#include <vtkImageToImageFilter.h>
Inheritance diagram for vtkImageToImageFilter:
vtkImageToImageFilter is a filter superclass that hides much of the pipeline complexity. It handles breaking the pipeline execution into smaller extents so that the vtkImageData limits are observed. It also provides support for multithreading. If you don't need any of this functionality, consider using vtkSimpleImageToImageFilter instead.
Definition at line 34 of file vtkImageToImageFilter.h.
Public Types | |
| typedef vtkImageSource | Superclass |
Public Member Functions | |
| virtual const char * | GetClassName () |
| virtual int | IsA (const char *type) |
| void | SetInputMemoryLimit (int) |
| void | PrintSelf (ostream &os, vtkIndent indent) |
| virtual void | SetInput (vtkImageData *input) |
| vtkImageData * | GetInput () |
| void | SetBypass (int) |
| void | BypassOn () |
| void | BypassOff () |
| virtual int | GetBypass () |
| virtual void | ThreadedExecute (vtkImageData *inData, vtkImageData *outData, int extent[6], int threadId) |
| virtual void | SetNumberOfThreads (int) |
| virtual int | GetNumberOfThreads () |
| long | GetInputMemoryLimit () |
| virtual int | SplitExtent (int splitExt[6], int startExt[6], int num, int total) |
Static Public Member Functions | |
| static int | IsTypeOf (const char *type) |
| static vtkImageToImageFilter * | SafeDownCast (vtkObject *o) |
Protected Member Functions | |
| vtkImageToImageFilter () | |
| ~vtkImageToImageFilter () | |
| void | ExecuteInformation () |
| virtual void | ExecuteInformation (vtkImageData *inData, vtkImageData *outData) |
| void | ExecuteData (vtkDataObject *output) |
| virtual vtkImageData * | AllocateOutputData (vtkDataObject *out) |
| void | MultiThread (vtkImageData *input, vtkImageData *output) |
| void | ComputeInputUpdateExtents (vtkDataObject *output) |
| virtual void | ComputeInputUpdateExtent (int inExt[6], int outExt[6]) |
| virtual void | SetInputScalarsSelection (const char *) |
| virtual int | FillInputPortInformation (int, vtkInformation *) |
Protected Attributes | |
| vtkMultiThreader * | Threader |
| int | Bypass |
| int | BypassWasOn |
| int | NumberOfThreads |
| char * | InputScalarsSelection |
|
|
Reimplemented from vtkImageSource. Reimplemented in vtkImageSpatialFilter. Definition at line 37 of file vtkImageToImageFilter.h. |
|
|
|
|
|
|
|
|
Reimplemented from vtkImageSource. Reimplemented in vtkImageSpatialFilter. |
|
|
Return 1 if this class type is the same type of (or a subclass of) the named class. Returns 0 otherwise. This method works in combination with vtkTypeRevisionMacro found in vtkSetGet.h. Reimplemented from vtkImageSource. Reimplemented in vtkImageSpatialFilter. |
|
|
Return 1 if this class is the same type of (or a subclass of) the named class. Returns 0 otherwise. This method works in combination with vtkTypeRevisionMacro found in vtkSetGet.h. Reimplemented from vtkImageSource. Reimplemented in vtkImageSpatialFilter. |
|
|
Reimplemented from vtkImageSource. Reimplemented in vtkImageSpatialFilter. |
|
||||||||||||
|
Methods invoked by print to print information about the object including superclasses. Typically not called by the user (use Print() instead) but used in the hierarchical print process to combine the output of several classes. Reimplemented from vtkImageSource. Reimplemented in vtkImageSpatialFilter. |
|
|
Set the Input of a filter. |
|
|
|
|
|
Obsolete feature - do not use. Definition at line 48 of file vtkImageToImageFilter.h. |
|
|
Obsolete feature - do not use. Definition at line 49 of file vtkImageToImageFilter.h. |
|
|
Obsolete feature - do not use. Definition at line 50 of file vtkImageToImageFilter.h. |
|
|
Obsolete feature - do not use. |
|
||||||||||||||||||||
|
If the subclass does not define an Execute method, then the task will be broken up, multiple threads will be spawned, and each thread will call this method. It is public so that the thread functions can call this method. |
|
|
Get/Set the number of threads to create when rendering |
|
|
Get/Set the number of threads to create when rendering |
|
|
Definition at line 70 of file vtkImageToImageFilter.h. |
|
|
Definition at line 72 of file vtkImageToImageFilter.h. |
|
||||||||||||||||||||
|
Putting this here until I merge graphics and imaging streaming. |
|
|
Reimplemented from vtkSource. Reimplemented in vtkImageSpatialFilter. |
|
||||||||||||
|
Reimplemented in vtkImageSpatialFilter. |
|
|
This method is the one that should be used by subclasses, right now the default implementation is to call the backwards compatibility method Reimplemented from vtkSource. |
|
|
Reimplemented from vtkImageSource. |
|
||||||||||||
|
|
|
|
What is the input update extent that is required to produce the desired output? By default, the whole input is always required but this is overridden in many subclasses. Reimplemented from vtkSource. |
|
||||||||||||
|
Reimplemented in vtkImageSpatialFilter. |
|
|
|
|
||||||||||||
|
Fill the input port information objects for this algorithm. This is invoked by the first call to GetInputPortInformation for each port so subclasses can specify what they can handle. Reimplemented from vtkProcessObject. |
|
|
Definition at line 85 of file vtkImageToImageFilter.h. |
|
|
Definition at line 86 of file vtkImageToImageFilter.h. |
|
|
Definition at line 87 of file vtkImageToImageFilter.h. |
|
|
Definition at line 88 of file vtkImageToImageFilter.h. |
|
|
Definition at line 108 of file vtkImageToImageFilter.h. |
