied. To scale with some data array, ScaleMode should be set accordingly.
| virtual void vtkGlyph3DMapper::SetScaleMode | ( | int | ) | [virtual] |
Either scale by individual components (SCALE_BY_COMPONENTS) or magnitude (SCALE_BY_MAGNITUDE) of the chosen array to SCALE with or disable scaling using data array all together (NO_DATA_SCALING). Default is NO_DATA_SCALING.
| virtual int vtkGlyph3DMapper::GetScaleMode | ( | ) | [virtual] |
Either scale by individual components (SCALE_BY_COMPONENTS) or magnitude (SCALE_BY_MAGNITUDE) of the chosen array to SCALE with or disable scaling using data array all together (NO_DATA_SCALING). Default is NO_DATA_SCALING.
| virtual void vtkGlyph3DMapper::SetScaleFactor | ( | double | ) | [virtual] |
Specify scale factor to scale object by. This is used only when Scaling is On.
| virtual double vtkGlyph3DMapper::GetScaleFactor | ( | ) | [virtual] |
Specify scale factor to scale object by. This is used only when Scaling is On.
| void vtkGlyph3DMapper::SetScaleModeToScaleByMagnitude | ( | ) | [inline] |
Definition at line 107 of file vtkGlyph3DMapper.h.
| void vtkGlyph3DMapper::SetScaleModeToScaleByVectorComponents | ( | ) | [inline] |
Definition at line 109 of file vtkGlyph3DMapper.h.
| void vtkGlyph3DMapper::SetScaleModeToNoDataScaling | ( | ) | [inline] |
Definition at line 111 of file vtkGlyph3DMapper.h.
| const char* vtkGlyph3DMapper::GetScaleModeAsString | ( | ) |
| virtual void vtkGlyph3DMapper::SetRange | ( | double | , | |
| double | ||||
| ) | [virtual] |
Specify range to map scalar values into.
| void vtkGlyph3DMapper::SetRange | ( | double | [2] | ) |
Specify range to map scalar values into.
| virtual double* vtkGlyph3DMapper::GetRange | ( | ) | [virtual] |
Specify range to map scalar values into.
| virtual void vtkGlyph3DMapper::GetRange | ( | double | data[2] | ) | [virtual] |
Specify range to map scalar values into.
| virtual void vtkGlyph3DMapper::SetOrient | ( | bool | ) | [virtual] |
Turn on/off orienting of input geometry. When turned on, the orientation array specified using SetOrientationArray() will be used.
| virtual bool vtkGlyph3DMapper::GetOrient | ( | ) | [virtual] |
Turn on/off orienting of input geometry. When turned on, the orientation array specified using SetOrientationArray() will be used.
| virtual void vtkGlyph3DMapper::OrientOn | ( | ) | [virtual] |
Turn on/off orienting of input geometry. When turned on, the orientation array specified using SetOrientationArray() will be used.
| virtual void vtkGlyph3DMapper::OrientOff | ( | ) | [virtual] |
Turn on/off orienting of input geometry. When turned on, the orientation array specified using SetOrientationArray() will be used.
| virtual void vtkGlyph3DMapper::SetOrientationMode | ( | int | ) | [virtual] |
Orientation mode indicates if the OrientationArray provides the direction vector for the orientation or the rotations around each axes. Default is DIRECTION
| virtual int vtkGlyph3DMapper::GetOrientationMode | ( | ) | [virtual] |
Orientation mode indicates if the OrientationArray provides the direction vector for the orientation or the rotations around each axes. Default is DIRECTION
| void vtkGlyph3DMapper::SetOrientationModeToDirection | ( | ) | [inline] |
Orientation mode indicates if the OrientationArray provides the direction vector for the orientation or the rotations around each axes. Default is DIRECTION
Definition at line 135 of file vtkGlyph3DMapper.h.
| void vtkGlyph3DMapper::SetOrientationModeToRotation | ( | ) | [inline] |
Orientation mode indicates if the OrientationArray provides the direction vector for the orientation or the rotations around each axes. Default is DIRECTION
Definition at line 137 of file vtkGlyph3DMapper.h.
| const char* vtkGlyph3DMapper::GetOrientationModeAsString | ( | ) |
Orientation mode indicates if the OrientationArray provides the direction vector for the orientation or the rotations around each axes. Default is DIRECTION
| virtual void vtkGlyph3DMapper::SetClamping | ( | bool | ) | [virtual] |
Turn on/off clamping of data values to scale with to the specified range.
| virtual bool vtkGlyph3DMapper::GetClamping | ( | ) | [virtual] |
Turn on/off clamping of data values to scale with to the specified range.
