abstract class defines interface between the widget and widget representation classes More...
#include <vtkWidgetRepresentation.h>
Detailed Description
abstract class defines interface between the widget and widget representation classes
This class is used to define the API for, and partially implement, a representation for different types of widgets. Note that the widget representation (i.e., subclasses of vtkWidgetRepresentation) are a type of vtkProp; meaning that they can be associated with a vtkRenderer end embedded in a scene like any other vtkActor. However, vtkWidgetRepresentation also defines an API that enables it to be paired with a subclass vtkAbstractWidget, meaning that it can be driven by a widget, serving to represent the widget as the widget responds to registered events.
The API defined here should be regarded as a guideline for implementing widgets and widget representations. Widget behavior is complex, as is the way the representation responds to the registered widget events, so the API may vary from widget to widget to reflect this complexity.
- Warning:
- The separation of the widget event handling and representation enables users and developers to create new appearances for the widget. It also facilitates parallel processing, where the client application handles events, and remote representations of the widget are slaves to the client (and do not handle events).
Definition at line 53 of file vtkWidgetRepresentation.h.
Member Typedef Documentation
Standard methods for instances of this class.
Reimplemented from vtkProp.
Reimplemented in vtkContourRepresentation, vtkBalloonRepresentation, vtkSphereRepresentation, vtkTexturedButtonRepresentation, vtkImplicitPlaneRepresentation, vtkAffineRepresentation2D, vtkBoxRepresentation, vtkTexturedButtonRepresentation2D, vtkBiDimensionalRepresentation2D, vtkCenteredSliderRepresentation, vtkLineRepresentation, vtkSliderRepresentation2D, vtkBorderRepresentation, vtkConstrainedPointHandleRepresentation, vtkRectilinearWipeRepresentation, vtkCompassRepresentation, vtkHandleRepresentation, vtkSliderRepresentation3D, vtkParallelopipedRepresentation, vtkProp3DButtonRepresentation, vtkAxesTransformRepresentation, vtkCameraRepresentation, vtkDistanceRepresentation3D, vtkAbstractPolygonalHandleRepresentation3D, vtkCaptionRepresentation, vtkResliceCursorLineRepresentation, vtkAngleRepresentation3D, vtkSplineRepresentation, vtkBiDimensionalRepresentation, vtkScalarBarRepresentation, vtkLogoRepresentation, vtkPointHandleRepresentation2D, vtkResliceCursorRepresentation, vtkAngleRepresentation2D, vtkDistanceRepresentation2D, vtkOrientedGlyphFocalPlaneContourRepresentation, vtkCheckerboardRepresentation, vtkFixedSizeHandleRepresentation3D, vtkButtonRepresentation, vtkPlaybackRepresentation, vtkAffineRepresentation, vtkOrientedGlyphContourRepresentation, vtkSphereHandleRepresentation, vtkPointHandleRepresentation3D, vtkOrientedPolygonalHandleRepresentation3D, vtkSliderRepresentation, vtkResliceCursorThickLineRepresentation, vtkSeedRepresentation, vtkTextRepresentation, vtkTensorProbeRepresentation, vtkEllipsoidTensorProbeRepresentation, vtkPolygonalHandleRepresentation3D, vtkFocalPlaneContourRepresentation, vtkAngleRepresentation, vtkXYPlotRepresentation, vtkContinuousValueWidgetRepresentation, and vtkDistanceRepresentation.
Definition at line 58 of file vtkWidgetRepresentation.h.
Constructor & Destructor Documentation
| vtkWidgetRepresentation::vtkWidgetRepresentation | ( | ) | [protected] |
| vtkWidgetRepresentation::~vtkWidgetRepresentation | ( | ) | [protected] |
Member Function Documentation
| static int vtkWidgetRepresentation::IsTypeOf | ( | const char * | type | ) | [static] |
Standard methods for instances of this class.
Reimplemented from vtkProp.
Reimplemented in vtkContourRepresentation, vtkBalloonRepresentation, vtkSphereRepresentation, vtkTexturedButtonRepresentation, vtkImplicitPlaneRepresentation, vtkAffineRepresentation2D, vtkBoxRepresentation, vtkTexturedButtonRepresentation2D, vtkBiDimensionalRepresentation2D, vtkCenteredSliderRepresentation, vtkLineRepresentation, vtkSliderRepresentation2D, vtkBorderRepresentation, vtkConstrainedPointHandleRepresentation, vtkRectilinearWipeRepresentation, vtkCompassRepresentation, vtkHandleRepresentation, vtkSliderRepresentation3D, vtkParallelopipedRepresentation, vtkProp3DButtonRepresentation, vtkAxesTransformRepresentation, vtkCameraRepresentation, vtkDistanceRepresentation3D, vtkAbstractPolygonalHandleRepresentation3D, vtkCaptionRepresentation, vtkResliceCursorLineRepresentation, vtkAngleRepresentation3D, vtkSplineRepresentation, vtkBiDimensionalRepresentation, vtkScalarBarRepresentation, vtkLogoRepresentation, vtkPointHandleRepresentation2D, vtkResliceCursorRepresentation, vtkAngleRepresentation2D, vtkDistanceRepresentation2D, vtkOrientedGlyphFocalPlaneContourRepresentation, vtkCheckerboardRepresentation, vtkFixedSizeHandleRepresentation3D, vtkButtonRepresentation, vtkPlaybackRepresentation, vtkAffineRepresentation, vtkOrientedGlyphContourRepresentation, vtkSphereHandleRepresentation, vtkPointHandleRepresentation3D, vtkOrientedPolygonalHandleRepresentation3D, vtkSliderRepresentation, vtkResliceCursorThickLineRepresentation, vtkSeedRepresentation, vtkTextRepresentation, vtkTensorProbeRepresentation, vtkEllipsoidTensorProbeRepresentation, vtkPolygonalHandleRepresentation3D, vtkFocalPlaneContourRepresentation, vtkAngleRepresentation, vtkXYPlotRepresentation, vtkContinuousValueWidgetRepresentation, and vtkDistanceRepresentation.
| virtual int vtkWidgetRepresentation::IsA | ( | const char * | type | ) | [virtual] |
Standard methods for instances of this class.
Reimplemented from vtkProp.
