Contour interpolator for placing points on an image. More...
#include <vtkDijkstraImageContourLineInterpolator.h>
Public Member Functions | |
| virtual int | InterpolateLine (vtkRenderer *ren, vtkContourRepresentation *rep, int idx1, int idx2) |
| virtual void | SetCostImage (vtkImageData *) |
| virtual vtkImageData * | GetCostImage () |
| virtual vtkDijkstraImageGeodesicPath * | GetDijkstraImageGeodesicPath () |
Static Public Member Functions | |
| static vtkDijkstraImageContourLineInterpolator * | New () |
Protected Member Functions | |
| vtkDijkstraImageContourLineInterpolator () | |
| ~vtkDijkstraImageContourLineInterpolator () | |
Protected Attributes | |
| vtkImageData * | CostImage |
| vtkDijkstraImageGeodesicPath * | DijkstraImageGeodesicPath |
| typedef vtkContourLineInterpolator | Superclass |
| static int | IsTypeOf (const char *type) |
| static vtkDijkstraImageContourLineInterpolator * | SafeDownCast (vtkObjectBase *o) |
| virtual int | IsA (const char *type) |
| vtkDijkstraImageContourLineInterpolator * | NewInstance () const |
| void | PrintSelf (ostream &os, vtkIndent indent) |
| virtual vtkObjectBase * | NewInstanceInternal () const |
Detailed Description
Contour interpolator for placing points on an image.
vtkDijkstraImageContourLineInterpolator interpolates and places contour points on images. The class interpolates nodes by computing a graph laying on the image data. By graph, we mean that the line interpolating the two end points traverses along pixels so as to form a shortest path. A Dijkstra algorithm is used to compute the path.
The class is meant to be used in conjunction with vtkImageActorPointPlacer. One reason for this coupling is a performance issue: both classes need to perform a cell pick, and coupling avoids multiple cell picks (cell picks are slow). Another issue is that the interpolator may need to set the image input to its vtkDijkstraImageGeodesicPath ivar.
Definition at line 49 of file vtkDijkstraImageContourLineInterpolator.h.
Member Typedef Documentation
Standard methods for instances of this class.
Reimplemented from vtkContourLineInterpolator.
Definition at line 56 of file vtkDijkstraImageContourLineInterpolator.h.
Constructor & Destructor Documentation
Member Function Documentation
| static int vtkDijkstraImageContourLineInterpolator::IsTypeOf | ( | const char * | type | ) | [static] |
Standard methods for instances of this class.
Reimplemented from vtkContourLineInterpolator.
| virtual int vtkDijkstraImageContourLineInterpolator::IsA | ( | const char * | type | ) | [virtual] |
Standard methods for instances of this class.
Reimplemented from vtkContourLineInterpolator.
| static vtkDijkstraImageContourLineInterpolator* vtkDijkstraImageContourLineInterpolator::SafeDownCast | ( | vtkObjectBase * | o | ) | [static] |
Standard methods for instances of this class.
Reimplemented from vtkContourLineInterpolator.
| virtual vtkObjectBase* vtkDijkstraImageContourLineInterpolator::NewInstanceInternal | ( | ) | const [protected, virtual] |
Standard methods for instances of this class.
Reimplemented from vtkContourLineInterpolator.
| vtkDijkstraImageContourLineInterpolator* vtkDijkstraImageContourLineInterpolator::NewInstance | ( | ) | const |
Standard methods for instances of this class.
Reimplemented from vtkContourLineInterpolator.
| void vtkDijkstraImageContourLineInterpolator::PrintSelf | ( | ostream & | os, |
| vtkIndent | indent | ||
| ) | [virtual] |
Standard methods for instances of this class.
Reimplemented from vtkContourLineInterpolator.
| static vtkDijkstraImageContourLineInterpolator* vtkDijkstraImageContourLineInterpolator::New | ( | ) | [static] |
Create an object with Debug turned off, modified time initialized to zero, and reference counting on.
Reimplemented from vtkObject.
| virtual int vtkDijkstraImageContourLineInterpolator::InterpolateLine | ( | vtkRenderer * | ren, |
| vtkContourRepresentation * | rep, | ||
| int | idx1, | ||
| int | idx2 | ||
| ) | [virtual] |
Subclasses that wish to interpolate a line segment must implement this. For instance vtkBezierContourLineInterpolator adds nodes between idx1 and idx2, that allow the contour to adhere to a bezier curve.
Implements vtkContourLineInterpolator.
| virtual void vtkDijkstraImageContourLineInterpolator::SetCostImage | ( | vtkImageData * | ) | [virtual] |
Set the image data for the vtkDijkstraImageGeodesicPath. If not set, the interpolator uses the image data input to the image actor. The image actor is obtained from the expected vtkImageActorPointPlacer.
| virtual vtkImageData* vtkDijkstraImageContourLineInterpolator::GetCostImage | ( | ) | [virtual] |
Set the image data for the vtkDijkstraImageGeodesicPath. If not set, the interpolator uses the image data input to the image actor. The image actor is obtained from the expected vtkImageActorPointPlacer.
| virtual vtkDijkstraImageGeodesicPath* vtkDijkstraImageContourLineInterpolator::GetDijkstraImageGeodesicPath | ( | ) | [virtual] |
access to the internal dijkstra path
Member Data Documentation
Definition at line 89 of file vtkDijkstraImageContourLineInterpolator.h.
vtkDijkstraImageGeodesicPath* vtkDijkstraImageContourLineInterpolator::DijkstraImageGeodesicPath [protected] |
Definition at line 90 of file vtkDijkstraImageContourLineInterpolator.h.
The documentation for this class was generated from the following file:
- dox/Interaction/Widgets/vtkDijkstraImageContourLineInterpolator.h