| virtual void vtkGlyph3DMapper::ClampingOn | ( | ) | [virtual] |
Turn on/off clamping of data values to scale with to the specified range.
| virtual void vtkGlyph3DMapper::ClampingOff | ( | ) | [virtual] |
Turn on/off clamping of data values to scale with to the specified range.
| virtual void vtkGlyph3DMapper::SetSourceIndexing | ( | bool | ) | [virtual] |
Enable/disable indexing into table of the glyph sources. When disabled, only the 1st source input will be used to generate the glyph. Otherwise the source index array will be used to select the glyph source. The source index array can be specified using SetSourceIndexArray().
| virtual bool vtkGlyph3DMapper::GetSourceIndexing | ( | ) | [virtual] |
Enable/disable indexing into table of the glyph sources. When disabled, only the 1st source input will be used to generate the glyph. Otherwise the source index array will be used to select the glyph source. The source index array can be specified using SetSourceIndexArray().
| virtual void vtkGlyph3DMapper::SourceIndexingOn | ( | ) | [virtual] |
Enable/disable indexing into table of the glyph sources. When disabled, only the 1st source input will be used to generate the glyph. Otherwise the source index array will be used to select the glyph source. The source index array can be specified using SetSourceIndexArray().
| virtual void vtkGlyph3DMapper::SourceIndexingOff | ( | ) | [virtual] |
Enable/disable indexing into table of the glyph sources. When disabled, only the 1st source input will be used to generate the glyph. Otherwise the source index array will be used to select the glyph source. The source index array can be specified using SetSourceIndexArray().
| virtual double* vtkGlyph3DMapper::GetBounds | ( | ) | [virtual] |
Redefined to take into account the bounds of the scaled glyphs.
Reimplemented from vtkMapper.
| virtual void vtkGlyph3DMapper::GetBounds | ( | double | bounds[6] | ) | [virtual] |
Same as superclass. Appear again to stop warnings about hidden method.
Reimplemented from vtkMapper.
| virtual void vtkGlyph3DMapper::Render | ( | vtkRenderer * | ren, | |
| vtkActor * | act | |||
| ) | [virtual] |
All the work is done is derived classes.
Implements vtkMapper.
Reimplemented in vtkOpenGLGlyph3DMapper.
| virtual void vtkGlyph3DMapper::SetNestedDisplayLists | ( | bool | ) | [virtual] |
If immediate mode is off, if NestedDisplayLists is false, only the mappers of each glyph use display lists. If true, in addition, matrices transforms and color per glyph are also in a parent display list. Not relevant if immediate mode is on. For debugging/profiling purpose. Initial value is true.
| virtual bool vtkGlyph3DMapper::GetNestedDisplayLists | ( | ) | [virtual] |
If immediate mode is off, if NestedDisplayLists is false, only the mappers of each glyph use display lists. If true, in addition, matrices transforms and color per glyph are also in a parent display list. Not relevant if immediate mode is on. For debugging/profiling purpose. Initial value is true.
| virtual void vtkGlyph3DMapper::NestedDisplayListsOn | ( | ) | [virtual] |
If immediate mode is off, if NestedDisplayLists is false, only the mappers of each glyph use display lists. If true, in addition, matrices transforms and color per glyph are also in a parent display list. Not relevant if immediate mode is on. For debugging/profiling purpose. Initial value is true.
| virtual void vtkGlyph3DMapper::NestedDisplayListsOff | ( | ) | [virtual] |
If immediate mode is off, if NestedDisplayLists is false, only the mappers of each glyph use display lists. If true, in addition, matrices transforms and color per glyph are also in a parent display list. Not relevant if immediate mode is on. For debugging/profiling purpose. Initial value is true.
| virtual void vtkGlyph3DMapper::SetMasking | ( | bool | ) | [virtual] |
Tells the mapper to skip glyphing input points that haves false values in the mask array. If there is no mask array (id access mode is set and there is no such id, or array name access mode is set and the there is no such name), masking is silently ignored. A mask array is a vtkBitArray with only one component. Initial value is false.
| virtual bool vtkGlyph3DMapper::GetMasking | ( | ) | [virtual] |
Tells the mapper to skip glyphing input points that haves false values in the mask array. If there is no mask array (id access mode is set and there is no such id, or array name access mode is set and the there is no such name), masking is silently ignored. A mask array is a vtkBitArray with only one component. Initial value is false.
| virtual void vtkGlyph3DMapper::MaskingOn | ( | ) | [virtual] |
Tells the mapper to skip glyphing input points that haves false values in the mask array. If there is no mask array (id access mode is set and there is no such id, or array name access mode is set and the there is no such name), masking is silently ignored. A mask array is a vtkBitArray with only one component. Initial value is false.
| virtual void vtkGlyph3DMapper::MaskingOff | ( | ) | [virtual] |
Tells the mapper to skip glyphing input points that haves false values in the mask array. If there is no mask array (id access mode is set and there is no such id, or array name access mode is set and the there is no such name), masking is silently ignored. A mask array is a vtkBitArray with only one component. Initial value is false.
| void vtkGlyph3DMapper::SetMaskArray | ( | const char * | maskarrayname | ) |
Set the name of the point array to use as a mask for generating the glyphs. This is a convenience method. The same effect can be achieved by using SetInputArrayToProcess(vtkGlyph3DMapper::MASK, 0, 0, vtkDataObject::FIELD_ASSOCIATION_POINTS, maskarrayname)
| void vtkGlyph3DMapper::SetMaskArray | ( | int | fieldAttributeType | ) |
Set the point attribute to use as a mask for generating the glyphs. fieldAttributeType is one of the following:
- vtkDataSetAttributes::SCALARS
- vtkDataSetAttributes::VECTORS
- vtkDataSetAttributes::NORMALS
- vtkDataSetAttributes::TCOORDS
- vtkDataSetAttributes::TENSORS This is a convenience method. The same effect can be achieved by using SetInputArrayToProcess(vtkGlyph3DMapper::MASK, 0, 0, vtkDataObject::FIELD_ASSOCIATION_POINTS, fieldAttributeType)
| void vtkGlyph3DMapper::SetOrientationArray | ( | const char * | orientationarrayname | ) |
Tells the mapper to use an orientation array if Orient is true. An orientation array is a vtkDataArray with 3 components. The first component is the angle of rotation along the X axis. The second component is the angle of rotation along the Y axis. The third component is the angle of rotation along the Z axis. Orientation is specified in X,Y,Z order but the rotations are performed in Z,X an Y. This definition is compliant with SetOrientation method on vtkProp3D. By using vector or normal there is a degree of freedom or rotation left (underconstrained). With the orientation array, there is no degree of freedom left. This is convenience method. The same effect can be achieved by using SetInputArrayToProcess(vtkGlyph3DMapper::ORIENTATION, 0, 0, vtkDataObject::FIELD_ASSOCIATION_POINTS, orientationarrayname);
| void vtkGlyph3DMapper::SetOrientationArray | ( | int | fieldAttributeType | ) |
Tells the mapper to use an orientation array if Orient is true. An orientation array is a vtkDataArray with 3 components. The first component is the angle of rotation along the X axis. The second component is the angle of rotation along the Y axis. The third component is the angle of rotation along the Z axis. Orientation is specified in X,Y,Z order but the rotations are performed in Z,X an Y. This definition is compliant with SetOrientation method on vtkProp3D. By using vector or normal there is a degree of freedom or rotation left (underconstrained). With the orientation array, there is no degree of freedom left. fieldAttributeType is one of the following:
- vtkDataSetAttributes::SCALARS
- vtkDataSetAttributes::VECTORS
- vtkDataSetAttributes::NORMALS
- vtkDataSetAttributes::TCOORDS
- vtkDataSetAttributes::TENSORS This is convenience method. The same effect can be achieved by using SetInputArrayToProcess(vtkGlyph3DMapper::ORIENTATION, 0, 0, vtkDataObject::FIELD_ASSOCIATION_POINTS, fieldAttributeType);
| void vtkGlyph3DMapper::SetScaleArray | ( | const char * | scalarsarrayname | ) |
Convenience method to set the array to scale with. This is same as calling SetInputArrayToProcess(vtkGlyph3DMapper::SCALE, 0, 0, vtkDataObject::FIELD_ASSOCIATION_POINTS, scalarsarrayname).
| void vtkGlyph3DMapper::SetScaleArray | ( | int | fieldAttributeType | ) |
Convenience method to set the array to scale with. This is same as calling SetInputArrayToProcess(vtkGlyph3DMapper::SCALE, 0, 0, vtkDataObject::FIELD_ASSOCIATION_POINTS, fieldAttributeType).
| void vtkGlyph3DMapper::SetSourceIndexArray | ( | const char * | arrayname | ) |
Convenience method to set the array to use as index within the sources. This is same as calling SetInputArrayToProcess(vtkGlyph3DMapper::SOURCE_INDEX, 0, 0, vtkDataObject::FIELD_ASSOCIATION_POINTS, arrayname).
| void vtkGlyph3DMapper::SetSourceIndexArray | ( | int | fieldAttributeType | ) |
Convenience method to set the array to use as index within the sources. This is same as calling SetInputArrayToProcess(vtkGlyph3DMapper::SOURCE_INDEX, 0, 0, vtkDataObject::FIELD_ASSOCIATION_POINTS, fieldAttributeType).
| virtual void vtkGlyph3DMapper::SetSelectionColorId | ( | unsigned | int | ) | [virtual] |
For selection by color id mode (not for end-user, called by vtkGlyphSelectionRenderMode). 0 is reserved for miss. it has to start at 1. Initial value is 1.
| virtual unsigned int vtkGlyph3DMapper::GetSelectionColorId | ( | ) | [virtual] |
For selection by color id mode (not for end-user, called by vtkGlyphSelectionRenderMode). 0 is reserved for miss. it has to start at 1. Initial value is 1.
| virtual void vtkGlyph3DMapper::SetSelectMode | ( | int | ) | [virtual] |
Called by vtkGlyphSelectionRenderMode.
| virtual bool vtkGlyph3DMapper::GetSupportsSelection | ( | ) | [inline, virtual] |
WARNING: INTERNAL METHOD - NOT INTENDED FOR GENERAL USE DO NOT USE THIS METHOD OUTSIDE OF THE RENDERING PROCESS Used by vtkHardwareSelector to determine if the prop supports hardware selection.
Reimplemented from vtkMapper.
Definition at line 289 of file vtkGlyph3DMapper.h.
| virtual int vtkGlyph3DMapper::RequestUpdateExtent | ( | vtkInformation * | request, | |
| vtkInformationVector ** | inInfo, | |||
| vtkInformationVector * | outInfo | |||
| ) | [protected, virtual] |
| virtual int vtkGlyph3DMapper::FillInputPortInformation | ( | int | port, | |
| vtkInformation * | info | |||
| ) | [protected, virtual] |
Fill the input port information objects for this algorithm. This is invoked by the first call to GetInputPortInformation for each port so subclasses can specify what they can handle.
Reimplemented from vtkAlgorithm.
| vtkPolyData* vtkGlyph3DMapper::GetSource | ( | int | idx, | |
| vtkInformationVector * | sourceInfo | |||
| ) | [protected] |
| vtkDataArray* vtkGlyph3DMapper::GetMaskArray | ( | vtkDataSet * | input | ) | [protected] |
Convenience methods to get each of the arrays.
| vtkDataArray* vtkGlyph3DMapper::GetSourceIndexArray | ( | vtkDataSet * | input | ) | [protected] |
Convenience methods to get each of the arrays.
| vtkDataArray* vtkGlyph3DMapper::GetOrientationArray | ( | vtkDataSet * | input | ) | [protected] |
Convenience methods to get each of the arrays.
| vtkDataArray* vtkGlyph3DMapper::GetScaleArray | ( | vtkDataSet * | input | ) | [protected] |
Convenience methods to get each of the arrays.
| vtkUnsignedCharArray* vtkGlyph3DMapper::GetColors | ( | vtkDataSet * | input | ) | [protected] |
Convenience methods to get each of the arrays.
Member Data Documentation
bool vtkGlyph3DMapper::Scaling [protected] |
Definition at line 315 of file vtkGlyph3DMapper.h.
double vtkGlyph3DMapper::ScaleFactor [protected] |
Definition at line 316 of file vtkGlyph3DMapper.h.
int vtkGlyph3DMapper::ScaleMode [protected] |
Definition at line 317 of file vtkGlyph3DMapper.h.
double vtkGlyph3DMapper::Range[2] [protected] |
Definition at line 319 of file vtkGlyph3DMapper.h.
bool vtkGlyph3DMapper::Orient [protected] |
Definition at line 320 of file vtkGlyph3DMapper.h.
bool vtkGlyph3DMapper::Clamping [protected] |
Definition at line 321 of file vtkGlyph3DMapper.h.
bool vtkGlyph3DMapper::SourceIndexing [protected] |
Definition at line 322 of file vtkGlyph3DMapper.h.
bool vtkGlyph3DMapper::Masking [protected] |
Definition at line 323 of file vtkGlyph3DMapper.h.
int vtkGlyph3DMapper::OrientationMode [protected] |
Definition at line 324 of file vtkGlyph3DMapper.h.
bool vtkGlyph3DMapper::NestedDisplayLists [protected] |
Definition at line 325 of file vtkGlyph3DMapper.h.
unsigned int vtkGlyph3DMapper::SelectionColorId [protected] |
Definition at line 327 of file vtkGlyph3DMapper.h.
int vtkGlyph3DMapper::SelectMode [protected] |
Definition at line 328 of file vtkGlyph3DMapper.h.
The documentation for this class was generated from the following file:
- dox/Rendering/vtkGlyph3DMapper.h
