vtkImageQuantizeRGBToIndex Class Reference
generalized histograms up to 4 dimensions.
More...
#include <vtkImageQuantizeRGBToIndex.h>
Inheritance diagram for vtkImageQuantizeRGBToIndex:
[legend]Collaboration diagram for vtkImageQuantizeRGBToIndex:
[legend]List of all members.
Detailed Description
generalized histograms up to 4 dimensions.
-
Date:
-
2001/10/11 13:37:51
-
Revision:
-
1.24
vtkImageQuantizeRGBToIndex takes a 3 component RGB image as input and produces a one component index image as output, along with a lookup table that contains the color definitions for the index values. This filter works on the entire input extent - it does not perform streaming, and it does not supported threaded execution (because it has to process the entire image).
To use this filter, you typically set the number of colors (between 2 and 65536), execute it, and then retrieve the lookup table. The colors can then be using the lookup table and the image index.
-
Tests:
-
vtkImageQuantizeRGBToIndex (Tests)
Definition at line 66 of file vtkImageQuantizeRGBToIndex.h.
Constructor & Destructor Documentation
| vtkImageQuantizeRGBToIndex::vtkImageQuantizeRGBToIndex |
( |
|
) |
[protected] |
|
| vtkImageQuantizeRGBToIndex::~vtkImageQuantizeRGBToIndex |
( |
|
) |
[protected] |
|
Member Function Documentation
| vtkImageQuantizeRGBToIndex* vtkImageQuantizeRGBToIndex::New |
( |
|
) |
[static] |
|
| virtual const char* vtkImageQuantizeRGBToIndex::GetClassName |
( |
|
) |
[virtual] |
|
| int vtkImageQuantizeRGBToIndex::IsTypeOf |
( |
const char * |
type |
) |
[static] |
|
|
|
Return 1 if this class type is the same type of (or a subclass of) the named class. Returns 0 otherwise. This method works in combination with vtkTypeMacro found in vtkSetGet.h.
Reimplemented from vtkImageToImageFilter. |
| virtual int vtkImageQuantizeRGBToIndex::IsA |
( |
const char * |
type |
) |
[virtual] |
|
|
|
Return 1 if this class is the same type of (or a subclass of) the named class. Returns 0 otherwise. This method works in combination with vtkTypeMacro found in vtkSetGet.h.
Reimplemented from vtkImageToImageFilter. |
| vtkImageQuantizeRGBToIndex* vtkImageQuantizeRGBToIndex::SafeDownCast |
( |
vtkObject * |
o |
) |
[static] |
|
|
|
Will cast the supplied object to vtkObject* is this is a safe operation (i.e., a safe downcast); otherwise NULL is returned. This method is defined in all subclasses of vtkObject with the vtkTypeMacro found in vtkSetGet.h.
Reimplemented from vtkImageToImageFilter. |
| void vtkImageQuantizeRGBToIndex::PrintSelf |
( |
ostream & |
os, |
|
|
vtkIndent |
indent |
|
) |
[virtual] |
|
|
|
Methods invoked by print to print information about the object including superclasses. Typically not called by the user (use Print() instead) but used in the hierarchical print process to combine the output of several classes.
Reimplemented from vtkImageToImageFilter. |
| virtual void vtkImageQuantizeRGBToIndex::SetNumberOfColors |
( |
int |
|
) |
[virtual] |
|
|
|
Set / Get the number of color index values to produce - must be a number between 2 and 65536. |
| virtual int vtkImageQuantizeRGBToIndex::GetNumberOfColors |
( |
|
) |
[virtual] |
|
|
|
Set / Get the number of color index values to produce - must be a number between 2 and 65536. |
| virtual vtkLookupTable* vtkImageQuantizeRGBToIndex::GetLookupTable |
( |
|
) |
[virtual] |
|
|
|
Get the resulting lookup table that contains the color definitions corresponding to the index values in the output image. |
| virtual float vtkImageQuantizeRGBToIndex::GetInitializeExecuteTime |
( |
|
) |
[virtual] |
|
| virtual float vtkImageQuantizeRGBToIndex::GetBuildTreeExecuteTime |
( |
|
) |
[virtual] |
|
| virtual float vtkImageQuantizeRGBToIndex::GetLookupIndexExecuteTime |
( |
|
) |
[virtual] |
|
| virtual int vtkImageQuantizeRGBToIndex::GetInputType |
( |
|
) |
[virtual] |
|
|
|
For internal use only - get the type of the image |
| virtual void vtkImageQuantizeRGBToIndex::SetInitializeExecuteTime |
( |
float |
|
) |
[virtual] |
|
|
|
For internal use only - set the times for execution |
| virtual void vtkImageQuantizeRGBToIndex::SetBuildTreeExecuteTime |
( |
float |
|
) |
[virtual] |
|
|
|
For internal use only - set the times for execution |
| virtual void vtkImageQuantizeRGBToIndex::SetLookupIndexExecuteTime |
( |
float |
|
) |
[virtual] |
|
|
|
For internal use only - set the times for execution |
| void vtkImageQuantizeRGBToIndex::ExecuteInformation |
( |
vtkImageData * |
inData, |
|
|
vtkImageData * |
outData |
|
) |
[protected, virtual] |
|
| void vtkImageQuantizeRGBToIndex::ComputeInputUpdateExtent |
( |
int |
inExt[6], |
|
|
int |
outExt[6] |
|
) |
[protected, virtual] |
|
| void vtkImageQuantizeRGBToIndex::ExecuteInformation |
( |
|
) |
[inline, protected, virtual] |
|
| virtual void vtkImageQuantizeRGBToIndex::ExecuteData |
( |
vtkDataObject * |
out |
) |
[protected, virtual] |
|
Member Data Documentation
int vtkImageQuantizeRGBToIndex::NumberOfColors [protected]
|
|
int vtkImageQuantizeRGBToIndex::InputType [protected]
|
|
float vtkImageQuantizeRGBToIndex::InitializeExecuteTime [protected]
|
|
float vtkImageQuantizeRGBToIndex::BuildTreeExecuteTime [protected]
|
|
float vtkImageQuantizeRGBToIndex::LookupIndexExecuteTime [protected]
|
|
The documentation for this class was generated from the following file:
