list of point or cell ids More...

#include <vtkIdList.h>

Inheritance diagram for vtkIdList:

Collaboration diagram for vtkIdList:

Public Types
enum	DeleteMethod { VTK_DATA_ARRAY_FREE = vtkAbstractArray::VTK_DATA_ARRAY_FREE , VTK_DATA_ARRAY_DELETE = vtkAbstractArray::VTK_DATA_ARRAY_DELETE , VTK_DATA_ARRAY_ALIGNED_FREE = vtkAbstractArray::VTK_DATA_ARRAY_ALIGNED_FREE , VTK_DATA_ARRAY_USER_DEFINED = vtkAbstractArray::VTK_DATA_ARRAY_USER_DEFINED }

Public Member Functions
void	Initialize ()
	Release memory and restore to unallocated state.

vtkTypeBool	Allocate (vtkIdType size, int strategy=0)
	Allocate memory for this id list.

vtkTypeBool	Reserve (vtkIdType size)
	Reserve the id list to the requested number of ids and preserve data.

vtkIdType	GetNumberOfIds () const noexcept
	Return the number of id's in the list.

vtkIdType	GetId (vtkIdType i)
	Return the id at location i.

vtkIdType	FindIdLocation (const vtkIdType id)
	Find the location i of the provided id.

void	SetNumberOfIds (vtkIdType number)
	Specify the number of ids for this object to hold.

void	SetId (vtkIdType i, vtkIdType id)
	Set the id at location i.

void	InsertId (vtkIdType i, vtkIdType id)
	Set the id at location i.

vtkIdType	InsertNextId (vtkIdType id)
	Add the id specified to the end of the list.

vtkIdType	InsertUniqueId (vtkIdType id)
	If id is not already in list, insert it and return location in list.

void	Sort ()
	Sort the ids in the list in ascending id order.

void	Fill (vtkIdType value)
	Fill the ids with the input value.

vtkIdType *	GetPointer (vtkIdType i)
	Get a pointer to a particular data index.

vtkIdType *	WritePointer (vtkIdType i, vtkIdType number)
	Get a pointer to a particular data index.

void	SetList (vtkIdType *array, vtkIdType size, bool save, int deleteMethod=VTK_DATA_ARRAY_DELETE)
	This method let's the user specify data to be held by the id list.

void	SetArray (vtkIdType *array, vtkIdType size, bool manageMemory=true)
	This method does the same as SetList but the save and manageMemory are opposite.

void	Reset ()
	Reset to an empty state but retain previously allocated memory.

void	Squeeze ()
	Free any unused memory.

void	ShallowCopy (vtkIdList *list)
	Copy an id list by copying the internal buffer pointer.

void	DeepCopy (vtkIdList *ids)
	Copy an id list by explicitly copying the internal array.

void	DeleteId (vtkIdType id)
	Delete specified id from list.

vtkIdType	IsId (vtkIdType id) VTK_FUTURE_CONST
	Return -1 if id specified is not contained in the list; otherwise return the position in the list.

void	IntersectWith (vtkIdList *otherIds)
	Intersect this list with another vtkIdList.

vtkIdType *	Resize (vtkIdType sz)
	Adjust the size of the id list while maintaining its content (except when being truncated).

vtkIdType *	Release ()
	This releases the ownership of the internal vtkIdType array and returns the pointer to it.

vtkIdType	GetCapacity () const
	Get the capacity of the id list.


vtkIdType *	begin ()
	To support range-based `for` loops.

vtkIdType *	end ()
	To support range-based `for` loops.

const vtkIdType *	begin () const
	To support range-based `for` loops.

const vtkIdType *	end () const
	To support range-based `for` loops.

Public Member Functions inherited from vtkObject
	vtkBaseTypeMacro (vtkObject, vtkObjectBase)

virtual void	DebugOn ()
	Turn debugging output on.

virtual void	DebugOff ()
	Turn debugging output off.

bool	GetDebug ()
	Get the value of the debug flag.

void	SetDebug (bool debugFlag)
	Set the value of the debug flag.

virtual void	Modified ()
	Update the modification time for this object.

virtual vtkMTimeType	GetMTime ()
	Return this object's modified time.

void	PrintSelf (ostream &os, vtkIndent indent) override
	Methods invoked by print to print information about the object including superclasses.

void	RemoveObserver (unsigned long tag)

void	RemoveObservers (unsigned long event)

void	RemoveObservers (const char *event)

void	RemoveAllObservers ()

vtkTypeBool	HasObserver (unsigned long event)

vtkTypeBool	HasObserver (const char *event)

vtkTypeBool	InvokeEvent (unsigned long event)

vtkTypeBool	InvokeEvent (const char *event)

std::string	GetObjectDescription () const override
	The object description printed in messages and PrintSelf output.

unsigned long	AddObserver (unsigned long event, vtkCommand *, float priority=0.0f)
	Allow people to add/remove/invoke observers (callbacks) to any VTK object.

unsigned long	AddObserver (const char event, vtkCommand , float priority=0.0f)
	Allow people to add/remove/invoke observers (callbacks) to any VTK object.

vtkCommand *	GetCommand (unsigned long tag)
	Allow people to add/remove/invoke observers (callbacks) to any VTK object.

void	RemoveObserver (vtkCommand *)
	Allow people to add/remove/invoke observers (callbacks) to any VTK object.

void	RemoveObservers (unsigned long event, vtkCommand *)
	Allow people to add/remove/invoke observers (callbacks) to any VTK object.

void	RemoveObservers (const char event, vtkCommand )
	Allow people to add/remove/invoke observers (callbacks) to any VTK object.

vtkTypeBool	HasObserver (unsigned long event, vtkCommand *)
	Allow people to add/remove/invoke observers (callbacks) to any VTK object.

vtkTypeBool	HasObserver (const char event, vtkCommand )
	Allow people to add/remove/invoke observers (callbacks) to any VTK object.

template<class U, class T>
unsigned long	AddObserver (unsigned long event, U observer, void(T::*callback)(), float priority=0.0f)
	Overloads to AddObserver that allow developers to add class member functions as callbacks for events.

template<class U, class T>
unsigned long	AddObserver (unsigned long event, U observer, void(T::callback)(vtkObject , unsigned long, void *), float priority=0.0f)
	Overloads to AddObserver that allow developers to add class member functions as callbacks for events.

template<class U, class T>
unsigned long	AddObserver (unsigned long event, U observer, bool(T::callback)(vtkObject , unsigned long, void *), float priority=0.0f)
	Allow user to set the AbortFlagOn() with the return value of the callback method.

vtkTypeBool	InvokeEvent (unsigned long event, void *callData)
	This method invokes an event and return whether the event was aborted or not.

vtkTypeBool	InvokeEvent (const char event, void callData)
	This method invokes an event and return whether the event was aborted or not.

virtual void	SetObjectName (const std::string &objectName)
	Set/get the name of this object for reporting purposes.

virtual std::string	GetObjectName () const
	Set/get the name of this object for reporting purposes.

Public Member Functions inherited from vtkObjectBase
const char *	GetClassName () const
	Return the class name as a string.

virtual vtkIdType	GetNumberOfGenerationsFromBase (const char *name)
	Given the name of a base class of this class type, return the distance of inheritance between this class type and the named class (how many generations of inheritance are there between this class and the named class).

virtual void	Delete ()
	Delete a VTK object.

virtual void	FastDelete ()
	Delete a reference to this object.

void	InitializeObjectBase ()

void	Print (ostream &os)
	Print an object to an ostream.

void	Register (vtkObjectBase *o)
	Increase the reference count (mark as used by another object).

virtual void	UnRegister (vtkObjectBase *o)
	Decrease the reference count (release by another object).

int	GetReferenceCount ()
	Return the current reference count of this object.

void	SetReferenceCount (int)
	Sets the reference count.

bool	GetIsInMemkind () const
	A local state flag that remembers whether this object lives in the normal or extended memory space.

virtual void	PrintHeader (ostream &os, vtkIndent indent)
	Methods invoked by print to print information about the object including superclasses.

virtual void	PrintTrailer (ostream &os, vtkIndent indent)
	Methods invoked by print to print information about the object including superclasses.

virtual bool	UsesGarbageCollector () const
	Indicate whether the class uses `vtkGarbageCollector` or not.

Protected Member Functions
	vtkIdList ()

	~vtkIdList () override

bool	AllocateInternal (vtkIdType sz, vtkIdType numberOfIds)
	Allocate ids and set the number of ids.

void	InitializeMemory ()
	Release memory.

Protected Member Functions inherited from vtkObject
	vtkObject ()

	~vtkObject () override

void	RegisterInternal (vtkObjectBase *, vtkTypeBool check) override

void	UnRegisterInternal (vtkObjectBase *, vtkTypeBool check) override

void	InternalGrabFocus (vtkCommand mouseEvents, vtkCommand keypressEvents=nullptr)
	These methods allow a command to exclusively grab all events.

void	InternalReleaseFocus ()
	These methods allow a command to exclusively grab all events.

Protected Member Functions inherited from vtkObjectBase
	vtkObjectBase ()

virtual	~vtkObjectBase ()

virtual void	ReportReferences (vtkGarbageCollector *)

	vtkObjectBase (const vtkObjectBase &)

void	operator= (const vtkObjectBase &)

Protected Attributes
vtkIdType	NumberOfIds

vtkBuffer< vtkIdType > *	Buffer

vtkIdType	Size

Protected Attributes inherited from vtkObject
bool	Debug

vtkTimeStamp	MTime

vtkSubjectHelper *	SubjectHelper

std::string	ObjectName

Protected Attributes inherited from vtkObjectBase
std::atomic< int32_t >	ReferenceCount

vtkWeakPointerBase **	WeakPointers

typedef vtkObject	Superclass
	Standard methods for instantiation, type information, and printing.

static vtkIdList *	New ()
	Standard methods for instantiation, type information, and printing.

static vtkTypeBool	IsTypeOf (const char *type)
	Standard methods for instantiation, type information, and printing.

static vtkIdList *	SafeDownCast (vtkObjectBase *o)
	Standard methods for instantiation, type information, and printing.

virtual vtkTypeBool	IsA (const char *type)
	Standard methods for instantiation, type information, and printing.

vtkIdList *	NewInstance () const
	Standard methods for instantiation, type information, and printing.

void	PrintSelf (ostream &os, vtkIndent indent) override
	Standard methods for instantiation, type information, and printing.

virtual vtkObjectBase *	NewInstanceInternal () const
	Standard methods for instantiation, type information, and printing.

Additional Inherited Members
Static Public Member Functions inherited from vtkObject
static vtkObject *	New ()
	Create an object with Debug turned off, modified time initialized to zero, and reference counting on.

static void	BreakOnError ()
	This method is called when vtkErrorMacro executes.

static void	SetGlobalWarningDisplay (vtkTypeBool val)
	This is a global flag that controls whether any debug, warning or error messages are displayed.

static void	GlobalWarningDisplayOn ()
	This is a global flag that controls whether any debug, warning or error messages are displayed.

static void	GlobalWarningDisplayOff ()
	This is a global flag that controls whether any debug, warning or error messages are displayed.

static vtkTypeBool	GetGlobalWarningDisplay ()
	This is a global flag that controls whether any debug, warning or error messages are displayed.

Static Public Member Functions inherited from vtkObjectBase
static vtkTypeBool	IsTypeOf (const char *name)
	Return 1 if this class type is the same type of (or a subclass of) the named class.

static vtkIdType	GetNumberOfGenerationsFromBaseType (const char *name)
	Given a the name of a base class of this class type, return the distance of inheritance between this class type and the named class (how many generations of inheritance are there between this class and the named class).

static vtkObjectBase *	New ()
	Create an object with Debug turned off, modified time initialized to zero, and reference counting on.

static void	SetMemkindDirectory (const char *directoryname)
	The name of a directory, ideally mounted -o dax, to memory map an extended memory space within.

static bool	GetUsingMemkind ()
	A global state flag that controls whether vtkObjects are constructed in the usual way (the default) or within the extended memory space.

Static Protected Member Functions inherited from vtkObjectBase
static vtkMallocingFunction	GetCurrentMallocFunction ()

static vtkReallocingFunction	GetCurrentReallocFunction ()

static vtkFreeingFunction	GetCurrentFreeFunction ()

static vtkFreeingFunction	GetAlternateFreeFunction ()

Detailed Description

list of point or cell ids

vtkIdList is used to represent and pass data id's between objects. vtkIdList may represent any type of integer id, but usually represents point and cell ids.

Online Examples:

OctreeFindPointsWithinRadius

OctreeKClosestPoints

StaticLocatorFindPointsWithinRadiusDemo

Cell3DDemonstration

PolyhedronAndHexahedron

FindCellIntersections

Tests:: vtkIdList (Tests)

Definition at line 134 of file vtkIdList.h.

Member Typedef Documentation

◆ Superclass

typedef vtkObject vtkIdList::Superclass

Standard methods for instantiation, type information, and printing.

Definition at line 150 of file vtkIdList.h.

Member Enumeration Documentation

◆ DeleteMethod

enum vtkIdList::DeleteMethod

Enumerator
VTK_DATA_ARRAY_FREE
VTK_DATA_ARRAY_DELETE
VTK_DATA_ARRAY_ALIGNED_FREE
VTK_DATA_ARRAY_USER_DEFINED

Definition at line 137 of file vtkIdList.h.

Constructor & Destructor Documentation

◆ vtkIdList()

vtkIdList::vtkIdList ( )

protected

◆ ~vtkIdList()

vtkIdList::~vtkIdList ( )

overrideprotected

Member Function Documentation

◆ New()

static vtkIdList * vtkIdList::New ( )

static

Standard methods for instantiation, type information, and printing.

◆ IsTypeOf()

static vtkTypeBool vtkIdList::IsTypeOf ( const char * type )

static

Standard methods for instantiation, type information, and printing.

◆ IsA()

virtual vtkTypeBool vtkIdList::IsA ( const char * type )

virtual

Standard methods for instantiation, type information, and printing.

Reimplemented from vtkObjectBase.

◆ SafeDownCast()

static vtkIdList * vtkIdList::SafeDownCast ( vtkObjectBase * o )

static

Standard methods for instantiation, type information, and printing.

◆ NewInstanceInternal()

virtual vtkObjectBase * vtkIdList::NewInstanceInternal ( ) const

protectedvirtual

Standard methods for instantiation, type information, and printing.

◆ NewInstance()

vtkIdList * vtkIdList::NewInstance ( ) const

Standard methods for instantiation, type information, and printing.

◆ PrintSelf()

void vtkIdList::PrintSelf	(	ostream &	os,
		vtkIndent	indent )

overridevirtual

Standard methods for instantiation, type information, and printing.

Reimplemented from vtkObjectBase.

◆ Initialize()

void vtkIdList::Initialize ( )

Release memory and restore to unallocated state.

◆ Allocate()

vtkTypeBool vtkIdList::Allocate	(	vtkIdType	size,
		int	strategy = 0 )

Allocate memory for this id list.

Delete old storage only if necessary. Note that strategy is no longer used. This method will reset NumberOfIds to 0 and change the id list's capacity such that this->Capacity >= size. If size is 0, all memory will be freed. Return 1 on success, 0 on failure.

◆ Reserve()

vtkTypeBool vtkIdList::Reserve ( vtkIdType size )

Reserve the id list to the requested number of ids and preserve data.

Increasing the id list capacity may allocate extra memory beyond what was requested. NumberOfIds will not be modified when increasing id list size.

Decreasing the id list capacity is effectively a no-op.

Returns 1 if resizing succeeded and 0 otherwise.

◆ GetNumberOfIds()

vtkIdType vtkIdList::GetNumberOfIds ( ) const

inlinenoexcept

Return the number of id's in the list.

Definition at line 185 of file vtkIdList.h.

◆ GetId()

vtkIdType vtkIdList::GetId ( vtkIdType i )

inline

Return the id at location i.

Definition at line 190 of file vtkIdList.h.

◆ FindIdLocation()

vtkIdType vtkIdList::FindIdLocation ( const vtkIdType id )

inline

Find the location i of the provided id.

Definition at line 198 of file vtkIdList.h.

◆ SetNumberOfIds()

void vtkIdList::SetNumberOfIds ( vtkIdType number )

Specify the number of ids for this object to hold.

Does an allocation as well as setting the number of ids. Preserves existing data.

◆ SetId()

void vtkIdList::SetId	(	vtkIdType	i,
		vtkIdType	id )

inline

Set the id at location i.

Doesn't do range checking so it's a bit faster than InsertId. Make sure you use SetNumberOfIds() to allocate memory prior to using SetId().

Definition at line 222 of file vtkIdList.h.

◆ InsertId()

void vtkIdList::InsertId	(	vtkIdType	i,
		vtkIdType	id )

inline

Set the id at location i.

Does range checking and allocates memory as necessary.

Definition at line 387 of file vtkIdList.h.

◆ InsertNextId()

vtkIdType vtkIdList::InsertNextId ( vtkIdType id )

inline

Add the id specified to the end of the list.

Range checking is performed.

Definition at line 401 of file vtkIdList.h.

◆ InsertUniqueId()

vtkIdType vtkIdList::InsertUniqueId ( vtkIdType id )

If id is not already in list, insert it and return location in list.

Otherwise return just location in list.

◆ Sort()

void vtkIdList::Sort ( )

Sort the ids in the list in ascending id order.

This method uses vtkSMPTools::Sort() so it can be sped up if built properly.

◆ Fill()

void vtkIdList::Fill ( vtkIdType value )

Fill the ids with the input value.

This method uses vtkSMPTools::Fill() so it can be sped up if built properly.

◆ GetPointer()

vtkIdType * vtkIdList::GetPointer ( vtkIdType i )

inline

Get a pointer to a particular data index.

Definition at line 259 of file vtkIdList.h.

◆ WritePointer()

vtkIdType * vtkIdList::WritePointer	(	vtkIdType	i,
		vtkIdType	number )

Get a pointer to a particular data index.

Make sure data is allocated for the number of items requested. Set MaxId according to the number of data values requested.

◆ SetList()

void vtkIdList::SetList	(	vtkIdType *	array,
		vtkIdType	size,
		bool	save,
		int	deleteMethod = VTK_DATA_ARRAY_DELETE )

This method let's the user specify data to be held by the id list.

The array argument is a pointer to the data. Size is the size of the array supplied by the user (as number of ids, not in bytes). Set save to 1 to prevent the class from deleting the array when it cleans up or reallocates memory. The class uses the actual array provided; it does not copy the data from the supplied array. If specified, the delete method determines how the data array will be deallocated. If the delete method is VTK_DATA_ARRAY_FREE, free() will be used. If the delete method is VTK_DATA_ARRAY_DELETE, delete[] will be used. If the delete method is VTK_DATA_ARRAY_ALIGNED_FREE _aligned_free() will be used on Windows, while free() will be used everywhere else. The default is VTK_DATA_ARRAY_DELETE.

◆ SetArray()

void vtkIdList::SetArray	(	vtkIdType *	array,
		vtkIdType	size,
		bool	manageMemory = true )

This method does the same as SetList but the save and manageMemory are opposite.

It was deprecated to promote uniformity between vtkIdList and vtkAOSDataArrayTemplate APIs.

◆ Reset()

void vtkIdList::Reset ( )

inline

Reset to an empty state but retain previously allocated memory.

Definition at line 295 of file vtkIdList.h.

◆ Squeeze()

void vtkIdList::Squeeze ( )

Free any unused memory.

◆ ShallowCopy()

void vtkIdList::ShallowCopy ( vtkIdList * list )

Copy an id list by copying the internal buffer pointer.

Note that this is a shallow copy, so the internal buffer is shared between the two id lists.

◆ DeepCopy()

void vtkIdList::DeepCopy ( vtkIdList * ids )

Copy an id list by explicitly copying the internal array.