Reimplemented in vtkContourRepresentation, vtkBalloonRepresentation, vtkSphereRepresentation, vtkTexturedButtonRepresentation, vtkImplicitPlaneRepresentation, vtkAffineRepresentation2D, vtkBoxRepresentation, vtkTexturedButtonRepresentation2D, vtkBiDimensionalRepresentation2D, vtkCenteredSliderRepresentation, vtkLineRepresentation, vtkSliderRepresentation2D, vtkBorderRepresentation, vtkConstrainedPointHandleRepresentation, vtkRectilinearWipeRepresentation, vtkCompassRepresentation, vtkHandleRepresentation, vtkSliderRepresentation3D, vtkParallelopipedRepresentation, vtkProp3DButtonRepresentation, vtkAxesTransformRepresentation, vtkCameraRepresentation, vtkDistanceRepresentation3D, vtkAbstractPolygonalHandleRepresentation3D, vtkCaptionRepresentation, vtkResliceCursorLineRepresentation, vtkAngleRepresentation3D, vtkSplineRepresentation, vtkBiDimensionalRepresentation, vtkScalarBarRepresentation, vtkLogoRepresentation, vtkPointHandleRepresentation2D, vtkResliceCursorRepresentation, vtkAngleRepresentation2D, vtkDistanceRepresentation2D, vtkOrientedGlyphFocalPlaneContourRepresentation, vtkCheckerboardRepresentation, vtkFixedSizeHandleRepresentation3D, vtkButtonRepresentation, vtkPlaybackRepresentation, vtkAffineRepresentation, vtkOrientedGlyphContourRepresentation, vtkSphereHandleRepresentation, vtkPointHandleRepresentation3D, vtkOrientedPolygonalHandleRepresentation3D, vtkSliderRepresentation, vtkResliceCursorThickLineRepresentation, vtkSeedRepresentation, vtkTextRepresentation, vtkTensorProbeRepresentation, vtkEllipsoidTensorProbeRepresentation, vtkPolygonalHandleRepresentation3D, vtkFocalPlaneContourRepresentation, vtkAngleRepresentation, vtkXYPlotRepresentation, vtkContinuousValueWidgetRepresentation, and vtkDistanceRepresentation.
| static vtkWidgetRepresentation* vtkWidgetRepresentation::SafeDownCast | ( | vtkObjectBase * | o | ) | [static] |
Standard methods for instances of this class.
Reimplemented from vtkProp.
Reimplemented in vtkContourRepresentation, vtkBalloonRepresentation, vtkSphereRepresentation, vtkTexturedButtonRepresentation, vtkImplicitPlaneRepresentation, vtkAffineRepresentation2D, vtkBoxRepresentation, vtkTexturedButtonRepresentation2D, vtkBiDimensionalRepresentation2D, vtkCenteredSliderRepresentation, vtkLineRepresentation, vtkSliderRepresentation2D, vtkBorderRepresentation, vtkConstrainedPointHandleRepresentation, vtkRectilinearWipeRepresentation, vtkCompassRepresentation, vtkHandleRepresentation, vtkSliderRepresentation3D, vtkParallelopipedRepresentation, vtkProp3DButtonRepresentation, vtkAxesTransformRepresentation, vtkCameraRepresentation, vtkDistanceRepresentation3D, vtkAbstractPolygonalHandleRepresentation3D, vtkCaptionRepresentation, vtkResliceCursorLineRepresentation, vtkAngleRepresentation3D, vtkSplineRepresentation, vtkBiDimensionalRepresentation, vtkScalarBarRepresentation, vtkLogoRepresentation, vtkPointHandleRepresentation2D, vtkResliceCursorRepresentation, vtkAngleRepresentation2D, vtkDistanceRepresentation2D, vtkOrientedGlyphFocalPlaneContourRepresentation, vtkCheckerboardRepresentation, vtkFixedSizeHandleRepresentation3D, vtkButtonRepresentation, vtkPlaybackRepresentation, vtkAffineRepresentation, vtkOrientedGlyphContourRepresentation, vtkSphereHandleRepresentation, vtkPointHandleRepresentation3D, vtkOrientedPolygonalHandleRepresentation3D, vtkSliderRepresentation, vtkResliceCursorThickLineRepresentation, vtkSeedRepresentation, vtkTextRepresentation, vtkTensorProbeRepresentation, vtkEllipsoidTensorProbeRepresentation, vtkPolygonalHandleRepresentation3D, vtkFocalPlaneContourRepresentation, vtkAngleRepresentation, vtkXYPlotRepresentation, vtkContinuousValueWidgetRepresentation, and vtkDistanceRepresentation.
| virtual vtkObjectBase* vtkWidgetRepresentation::NewInstanceInternal | ( | ) | const [protected, virtual] |
Standard methods for instances of this class.
Reimplemented from vtkProp.
Reimplemented in vtkContourRepresentation, vtkBalloonRepresentation, vtkSphereRepresentation, vtkTexturedButtonRepresentation, vtkImplicitPlaneRepresentation, vtkAffineRepresentation2D, vtkBoxRepresentation, vtkTexturedButtonRepresentation2D, vtkBiDimensionalRepresentation2D, vtkCenteredSliderRepresentation, vtkLineRepresentation, vtkSliderRepresentation2D, vtkBorderRepresentation, vtkConstrainedPointHandleRepresentation, vtkRectilinearWipeRepresentation, vtkCompassRepresentation, vtkHandleRepresentation, vtkSliderRepresentation3D, vtkParallelopipedRepresentation, vtkProp3DButtonRepresentation, vtkAxesTransformRepresentation, vtkCameraRepresentation, vtkDistanceRepresentation3D, vtkAbstractPolygonalHandleRepresentation3D, vtkCaptionRepresentation, vtkResliceCursorLineRepresentation, vtkAngleRepresentation3D, vtkSplineRepresentation, vtkBiDimensionalRepresentation, vtkScalarBarRepresentation, vtkLogoRepresentation, vtkPointHandleRepresentation2D, vtkResliceCursorRepresentation, vtkAngleRepresentation2D, vtkDistanceRepresentation2D, vtkOrientedGlyphFocalPlaneContourRepresentation, vtkCheckerboardRepresentation, vtkFixedSizeHandleRepresentation3D, vtkButtonRepresentation, vtkPlaybackRepresentation, vtkAffineRepresentation, vtkOrientedGlyphContourRepresentation, vtkSphereHandleRepresentation, vtkPointHandleRepresentation3D, vtkOrientedPolygonalHandleRepresentation3D, vtkSliderRepresentation, vtkResliceCursorThickLineRepresentation, vtkSeedRepresentation, vtkTextRepresentation, vtkTensorProbeRepresentation, vtkEllipsoidTensorProbeRepresentation, vtkPolygonalHandleRepresentation3D, vtkFocalPlaneContourRepresentation, vtkAngleRepresentation, vtkXYPlotRepresentation, vtkContinuousValueWidgetRepresentation, and vtkDistanceRepresentation.
Standard methods for instances of this class.
Reimplemented from vtkProp.
Reimplemented in vtkContourRepresentation, vtkBalloonRepresentation, vtkSphereRepresentation, vtkTexturedButtonRepresentation, vtkImplicitPlaneRepresentation, vtkAffineRepresentation2D, vtkBoxRepresentation, vtkTexturedButtonRepresentation2D, vtkBiDimensionalRepresentation2D, vtkCenteredSliderRepresentation, vtkLineRepresentation, vtkSliderRepresentation2D, vtkBorderRepresentation, vtkConstrainedPointHandleRepresentation, vtkRectilinearWipeRepresentation, vtkCompassRepresentation, vtkHandleRepresentation, vtkSliderRepresentation3D, vtkParallelopipedRepresentation, vtkProp3DButtonRepresentation, vtkAxesTransformRepresentation, vtkCameraRepresentation, vtkDistanceRepresentation3D, vtkAbstractPolygonalHandleRepresentation3D, vtkCaptionRepresentation, vtkResliceCursorLineRepresentation, vtkAngleRepresentation3D, vtkSplineRepresentation, vtkBiDimensionalRepresentation, vtkScalarBarRepresentation, vtkLogoRepresentation, vtkPointHandleRepresentation2D, vtkResliceCursorRepresentation, vtkAngleRepresentation2D, vtkDistanceRepresentation2D, vtkOrientedGlyphFocalPlaneContourRepresentation, vtkCheckerboardRepresentation, vtkFixedSizeHandleRepresentation3D, vtkButtonRepresentation, vtkPlaybackRepresentation, vtkAffineRepresentation, vtkOrientedGlyphContourRepresentation, vtkSphereHandleRepresentation, vtkPointHandleRepresentation3D, vtkOrientedPolygonalHandleRepresentation3D, vtkSliderRepresentation, vtkResliceCursorThickLineRepresentation, vtkSeedRepresentation, vtkTextRepresentation, vtkTensorProbeRepresentation, vtkEllipsoidTensorProbeRepresentation, vtkPolygonalHandleRepresentation3D, vtkFocalPlaneContourRepresentation, vtkAngleRepresentation, vtkXYPlotRepresentation, vtkContinuousValueWidgetRepresentation, and vtkDistanceRepresentation.
| void vtkWidgetRepresentation::PrintSelf | ( | ostream & | os, |
| vtkIndent | indent | ||
| ) | [virtual] |
Standard methods for instances of this class.
Reimplemented from vtkProp.
Reimplemented in vtkContourRepresentation, vtkBalloonRepresentation, vtkSphereRepresentation, vtkTexturedButtonRepresentation, vtkImplicitPlaneRepresentation, vtkAffineRepresentation2D, vtkBoxRepresentation, vtkTexturedButtonRepresentation2D, vtkBiDimensionalRepresentation2D, vtkCenteredSliderRepresentation, vtkLineRepresentation, vtkSliderRepresentation2D, vtkBorderRepresentation, vtkConstrainedPointHandleRepresentation, vtkRectilinearWipeRepresentation, vtkCompassRepresentation, vtkHandleRepresentation, vtkSliderRepresentation3D, vtkParallelopipedRepresentation, vtkProp3DButtonRepresentation, vtkAxesTransformRepresentation, vtkCameraRepresentation, vtkDistanceRepresentation3D, vtkAbstractPolygonalHandleRepresentation3D, vtkCaptionRepresentation, vtkResliceCursorLineRepresentation, vtkAngleRepresentation3D, vtkSplineRepresentation, vtkBiDimensionalRepresentation, vtkScalarBarRepresentation, vtkLogoRepresentation, vtkPointHandleRepresentation2D, vtkResliceCursorRepresentation, vtkAngleRepresentation2D, vtkDistanceRepresentation2D, vtkOrientedGlyphFocalPlaneContourRepresentation, vtkCheckerboardRepresentation, vtkFixedSizeHandleRepresentation3D, vtkButtonRepresentation, vtkPlaybackRepresentation, vtkAffineRepresentation, vtkOrientedGlyphContourRepresentation, vtkSphereHandleRepresentation, vtkPointHandleRepresentation3D, vtkOrientedPolygonalHandleRepresentation3D, vtkSliderRepresentation, vtkResliceCursorThickLineRepresentation, vtkSeedRepresentation, vtkTextRepresentation, vtkTensorProbeRepresentation, vtkEllipsoidTensorProbeRepresentation, vtkPolygonalHandleRepresentation3D, vtkFocalPlaneContourRepresentation, vtkAngleRepresentation, vtkXYPlotRepresentation, vtkContinuousValueWidgetRepresentation, and vtkDistanceRepresentation.
| virtual void vtkWidgetRepresentation::PickingManagedOn | ( | ) | [virtual] |
Enable/Disable the use of a manager to process the picking. Enabled by default.
| virtual void vtkWidgetRepresentation::PickingManagedOff | ( | ) | [virtual] |
Enable/Disable the use of a manager to process the picking. Enabled by default.
| virtual void vtkWidgetRepresentation::SetPickingManaged | ( | bool | ) | [virtual] |
Enable/Disable the use of a manager to process the picking. Enabled by default.
| virtual bool vtkWidgetRepresentation::GetPickingManaged | ( | ) | [virtual] |
Enable/Disable the use of a manager to process the picking. Enabled by default.
| virtual void vtkWidgetRepresentation::SetRenderer | ( | vtkRenderer * | ren | ) | [virtual] |
Subclasses of vtkWidgetRepresentation must implement these methods. This is considered the minimum API for a widget representation.
SetRenderer() - the renderer in which the widget is to appear must be
set. BuildRepresentation() - update the geometry of the widget based
on its current state. WARNING: The renderer is NOT reference counted by the representation, in order to avoid reference loops. Be sure that the representation lifetime does not extend beyond the renderer lifetime.
Reimplemented in vtkLineRepresentation, vtkConstrainedPointHandleRepresentation, vtkHandleRepresentation, vtkCompassRepresentation, vtkOrientedGlyphFocalPlaneContourRepresentation, and vtkOrientedGlyphContourRepresentation.
| virtual vtkRenderer* vtkWidgetRepresentation::GetRenderer | ( | ) | [virtual] |
Subclasses of vtkWidgetRepresentation must implement these methods. This is considered the minimum API for a widget representation.
SetRenderer() - the renderer in which the widget is to appear must be
set. BuildRepresentation() - update the geometry of the widget based
on its current state. WARNING: The renderer is NOT reference counted by the representation, in order to avoid reference loops. Be sure that the representation lifetime does not extend beyond the renderer lifetime.
| virtual void vtkWidgetRepresentation::BuildRepresentation | ( | ) | [pure virtual] |
Subclasses of vtkWidgetRepresentation must implement these methods. This is considered the minimum API for a widget representation.
SetRenderer() - the renderer in which the widget is to appear must be
set. BuildRepresentation() - update the geometry of the widget based
on its current state. WARNING: The renderer is NOT reference counted by the representation, in order to avoid reference loops. Be sure that the representation lifetime does not extend beyond the renderer lifetime.
Implemented in vtkContourRepresentation, vtkSphereRepresentation, vtkImplicitPlaneRepresentation, vtkSplineRepresentation, vtkBalloonRepresentation, vtkConstrainedPointHandleRepresentation, vtkPointHandleRepresentation3D, vtkBorderRepresentation, vtkBoxRepresentation, vtkLineRepresentation, vtkAffineRepresentation2D, vtkParallelopipedRepresentation, vtkDistanceRepresentation, vtkSliderRepresentation3D, vtkTexturedButtonRepresentation, vtkAngleRepresentation, vtkDistanceRepresentation3D, vtkSliderRepresentation2D, vtkAxesTransformRepresentation, vtkSeedRepresentation, vtkCenteredSliderRepresentation, vtkResliceCursorRepresentation, vtkTexturedButtonRepresentation2D, vtkCheckerboardRepresentation, vtkCompassRepresentation, vtkCameraRepresentation, vtkSphereHandleRepresentation, vtkAngleRepresentation3D, vtkRectilinearWipeRepresentation, vtkOrientedGlyphFocalPlaneContourRepresentation, vtkOrientedGlyphContourRepresentation, vtkBiDimensionalRepresentation2D, vtkDistanceRepresentation2D, vtkAbstractPolygonalHandleRepresentation3D, vtkCaptionRepresentation, vtkProp3DButtonRepresentation, vtkAngleRepresentation2D, vtkPointHandleRepresentation2D, vtkFixedSizeHandleRepresentation3D, vtkPlaybackRepresentation, vtkLogoRepresentation, vtkScalarBarRepresentation, vtkTextRepresentation, vtkResliceCursorLineRepresentation, vtkXYPlotRepresentation, vtkTensorProbeRepresentation, vtkContinuousValueWidgetRepresentation, and vtkEllipsoidTensorProbeRepresentation.
| virtual void vtkWidgetRepresentation::PlaceWidget | ( | double * | vtkNotUsedbounds[6] | ) | [inline, virtual] |
The following is a suggested API for widget representations. These methods define the communication between the widget and its representation. These methods are only suggestions because widgets take on so many different forms that a universal API is not deemed practical. However, these methods should be implemented when possible to insure that the VTK widget hierarchy remains self-consistent.
PlaceWidget() - given a bounding box (xmin,xmax,ymin,ymax,zmin,zmax), place the widget inside of it. The current orientation of the widget is preserved, only scaling and translation is performed. StartWidgetInteraction() - generally corresponds to a initial event (e.g., mouse down) that starts the interaction process with the widget. WidgetInteraction() - invoked when an event causes the widget to change appearance. EndWidgetInteraction() - generally corresponds to a final event (e.g., mouse up) and completes the interaction sequence. ComputeInteractionState() - given (X,Y) display coordinates in a renderer, with a possible flag that modifies the computation, what is the state of the widget? GetInteractionState() - return the current state of the widget. Note that the value of "0" typically refers to "outside". The interaction state is strictly a function of the representation, and the widget/represent must agree on what they mean. Highlight() - turn on or off any highlights associated with the widget. Highlights are generally turned on when the widget is selected.
Note that subclasses may ignore some of these methods and implement their own depending on the specifics of the widget.
Definition at line 111 of file vtkWidgetRepresentation.h.
| virtual void vtkWidgetRepresentation::StartWidgetInteraction | ( | double | eventPos[2] | ) | [inline, virtual] |
The following is a suggested API for widget representations. These methods define the communication between the widget and its representation. These methods are only suggestions because widgets take on so many different forms that a universal API is not deemed practical. However, these methods should be implemented when possible to insure that the VTK widget hierarchy remains self-consistent.
PlaceWidget() - given a bounding box (xmin,xmax,ymin,ymax,zmin,zmax), place the widget inside of it. The current orientation of the widget is preserved, only scaling and translation is performed. StartWidgetInteraction() - generally corresponds to a initial event (e.g., mouse down) that starts the interaction process with the widget. WidgetInteraction() - invoked when an event causes the widget to change appearance. EndWidgetInteraction() - generally corresponds to a final event (e.g., mouse up) and completes the interaction sequence. ComputeInteractionState() - given (X,Y) display coordinates in a renderer, with a possible flag that modifies the computation, what is the state of the widget? GetInteractionState() - return the current state of the widget. Note that the value of "0" typically refers to "outside". The interaction state is strictly a function of the representation, and the widget/represent must agree on what they mean. Highlight() - turn on or off any highlights associated with the widget. Highlights are generally turned on when the widget is selected.
Note that subclasses may ignore some of these methods and implement their own depending on the specifics of the widget.
Reimplemented in vtkContourRepresentation, vtkSphereRepresentation, vtkImplicitPlaneRepresentation, vtkSplineRepresentation, vtkConstrainedPointHandleRepresentation, vtkBalloonRepresentation, vtkPointHandleRepresentation3D, vtkBorderRepresentation, vtkBoxRepresentation, vtkLineRepresentation, vtkDistanceRepresentation, vtkAffineRepresentation2D, vtkSliderRepresentation3D, vtkAngleRepresentation, vtkSliderRepresentation2D, vtkAxesTransformRepresentation, vtkCenteredSliderRepresentation, vtkCompassRepresentation, vtkSphereHandleRepresentation, vtkRectilinearWipeRepresentation, vtkOrientedGlyphFocalPlaneContourRepresentation, vtkOrientedGlyphContourRepresentation, vtkAbstractPolygonalHandleRepresentation3D, vtkPointHandleRepresentation2D, vtkResliceCursorLineRepresentation, and vtkContinuousValueWidgetRepresentation.
Definition at line 112 of file vtkWidgetRepresentation.h.
| virtual void vtkWidgetRepresentation::WidgetInteraction | ( | double | newEventPos[2] | ) | [inline, virtual] |
The following is a suggested API for widget representations. These methods define the communication between the widget and its representation. These methods are only suggestions because widgets take on so many different forms that a universal API is not deemed practical. However, these methods should be implemented when possible to insure that the VTK widget hierarchy remains self-consistent.
PlaceWidget() - given a bounding box (xmin,xmax,ymin,ymax,zmin,zmax), place the widget inside of it. The current orientation of the widget is preserved, only scaling and translation is performed. StartWidgetInteraction() - generally corresponds to a initial event (e.g., mouse down) that starts the interaction process with the widget. WidgetInteraction() - invoked when an event causes the widget to change appearance. EndWidgetInteraction() - generally corresponds to a final event (e.g., mouse up) and completes the interaction sequence. ComputeInteractionState() - given (X,Y) display coordinates in a renderer, with a possible flag that modifies the computation, what is the state of the widget? GetInteractionState() - return the current state of the widget. Note that the value of "0" typically refers to "outside". The interaction state is strictly a function of the representation, and the widget/represent must agree on what they mean. Highlight() - turn on or off any highlights associated with the widget. Highlights are generally turned on when the widget is selected.
Note that subclasses may ignore some of these methods and implement their own depending on the specifics of the widget.
Reimplemented in vtkContourRepresentation, vtkSphereRepresentation, vtkImplicitPlaneRepresentation, vtkSplineRepresentation, vtkConstrainedPointHandleRepresentation, vtkPointHandleRepresentation3D, vtkBorderRepresentation, vtkBoxRepresentation, vtkLineRepresentation, vtkDistanceRepresentation, vtkAffineRepresentation2D, vtkSliderRepresentation3D, vtkAngleRepresentation, vtkSliderRepresentation2D, vtkAxesTransformRepresentation, vtkCenteredSliderRepresentation, vtkCompassRepresentation, vtkSphereHandleRepresentation, vtkRectilinearWipeRepresentation, vtkOrientedGlyphFocalPlaneContourRepresentation, vtkBiDimensionalRepresentation2D, vtkOrientedGlyphContourRepresentation, vtkAbstractPolygonalHandleRepresentation3D, vtkPointHandleRepresentation2D, vtkScalarBarRepresentation, vtkResliceCursorLineRepresentation, vtkXYPlotRepresentation, and vtkContinuousValueWidgetRepresentation.
Definition at line 113 of file vtkWidgetRepresentation.h.
| virtual void vtkWidgetRepresentation::EndWidgetInteraction | ( | double | newEventPos[2] | ) | [inline, virtual] |
The following is a suggested API for widget representations. These methods define the communication between the widget and its representation. These methods are only suggestions because widgets take on so many different forms that a universal API is not deemed practical. However, these methods should be implemented when possible to insure that the VTK widget hierarchy remains self-consistent.
PlaceWidget() - given a bounding box (xmin,xmax,ymin,ymax,zmin,zmax), place the widget inside of it. The current orientation of the widget is preserved, only scaling and translation is performed. StartWidgetInteraction() - generally corresponds to a initial event (e.g., mouse down) that starts the interaction process with the widget. WidgetInteraction() - invoked when an event causes the widget to change appearance. EndWidgetInteraction() - generally corresponds to a final event (e.g., mouse up) and completes the interaction sequence. ComputeInteractionState() - given (X,Y) display coordinates in a renderer, with a possible flag that modifies the computation, what is the state of the widget? GetInteractionState() - return the current state of the widget. Note that the value of "0" typically refers to "outside". The interaction state is strictly a function of the representation, and the widget/represent must agree on what they mean. Highlight() - turn on or off any highlights associated with the widget. Highlights are generally turned on when the widget is selected.
Note that subclasses may ignore some of these methods and implement their own depending on the specifics of the widget.
Reimplemented in vtkImplicitPlaneRepresentation, vtkSplineRepresentation, vtkBalloonRepresentation, and vtkAffineRepresentation2D.
Definition at line 114 of file vtkWidgetRepresentation.h.
| virtual int vtkWidgetRepresentation::ComputeInteractionState | ( | int | X, |
| int | Y, | ||
| int | modify = 0 |
||
| ) | [virtual] |
The following is a suggested API for widget representations. These methods define the communication between the widget and its representation. These methods are only suggestions because widgets take on so many different forms that a universal API is not deemed practical. However, these methods should be implemented when possible to insure that the VTK widget hierarchy remains self-consistent.
PlaceWidget() - given a bounding box (xmin,xmax,ymin,ymax,zmin,zmax), place the widget inside of it. The current orientation of the widget is preserved, only scaling and translation is performed. StartWidgetInteraction() - generally corresponds to a initial event (e.g., mouse down) that starts the interaction process with the widget. WidgetInteraction() - invoked when an event causes the widget to change appearance. EndWidgetInteraction() - generally corresponds to a final event (e.g., mouse up) and completes the interaction sequence. ComputeInteractionState() - given (X,Y) display coordinates in a renderer, with a possible flag that modifies the computation, what is the state of the widget? GetInteractionState() - return the current state of the widget. Note that the value of "0" typically refers to "outside". The interaction state is strictly a function of the representation, and the widget/represent must agree on what they mean. Highlight() - turn on or off any highlights associated with the widget. Highlights are generally turned on when the widget is selected.
Note that subclasses may ignore some of these methods and implement their own depending on the specifics of the widget.
Reimplemented in vtkContourRepresentation, vtkSphereRepresentation, vtkImplicitPlaneRepresentation, vtkSplineRepresentation, vtkBalloonRepresentation, vtkConstrainedPointHandleRepresentation, vtkPointHandleRepresentation3D, vtkBorderRepresentation, vtkBoxRepresentation, vtkLineRepresentation, vtkParallelopipedRepresentation, vtkAffineRepresentation2D, vtkDistanceRepresentation, vtkTexturedButtonRepresentation, vtkAngleRepresentation, vtkAxesTransformRepresentation, vtkCenteredSliderRepresentation, vtkSeedRepresentation, vtkCompassRepresentation, vtkSphereHandleRepresentation, vtkTexturedButtonRepresentation2D, vtkRectilinearWipeRepresentation, vtkOrientedGlyphFocalPlaneContourRepresentation, vtkOrientedGlyphContourRepresentation, vtkAbstractPolygonalHandleRepresentation3D, vtkBiDimensionalRepresentation2D, vtkPointHandleRepresentation2D, vtkProp3DButtonRepresentation, and vtkResliceCursorLineRepresentation.
| virtual int vtkWidgetRepresentation::GetInteractionState | ( | ) | [inline, virtual] |
The following is a suggested API for widget representations. These methods define the communication between the widget and its representation. These methods are only suggestions because widgets take on so many different forms that a universal API is not deemed practical. However, these methods should be implemented when possible to insure that the VTK widget hierarchy remains self-consistent.
PlaceWidget() - given a bounding box (xmin,xmax,ymin,ymax,zmin,zmax), place the widget inside of it. The current orientation of the widget is preserved, only scaling and translation is performed. StartWidgetInteraction() - generally corresponds to a initial event (e.g., mouse down) that starts the interaction process with the widget. WidgetInteraction() - invoked when an event causes the widget to change appearance. EndWidgetInteraction() - generally corresponds to a final event (e.g., mouse up) and completes the interaction sequence. ComputeInteractionState() - given (X,Y) display coordinates in a renderer, with a possible flag that modifies the computation, what is the state of the widget? GetInteractionState() - return the current state of the widget. Note that the value of "0" typically refers to "outside". The interaction state is strictly a function of the representation, and the widget/represent must agree on what they mean. Highlight() - turn on or off any highlights associated with the widget. Highlights are generally turned on when the widget is selected.
Note that subclasses may ignore some of these methods and implement their own depending on the specifics of the widget.
Definition at line 116 of file vtkWidgetRepresentation.h.
| virtual void vtkWidgetRepresentation::Highlight | ( | int | vtkNotUsedhighlightOn | ) | [inline, virtual] |
The following is a suggested API for widget representations. These methods define the communication between the widget and its representation. These methods are only suggestions because widgets take on so many different forms that a universal API is not deemed practical. However, these methods should be implemented when possible to insure that the VTK widget hierarchy remains self-consistent.
PlaceWidget() - given a bounding box (xmin,xmax,ymin,ymax,zmin,zmax), place the widget inside of it. The current orientation of the widget is preserved, only scaling and translation is performed. StartWidgetInteraction() - generally corresponds to a initial event (e.g., mouse down) that starts the interaction process with the widget. WidgetInteraction() - invoked when an event causes the widget to change appearance. EndWidgetInteraction() - generally corresponds to a final event (e.g., mouse up) and completes the interaction sequence. ComputeInteractionState() - given (X,Y) display coordinates in a renderer, with a possible flag that modifies the computation, what is the state of the widget? GetInteractionState() - return the current state of the widget. Note that the value of "0" typically refers to "outside". The interaction state is strictly a function of the representation, and the widget/represent must agree on what they mean. Highlight() - turn on or off any highlights associated with the widget. Highlights are generally turned on when the widget is selected.
Note that subclasses may ignore some of these methods and implement their own depending on the specifics of the widget.
Definition at line 118 of file vtkWidgetRepresentation.h.
| virtual void vtkWidgetRepresentation::SetPlaceFactor | ( | double | ) | [virtual] |
Set/Get a factor representing the scaling of the widget upon placement (via the PlaceWidget() method). Normally the widget is placed so that it just fits within the bounding box defined in PlaceWidget(bounds). The PlaceFactor will make the widget larger (PlaceFactor > 1) or smaller (PlaceFactor < 1). By default, PlaceFactor is set to 0.5.
| virtual double vtkWidgetRepresentation::GetPlaceFactor | ( | ) | [virtual] |
Set/Get a factor representing the scaling of the widget upon placement (via the PlaceWidget() method). Normally the widget is placed so that it just fits within the bounding box defined in PlaceWidget(bounds). The PlaceFactor will make the widget larger (PlaceFactor > 1) or smaller (PlaceFactor < 1). By default, PlaceFactor is set to 0.5.
| virtual void vtkWidgetRepresentation::SetHandleSize | ( | double | ) | [virtual] |
Set/Get the factor that controls the size of the handles that appear as part of the widget (if any). These handles (like spheres, etc.) are used to manipulate the widget. The HandleSize data member allows you to change the relative size of the handles. Note that while the handle size is typically expressed in pixels, some subclasses may use a relative size with respect to the viewport. (As a corollary, the value of this ivar is often set by subclasses of this class during instance instantiation.)
Reimplemented in vtkPointHandleRepresentation3D, and vtkSphereHandleRepresentation.
| virtual double vtkWidgetRepresentation::GetHandleSize | ( | ) | [virtual] |
Set/Get the factor that controls the size of the handles that appear as part of the widget (if any). These handles (like spheres, etc.) are used to manipulate the widget. The HandleSize data member allows you to change the relative size of the handles. Note that while the handle size is typically expressed in pixels, some subclasses may use a relative size with respect to the viewport. (As a corollary, the value of this ivar is often set by subclasses of this class during instance instantiation.)
| virtual int vtkWidgetRepresentation::GetNeedToRender | ( | ) | [virtual] |
Some subclasses use this data member to keep track of whether to render or not (i.e., to minimize the total number of renders).
| virtual void vtkWidgetRepresentation::SetNeedToRender | ( | int | ) | [virtual] |
Some subclasses use this data member to keep track of whether to render or not (i.e., to minimize the total number of renders).
| virtual void vtkWidgetRepresentation::NeedToRenderOn | ( | ) | [virtual] |
Some subclasses use this data member to keep track of whether to render or not (i.e., to minimize the total number of renders).
| virtual void vtkWidgetRepresentation::NeedToRenderOff | ( | ) | [virtual] |
Some subclasses use this data member to keep track of whether to render or not (i.e., to minimize the total number of renders).
| virtual double* vtkWidgetRepresentation::GetBounds | ( | void | ) | [inline, virtual] |
Methods to make this class behave as a vtkProp. They are repeated here (from the vtkProp superclass) as a reminder to the widget implementor. Failure to implement these methods properly may result in the representation not appearing in the scene (i.e., not implementing the Render() methods properly) or leaking graphics resources (i.e., not implementing ReleaseGraphicsResources() properly).
Reimplemented from vtkProp.
Reimplemented in vtkSphereRepresentation, vtkImplicitPlaneRepresentation, vtkSplineRepresentation, vtkPointHandleRepresentation3D, vtkBoxRepresentation, vtkLineRepresentation, vtkSliderRepresentation3D, vtkTexturedButtonRepresentation, vtkTexturedButtonRepresentation2D, vtkOrientedGlyphContourRepresentation, vtkDistanceRepresentation3D, vtkAxesTransformRepresentation, vtkAbstractPolygonalHandleRepresentation3D, vtkSphereHandleRepresentation, vtkParallelopipedRepresentation, vtkProp3DButtonRepresentation, vtkPointHandleRepresentation2D, and vtkResliceCursorLineRepresentation.
Definition at line 161 of file vtkWidgetRepresentation.h.
| virtual void vtkWidgetRepresentation::ShallowCopy | ( | vtkProp * | prop | ) | [virtual] |
Methods to make this class behave as a vtkProp. They are repeated here (from the vtkProp superclass) as a reminder to the widget implementor. Failure to implement these methods properly may result in the representation not appearing in the scene (i.e., not implementing the Render() methods properly) or leaking graphics resources (i.e., not implementing ReleaseGraphicsResources() properly).
