#include <vtkVoxel.h>
Inheritance diagram for vtkVoxel:
vtkVoxel is a concrete implementation of vtkCell to represent a 3D orthogonal parallelepiped. Unlike vtkHexahedron, vtkVoxel has interior angles of 90 degrees, and sides are parallel to coordinate axes. This results in large increases in computational performance.
Definition at line 41 of file vtkVoxel.h.
Public Types | |
| typedef vtkCell3D | Superclass |
Public Member Functions | |
| virtual const char * | GetClassName () |
| virtual int | IsA (const char *type) |
| void | PrintSelf (ostream &os, vtkIndent indent) |
| virtual void | GetEdgePoints (int edgeId, int *&pts) |
| virtual void | GetFacePoints (int faceId, int *&pts) |
| virtual double * | GetParametricCoords () |
| int | GetCellType () |
| int | GetCellDimension () |
| int | GetNumberOfEdges () |
| int | GetNumberOfFaces () |
| vtkCell * | GetEdge (int edgeId) |
| vtkCell * | GetFace (int faceId) |
| int | CellBoundary (int subId, double pcoords[3], vtkIdList *pts) |
| void | Contour (double value, vtkDataArray *cellScalars, vtkPointLocator *locator, vtkCellArray *verts, vtkCellArray *lines, vtkCellArray *polys, vtkPointData *inPd, vtkPointData *outPd, vtkCellData *inCd, vtkIdType cellId, vtkCellData *outCd) |
| int | EvaluatePosition (double x[3], double *closestPoint, int &subId, double pcoords[3], double &dist2, double *weights) |
| void | EvaluateLocation (int &subId, double pcoords[3], double x[3], double *weights) |
| int | IntersectWithLine (double p1[3], double p2[3], double tol, double &t, double x[3], double pcoords[3], int &subId) |
| int | Triangulate (int index, vtkIdList *ptIds, vtkPoints *pts) |
| void | Derivatives (int subId, double pcoords[3], double *values, int dim, double *derivs) |
Static Public Member Functions | |
| static vtkVoxel * | New () |
| static int | IsTypeOf (const char *type) |
| static vtkVoxel * | SafeDownCast (vtkObject *o) |
| static void | InterpolationFunctions (double pcoords[3], double weights[8]) |
| static void | InterpolationDerivs (double pcoords[3], double derivs[24]) |
| static int * | GetEdgeArray (int edgeId) |
| static int * | GetFaceArray (int faceId) |
Protected Member Functions | |
| vtkVoxel () | |
| ~vtkVoxel () | |
Protected Attributes | |
| vtkLine * | Line |
| vtkPixel * | Pixel |
|
|
Reimplemented from vtkCell3D. Definition at line 45 of file vtkVoxel.h. |
|
|
|
|
|
|
|
|
Create an object with Debug turned off, modified time initialized to zero, and reference counting on. Reimplemented from vtkObject. |
|
|
Reimplemented from vtkCell3D. |
|
|
Return 1 if this class type is the same type of (or a subclass of) the named class. Returns 0 otherwise. This method works in combination with vtkTypeRevisionMacro found in vtkSetGet.h. Reimplemented from vtkCell3D. |
|
|
Return 1 if this class is the same type of (or a subclass of) the named class. Returns 0 otherwise. This method works in combination with vtkTypeRevisionMacro found in vtkSetGet.h. Reimplemented from vtkCell3D. |
|
|
Reimplemented from vtkCell3D. |
|
||||||||||||
|
Methods invoked by print to print information about the object including superclasses. Typically not called by the user (use Print() instead) but used in the hierarchical print process to combine the output of several classes. Reimplemented from vtkCell3D. |
|
||||||||||||
|
See vtkCell3D API for description of these methods. Implements vtkCell3D. |
|
||||||||||||
|
Get the list of vertices that define a face. The list is terminated with a negative number. Note that the vertices are 0-offset; that is, they refer to the ids of the cell, not the point ids of the mesh that the cell belongs to. The faceId must range between 0<=faceId<this->GetNumberOfFaces(). Implements vtkCell3D. |
|
|
Return a contiguous array of parametric coordinates of the points defining this cell. In other words, (px,py,pz, px,py,pz, etc..) The coordinates are ordered consistent with the definition of the point ordering for the cell. This method returns a non-NULL pointer when the cell is a primary type (i.e., IsPrimaryCell() is true). Note that 3D parametric coordinates are returned no matter what the topological dimension of the cell. Reimplemented from vtkCell. |
|
|
See the vtkCell API for descriptions of these methods. Implements vtkCell. Definition at line 57 of file vtkVoxel.h. References VTK_VOXEL. |
|
|
See the vtkCell API for descriptions of these methods. Reimplemented from vtkCell3D. Definition at line 58 of file vtkVoxel.h. |
|
|
See the vtkCell API for descriptions of these methods. Implements vtkCell. Definition at line 59 of file vtkVoxel.h. |
|
|
See the vtkCell API for descriptions of these methods. Implements vtkCell. Definition at line 60 of file vtkVoxel.h. |
|
|
See the vtkCell API for descriptions of these methods. Implements vtkCell. |
|
|
See the vtkCell API for descriptions of these methods. Implements vtkCell. |
|
||||||||||||||||
|
See the vtkCell API for descriptions of these methods. Implements vtkCell. |
|
||||||||||||||||||||||||||||||||||||||||||||||||
|
See the vtkCell API for descriptions of these methods. Reimplemented from vtkCell3D. |
|
||||||||||||||||||||||||||||
|
See the vtkCell API for descriptions of these methods. Implements vtkCell. |
|
||||||||||||||||||||
|
See the vtkCell API for descriptions of these methods. Implements vtkCell. |
|
||||||||||||||||||||||||||||||||
|
See the vtkCell API for descriptions of these methods. Implements vtkCell. |
|
||||||||||||||||
|
See the vtkCell API for descriptions of these methods. Implements vtkCell. |
|
||||||||||||||||||||||||
|
See the vtkCell API for descriptions of these methods. Implements vtkCell. |
|
||||||||||||
|
Voxel specific methods for interpolation and derivatives. |
|
||||||||||||
|
Voxel specific methods for interpolation and derivatives. |
|
|
Voxel specific methods for interpolation and derivatives. |
|
|
Voxel specific methods for interpolation and derivatives. |
|
|
Definition at line 93 of file vtkVoxel.h. |
|
|
Definition at line 94 of file vtkVoxel.h. |