◆ DeleteId()

void vtkIdList::DeleteId ( vtkIdType id )

Delete specified id from list.

Will remove all occurrences of id in list.

◆ IsId()

vtkIdType vtkIdList::IsId ( vtkIdType id )

inline

Return -1 if id specified is not contained in the list; otherwise return the position in the list.

Definition at line 414 of file vtkIdList.h.

◆ IntersectWith()

void vtkIdList::IntersectWith ( vtkIdList * otherIds )

Intersect this list with another vtkIdList.

Updates current list according to result of intersection operation.

◆ Resize()

vtkIdType * vtkIdList::Resize ( vtkIdType sz )

Adjust the size of the id list while maintaining its content (except when being truncated).

◆ Release()

vtkIdType * vtkIdList::Release ( )

This releases the ownership of the internal vtkIdType array and returns the pointer to it.

The caller is responsible of calling delete [] on the returned value. This vtkIdList will be set to initialized state after this call.

◆ GetCapacity()

vtkIdType vtkIdList::GetCapacity ( ) const

inline

Get the capacity of the id list.

This returns the number of id slots in the id list's allocated storage.

Definition at line 351 of file vtkIdList.h.

◆ begin() [1/2]

vtkIdType * vtkIdList::begin ( )

inline

To support range-based for loops.

Definition at line 357 of file vtkIdList.h.

◆ end() [1/2]

vtkIdType * vtkIdList::end ( )

inline

To support range-based for loops.

Definition at line 358 of file vtkIdList.h.

◆ begin() [2/2]

const vtkIdType * vtkIdList::begin ( ) const

inline

To support range-based for loops.

Definition at line 359 of file vtkIdList.h.

◆ end() [2/2]

const vtkIdType * vtkIdList::end ( ) const

inline

To support range-based for loops.

Definition at line 360 of file vtkIdList.h.

◆ AllocateInternal()

bool vtkIdList::AllocateInternal	(	vtkIdType	sz,
		vtkIdType	numberOfIds )

protected

Allocate ids and set the number of ids.

◆ InitializeMemory()

void vtkIdList::InitializeMemory ( )

protected

Release memory.

Member Data Documentation

◆ NumberOfIds

vtkIdType vtkIdList::NumberOfIds

protected

Definition at line 377 of file vtkIdList.h.

◆ Buffer

vtkBuffer<vtkIdType>* vtkIdList::Buffer

protected

Definition at line 378 of file vtkIdList.h.

◆ Size

vtkIdType vtkIdList::Size

protected

Definition at line 379 of file vtkIdList.h.

The documentation for this class was generated from the following file:

Common/Core/vtkIdList.h

Public Types

Public Member Functions

Protected Member Functions

Protected Attributes

Additional Inherited Members

Detailed Description

Member Typedef Documentation

◆ Superclass

Member Enumeration Documentation

◆ DeleteMethod

Constructor & Destructor Documentation

◆ vtkIdList()

◆ ~vtkIdList()

Member Function Documentation

◆ New()

◆ IsTypeOf()

◆ IsA()

◆ SafeDownCast()

◆ NewInstanceInternal()

◆ NewInstance()

◆ PrintSelf()

◆ Initialize()

◆ Allocate()

◆ Reserve()

◆ GetNumberOfIds()

◆ GetId()

◆ FindIdLocation()

◆ SetNumberOfIds()

◆ SetId()

◆ InsertId()

◆ InsertNextId()

◆ InsertUniqueId()

◆ Sort()

◆ Fill()

◆ GetPointer()

◆ WritePointer()

◆ SetList()

◆ SetArray()

◆ Reset()

◆ Squeeze()

◆ ShallowCopy()

◆ DeepCopy()

◆ DeleteId()

◆ IsId()

◆ IntersectWith()

◆ Resize()

◆ Release()

◆ GetCapacity()

◆ begin() [1/2]

◆ end() [1/2]

◆ begin() [2/2]

◆ end() [2/2]

◆ AllocateInternal()

◆ InitializeMemory()

Member Data Documentation

◆ NumberOfIds

◆ Buffer

◆ Size