Reimplemented from vtkProp.
Reimplemented in vtkConstrainedPointHandleRepresentation, vtkPointHandleRepresentation3D, vtkAffineRepresentation2D, vtkTexturedButtonRepresentation, vtkHandleRepresentation, vtkTexturedButtonRepresentation2D, vtkSphereHandleRepresentation, vtkAbstractPolygonalHandleRepresentation3D, vtkButtonRepresentation, vtkProp3DButtonRepresentation, vtkPointHandleRepresentation2D, and vtkAffineRepresentation.
| virtual void vtkWidgetRepresentation::GetActors | ( | vtkPropCollection * | ) | [inline, virtual] |
Methods to make this class behave as a vtkProp. They are repeated here (from the vtkProp superclass) as a reminder to the widget implementor. Failure to implement these methods properly may result in the representation not appearing in the scene (i.e., not implementing the Render() methods properly) or leaking graphics resources (i.e., not implementing ReleaseGraphicsResources() properly).
Reimplemented from vtkProp.
Reimplemented in vtkImplicitPlaneRepresentation, vtkConstrainedPointHandleRepresentation, vtkPointHandleRepresentation3D, vtkLineRepresentation, vtkSliderRepresentation3D, vtkTexturedButtonRepresentation, vtkTexturedButtonRepresentation2D, vtkCenteredSliderRepresentation, vtkCompassRepresentation, vtkSphereHandleRepresentation, vtkCheckerboardRepresentation, vtkOrientedGlyphContourRepresentation, vtkAbstractPolygonalHandleRepresentation3D, vtkProp3DButtonRepresentation, vtkTensorProbeRepresentation, vtkParallelopipedRepresentation, and vtkEllipsoidTensorProbeRepresentation.
Definition at line 163 of file vtkWidgetRepresentation.h.
| virtual void vtkWidgetRepresentation::GetActors2D | ( | vtkPropCollection * | ) | [inline, virtual] |
Methods to make this class behave as a vtkProp. They are repeated here (from the vtkProp superclass) as a reminder to the widget implementor. Failure to implement these methods properly may result in the representation not appearing in the scene (i.e., not implementing the Render() methods properly) or leaking graphics resources (i.e., not implementing ReleaseGraphicsResources() properly).
Reimplemented from vtkProp.
Reimplemented in vtkBorderRepresentation, vtkAffineRepresentation2D, vtkSliderRepresentation2D, vtkRectilinearWipeRepresentation, vtkCameraRepresentation, vtkOrientedGlyphFocalPlaneContourRepresentation, vtkCaptionRepresentation, vtkPointHandleRepresentation2D, vtkPlaybackRepresentation, vtkScalarBarRepresentation, vtkLogoRepresentation, vtkTextRepresentation, and vtkXYPlotRepresentation.
Definition at line 164 of file vtkWidgetRepresentation.h.
| virtual void vtkWidgetRepresentation::GetVolumes | ( | vtkPropCollection * | ) | [inline, virtual] |
Methods to make this class behave as a vtkProp. They are repeated here (from the vtkProp superclass) as a reminder to the widget implementor. Failure to implement these methods properly may result in the representation not appearing in the scene (i.e., not implementing the Render() methods properly) or leaking graphics resources (i.e., not implementing ReleaseGraphicsResources() properly).
Reimplemented from vtkProp.
Definition at line 165 of file vtkWidgetRepresentation.h.
| virtual void vtkWidgetRepresentation::ReleaseGraphicsResources | ( | vtkWindow * | ) | [inline, virtual] |
Methods to make this class behave as a vtkProp. They are repeated here (from the vtkProp superclass) as a reminder to the widget implementor. Failure to implement these methods properly may result in the representation not appearing in the scene (i.e., not implementing the Render() methods properly) or leaking graphics resources (i.e., not implementing ReleaseGraphicsResources() properly).
Reimplemented from vtkProp.
Reimplemented in vtkContourRepresentation, vtkSphereRepresentation, vtkImplicitPlaneRepresentation, vtkSplineRepresentation, vtkConstrainedPointHandleRepresentation, vtkPointHandleRepresentation3D, vtkBalloonRepresentation, vtkBorderRepresentation, vtkBoxRepresentation, vtkLineRepresentation, vtkAffineRepresentation2D, vtkSliderRepresentation3D, vtkParallelopipedRepresentation, vtkTexturedButtonRepresentation, vtkTexturedButtonRepresentation2D, vtkSliderRepresentation2D, vtkDistanceRepresentation3D, vtkAxesTransformRepresentation, vtkCenteredSliderRepresentation, vtkRectilinearWipeRepresentation, vtkCompassRepresentation, vtkSphereHandleRepresentation, vtkCameraRepresentation, vtkCheckerboardRepresentation, vtkOrientedGlyphFocalPlaneContourRepresentation, vtkAngleRepresentation3D, vtkBiDimensionalRepresentation2D, vtkOrientedGlyphContourRepresentation, vtkAbstractPolygonalHandleRepresentation3D, vtkProp3DButtonRepresentation, vtkCaptionRepresentation, vtkPointHandleRepresentation2D, vtkDistanceRepresentation2D, vtkAngleRepresentation2D, vtkPlaybackRepresentation, vtkTensorProbeRepresentation, vtkScalarBarRepresentation, vtkLogoRepresentation, vtkTextRepresentation, vtkResliceCursorLineRepresentation, vtkXYPlotRepresentation, and vtkEllipsoidTensorProbeRepresentation.
Definition at line 166 of file vtkWidgetRepresentation.h.
| virtual int vtkWidgetRepresentation::RenderOverlay | ( | vtkViewport * | vtkNotUsedviewport | ) | [inline, virtual] |
Methods to make this class behave as a vtkProp. They are repeated here (from the vtkProp superclass) as a reminder to the widget implementor. Failure to implement these methods properly may result in the representation not appearing in the scene (i.e., not implementing the Render() methods properly) or leaking graphics resources (i.e., not implementing ReleaseGraphicsResources() properly).
Definition at line 167 of file vtkWidgetRepresentation.h.
| virtual int vtkWidgetRepresentation::RenderOpaqueGeometry | ( | vtkViewport * | vtkNotUsedviewport | ) | [inline, virtual] |
Methods to make this class behave as a vtkProp. They are repeated here (from the vtkProp superclass) as a reminder to the widget implementor. Failure to implement these methods properly may result in the representation not appearing in the scene (i.e., not implementing the Render() methods properly) or leaking graphics resources (i.e., not implementing ReleaseGraphicsResources() properly).
Definition at line 168 of file vtkWidgetRepresentation.h.
| virtual int vtkWidgetRepresentation::RenderTranslucentPolygonalGeometry | ( | vtkViewport * | vtkNotUsedviewport | ) | [inline, virtual] |
Methods to make this class behave as a vtkProp. They are repeated here (from the vtkProp superclass) as a reminder to the widget implementor. Failure to implement these methods properly may result in the representation not appearing in the scene (i.e., not implementing the Render() methods properly) or leaking graphics resources (i.e., not implementing ReleaseGraphicsResources() properly).
Definition at line 169 of file vtkWidgetRepresentation.h.
| virtual int vtkWidgetRepresentation::RenderVolumetricGeometry | ( | vtkViewport * | vtkNotUsedviewport | ) | [inline, virtual] |
Methods to make this class behave as a vtkProp. They are repeated here (from the vtkProp superclass) as a reminder to the widget implementor. Failure to implement these methods properly may result in the representation not appearing in the scene (i.e., not implementing the Render() methods properly) or leaking graphics resources (i.e., not implementing ReleaseGraphicsResources() properly).
Definition at line 170 of file vtkWidgetRepresentation.h.
| virtual int vtkWidgetRepresentation::HasTranslucentPolygonalGeometry | ( | ) | [inline, virtual] |
Methods to make this class behave as a vtkProp. They are repeated here (from the vtkProp superclass) as a reminder to the widget implementor. Failure to implement these methods properly may result in the representation not appearing in the scene (i.e., not implementing the Render() methods properly) or leaking graphics resources (i.e., not implementing ReleaseGraphicsResources() properly).
Reimplemented from vtkProp.
Reimplemented in vtkContourRepresentation, vtkSphereRepresentation, vtkImplicitPlaneRepresentation, vtkSplineRepresentation, vtkConstrainedPointHandleRepresentation, vtkPointHandleRepresentation3D, vtkBorderRepresentation, vtkBoxRepresentation, vtkLineRepresentation, vtkSliderRepresentation3D, vtkTexturedButtonRepresentation, vtkTexturedButtonRepresentation2D, vtkRectilinearWipeRepresentation, vtkSphereHandleRepresentation, vtkCameraRepresentation, vtkCheckerboardRepresentation, vtkOrientedGlyphFocalPlaneContourRepresentation, vtkAngleRepresentation3D, vtkOrientedGlyphContourRepresentation, vtkAbstractPolygonalHandleRepresentation3D, vtkProp3DButtonRepresentation, vtkCaptionRepresentation, vtkPlaybackRepresentation, vtkScalarBarRepresentation, vtkTextRepresentation, vtkResliceCursorLineRepresentation, and vtkXYPlotRepresentation.
Definition at line 171 of file vtkWidgetRepresentation.h.
| void vtkWidgetRepresentation::AdjustBounds | ( | double | bounds[6], |
| double | newBounds[6], | ||
| double | center[3] | ||
| ) | [protected] |
| virtual void vtkWidgetRepresentation::RegisterPickers | ( | ) | [protected, virtual] |
Register internal Pickers in the Picking Manager. Must be reimplemented by concrete widget representations to register their pickers.
Reimplemented in vtkImplicitPlaneRepresentation, vtkSphereRepresentation, vtkSplineRepresentation, vtkBoxRepresentation, vtkPointHandleRepresentation3D, vtkAbstractPolygonalHandleRepresentation3D, vtkSliderRepresentation3D, vtkTexturedButtonRepresentation, vtkSphereHandleRepresentation, vtkProp3DButtonRepresentation, and vtkEllipsoidTensorProbeRepresentation.
| virtual void vtkWidgetRepresentation::UnRegisterPickers | ( | ) | [protected, virtual] |
Unregister internal pickers from the Picking Manager.
| virtual void vtkWidgetRepresentation::PickersModified | ( | ) | [protected, virtual] |
Update the pickers registered in the Picking Manager when pickers are modified.
| vtkPickingManager* vtkWidgetRepresentation::GetPickingManager | ( | ) | [protected] |
Return the picking manager associated on the context on which the widget representation currently belong.
| vtkAssemblyPath* vtkWidgetRepresentation::GetAssemblyPath | ( | double | X, |
| double | Y, | ||
| double | Z, | ||
| vtkAbstractPropPicker * | picker | ||
| ) | [protected] |
Proceed to a pick, whether through the PickingManager if the picking is managed or directly using the registered picker, and return the assembly path.
| double vtkWidgetRepresentation::SizeHandlesRelativeToViewport | ( | double | factor, |
| double | pos[3] | ||
| ) | [protected] |
| double vtkWidgetRepresentation::SizeHandlesInPixels | ( | double | factor, |
| double | pos[3] | ||
| ) | [protected] |
Member Data Documentation
vtkWeakPointer<vtkRenderer> vtkWidgetRepresentation::Renderer [protected] |
Definition at line 179 of file vtkWidgetRepresentation.h.
int vtkWidgetRepresentation::InteractionState [protected] |
Definition at line 182 of file vtkWidgetRepresentation.h.
double vtkWidgetRepresentation::StartEventPosition[3] [protected] |
Definition at line 186 of file vtkWidgetRepresentation.h.
double vtkWidgetRepresentation::PlaceFactor [protected] |
Definition at line 189 of file vtkWidgetRepresentation.h.
int vtkWidgetRepresentation::Placed [protected] |
Definition at line 190 of file vtkWidgetRepresentation.h.
double vtkWidgetRepresentation::InitialBounds[6] [protected] |
Definition at line 192 of file vtkWidgetRepresentation.h.
double vtkWidgetRepresentation::InitialLength [protected] |
Definition at line 193 of file vtkWidgetRepresentation.h.
int vtkWidgetRepresentation::ValidPick [protected] |
Definition at line 200 of file vtkWidgetRepresentation.h.
bool vtkWidgetRepresentation::PickingManaged [protected] |
Definition at line 204 of file vtkWidgetRepresentation.h.
double vtkWidgetRepresentation::HandleSize [protected] |
Definition at line 234 of file vtkWidgetRepresentation.h.
int vtkWidgetRepresentation::NeedToRender [protected] |
Definition at line 239 of file vtkWidgetRepresentation.h.
vtkTimeStamp vtkWidgetRepresentation::BuildTime [protected] |
Definition at line 243 of file vtkWidgetRepresentation.h.
The documentation for this class was generated from the following file:
- dox/Interaction/Widgets/vtkWidgetRepresentation.h
